Vifa Copenhagen User manual

Vifa Copenhagen, power cable, AUX 3.5 mm mini

jack cable, travel bag, quick-guide and warranty.

COPENHAGEN

Model:VIFA012

Quick Guide

ENGLISH For more information please visit our website at vifa.dk

IMPORTANT SAFETY INSTRUCTIONS

Regulatory Safety Information

This device complies with Part 15 of the FCC

Rules. Its operation is subject to the following

two conditions:

1. This device may not cause harmful inter-

ference, and

2. This device must accept any interference

received, including interference that may

cause undesired operation.

Cet appareil est conforme à la section 15 des ré-

glementations de la FCC. Le fonctionnement de

l’appareil est sujetaux deux conditions suivantes:

1. Cet appareil ne doit pas provoquer

d’interférences néfastes, et 2. Cet appar-

eil doit tolérer les interférences reçues, y

compris celles qui risquent de provoquer

un fonctionnement indésirable.

Note: This product has been tested and found

to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reason-

able protection against harmful interference

in a residential installation. This product gen-

erates, uses, and can radiate radio frequency

energy and, if not installed and used in accord-

ance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interfer-

ence will not occur in a particular installation. If

this product does cause harmful interference

to radio or television reception, which can be

determined by turning the equipment off and

on, the user is encouraged to try to correct the

interference by one or more of the following

measures:

· Reorient or relocate the receiving antenna.

· Increase the separation between the

equipment and receiver.

· Connect the equipment into an outlet on

a circuit different from that to which the

receiver is connected.

· Consult the dealer or an experienced radio/

TV technician for help.

Changes or modiﬁcations not expressly ap-

proved by the party responsible for compliance

could void the user’s authority to operate the

equipment.

This device complies with Industry Canada

licence-exempt RSS standard(s).

Operation is subject to the following two con-

ditions:

1. This device may not cause interference, and

2. This device must accept any interference,

including interference that may cause un-

desired operation of the device.

Le présent appareil est conforme aux CNR

d’Industrie Canada applicables aux appareils

radioexempts de licence. L’exploitation est au-

torisée aux deux conditions suivantes :

1. l’appareil ne doit pas produire de brouil-

lage, et

2. l’utilisateur de l’appareil doit accepter tout

brouillage radioélectrique subi, même si le

brouillage est susceptible d’en comprom-

ettre le fonctionnement.

FCC/IC Radiation Exposure Statement

This equipment complies with FCC/IC RSS-102

radiation exposure limits set forth for an uncon-

trolled environment. This equipment should be

installed and operated With minimum distance

20 cm between the radiator & your body.

Déclaration de la FCC et d'IC sur l'exposition

aux radiations Cet appareil est conforme à la

norme RSS102 de la FCC/IC relative aux limites

d'exposition aux radiations dans un environne-

ment non contrôlé. Vous devez installer et uti-

liser cet appareil en respectant une distance

minimale de 20 cm entre votre corps et &!'élé-

ment rayonnant.

Vifa Denmark A/S

Mariendalsvej 2A

DK - 8800 Viborg

vifa.dk

IMPORTANT STATEMENTS: REGISTER AND TRADEMARKS

We encourage you to register your product at: www.vifa.dk/register

SPECIFICATIONS

Description Vifa®HOME – wireless loudspeaker

Technical features Bluetooth®

Qualcomm®aptX™ HD audio

Wi-Fi B/G, 2,4GHz

Apple AirPlay

Works with DLNA

DSP signal processing

Lithium Ion battery

Force Balanced Woofers

6 channel high performance power ampliﬁer

Driver units

Tweeter 2 X 28 mm Vifa driver unit with soft dome

and neodymium magnet.

Midrange 2 X 50 mm Vifa driver unit with

aluminium cone and neodymium magnet .

Woofer 2 X 80 mm Vifa driver unit with ﬂat sandwich

cone and neodymium magnet. Mounted

mechanically back to back in a force balanced

conﬁguration supported by 4 passive radiators.

Frequency response 50Hz - 20kHz @ +/- 3 dB

Input voltage 100-240V ~ 50/60Hz

Max. Rated power consumption 160 watt

Standby power consumption Less than 0,5 watt

Output USB 5 volt / 2.1 A (plugged in to the mains)

0.5 A (battery mode)

Inputs Bluetooth aptX™ HD

Wi-Fi Direct

Wi-Fi networked

Wired optical or analog (3.5 mm minijack)

Wired USB (only USB DISK at present)

Dimensions Height/Width/Depth 268 mm / 362 mm / 90 mm

Net weight 4.5 kg

Frame One piece diecast aluminium

Textile Custom made Kvadrat textile

A Vifa product is in compliance with directives of relevance, including RoHS

directive – see product label for more regional

Made for iPod touch (3rd through 6th generation), iPod nano (4th through 7th gener-

ation), iPhone (7 Plus, 7, 6s Plus, 6s, 6 Plus, 6, 5s, 5c, 5, 4s, 4, 3GS), iPad (Air 2, mini

3, Air, mini2, mini, 4th through 1st generation), AirPlay, iPad, iPhone, iPod nano and

iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries.

