Overview
The Vincent CP Press consists of a screw rotating within a screen housing, a flanged inlet
hopper, and a discharge opening. At the discharge end, the mouth of the screen housing is
closed by a pneumatically activated cone which moves back and forth on the screw shaft in
proportion to the internal pressure in the screen frame. This motion is opposed by the cone's
two cylinders' thrust, thereby regulating the discharge of solids. An air regulator is provided to
adjust the pressure on the cone. The liquids, which are squeezed from the wet product, escape
through the screen housing and are caught in a built-in pan under the screen.
The screw is driven by a fixed speed electric motor that is C-face mounted to a gearbox. The
gearbox reduces the RPM's from the (typically) 1750RPM output of the motor to an appropriate
speed for the application, 5 - 50 RPM. The hollow bore gearbox mounts directly on the screw
shaft and is flange mounted to the machine.
The numbers in the model designation stand for the nominal diameter of the screw in inches.
As the press has been adapted to many different applications, options have been added to the
press. These include interrupted or continuous flighted screws, conical screws where the shaft
increases in diameter, different shape inlet hoppers, different style cones, etc. As a result, not all
the information contained in this manual will apply to your press.
Safety
A screw press, like any screw conveyor, is totally unforgiving. If clothing or a limb gets
caught in a rotating screw, the screw will not stop.
·Wear safety glasses around the press.
·Avoid loose-fitting jewelry or clothing,
including high-visibility safety vests. If vests are required, the Velcro, tear-away type
are recommended.
·Always lock out electric and compressed air
before working on the press.
·Dewatering presses squirt liquid out,
particularly if screen covers are removed. If material is hot, acidic, or caustic, do not
remove screen covers while operating.
·Wear gloves when performing maintenance.
·When removing the tailstock and discharge mechanism, watch for pinch points and
hinged assemblies. Be careful when removing or installing the screw and screen
when they are fed through the C-plate as this is a particular pinch point.
·Never stand near a press being suspended during installation.
·Provide an E-stop button near the press.
·Keep hands out of the press inlet and press cake discharge area.

6
Rigging
Be sure to properly support the press when lifting it from the truck. Usually a sling
positioned under the inlet hopper, on the side closest to the gearbox, finds the center of
gravity. On bigger presses, do not lift just one end of the press, as it is possible for the frame
to deflect, shifting the screw within the press.
Installation
These presses are typically called horizontal screw presses. This doesn't mean that the
presses have to be installed exactly level from inlet to discharge. Presses are often installed
at an upward angle. Consult the factory if you need to install the press at an angle above
15% as an adjustment to the gearbox may be required.
Be careful not to rack the press when tightening the mounting bolts. In the case of large
presses, do not just bolt or weld the press down to a level foundation! Instead, first place the
press where it is to be installed. Next, place shims between the press frame and the steelwork
(or floor, concrete pedestal or foundation) to fill any gap where the press is to be anchored.
Only after shimming (or grouting) should the press be pulled down tight. Doing otherwise
can rack the frame of the press, and this can cause screw-to-screen interference.
A large press must be mounted solidly, preferably to a foundation or structural steel. If a
press draws its full rated horsepower without the press being anchored to the floor, the frame
of the press can twist.
For maintenance, the screw is removed through the cake discharge end of the press. Allow
the space required.
To suit individual conditions, a hollow bore gearbox can be rotated 180o, even 90oeither
way. Consult the owner's manual or factory in these situations as it is likely that the oil level
in the gearbox will have to be adjusted.
Material can be fed into the press many ways. You may need to allow for return feed of
overflow material in the event that more is fed to the press than it can take. When material is
piped to a press in a closed piping system, it is important to have a 2" vent line open to the
atmosphere, along with an overflow return line. The vent is necessary to prevent a siphon
effect which can induce a vacuum in the inlet hopper and reduce press capacity. The return
line should empty above the surface of the return pit. The overflow should fill less than half
of the cross section of the return line.
Spill containment is a consideration which should be taken into account, because it may be
possible for un-pressed material to purge from the cake discharge of a press.

