Viking VS-12BL User manual

VIKING
Fingerprint
Lock
Enter

2
5
8
0
1
4
7
*
3
6
9
#
BIOMETRIC FINGERPRINT - LCD - KEYPAD SAFE
Body Material Steel
Can be open by Fingerprint / PIN code / Key
Optical Sensor 500 DPI, opens in fraction of a second
Fingerprint Entry Stores up to 32 ngerprints,
Memory Non-volatile memory - stored information is retained if batteries are removed.
Key Pad Entry Opens with 4-8 digits PIN code
Locking System Motorized door, deadbolt lock
High Security Keys 4 prong cross keys. Two included.
LCD display Battery Level indicator, Data Count indicator, OK and Error indicator, etc.
Sounds Mode On and OFF operational sounds
Warning sound Safe starts beeping if door is left unlocked for more than 1 minute.
Time Out Operation is put on HOLD for 2 minutes if multiple incorrect PIN or ngerprints are
input
LED light Build in LED light operates independently with 2 AA batteries
Warranty One-Year Limited Warranty
Batteries 4 AA
Included Accessories Mounting hardware and batteries
Fireproof No
Door Thickness 5 mm
Body Thickness 2 mm
www.vikingsecuritysafe.com | [email protected] | 650-539-9482
DISCLAIMER: Not recommend for age groups 55 and above. Due to thinning ngerprints
ALL ngerprint readers will lose accuracy with increasing age.
VS-12BL WALL SAFE
VS-14BL TOP OPENING DRAWER SAFE
VS-20BLX MINI
VS-25BL
VS-25DBL SMALL DEPOSITORY SAFE
VS-35BL
VS-38BL EXTRA WIDE LAPTOP SAFE
VS-50BL LARGE
VS-52BL HIDDEN WALL SAFE
VS-52BLX HIDDEN WALL SAFE LASER CUT
Viking Security Saf
e

1. BEFORE FIRST USE
1.1. Unlock the safe with key. Keyhole is located under the Logo Plate. Remove
using Allen Key.
1.2. Install 4 AA batteries in battery compartment B .
1.3. Install 2 AA batteries in LED light D (see point 9 for instructions).
VIKING SECURITY SAFE
USER'S MANUAL
IMPORTANT
• Operational sounds can be switched ON and OFF. However, Warning Beep sounds if safe is left UNLOCKED
for longer than 1 minute.
• If the safe is in lock state, locking bars sticking out, Red Button (A) is NOT functional. You cannot erase
ngerprint data, program the safe nor do any operation.
• Remember to program the same ngerprint in multiple positions.
• Remember to register new PIN code, so safe can no longer be open with factory default PIN “1234”
• If safe is reset to factory default mode, any ngerprint and default PIN code can open the safe.
• Test with non-registered ngerprints and PIN code. If safe opens, the safe is still in factory default mode.
• Time Out Period locks the safe for 2 minutes if multiple incorrect PIN codes or ngerprints are input. LCD
displays “HOLD-Err”.
• Test the keys and store them in a secure place, NOT inside of the safe.
• When the screen shows " ", please change the battery. All registered ngerprints and PIN will be
saved.
DISCLAIMER: Not recommend for age groups 55 and above. Due to thinning ngerprints ALL ngerprint
readers will lose accuracy with increasing age.
GENERAL DESCRIPTION
VIKING
Fingerprint
Lock
Enter

2
5
8
0
1
4
7
*
3
6
9
#
D
B
E
A
F
G
I
H
C
M
LK
J
AInitialization/Reset Red Button
BBattery Compartment
CLocking Bars
DLED light
EMotorized Door
FFingerprint Scanner
GLCD display
HData Count Indicator
IBattery Indicator
JKey Pad
KStar Button (*)
LPre-Scan Pound Button (#)
MLogo Plate and Key Access
VIKING
page 2/4
www.vikingsecuritysafe.com | [email protected] | 650-539-9482

