ViewSonic’s PJ558D projector features DLP®technology that delivers
amazingly crisp digital images. With 2,500 LUMENS AND AN ULTRA-
HIGH 2000:1 CONTRAST RATIO (TYP) this portable projector lets you
deliver multimedia lessons in the classroom or dynamic presentations
in the boardroom with stunning visual impact. The native 1024x768
XGA resolution, DIGITAL KEYSTONE CORRECTION AND OPTICAL
ZOOM LENS ensure that you’ll get the best possible image in
virtually any setting. Experience the flexibility of the PJ558D thanks
to SUPPORT FOR 720P AND 1080I HD SIGNALS, advanced video
features and multiple inputs. It’s a lightweight, powerful projector
that lets you take your presentations to a new and brighter level in
the office, on the road or in schools.
Bright DLP
®
projector.
PJ558D
LIGHT, BRIGHT AND
PORTABLE PROJECTOR
WITH KEYSTONE CORRECTION
>Bright in virtually any setting with 2,500 lumens
Packs 2,500 lumens in just 5.4 lb. It’s the bright choice
for mobile presenters
.
>DLP®technology
Stunning all digital clarity delivers lifelike color, sharp
graphics, and outstanding video.
>Ultimate video source flexibility
Connect a computer or add a video source for dynamic
meetings and presentations
.
>Supports HD signals including 720p and 1080i
Capable of displaying HDTV signals as well as other
video and data sources*
.
>Advanced video features
Motion adaptive deinterlacer for superior video
performance
.
>Whisper-mode extends lamp life
Extend the life of your lamp up to 3,000 hours**
and reduce noise output
.
>OnView®controls for superior screen adjustablility
Screen geometry and color
adjustments are precisely
made via an easy-to-use,
on-screen menu
.
>The best warranty
in the business
Covered by a three-year parts
and labor limited
warranty, first-year Express
Exchange
®
and one-year
limited lamp warranty.***
VISUALLY APPEALING
MULTIMEDIA PRESENTATIONS

PROJECTOR Type 0.55" DDR DMD, DLP®
Pixel Format 1024x768 XGA
Lens Manual zoom/manual focus
Zoom Factor 1.2
Keystone Vertical ± 15º
DISPLAY Size 30"–300" (diagonally)
Throw Distance 46.8"–393.6"
Throw Ratio 1.64–1.96:1
Lamp 230W, 2,000 hours**
Brightness 2,500 ANSI lumens
Contrast Ratio 2000:1
Aspect Ratio 4:3 (native), 16:9
AUDIO Speakers 1x2 watts
INPUT SIGNAL Computer and Video NTSC, NTSC 4.43, PAL, SECAM, RGB analog,
HDTV (480i, 480p, 576i, 576p, 720p, 1080i)
Frequency Fh: 31–79kHz; Fv: 56–85Hz
COMPATIBILITY PC Analog: from VGA up to SXGA (scaled)
Mac®†Analog: up to SXGA (may require a Mac adapter)
CONNECTOR RGB (input) 15-pin HD, D-sub cable (x1)
RGB (output) 15-pin HD, D-sub cable (x1)
Composite Video (input) RCA jack (x1)
S-Video (input) Mini-Din 4-pin (x1)
Component Video (input) VGA DB-15 to HDTV/component cable*
Audio (input) Stereo mini-jack (x1)
CONTROL 6-pin mini-din
POWER Voltage 100–240 VAC, 50/60Hz (universal)
Consumption 250W (typ)
CONTROLS Basic Standby/On, input, menu
OnView®Display mode, brightness, contrast, keystone, aspect ratio,
blank screen, gamma, white peaking, color temperature,
user color, video (sharpness, saturation, tint), display (phase,
tracking, H. position, V. position), advance (auto source
select, rear, ceiling, eco mode, lamp hours, lamp reset,
auto shutdown, OSD timeout, menu position, factory
reset), audio (audio, mute)
OPERATING Temperature 32–104°F (0–40°C)
CONDITIONS Humidity 10–90% (non-condensing)
NOISE LEVEL Normal/Whisper mode 37 dB (typ)/32 dB (typ)
DIMENSIONS Physical (mm) 264mm x 203mm x 96.5mm
(W x H x D) Physical (in.) 10.4" x 3.8" x 8"
WEIGHT Net 5.4 lb. (2.5 kg)
Gross 12 lb. (5.4 kg)
REGULATIONS UL, FCC-B, NOM, C-UL, ICES-003, TUV-S, RoHS
OTHER Vertical digital keystone correction, 3:2 pull down,
whisper mode
PACKAGE CONTENTS Projector, power cord, VGA cable, RCA video cable, S-video
cable, remote control, soft case, lens cap, ViewSonic
Wizard CD, Quick Start Guide
WARRANTY Three-year limited warranty on parts and labor, first-year
Express Exchange®Service. One-year limited warranty
on lamp***
PJ558D
LIGHT, BRIGHT AND PORTABLE PROJECTOR WITH KEYSTONE CORRECTION
For more product information, visit us on the web at ViewSonic.com
ViewSonic Corporation • 381 Brea Canyon Road, Walnut, CA 91789
Customer Service and Technical Support: [phone] • Sales: [phone] • [email protected] • ViewSonic.com
*Optional cables required. **Running whisper-mode exclusively can extend lamp life. ***See ViewSonic.com for details. †Adapter may be required. Analog adapter available from ViewSonic. The DLP logo is a trademark of
Texas Instruments. Specifications subject to change without notice. Selection, offers and programs vary by country. See your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the
property of their respective companies. Copyright © 2006 ViewSonic Corporation. All rights reserved. [13457-00B-03/07] PJ558D-1
Optional Accessories
• Replacement lamp . . . . . . . . . . . . . . . . .RLC-023
• Stackable ATA hard shipping case . . .CASE-003
• Hard case with wheels . . . . . . . . . . . . . .PRJ-HCA-001
• Extended Express Exchange
®
. . . . . . .PRJ-EE-05-03
• Soft case with wheels . . . . . . . . . . . . . .CASE-006
• Universal ceiling mount kit . . . . . . . . . .WMK-005
• VGA to component video adapter . . .ADPT-002
• Wireless G Presentation Gateway . . . .WPG-100
