Viking C-1000B Quick setup guide

5 Easy Ways
1-8-08
DOD # 886
to integrate Viking video entry
phones with your home TV or PC
www.vikingelectronics.com • Info..715.386.8861
[e-mail] • FaxBack...715.386.4345
Answer the door
from any phone!
View the video on anyTV!

Composite
Video Input
*Holland Electronics
Model HMM-10H
Modulator
*HollandElectronics
Model GHS-2
Combiner/Splitter
Input Signal from
CATV Distribution
Viking Model C-200
Door Entry Controller
DOD # 169
Telephone Line
House Phones
Digital Cable TV (with cable set top box) /
Video Door Entry Application
Audio
High Pass
Filter
Television
Cable Set Top Box
CATV / Antenna
Input
CATV
Input
Output
(to TV)
*Holland Electronics
Model HPF-230
230 mHz High Pass Filter
(2) 90 degree connectors
(not included)
1-8-08
* For more information on Holland Electronics products,
visit: www.hollandelectronics.com
RF Output
GHS-2
GHS-2
GHS-2
Viking Model E-50
Video Entry Phone
DOD # 191
This video application
also applies to these
Viking video entry phones:
Model DOD#
E-35 178
K-1705-3 159
(requires C-2000A controller)
W-3005 181
(requires C-1000B controller)

Viking Model E-50
Video Entry Phone
DOD # 191
This video application
also applies to these
Viking video entry phones:
Model DOD#
E-35 178
K-1705-3 159
(requires C-2000A controller)
W-3005 181
(requires C-1000B controller)
Viking Model C-200
Door Entry Controller
DOD # 169
Telephone Line
House Phones
Analog Cable TV (no cable box) / Video Door Entry Application
Composite
Video Input
Holland Electronics
Model HMM-10H
Modulator*
Audio
* For more information on Holland Electronics products, visit: www.hollandelectronics.com
Television
CATV
Input
1-8-08
Holland Electronics
Model GHS-2
Combiner/Splitter*
Input Signal from
CATV Distribution
RF Output

Viking Model E-50
Video Entry Phone
DOD # 191
This video application
also applies to these
Viking video entry phones:
Model DOD#
E-35 178
K-1705-3 159
(requires C-2000A controller)
W-3005 181
(requires C-1000B controller)
Viking Model C-200
Door Entry Controller
DOD # 169
Telephone Line
House Phones
Satellite TV / Video Door Entry Application
Composite
Video Input
Audio
Satellite Receiver
Television
Antenna / RF Input
1-8-08
Holland Electronics
Model HMM-10H
Modulator*
* For more information on Holland Electronics products, visit: www.hollandelectronics.com
RF Output

Viking Model E-50
Video Entry Phone
DOD # 191
This video application
also applies to these
Viking video entry phones:
Model DOD#
E-35 178
K-1705-3 159
(requires C-2000A controller)
W-3005 181
(requires C-1000B controller)
Viking Model C-200
Door Entry Controller
DOD # 169
Telephone Line
House Phones
Using PIP (Picture In Picture) on Your TV to See
Who is at the Door throughout the Home
Composite
Video
Audio
Satellite Receiver
Television
Set PIP source input to "Ant", tune
PIP "Ant" input to modulated channel.
Living Room
1-8-08
Family Room
Dining Room
Bedroom DVD Player
Etc.
Etc.
CATV / Ant
RF Input
Splitter
CATV / Ant
RF Input
Holland Electronics
Model HMM-10H
Modulator*
* For more information on Holland Electronics products, visit: www.hollandelectronics.com
** May be required when splitting to more than 4 locations.
** Optional RF
Amplifier
*Holland Electronics
Model HDA-30
RF Amplifier
*Holland Electronics
Model GHS-4
Splitter

Viking Model C-2000A
Door Entry Controller
DOD # 156
Monitor Who is at Your Door/Gate on Your
Receptionist's Computer Monitor
* For more information on Axis Communications products, visit: www.axis.com
1-8-08
PoE Switch
Facilitate the installation by
powering the video server via a
Power over Ethernet-enabled
switch. Optionally secure the
system with a Uninterruptible
Power Supply (UPS).
PC
Monitor the
K-1705-3
camera remotely
over the WAN or
Internet network.
Receptionist PC
with video management
software (included with
Axis 247S). Monitor,
record and play back
video.
INTERNET
Network
(PoE)
Composite
Video Out
RG59 or
RG6 Cable
Video In
(BNC Connector)
*Axis
Communications
Model 247S
Video Server
Doorstrike/
Magnetic Lock
Viking Model K-1705-3
Video Entry Phone with Keypad
(shown in optional VE-6x7)
DOD # 159
Camera
Power
Unused Line/
Trunk Input on
Phone System
(PABX/KSU)
How it Works:
The receptionist can simply answer the call from the
entrance, check their computer monitor to verify
identity then enter a touch tone command on the phone
to activate the doorstrike or gate.
Step 1. Connect the power, required entry phones and doorstrike
outputs (if required).
Step 2. Connect the unused phone system (PABX/KSU line/trunk
port to terminals 4 & 5, “LINE OUT TO PHONES" on the
C-2000A.
Step 3. Access programming. Enter *5, two beeps should be heard.
Step 4. Enter additional desired programming, then hang-up the
phone and place DIP switch 2 back to the OFF position.
C-2000A Programming Steps Required when Connecting
to a Phone System's Unused Line Input:
This video application also applies
to these Viking video phones:
Model DOD#
E-35 178
E-50 191
