ViewSonic PJD7383 User manual

Short Distance – Big Presentations
PJD7383
XGA ULTRA SHORT THROW
DLP®PROJECTOR
120HZ AND 3D READY
The PJD7383 is an advanced ultra short throw DLP®projector which
includes BrilliantColor™technology to produce more vibrant colors,
while the high brightness and contrast ratio make this projector shine
in virtually any lighting situation. With its ultra short throw lens, it can
project an 81-inch image from just 3 feet. The PJD7383 delivers 3000
lumens, 3000:1 dynamic contrast ratio with a 1024 x 768 XGA native
resolution, and has a wide range of input options including dual
RGB ports, Ethernet RJ45, USB and WiFi (with optional adapter). The
PJD7383 can be displayed and managed over the network through its
advanced management software. The ViewSonic PJD7383 is the ideal
projector for both businesses and schools.
VERSATILE PRESENTATIONS ANYWHERE
Short throw lens for large, stunning images in small places
The short throw lens enables large images to be projected from
short distances in small rooms. A screen size of 81-inch is possible
from just 39 inches.
BrilliantColor™technology
BrilliantColor technology delivers stunning all-digital clarity with
life-like color, sharp graphics and outstanding video. The 6-
segment color wheel enhances the yellow color performance that
is key to accurate and vivid color reproduction.
PC-Less Slide Show Presentation
Project your pictures or images directly from a USB flash drive
without a PC.
Network Display
With its advanced management software, you can project
up to 4 PCs at the same time with the ability to broadcast
up to 8 projectors.
USB Display
Project your presentations through any USB connection without
the hassle of running a bulky VGA cable.
Wireless Capability
Allow the projector to be WiFi enabled with
an optional USB wireless adapter (WPD-100)
Network control through RJ45
Schedule, manage and monitor the projector remotely and
receive e-mail alerts of projector lamp status. Use the unique
integrated clock to perform commands even when the host PC
is powered down.
Eco-mode extendlamp life
Extend the life of your lamp up to
6,000 hours and reduce noise output.
Supports Crestron RoomView®Express
Manage up to 250 network projectors
in real time monitoring and control.
Manage assets, schedule events and
program email alerts with this amazing software.
>
>
>
>
>
>
>
>
>

Optional Accessories
> Replacement Lamp RLC-057
> Short throw mount WMK-027
> Wireless G Presentation Gateway WPG-360
> USB Wireless Adaptor (802.11b/g/n) WPD-100
> Extended Express Exchange®PRJ-EE-08-03
Sales: [phone] . [email protected] . ViewSonic.com
*Running eco-mode exclusively can extend lamp life. **See ViewSonic.com for full Express Exchange details. Specifications and availability
are subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete
details. Crestron RoomView is a registered trademark of Crestron Electronics, Inc. DLP®and the DLP logo are registered trademarks of Texas
Instruments and BrilliantColor™ is a trademark of Texas Instruments. Corporate names, trademarks stated herein are the property of their
respective companies. Copyright © 2010 ViewSonic Corporation. All rights reserved [15342-00B-11/10] PJD7383-1
Projection
Distance
M
0.5
1.0
1.2
1.5
2.5
3.7
DISPLAY Type 0.55" Digital Micromirror Device (DLP™)
Resolution XGA 1024x768 (Native)
Lens Fixed Lens / Manual Focus
Keystone Vertical digital keystone correction: +/– 40 degrees
Display Size (Diagonal) 30"–300" /0.762m–7.62m
Throw Distance 0.37m–3.7m / 1.2ft–12.1ft
Throw Ratio 0.61:1
Lamp 210 watt
Lamp Life (Normal / Eco-mode) 4000 / 6000 hours*
Brightness 3000 Lumens
Contrast Ratio 2000:1 static (typ); 3000:1 (dynamic)
Aspect Ratio 4:3 (native) and 16:9, Auto
Color Depth 24 bits, 16.7M color (8+8+8)
Color Wheel 6-Segment RGBCYW / 7200rpm
Color Gamut 98% NTSC 1931 CIE
INPUT SIGNAL Computer and Video NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60),
SECAM (B, D, G, K, K1, L), SD 480i/576i, ED 480p/576p,
HD 720p/1080i
Frequency Fh: 31–100KHz, Fv: 48–120Hz
COMPATIBILITY PC VGA to UXGA
Mac®Up to UXGA (scaled)
CONNECTOR RGB Input 15-pin mini D-sub (x2)
RGB Output 15-pin mini D-sub
Composite Input RCA jack
S-video Input 4-pin mini-DIN
Audio Input 3.5mm mini jack (x1), RCA (L/R)x1
Audio Output 3.5mm mini jack
Mic-In 3.5mm mini jack
12V trigger 2mm/1A
Control RS-232 (DB-9)
LAN RJ-45
USB Type A for PC-less slide show presentation – support
JPEG, BMP, TIFF, PNG, GIF from USB flash drive, optional
wireless USB adapter.
