Vigitron Vi61000 User manual

Application Drawings
Vi61000 UTP HD Video Transmitter Installation Manual
DO NOT OPEN
RISK OF ELECTRIC SHOCK
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DO NOT REMOVE COVER. NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The Smart Choice for Transmission Solutions www.vigitron.com
Important Safety Warning
HD DVR-end (Vi61001) Installation
- Read and keep these instructions.
- Heed all warnings.
- Follow all instructions.
- Do not use this apparatus near water.
- Clean only with a dry cloth.
- Install in accordance with the manufacturer’s instructions.
- This installation should be made by a qualified service person and should conform to all local
codes.
- DO NOT bundle UTP or Coax signals in the same conduit as high-voltage wiring.
- To reduce the risk of fire or electrical shock, do not expose these products to rain, moisture,
dripping or splashing.
- No objects filled with liquids, such as vases, shall be placed on Vigitron equipment.
- DO NOT install the unit in a place where the operating ambient temperature exceeds 70°C or
is below - 10°C.
- Make sure that the external power supply output voltage is in the recommended range.
- Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus that produce heat.
- Protect the power cord from being walked on or pinched particularly at power source,
convenience receptacles, and the point where they exit from the apparatus.
- Only use attachments/accessories specified by the manufacturer.
- Unplug this apparatus during lightning storms or when unused for long periods of time.
- Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as when a power supply cord or plug is damaged, liquid
has been spilled, objects have fallen inside the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or has been dropped.
- The main plug is used as the disconnect device and shall remain readily operable.
WARNING! - To reduce the risk of fire or electric shock, do not expose
this apparatus to rain or moisture. This apparatus shall not be exposed to
dripping or splashing and no objects filled with liquids, such as vases shall
be placed on the apparatus.
WARNING! - This apparatus is a Class I product. This product must
be connected to a mains socket outlet thru an AC to DC Power supply.
WARNING! - The mains plug is used as the disconnect device and
shall remain readily operable.
The Vigitron Vi61000 is an advanced active device that transmits HD video
over unshielded twisted pair wires. It is compatiable with HD-TVI, HD-CVI
and AHD video formats. The Vi61000 uses Cat 5/6 UTP cables and can
provide quality HD video up to 2000 feet (610 m) depending on the video
format when it is paired with Vigitron Vi61001 active receiver.
The Vi61000 requires a 12VDC power supply. The Vi61000 is compact in
size and very easy to install. It provides a single slide switch for selecting
the distance range for best performance. Vigitron's Vi61000 is tested and
certified to assure operational specification performance.
The Vi61000 innovative design offers exceptional quality video and system
flexibility that makes it ideal for a wide variety of CCTV applications and
makes a cost-effective alternative to expensive Coax or fiber optic solutions.
The Vi61000 is a HD video transmitter that should be powered by a 12VDC local
power supply.
UTP Port (Terminal Block):
- Connect a twisted-pair wire, 24 AWG or better, to the connector labeled “Video Out”.
It is important to note which wire color connects to the "+" and "-" terminals in order
to keep the same polarity on both transmit and receive end of the UTP wire.
Video:
- Connect the camera video output to the “Video In” BNC connector of of the
Vi61000.
Power:
- Connect a 12VDC power supply to the power connector of the Vi61000.
- Connect the GND terminal block with a short 18 AWG wire to Earth Ground.
Set the Distance switch of the Vi61000 to the position that provides the best picture.
HD Camera-end Installation
The Vi61001 is a HD video receiver that should be powered by a 12VDC local power
supply.
UTP Port (Terminal Block):
- Connect a twisted-pair wire, 24 AWG or better, to the connector labeled “Video In”.
It is important to note which wire color connects to the "+" and "-" terminals in order
to keep the same polarity on both transmit and receive end of the UTP wire.
Video:
- Connect the video input of the HD DVR to one of the BNC Video outputs of the
Vi61001. The other output can be used for monitoring or recording on another DVR.
Power:
- Connect a 12VDC power supply to the power connector of the Vi61000.
- Connect the GND terminal block with a short 18 AWG wire to Earth Ground.
Extended Network
OmniiLynx
HD Transmission
The Vi61000 series can provide HD video transmission over UTP at distances up to
2,000 feet depending on the HD video format.
HD Camera
HD DVR
Vi61000
Vi61001
Coax
HD Video
UTP up to 2,000 feet
HD Video
Coax
HD Video

Limited Lifetime Warranty
Vigitron, Inc. warrants that all Vigitron products (“Product”), if used in accordance
with these instructions, will be free of defects in material and workmanship for
lifetime defined as the duration period of time until product end of life is announce-
ment. After which Vigitron will continue to provide warranty services for a period of 3
years. Period covering valid warranty will be determined by proof of purchase in the
form of an invoice from an authorized Vigitron dealer.
Warranty will only be provided for as long as the original end user purchaser owns
the product. Warranty is not transferrable. At Vigitron's option, defective product will
be repaired, replaced or substituted with a product of equal value. This warranty
does not apply if, in the judgment of Vigitron, Inc., the Product fails due to damage
from shipment, handling, storage, accident, abuse or misuse, or if it has been used
or maintained not conforming to Product manual instructions, has been modified, or
serial number removed or defaced. Repair by anyone other than Vigitron, Inc. or an
approved agent will void this warranty. Vigitron, Inc. shall not under any circum-
stances be liable to any person for any incidental, indirect or consequential
damages, including damages resulting from use or malfunction of the product, loss
of profits or revenues or costs of replacement goods. The maximum liability of
Vigitron, Inc. under this warranty is limited to the original purchase price of the
Product only.
Prior to returning any defective Product, the end customer or the reseller from whom
the end customer originally purchased the Product must obtain a Return Materials
Authorization (RMA) number from Vigitron, Inc. All defective Products should be
returned to Vigitron, Inc. with shipping charges prepaid. No collect shipments will be
accepted.
Technical Specifications*
RoHS
© Copyright 2016 Vigitron, Inc.
TEL (+1) 858 - 484 - 5209 • FAX (+1) 858 - 484 - 1205
7810 Trade Street, Suite 100, San Diego, CA 92121, USA • [email protected] • www.vigitron.com
UMVi61000_0216
Ordering Information
Electrical
Video Format HD-TVI, HD-CVI and AHD
Data Pass Through
UTP 100 Ohm +/- 20%
HD-TVI: 1,200 feet (365m)
HD-CVI: 1,300 feet (396m)
AHD: 2,000 feet (610m)
Coax RG59
Power Source 12VDC
Status LEDs Power: Power On
Connectors UTP Interface: 2-pin Screw-less terminal blocks
Video: 75 Ohm BNC connector
Power: Circular power connector
Regulatory
Safety CE
Environmental RoHS, WEEE
Environmental
Humidity 0 to 95%, non-condensing
Temperature Operating: 0°C to +70°C
Storage: -40°C to +85°C
Mechanical
Dimensions 0.97 x 1.76 x 2.15 in., 2.5 x 4.5 x 5.5 cm (HxWxL)
Weight 0.14 lb (63.5 g)
Housing Aluminum
*Specifications subject to change without notice.
Vi61000 Active HD Video transmitter
Vi61001 1-port Active HD Video Receiver
Vi0012 12VDC @ 12W Power Supply
Part No. Description
Drawings
0.97"
2.5 cm
Top ViewLeft View Right View
2.15"
5.5 cm
1.76"
4.5 cm
Data
Power
HD UTP Video Transmitter
Vi61000
Made in U.S.A.
Distance
Video In
12VDC
