Viking DFRB530 Series User manual

REFRIGERATION
Quiet Cool™ Built-In 30”W. All Re rigerator
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
All models include
• Capacity—18.2 cu. ft. (515.1 L)
o 84”H./24”D.
• ProChill™ Temperature Management
System
oVariable-spee DC Over rive™
Compressor is one of the quietest,
most technologically a vance
compressors available
oElectronic controls maintain the
temperature selection within 1ºF
oMulti-channel airflow system an
O or Eliminator™ Evaporator
removes o ors an excess humi ity
• A justable Col Zone™ rawer with
precision ball-bearing gli es
oSeparate temperature control can be
set for pro uce or fresh meat storage
oQuick chill option chills foo s an
beverages in minutes
• A justable Humi ity Zone™ rawers
with precision ball-bearing gli es
oHumi ity can be set high for leafy
greens or low for fruits an
vegetables with skins
• Four a justable, full-wi th, tempere
glass spillproof shelves
• Two conveniently locate eli rawers
with full-extension precision ball-
bearing gli es
• Two in-the- oor seale airy
compartments with covers
• Four patente a justable aluminum
oor bins with tempere glass fronts
• Top-shelf provi es quick chill- own
area
• Super Clog-Resistant™ Con enser is
maintenance-free un er normal use
• Tru-Flush™ esign
oAllows Professional Integrate an
Custom Panel mo els to fit flush into
24” eep installation cutout
• Open oor alarm soun s an glows to
warn that oor has been ajar for three
minutes
• A justable oor stops stan ar —90°,
110°, or 120° swing
• Sabbath Mo e
• For installation of two units si e-by-
si e, a separate grille kit accessory
must be purchase
• Must be or ere right or left hinge.
(As you face unit, RIGHT has hinge on
right si e an han le on left si e;
LEFT has hinge on left si e an
han le on right si e.)
VCRB530/VIRB530
Professional/Professional Integrated
FINISH DETAILS FOR DFRB MODEL
• Han le not inclu e —opt for custom
han le, or purchase a Viking
Professional Series or Designer Series
han le kit (see Installation Notes &
Accessories).
• See Custom Panels section for
more information an a itional
specifications.
FINISH DETAILS FOR VCRB/VIRB MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW),
Oyster Gray (OG), Gol en Mist (GM),
Lemona e (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iri escent Blue
(IB), Viking Blue (VB), Pumpkin (PM),
Racing Re (RR), Apple Re (AR),
Burgun y (BU), Plum (PL), Chocolate
(CH), an Cobalt Blue (CB).
• Finish co es esignate oor front.
Stainless steel upper grille, si e trim,
an han le (with chrome-plate
brackets); black lower kickplate.
• Brass Trim Option (BR)—nameplate,
han le/brackets, an si e trim.
Brass components have a urable
protective coating for maintenance-
free normal use.
DFRB530
Custom Front
Standard Features & Accessories
Model Options
ORDERING INSTRUCTIONS
First specify mo el number, followe by hinge preference (“R” for right or “L” for left), an then color co e (VCRB530RSS).
If or ering optional brass trim, specify co e at en (VCRB530RSSBR).
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE

REFRIGERATION
Quiet Cool™ Built-In 30”W. All Re rigerator
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1

Please see
Installation Notes &
Accessories
for important
information,
inclu ing panel,
grille, trim, an
han le kits.
24–11/16”
(62.7cm)
29”
(73.7cm)
75–15/16”
(192.9cm)
3–19/32”
(9.1cm)
30”
(76.2cm)
9–5/32”
(23.3cm)
82–3/4”
(210.2 cm)
min.
to
84–1/16”
(213.5 cm)
max.
20–3/4”
(52.7 cm)
22–3/16”
(56.4cm)
27–1/4”
(69.2cm)
26-1/2”
(67.3cm)
29”
(73.7cm)
75–15/16”
(192.9cm)
3–19/32”
(9.1cm)
30”
(76.2cm)
9–5/32”
(23.3cm)
82–3/4”
(210.2 cm)
min.
to
84–1/16”
(213.5 cm)
max.
23-3/8”
(59.4 cm)
24”
(61.0cm)
26–1/2”
(67.3cm)
PROFESSIONAL PROFESSIONAL
INTEGRATED
VCRB530 VIRB5530
Overall w dth 30” (76.2 cm)
Overall he ght (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To front edge of s de tr m 22-3/16” (56.4 cm) 23-3/8” (59.4 cm)
To front of top gr lle 24-11/16” (62.7 cm) 24” (61.0 cm)
To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)
Approx. sh p we ght 425 lbs. (193.2 kg)
VCRB530/VIRB530
Professional/
Professional Integrated
Dimensions & Speci ications
PRODUCT DIMENSIONS
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE

