The ViewSonic®PJ358 ultra-portable projector is a performance leader
with a rich feature set at an affordable price. The PJ358 delivers 2,000
LUMENS AND 1024X768 XGA RESOLUTION for crisp, detailed images
in any lighting situation. The short throw distance enables you to
DISPLAY A 60-INCH IMAGE FROM 4.9 FEET. At just 3.9 lbs, This pro-
jector’s portability is enhanced by its small footprint. It's also easy to
set up with auto vertical keystone correction and easy to pack up with
its DIRECT OFF FEATURE. A wide array of PC and video connectivity
options let you deliver dynamic, versatile presentations and you can
connect a USB FLASH DRIVE to project JPEG and M-JPEG images
without a PC. The PJ358 is ideal for table-top or mounted use in the
office or on the road.
Versatile and highly portable.
PJ358
LIGHT, BRIGHT AND
PORTABLE PROJECTOR
WITH KEYSTONE CORRECTION
>Bright in virtually any setting with 2,000 lumens
Packs 2,000 lumens in just 3.9 lbs. It’s the bright choice
for mobile presenters
.
>Quick set up
Auto vertical keystone correction automatically squares the
image for quick set up. The direct off feature lets you just
unplug the projector and go.
>Present without PC
USB flash drive lets you project JPEG and M-JPEG images
without a PC
.
>Enhanced security features
Assign a PIN code to password protect the projector from
unauthorized use
.
>Ultimate display source flexibility
Connect a computer (2 RGB inputs) or add a video source
for dynamic meetings and presentations
.
>Easy maintenance
The sliding filter cover and simple lamp replacement from
the top of the unit make
maintenance a breeze.
>Whisper-mode extends
lamp life and reduces
noise output
>The best warranty
in the business
DYNAMIC MEETINGS
AND PRESENTATIONS

PROJECTOR Type 0.6" Poly-Si TFT with micro-lens
Pixel Format 1024x768 XGA
Lens Manual zoom, manual focus
Zoom Factor 1.2
Keystone Vertical ± 30º
DISPLAY Size 30"–300" (diagonally)
Throw Distance 32"–307"
Throw Ratio 1.3-1.5:1
Lamp 160W, 2,000 hours normal, up to 3000 hours whisper**
Brightness (max) 2,000 ANSI lumens
Contrast Ratio 500:1
Aspect Ratio 4:3 (native), 16:9
AUDIO Speakers 1x1 watts
INPUT SIGNAL Video RGB analog, NTSC M, NTSC 4.43, PAL, SECAM, HDTV
(480i, 480p, 576i, 720p, 1080i)
Frequency Fh: 31–106kHz; Fv: 56–120Hz
COMPATIBILITY PC Analog: from VGA up to UXGA (scaled)
Mac®†Analog: up to SXGA (may require a Mac adapter)
CONNECTOR RGB (input) 15-pin HD, D-sub cable (x2)
Composite Video (input) RCA jack (x1)
S-Video (input) Mini-Din 4-pin
Component Video (input) VGA DB-15 to component adapter*
Audio (input/output) Stereo mini-jack 1 in, 1 out
USB Type A(x1) for PC-less presentation (JPEG, M-JPEG)
Type B(x1) for mouse control
POWER Voltage 100–240 VAC, 50–60Hz (universal)
Consumption 250W (typ)
CONTROLS Basic Standby, input, reset, V keystone
OnView®Language, brightness, contrast, gamma, color temperature,
color, tint, sharpness, progressive, My Memory, aspect,
overscan, V. position, H. position, H. phase, H. size, auto
adjust, color space, component, video format, information,
V. keystone, whisper, mirror, volume, language, menu position,
OSD bright, blank color, start up, My Screen, My Screen Lock,
message, auto search, lamp time, filter time, service menu,
security, USB storage
OPERATING Temperature 41–95°F (5–35°C)
CONDITIONS Humidity 10–85% (non-condensing)
NOISE LEVEL Normal 36 dB (typ)
Whisper Mode 30 dB (typ)
DIMENSIONS Physical (mm) 274mm x 205mm x 59mm
(W x H x D) Physical (in.) 10.8" x 8.1" x 2.3"
WEIGHT Net 3.9 lb. (1.8 kg)
Gross 9.9 lb. (4.5 kg)
REGULATIONS UL 60950, C-UL, FCC-B, UL-DEMKO/GS, CCC, CB, CE,
C-TICK, GOST, NOM, PSB, TUV-S
OTHER Short throw, auto vertical digital keystone correction,
progressive scan, 3:2 pull down, auto adjust, remote
control, direct off, low noise (30 dB), unplug and go,
daylight mode, adjustable fan speed
WARRANTY Three-year limited warranty on parts and labor, first-year
Express Exchange®Service. One-year limited warranty on
lamp***
PJ358
LIGHT, BRIGHT AND PORTABLE PROJECTOR WITH KEYSTONE CORRECTION
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
*Optional cables required. **Running whisper-mode exclusively can extend lamp life. ***Visit ViewSonic.com for full details. †Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without
notice. Selection, offers and programs vary by country. See your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2007 ViewSonic
Corporation. All rights reserved. [13306-01B-11/07] PJ358-1
Optional Accessories
• Replacement lamp . . . . . . . . . . . . . . . . .RLC-027
• Extended Express Exchange
®
. . . . . . .PRJ-EE-05-03
• Soft case with wheels
and laptop bag . . . . . . . . . . . . . . . . . . . .CASE-006
• Universal ceiling mount kit . . . . . . . . . .WMK-005
• VGA to component video adapter . . .ADPT-002
• Wireless G Presentation Adapter . . . . .WPG-100