2. HOW TO RESET SAFE TO FACTORY DEFAULT SETTINGS
2.1. PRESS and HOLD down red button A for 10 seconds. “INIT” ashes on LCD display followed by “OK”. Safe is
reset to Factory Default. All data is deleted and you can begin new registration when red light comes on.
3. HOW TO REGISTER FINGERPRINTS ON FINGERPRINT SCANNER
3.1. To register ngerprints PRESS BRIEFLY red button A . As soon as red light comes on, press your ngerprint
on the Glass Fingerprint Scanner F. LCD screen will display “OK”, battery indicator and data count indicator
“1d--01”.
3.2. If the registration fails “Err” will be displayed on LCD screen. Register the same nger again by repeating Step 3.1.
3.3. Repeat Step 3.1 with the same ngerprint but change ngerprint position on the Glass Fingerprint Scanner - left,
right, up, down, to the side.
Note:
The more times and various positions you program one ngerprint the more likely it is to open in an emergency.
3.4. To register a completely different ngerprint, repeat Step 3.1.
4. HOW TO REGISTER/CHANGE PIN CODE ON KEYPAD
Note: Start with Factory Default PIN 1234 if safe is new or reset. Register New PIN code using 4-8 digits. If
you want to change already registered PIN, follow the same steps beginning with your Registered PIN and
changing it to the New PIN. Test both PIN codes. Only Registered PIN code should open the safe.
4.1. Punch in the PIN and HOLD DOWN star button (*) until underscore (_) is displayed on the LCD screen.
4.2. Immediately punch in the New PIN code and press star button(*). Underscore (_) is displayed again. Punch in
the New PIN again and press star button(*) again. An "OK" will display after the PIN is input twice. New PIN is
registered. Test with New PIN as well as with Old PIN.
5. HOW TO UNLOCK AND LOCK THE SAFE WITH YOUR
FINGERPRINT
5.1. UNLOCK: Press pound button (#). When red light comes on,
press a registered ngerprint on the Glass Fingerprint Scanner.
Battery indicator and data count indicator “1d - -01” will display
on LCD screen. Safe is Unlocked.
5.2. LOCK: Press either star button (*) or pound button (#).
6. HOW TO UNLOCK AND LOCK THE
SAFE WITH PIN CODE
6.1. UNLOCK: Punch in a registered PIN
code and press star button (*).
6.2. LOCK: Press either star button (*) or
pound button (#).
7. HOW TO UNLOCK AND LOCK THE SAFE WITH A KEY
7.1. Insert the key in the keyhole and rotate to the right/clockwise to unlock
and back to the starting/lock position to lock the safe.
8. HOW TO TURN SOUNDS ON/OFF
8.1. SOUNDS ON: Press 1 & (*) star button, you will hear a long beep, sound is on.
8.2. SOUNDS OFF: Press 0 & (*) star button, the sound is off.
9. HOW TO INSTALL/CHANGE BATTERIES ON LED LIGHT
9.1. Unscrew the little bolt. Remove the LED light carefully. Put 2 fresh
AA batteries on the back of the light. Insert LED light back in the safe.
Note: 2 AA batteries are provided and have to be installed
.
Fingerprint
Lock
Enter

2
5
8
0
2
4
7
*
3
6
9
#
F
Center Left Right ...
Down Up
page 3/4
www.vikingsecuritysafe.com | [email protected] | 650-539-9482
12
A

MOUNTING INSTRUCTIONS
It is recommended to bolt down the safe.
Note: The safe may be mounted to a wall or oor. Be aware of the load bearing. Failure to do so can result in
personal injury and/or damage to property. Use appropriate tools when performing work and always use eye
protection
• Wall Mounting
-Do not mount the safe without anchoring to the wall
-Find the studs in the wall, at your desired location. Most studs are
16 inches or 24 inches apart
-Check the wall for concealed wires or pipes
-Measure the location of the pre-set drill holes; mark their exact
position onto the wall ensuring that the studs or anything else behind
will not interfere
-Drill the appropriate size holes for the anchors you are using
-Carefully press the anchor into the holes at this time
-Mount the safe by running screws from inside of the safe and
securing to anchors; ensure the safe is mounted securely.
• Floor Mounting
-Use proper drill tools depending on the type of oor you are mounting the safe (wood, tile, or concrete)
-Measure the location of the pre-set drill holes; mark their exact position onto the oor
-Drill the appropriate size holes for the anchors you are using
-Carefully press the anchor into the holes at this time
-Mount the safe by running screws from inside of the safe and securing to anchors; ensure the safe is mounted
securely.
CARE AND MAINTENANCE
To maximize the security and performance of the safe, keep Glass Fingerprint Scanner Fclean
• Use a dry cloth to remove any smudges or prints off the Fingerprint Scanner after use
• Use gentle cleaning agents to clean the safe and Glass Fingerprint Sacnner
• Test registered ngerprints and PIN code every 6 months
• Keep liquids away from the control panel. Spills on the control panel will cause damage and possibly electric shock
• Secure safe in a proper area to prevent from falling and causing damage or injury
• DO NOT disassemble the product. For all repairs, contact Viking Security Safe Customer Service
page 4/4
www.vikingsecuritysafe.com | [email protected] | 650-539-9482
Mounting Holes
*Actual Model may vary
Viking Security Saf
e
WARNING
Never store rearms and ammunition together. The safest protection against accidents involving
children is to store your rearm unloaded in an approved Firearm Safety Lock Box, with ammunition
stored separately.
