Portable SVGA Projector
The PJD5126 is a high-performance SVGA 800x600
DLP projector with 2700 ANSI lumens and 4000:1
contrast ratio. With new Smart ECO technology,
presenters can control the audience’s focus by
dimming the brightness down to 30% with a click of
the remote. This projector offers a variety of hardware
and software features including multiple PC and video
input options, 1.1x manual optical zoom, keystone
correction and 120Hz/3D-ready. It supports HD video
signal and has an integrated speaker. Filter-less
design and energy-saving eco mode provide easy
maintenance and reliable
product life. The PJD5126 with
its lightweight design is ideal for tabletop use or ceiling
mounting in both classrooms and corporate ofces.
PJD5126
BrilliantColor™technology
Latest BrilliantColor technology delivers stunning all-digital clarity with
life-like color, sharp graphics and outstanding video. The sophisticated
6-segment color wheel enhances the yellow color performance that is key
to accurate and vivid color reproduction.
1
Bright in virtually any setting with 2,700 lumens
Packs 2,700 lumens and with a high contrast ratio 4000:1 (with DCR),
your presentations are guaranteed to be vibrant even in the brightest ofce
environments.
2
Long lamp life up to 6000 hours
The new advanced lamp technology extends the lamp life up to 6000 hours*
and saves on maintenance costs.
3
Smart ECO™ Technology
Take command of presentations by dimming the main screen image - up
to 70% - with Smart ECO™ button on the remote.
4
3D-Ready Powered by DLP®Link™Technology
Get amazing 3D capabilities with DLP Link technology, at your disposal.
The projector's embedded emitter function makes it easy to unlock 3D
capabilities simply with a pair of DLP Link compatible glasses, such as the
optional ViewSonic PGD-250 active shutter glass kit*
Give greener presentations and save
Use energy-saving Eco-mode to lower power consumption, extend lamp
life and reduce noise. Filter-less design for
saving maintenance costs and labor.
Ultra slim design
At only 3.3 inches high and a lightweight 5.7 pounds, the PJ5126 is
designed for true portability. It’s so convenient to move from location to location.
5
6
7

Portable SVGA Projector
PJD5126
Specications
DISPLAY Type: 0.55" Digital Micromirror Device (DLP™)
Resolution: SVGA 800x600 (Native)
Lens: 1.1x Manual optical zoom / Manual optical focus
Keystone: Vertical digital keystone correction, +/- 40º
Size: 30" - 300" / 0.76m - 7.6 m (Diagonal)
Throw Distance: 3.9' - 33' / 1.2 m - 10 m
Throw Ratio: 1.86 - 2.04:1
Lamp: 180 watt
Lamp Life (Normal / Eco-mode): 5,000 / 6,000*
Brightness: 2700 Lumens
Contrast Ratio: 4000:1 (dynamic)
Aspect Ratio: 4:3 (native), 16:9, auto
Color Depth: 30 bits, 1.07B Colors (10+10+10)
Color Wheel: 6-Seg RGBCYW / 7200RPM
INPUT SIGNAL Computer and Video: NTSC M (3.58 MHz), 4.43MHz,
PAL (B, D, G, H, I, M, N, 60), SECAM ( B, D, G, K, K1, L), SD 480i
and 576i, ED 480p and 576p, HD 720p, 1080i and 1080p
Frequency: Fh: 31 -100KHz, Fv: 50 -120Hz
COMPATIBILITY PC: VGA to UXGA
MAC®: up to SXGA+ (may require Mac Adapter)
CONNECTOR RGB Input: 2 x 15-pin mini D- sub
RGB Output: 1 x 15-pin mini D-sub
Component: 2 x 15-in mini -D-Sub (shared with RGB)
Composite Input: 1 x RCA jack
S-video Input: 1 x 4-pin mini-DIN
Audio Input: 1 x 3.5mm mini jack
Audio Output: 1 x 3.5mm mini jack
Control: 1 x RS-232 (DB-9)
AUDIO Speaker: 2W (x1)
POWER Voltage: 100 ~ 240VAC (Auto Switching), 50/60Hz (universal)
Consumption: 243W (typ) <1W (stand-by mode)
CONTROLS Basic: Power, keystone/arrow keys, left/blank, menu/exit,
right/lock, mode/enter, auto