Mini-B for direct presentation from PC (not MAC compatible)
mouse control
AUDIO Speaker 10W (x1)
POWER Voltage 100~240VAC (Auto Switching), 50/60Hz (universal)
Consumption 296W (typ) /<1W (stand-by mode)
CONTROLS Basic Power, keystone/arrow keys, left/blank, menu/exit,
right/panel key lock, auto, mode/enter, source
OSD Display: Screen color, Aspect raito, Keystone, Position,
Phase, H. Size, Zoom, 3D sync, 3D sync invert, Color
Management
Picture: Color Mode, Reference Mode, Brightness, Contrast,
Color, Tint, Sharpness, Brilliant Color, Color Temp., Save Settings
Source: Quick Auto Search
System Setup (Basic): Language, Projector Position, Auto
Power Off, Blank Timer, Panel Key lock, Splash Screen,
Screen Capture, Message, LAN Control Settings,
Standby Settings
System Setup (Advanced): High Altitude Mode, DCR,
Audio Settings, Menu Settings, Closed Caption, Lamp
Settings, Presentation Timer, Security Setting, Reset All
Settings
Information: Current System Status
OPERATING Temperature 32ºF–104ºF (0ºC–40ºC)
CONDITIONS Humidity 10%–90% (non-condensing)
Altitude 0~6,000 ft. (1,800m), operational up to 10,000 ft. (3048m)
NOISE LEVEL Normal / Eco-mode 32dB / 27dB
DIMENSIONS Physical 11.4" x 5.0" x 10.0" / 290mm x 126mm x 254mm
(W x H x D) Packaging 15" x 15.4" x 8.3" / 380mm x 392mm x 210mm
WEIGHT Net 7.7 lb. (3.5 kg)
Gross 12.1 lb. (5.5 kg)
REGULATIONS CB, UL, cUL, FCC (including ICES-003), CE, UL-Argentina,
NOM, TUV-GS, GOST-R, SASO, Ukraine, PSB, C-Tick,
Korean-eK, CCC, Hygiene, WEEE, RoHS
PACKAGE CONTENTS ViewSonic projector, power cable, VGA cable, interactive
pen, laser remote control with batteries, lens cap, Quick
Start Guide, ViewSonic Wizard CD (with User Guide)
WARRANTY 3-year limited warranty on parts and labor, 1-year limited
warranty on lamp, 1st year Express Exchange®service**
For more product information, visit us on the web at ViewSonic.com
PJD7383
XGA ULTRA SHORT THROW DLP®PROJECTOR – 120HZ AND 3D-READY
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
Feet
1.6
3.3
3.9
4.9
8.2
12.1
Inches
39.3
81.1
95.9
120.5
201.6
297.5
M
1.0
2.06
2.44
3.06
5.12
7.56
4:3
Aspect Ratio