REFRIGERATION
Quiet Cool™ Built-In 30”W. All Re rigerator
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1

Please see
Installation Notes &
Accessories
for important
information,
inclu ing panel,
grille, trim, an
han le kits.
24”
(61.0cm)
29”
(73.7cm)
75–15/16”
(192.9cm)
3–1/2”
(8.9cm)
9–5/32”
(23.3cm)
82–3/4”
(210.2 cm)
min.
to
84–1/16”
(213.5 cm)
max.
20–3/4”
(52.7 cm)
23–3/8”
(59.4cm)
26”
(66.0cm)
30”
(76.2cm)
CUSTOM FRONT
DFRB530
Overall w dth 30” (76.2 cm)
Overall he ght (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To front edge of s de tr m 23-13/16” (60.5 cm)
To front of top gr lle 24-3/4” (62.9 cm)
To front of handle Varies
Approx. sh p we ght 425 lbs. (193.2 kg)
DFRB530
Custom Front
See Custom Panels section for
more information an a itional
specifications.
Dimensions & Speci ications
PRODUCT DIMENSIONS
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE

22--11//22””
((66..44ccmm))
1111--77//88””
((3300..22ccmm))
1155--2277//3322”
((4400..22ccmm))
33--11//3322””
((77..77ccmm))
112200..0000
111100..000
0
9900..0000
””
5522--33//88””
((113333..00ccmm))
2244--1111//1166””
((6622..77ccmm))
5511””
((112299..55ccmm))
4499--11//1166””
((112244..66ccmm)
3300””
((7766..22ccmm))
2299””
((7733..77ccmm))
VCRB530/VIRB530
Professional/
Professional Integrated
DFRB530
Custom Front
REFRIGERATION
Quiet Cool™ Built-In 30”W. All Re rigerator
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
22--11//1166””
((55..22ccmm))
1100--3311//3322””
((2277..99ccmm))
1155--33//3322””
((3388..33ccmm))
11--2277//3322””
((44..77ccmm))
112200..0000
111100..0000
9900..0000
5522--1111//3322””
((113322..99ccmm))
5511””
((112299..55ccmm))
4499--11//1166””
((112244..66ccmm)
2244””
6611..00ccmm))
3300””
((7766..22ccmm))
2299””
((7733..77ccmm))
((
PROFESSIONAL INTEGRATED
See Custom Panels section for
more information an a itional
specifications.
Dimensions & Speci ications
DOOR SWING
• A justable oor stops stan ar —90°, 110°, or 120° swing
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
PROFESSIONAL

REFRIGERATION
Quiet Cool™ Built-In 30”W. All Re rigerator
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
2-1/2”
(6.4 cm) offset
Partial overlay
cabinet door
Door
Wall
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
3/4”
(1.9 cm)
full end panel
24”
(61.0 cm)
standard
cabinet
depth
2-1/2”
(6.4 cm) offset
5/16”
(0.8 cm)
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
2-1/2”
(6.4 cm) offset
Countertop
overhang
Dimensions & Speci ications
CLEARANCE DIMENSIONS PROFESSIONAL
TOP VIEW
TOP VIEW
TOP VIEW
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE

REFRIGERATION
Quiet Cool™ Built-In 30”W. All Re rigerator
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
Door
Wall
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
3/4”
(1.9 cm)
full end panel
25”
(63.5 cm)
Flush
Door
24”
(61.0 cm)
standard
cabinet depth
25”
(63.5 cm)
countertop
depth
Wall
3/4”
(1.9 cm)
full end panel
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Dimensions & Speci ications
CLEARANCE DIMENSIONS PROFESSIONAL INTEGRATED
Door
24”
(61.0 cm)
standard
cabinet
depth
24-3/4”
(62.9 cm)
Wall
3/4”
(1.9 cm)
full end panel
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depthis used
Flush
Cabinet
door
TOP VIEW
TOP VIEW
TOP VIEW
Overlapp ng cab net doors
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
REFRIGERATION
Quiet Cool™ Built-In 30”W. All Re rigerator
UTILITY
REQUIREMENTS
GAS
Not applicable
ELECTRICAL
• Three-wire cor
with
groun e
three-prong plug
attache to
pro uct
• 115 VAC/60 Hz;
15 amp
e icate circuit
• Maximum amp
usage—5.7
• Estimate
energy usage—
404 kWh/year
PLUMBING
Not applicable
Installation Requirements
Anti-tipboard
6”
(15.2cm)
9”
(22.9 cm)
73-3/8”
(186.4cm)
82-7/8”
(210.5cm)min.
anti-tipboard&
openingheight
84-1/16”
(213.5cm)max.
anti-tipboard&
openingheight
29-1/2”
(74.9cm)min.
to
29-3/4”
(75.6cm)max.
Professional
30”
(76.2cm)
ProfessionalIntegrated/
Custom Front
24”*
(61.0cm)
min.
9”
(22.9cm)
VCRB530 VIRB530 DFRB530
Cutout w dth 29-1/2” (74.9 cm) m n. to 30” (76.2 cm) 30” (76.2 cm)
29-3/4” (75.6 cm) max.
Cutout he ght 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.*
VCRB530/VIRB530
Professional/
Professional Integrated
DFRB530
Custom Front
See Custom Panels section for
more information an a itional
specifications.
ACCESS REQUIREMENTS – Single Installation
ELECTRIC OUTLET LOCATION
*Custom front models f t flush n 25”-deep (63.5 cm) cab net open ngs. They can be nstalled n standard 24”-
deep open ngs. The door faces and top gr lle w ll protrude 3/4” (1.9 cm) nto the room.
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE

9”
(22.9cm)
73-3/8”
(186.4cm)
82-7/8”
(210.5cm)min.
anti-tipboard&
openingheight
84-1/16”
(213.5cm)max.
anti-tipboard&
openingheight
65-1/2”Professional
(166.4cm)
66”ProfessionalIntegrated/
CustomFront
(167.6cm)
24”*
(61.0cm)
6-3/4”
(17.1cm)
7-5/8”
(19.4cm)
3”
(7.6cm)
5/8”
(1.5cm)
5/8”
(1.5cm)
10-1/2”
(26.7cm)
5/8”
(1.5cm)
10-3/4”
(27.3cm)
3-5/8”
(9.2cm)
Optionalfloor
waterline entry
1”
(2.5cm)
Seeanti-tipboardinstallation
6”
(15.2cm)
9”
(22.9cm)
9”
(22.9cm)
73-3/8”
(186.4cm)
82-7/8”
(210.5cm)min.
anti-tipboard&
openingheight
84-1/16”
(213.5cm)max.
anti-tipboard&
openingheight
59-1/2” Professional
(151.1cm)
60”ProfessionalIntegrated/
CustomFront
(152.4cm)
24”*
(61.0cm)
6-3/4”
(17.1cm)
7-5/8”
(19.4cm)
3”
(7.6cm)
5/8”
(1.5cm)
5/8”
(1.5cm)
10-1/2”
(26.7cm)
5/8”
(1.5cm)
10-3/4”
(27.3cm)
3-5/8”
(9.2cm)
Optionalfloor
waterlineentry
1”
(2.5cm)
Seeanti-tipboardinstallation
6”
(15.2cm)
9”
(22.9cm)
REFRIGERATION
Quiet Cool™ Built-In 30”W. All Re rigerator
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
Installation Requirements
VCRB530/VCFB536 VIRB530/VIFB536 DFRB530/DFFB536
Cutout w dth 65-1/2” (166.4 cm) 66” (167.6 cm) 66” (167.6 cm)
Cutout he ght 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.*
VCRB530/VCFB530 VIRB530/VIFB530 DFRB530/DFFB530
Cutout w dth 59-1/2” (151.1 cm) 60” (152.4 cm) 60” (152.4 cm)
Cutout he ght 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.*
30”W./30”W. REFRIGERATOR/
FREEZER COMBINATION
30”W./36”W. REFRIGERATOR/
FREEZER COMBINATION
ACCESS REQUIREMENTS – Dual Installation
ELECTRIC OUTLET LOCATION
WATER LINE ENTRY AREA
Note: cutout opening shown with All Freezer mo el on left.
Reverse water line entry if All Freezer mo el is on right
ELECTRIC OUTLET LOCATION
WATER LINE ENTRY AREA
Note: cutout opening shown with All Freezer mo el on left.
Reverse water line entry if All Freezer mo el is on right
*Custom front models f t flush n 25”-deep (63.5 cm) cab net open ngs. They can be nstalled n standard 24”-deep open ngs. The
door faces and top gr lle w ll protrude 3/4” (1.9 cm) nto the room.
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE

Side Panel Kits
• Stainless Steel (SS)
•Panels provi e finishe , freestan ing look; unit must still be secure to the wall
• Kit inclu es one panel an installation har ware
Side Panel Hardware Kit
• For use with Designer built-in refrigerator/freezers
• Har ware allows installation of custom si e panels
• Kit inclu es brackets, screws, an installation instructions to mount panels on left an right si e
Top Panel Kit
• Stainless Steel (SS)
• Panel provi es finishe , freestan ing look; unit must still be secure to the wall
• Kit inclu es one panel an installation har ware
Top Grille Kits
• Stainless Steel (SS)
• 60”W. top grille kit—for use with installation of two 30”W. all refrigerators/all freezers si e-by-si e
• 66”W. top grille kit—for use with installation of one 30”W. an one 36”W. all refrigerators/all freezers si e-by-si e
• Grille creates a single unit look
• Kit inclu es one full-length grille, center cabinet trim connector, an installation har ware
REFRIGERATION
Quiet Cool™ Built-In 30”W. All Re rigerator
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
PSSPL2 Profess onal s de panel left (VCRB) 45 (20.2)
PSSPR2 Profess onal s de panel r ght (VCRB) 45 (20.2)
DSSPL2 Des gner s de panel left (VIRB/DFRB) 45 (20.2)
DSSPR2 Des gner s de panel r ght (VIRB/DFRB) 45 (20.2)
Model Description Approx. ship wt. lbs. (kg)
PGK60-SS Profess onal 60”W. gr lle (for two VCRB/VCFB un ts) 21 (9.5)
PGK66-SS Profess onal 66”W. gr lle (for two VCRB/VCFB un ts) 23 (10.4)
IGK60-SS Profess onal Integrated 60”W. gr lle (for two VIRB/VIFB un ts) 21 (9.5)
IGK66-SS Profess onal Integrated 66”W. gr lle (for two VIRB/VIFB un ts) 23 (10.4)
DGK60-SS Des gner 60”W. gr lle (for two DFRB/DFFB un ts) 21 (9.5)
DGK66-SS Des gner 66”W. gr lle (for two DFRB/DFFB un ts) 23 (10.4)
Model Description Approx. ship wt. lbs. (kg)
TOP-30 30”W. top panel 21 (9.5)
Model Description Approx. ship wt. lbs. (kg)
SPHKDS S de panel hardware 3 (1.4)
Model Description Approx. ship wt. lbs. (kg)
FCTK-SS Center tr m 5 (2.3)
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
Center Trim Kit
• Stainless Steel (SS)
• Kit inclu es center cabinet trim connector to install two custom front units with woo top grille

REFRIGERATION
Quiet Cool™ Built-In 30”W. All Re rigerator
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
Handle Kits
• For use with custom front refrigerators
• For use on locally supplie custom front panels
•Han les allow refrigerators/freezers with custom front panel to coor inate with other Professional an Designer pro ucts
• K t ncludes handle(s) and nstallat on hardware
Compliance In ormation
WARRANTY SUMMARY*
• Two-year full warranty—complete unit
• Six-year full warranty—seale refrigeration system
• Twelve-year limite warranty—seale refrigeration system (inclu es compressor, con enser,
ryer/strainer, evaporator, an connecting tubing)
• Ninety- ay limite warranty—cosmetic parts such as glass, painte , an ecorative items
*For complete warranty see Use & Care Guide. Warranty vali on Viking pro ucts shippe within the Unite States an Cana a.
Model Description Approx. ship wt. lbs. (kg)
PHK28-SS Profess onal one handle (Sta nless Steel) 7 (3.2)
PHK28-BR Profess onal one handle (Brass) 7 (3.2)
DHK25-SS Des gner one handle (Sta nless Steel) 7 (3.2)
DHK25-BR Des gner one handle (Brass) 7 (3.2)
PHKDFSB5-SS Profess onal two handles (Sta nless Steel) 10 (4.5)
PHKDFSB5-BR Profess onal two handles (Brass) 10 (4.5)
HKFDS-SS Des gner two handles (Sta nless Steel) 10 (4.5)
HKFDS-BR Des gner two handles (Brass) 10 (4.5)
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