7
We recommend that a manual disconnect, for killing power to the motor, be installed close to
the press.
A variable frequency drive (VFD) programmed for either variable speed or auto-reversing
may be required, depending on the application. If not, the use of a reversing starter switch is
recommended; they cost only a little extra. Such a switch is handy for clearing a jammed
press.
It is possible that, when operating intermittently with very wet material left in the press
between runs, the liquid may loosen the cake plug at the discharge. This might cause the
plug to blow out upon start-up. To minimize this condition, the press can be installed with
the discharge tilted upwards.

8
Press Components
A-B-C-D PLATES
There are five vertical plates making up the frame of the press, called out in the
Nomenclature drawing at the end of this manual. Starting from the drive end of a press with
a hollow bore gearbox, the first one is the Adapter Plate. The gearbox is bolted to the adapter
plate. Through four spacers, the adapter plate is welded to the A Plate. This A Plate forms
one wall of the inlet hopper. The shaft seal housing is bolted to the A Plate.
The next plate is the B Plate. It forms the downstream wall of the inlet hopper. The screen
starts at the B Plate. Some presses will be supplied with a notch, called a Cord Cutter, in the
B plate. Also, there may be a bar called Brian's Stripper welded to the B Plate, inside the
inlet hopper; it is in a position to kiss the edge of the screw flight as it passes. These two
features prevent long fiber pieces from balling up at the exit of the inlet hopper. See the
section ahead on Cord Cutters.
The next plate, the C Plate, supports the discharge end of the screen. The discharge cone
touches the C Plate when the cone is in the closed position.
The final plate, the D plate has the twin air cylinders mounted on it. The screw shaft
terminates at the D plate via the attached flange bearing.

9
Air Regulator/Three-Position Valve
To regulate the air pressure of the discharge air cylinder, presses are supplied with an air
pressure regulator along with a Parker three-position valve (sometimes called a four-way
valve). These are typically installed near the cone end of the press. (Until recently FRL
(Filter, Regulator, Lubricator) sets were provided to regulate air pressure. Most air cylinder
manufacturers now recommend against the use of lubricators.)
The Parker valve allows manual selection of the shut, open, or "neutral" position. This valve
connects air supply from the regulator to one end of the air cylinder, while simultaneously
Filter/Regulator

10
opening the other end to atmosphere. The vent line on the three-position valve allows air to
escape when pressure is switched from one end of the air cylinders to the other.
Continuous air flow from the Parker vent line indicates a leak inside one of the air cylinder,
or possibly a faulty three-position valve.
The neutral position of the Parker valve is used only in testing. If left in the neutral position,
the cone will not move unless it is pushed open by press cake. If, later, the flow of press
cake is diminished, the cone will remain in the position to which it was pushed, and purging
can occur.
Discharge Cone
The principal adjustment of the press is made with the discharge cone. The cone is the
component at the cake discharge end of the press that acts as a door or stopper plug to restrict
material from leaving the press. The more pressure exerted by the discharge cone, the drier
the cake material will be leaving the press. Also, the motor amps can be expected to increase
with added pressure, and throughput may decrease.
The discharge cone is moved in (actuated) by twin air cylinders. Typical air cylinder
pressures are in the range of 30 to 60 psi. Some materials will press only in a low range, say
10 to 20 psi. Other materials may press best with a pressure of 60 to 100 psi. Air
consumption is minimal in all models, 1 to 2 cfm.
During initial, first-time start up, presses with air cylinder actuators are generally started up
with the discharge cone in the withdrawn position. This will avoid an unnecessary jam.
With the air cylinder models, the discharge cone mechanism can readily be positioned in the
"open" (withdrawn or "out") position.
Note that with many materials it is necessary to start the press with the discharge cone in the
closed position at low air pressure. Thin or soupy materials, like pumped manure or clarifier
underflow, can tend to purge right through the press if the press is operated with the
discharge cone open (in the withdrawn ("out") position). However, with materials that are
dry to begin with, such as sawdust or plastic wash tank sludge, it becomes more important to
start with the discharge cone in the open position. This is because these materials may tend to
jam or overload the press. Similarly, high freeness materials, from which the water falls
away freely, will have a tendency to jam in a press. Be sure to start the press with the cone
open, and gradually close it with low air pressure, when running such materials for the first
time.
Once you are through the initial start up, it will be unlikely that your press should have the
cone open before starting. Most operators rarely open or shut the cone once it is set.
As the pressure on the discharge cone is increased, not only will the cake become drier, but
the flow through the press may also be reduced. With very slippery or slimy feed material it
may be possible to apply enough discharge cone pressure to stop the flow altogether.
High discharge cone pressures can result in increased quantities of suspended solids in the
press liquor.