AirPlay works with iPhone, iPad, and iPod touch with iOS 4.3.3 or later, Mac with

OS X Mountain Lion or later, and PC with iTunes 10.2.2 or later

AirPlay works with iPhone, iPad, and iPod touch with iOS 4.3.3 or later, Mac with

OS X Mountain Lion or later, and PC with iTunes 10.2.2 or later. Supports iOS 7 or

later for setup using.

“Made for iPod”,” Made for iPhone” and” Made for iPad” mean that an electronic

accessory has been designed to connect speciﬁcally to iPod, iPhone, or iPad, re-

spectively, and has been certiﬁed by the developer to meet Apple performance

standards. Apple is not responsible for the operation of this device or its compliance

with safety and regulatory standards. Please note that the use of this accessory

with iPod, iPhone, or iPad may affect wireless performance.

Apple, the Apple logo, Airplay, the Airplay logo, iPad, iPhone, iPod nano and

iPod touch are trademarks of Apple Inc., registered in the U.S. and other

countries. App Store is a service mark of Apple Inc., registered in the U.S.

and other countries.

The Wi-Fi CERTIFIED™

Logo is a certiﬁcation mark of Wi-Fi Alliance®.

The Bluetooth®word mark and logos are registered

trademarks owned by Bluetooth SIG, Inc., and any

use of such marks by Vifa Denmark A/S is under

license.

Qualcomm®aptX™ is a product of

Qualcomm Technologies International, Ltd.

The N-Mark is a trademark or registered trademark

of NFC Forum, Inc. in the United States and in other

countries.

The Spotify software is subject to third party

licenses found here:

www.spotify.com/connect/third-party-licenses.

Vifa®HOME, Vifa®PLAY, Vifa®LINK and the logos are

trademarks of Vifa Denmark A/S.

Google Play and the Google Play logo

are trademarks of Google Inc.

IN THE BOX

1 Read these instructions.

2 Keep these instructions.

3 Heed all warnings.

4 Follow all instructions.

5 Do not use this apparatus near water.

6 Clean only with dry cloth.

7 Do not block any ventilation openings. Install in accord-

ance with the manufacturer’s instructions.

8 Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including ampli-

ﬁers) that produce heat.

9 Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with

one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the

third prong are provided for your safety. If the provided

plug does not ﬁt into your outlet consult an electrician for

replacement of the obsolete outlet.

10 Protect the power cord from being wal-ked on or pinched

particularly at plugs convenience receptacles and the

point where they exit from the apparatus.

11 Only use attachments/accessories speciﬁed by the manu-

facturer.

12 Use only with the cart, stand, tripod, bracket

or table speciﬁed by the manufacturer or

sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus

combination to avoid injury from tip-over.

13 Unplug this apparatus during lightning storms or when

unused for long periods of time.

14 Refer all servicing to qualiﬁed service personnel. Servicing

is required when the apparatus has been damaged in any

way, such as power-supply cord or plug is damaged, liquid

has been spilled or objects have fallen into the apparatus,

the apparatus has been exposed to rain or moisture, does

not operate normally or has been dropped.

15 To completely disconnect unit power from the AC mains,

disconnect the unit’s power cord from the mains socket.

16 Important! This equipment is not intended to be used on

soft support(like beddings. Blankets etc.)

17 The socket-outlet shall be easily accessible.

18 Disposal of a battery into ﬁre or a hot oven, or mechani-

cally crushing or cutting of a battery can result in an explo-

sion

19 High or low extreme temperatures that a battery can be

subjected to during use is 10ºC - 45ºC, storage -20ºC -

40ºC or transportation 10ºC - 45ºC; and low air pressure

is 86-106Kpa at 2000m. high altitude

20 Leaving a battery in an extremely high temperature sur-

rounding environment that can result in an explosion or

the leakage of ﬂammable liquid or gas.

21 Battery subjected to extremely low air pressure that may

result in an explosion or the leakage of ﬂammable liquid or

gas.

22 Product label afﬁxed to the bottom of the product.

23 CAUTION: Danger of explosion if battery is incorrectly

replaced. Replace only with the same or equivalent type.

24 WARNING: The Battery(battery pack or batteries in-

stalled) shall not be exposed to excessive heat such as

sunshine, ﬁre or the like.

25 WARNING:The main plug shall remain readily operable

26 Keep minimum distances 1cm around the apparatus for

sufﬁcient ventilation

27 The ventilation should not be impeded by covering the

ventilation openings with items, such as newspapers,

table-cloths, curtains, etc.

28 Attention should be drawn to the environmental aspects

of battery disposal.

29 The use of apparatus in tropical and/or moderate climates.

30 Risk of explosion if the battery is replaced by an incorrect

type.

WARNING:

• To reduce the risk of ﬁre and electric shock do not ex-

pose this apparatus to rain or moisture.

• Do not place objects ﬁlled with liquids such as vases on

the apparatus.

• Do not open apparatus. There are no user-serviceable

parts inside. Risk of electric shock inside.

• The apparatus shall not be exposed to dripping or splash-

ing.

• No naked ﬂame sources, such as lighted candles,such as

lighted candles, should be placed on the apparatus

The lightning ﬂash and arrow head within the

triangle is a warning sign alerting you of dan-

gerous voltage inside the product

The exclamation point within the triangle is

a warning sign alert-ing you oﬁmportant in-

structions accompanying the product.

2016 01 REV.1.1