OSD: Display: Screen color, Aspect Ratio, Keystone, Position,
Phase, H. Size, Zoom, 3D Sync, 3D Sync Invert, Color
Management
Picture: Color Mode: PC (Brightest, PC, ViewMatch, Cinema,
Dynamic PC, User 1, User 2), Video (Brightest, Gaming,
ViewMatch, Cinema, Dynamic PC, User 1, User 2),
Reference Mode: PC (Brightest, PC, ViewMatch, Cinema,
Dynamic PC), Video (Brightest, Gaming, ViewMatch, Cinema,
Dynamic PC), Brightness, Contrast, Color, Tint, Sharpness,
Brilliant Color, Color Temp., Save Settings
Source: Quick Auto Search, Smart Eco, Timer, Smart Restart,
Pattern, My Button
System Setup (Basic): Language, Projector Position, Auto
Power Off, Blank Timer, Panel Key Lock, Message, Standby
Settings (Active VGA Out / Active Audio Out)
System Setup (Advanced): High Altitude Mode, DCR, Audio
Settings (Mute / Volume), Menu Settings, Closed Caption,
Lamp Settings, Presentation Timer (Timer Period, Timer
Display, Timer Position, Timer Counting Direction, Sound
Reminder), Security Settings, Remote Control Code,
Reset All Settings
Information: Current System Status (Source, Color mode,
Resolution, Color System, Equivalent Lamp Hour)
OPERATING CONDITIONS Temperature: 32 F-104 F (0ºC-40ºC)
Humidity: 10%-90% (non-condensing)
Altitude: 0~6,000 ft (1,800 m), operational up to 10,000 ft (3048 m)
NOISE LEVEL Normal / Eco-mode: 32dB / 29dB
DIMENSIONS (WxHxD) Physical: 11.6" x 3.3" x 9.5" (294 x 84 x 242 mm)
Packaging: 15" x 13.6" x 7.6" (380 x 345 x 192 mm)
WEIGHT Net: 5.7 lb. (2.6 kg)
Gross: 9.0 lb. (4.1kg)
REGULATIONS CB, UL, cUL, FCC (including ICES-003), CE, UL-Argentina, NOM, GS,
GOST-R, SASO, Ukraine, PSB, C-Tick, Korean-KC,
CCC, CECP, WEEE, RoHS
WARRANTY 3-year limited warranty on parts and labor, 1-year limited warranty
on lamp, 1st year Express Exchange®service.
Sales: [phone] or [email protected] • More product information: www.ViewSonic.com
*Lamp life may vary based on actual usage and other factors. Specifications and availability are subject to change without notice. Selection, offers and programs may vary by country; see your
ViewSonic representative for complete details.Corporate names, trademarks stated herein are the property of their respective companies, DLP® and DLP logo are registered trademarks of Texas Instruments
and BrilliantColor™is a trademark of Texas Instruments. Copyright © 2011 ViewSonic Corporation. All rights reserved. [15970-00B-12/11] PJD5126
Optinal Accessories
> Replacement Lamp ............................... RLC-070
> Universal Ceiling Mount Kit ..................WMK-005
> 3D HD Video Processor ........................... VP3D1
> 3D Active Shutter Glasses.....................PGD-250
> Wireless Presentation Gateway ...........WPG-360
> Soft Case....................................... PJ-CASE-001
> Extended 5-year warranty ........... PRJ-EW-07-02
Focus & Zoom Rings
Control Panel
IR Remote Sensor
Projection Lens
Quick Elevation Button
Projection Distance Screen Size (4:3)
Feet
5.0 – 5.35
10.0 – 10.7
16.0 – 17.7
23.0 – 25.2
30.0 – 32.2
32.8 – 35.8
37.1 – 40.7
Inches
40
79
130
185
236
264
300
Meters
1.5 – 1.63
3.0 – 3.26
4.9 – 5.4
7.0 – 7.67
9.0 – 9.8
10.0 – 10.9
11.3 – 12.4
Meters
1.0
2.0
3.3
4.7
6.0
6.7
7.62
ViewSonic Corporation’s QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
S-Video/Video Inputs
Audio In / Audio Out
RGB / Component
Video Inputs
Type B USB
(Mouse Control & Service)
RS-232
Monitor Out
AC Power Security Bar Kensington®Lock Slot
ViewSonic PJD5126 projector, power cable, VGA cable, remote control with batteries, lens cap,
Quick Start Guide, ViewSonic Wizard CD (with User Guide)
Package Contents
