For true-to-life picture depth and clarity in any room.
The 23" Full HD Widescreen LED
ViewSonic’s new VX2336s-LED is a 23"
environmentally friendly Full HD monitor with mercury-
free LED backlight and IPS wide viewing angle
technology. With 1920x1080 resolution, 20,000,000:1
Dynamic Contrast Ratio, DVI and VGA inputs and
VESA mountable glossy nish design, VX2336s-LED
is ideal for both homes and ofces. It also has an
automatic aspect ratio adjustment so when your input
is a 4:3 signal, the image will not be stretched but
instead it will be positioned in the middle of the screen
with side bars. 3-year limited warranty, one of the
industry's best pixel performance policy and energy
saving Eco-mode* make the VX2336s-LED the best
choice for both corporate and education customers.
2
Without compromising your viewing quality and has eco-friendly mercury
free LED backlight.
Up to 50% energy saving with LED backlight
3
Multi-mode input technology supports both digital (DVI) and analog (VGA)
signals for ultimate compatibility and conguration exibility.
OptiSync®digital/analog inputs expand your connectivity
4MEGA dynamic contrast ratio at 20,000,000:1
The widescreen aspect ratio allows you to view Full HD content in its
native format with no strethching or distortion.
5Widescreen aspect ratio with 1920x1080 resolution
100mm x 100mm VESA compliant.
6Wall moutable design
VX2336s-LED
1
Provide for wider viewing angles, and better uniformity.
Xtreme View™IPS panel technology

The 23" Full HD Widescreen LED
Specications
Display 23" diagonal color active matrix IPS type TFT LED
Resolution 1920x1080
Brightness 250 cd/m2 (typ)
Contrast Ratio 1000:1 (typ)
Dynamic Contrast Ratio 20,000,000:1
Viewing Angles 178º horizontal, 178º vertical
Response Time 14ms (typ)
Input Signal Analog: RGB analog (0.7/1.0 Vp-p, 75 ohms)
Digital: DVI-D (TMDS, 100 ohms)
Sync: Fh= 24 ~83 kHz ; Fv=50 ~76 Hz
Compatibility PC and compatibles: VGA up to 1920x1080 non-interlaced
Mac: Up to 1920x1080
Power Voltage AC 100–240V (universal), 50/60Hz
Power Consumption Consumption: 35W (typ)
Eco-mode: 28W (optimize) ; 21W (conserve)
Power Save: <0.5W
Physical Dimensions (WxHxD) With stand: 21.57" x 16.77" x 7.91" (548mm x 426mm x 201mm)
Without stand: 21.57" x 13.62" x 2.36" (548mm x 346mm x 60mm)
Packaging Dimensions (WxHxD) 24.17" x 20.55" x 5.47" (614mm x 522mm x 139mm)
Weight With stand: 8.00 lb. (3.63 kg)
Without stand: 7.12 lbs. (3.23 kg)
Regulaitions CCC, UL/cUL, FCC-B, WEEE, RoHS, SVHC list, CEL, Energy Star,
GOST-R/Hygienic, UkrSEPRO, Ergo, Erp, Mexico UL Coc, SASO,
C-tick, BSMI, CE, CB, PSB
Warranty Three-year limited warranty on parts, labor and backlight
Sales: [phone] or [email protected] • More product information: www.ViewSonic.com
*Energy saving may vary based on costs, actual usage and other factors. Program specications and availability are subject to change without notice. Selection, offers and programs may vary by country; see your
ViewSonic representative for complete details.Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2011 ViewSonic Corporation. All rights reserved. [15931-00B-11/11] VX2336s-
LED
ViewSonic Corporation’s QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
VX2336s-LED display, power cable, VGA cable, DVI cable, Quick Start Guide, ViewSonic Wizard CD.
Package Content
VX2336s-LED
AC Input DVI port
VGA port
7.0cm
4.5cm