11
Care must be taken if a press is to be left running at a very low pressure like 10 psi. If some
fiber enters between the cone bushing and the screw shaft, it will take more than that much
pressure to close a cone which has been pushed open by a heavy flow of cake. The result
will be either high moisture content in the cake or, worse, purging.
With some feed materials, the press can be operated with the discharge cone in the
withdrawn position. The screw alone may do enough compressing and dewatering to
produce a cake at the discharge.
It is acceptable to open the discharge cone, in most cases, during normal operating
conditions. This allows inspection, while in operation, of the discharge end of the screw and
screen. This will give the operator a chance to observe operation with minimum dewatering
and maximum throughput. It is also a good technique for purging bad material i.e., either
jammed or spoiled material, from the press. (Do not try this trick if you are pressing hot or
chemically aggressive materials.)
Where very low air pressure is required for proper operation, it may be practical to put the 3-
position valve in a neutral position, half way between open and closed. A press cannot be
left permanently in this condition: keep in mind that a slug of cake will push the cone open,
and it will not re-close on its own afterwards.
An unusual technique is to set the air pressure so that the cone normally stays completely
shut. A timer is used to periodically open the cone. The closed period is determined by the
amount to time required for press cake to accumulate in the press. This type of operation is
used with slippery or slimy press cake that cannot be dewatered to sufficient firmness to
force the cone open. The duration of the "cone open" period is long enough to dump the
majority of the press cake that has been formed. Cone Timer panels are available from
Vincent at no charge.
Once through start-up, the cone is almost always left in the closed position at whatever air
pressure had been found to be effective. A plug of cake will be left around the cone
whenever the press is turned off; this will normally clear on its own accord on restarting the
press. To prevent a potential jam upon restarting, it is a good idea to open the cone for a few
minutes prior to shutting down the press, after flow to the press has been stopped. Although
there will be solids left in the press, they won't be highly compacted.
There are a few applications where the air cylinders are removed and replaced with a jacking
bolt. This is used if the cone pushes completely closed even with the lowest air pressure. It
results in operating the press with a fixed discharge annulus. Air cylinders with linear
actuators are available.
Cone Bushing
The cone rides on the shaft of the screw. "Cone Sleeve" is the name given to the portion of
the screw on which the cone rides. There is a single or dual bronze bushing in the cone to
support and guide it, and to protect the Cone Sleeve journal surface of the screw shaft.

12
Sometimes the bushing is lubricated with liquid from the material being pressed, such as the
juice from apples or water from pectin peel. Sometimes there is a grease fitting provided for
lubricating the bushing or to minimize leakage of press liquor through the cone bushing.
And sometimes, an AutoLube is included for automated lubrication of the cone bushing.
Bushing lubrication is extremely important when materials that are dry (like paper mill
screen rejects) are being pressed. By the time such materials reach the discharge of the press,
they do not have enough free moisture left in them to adequately lubricate the cone bushings.
In these applications the operator should, at the start of each shift, pump grease in until it
comes out between the cone bushing and the screw shaft. Then he should open and shut the
cone three times in order to spread the grease.
Rarely, presses are supplied with additional lubrication fittings so that water, in addition to
grease, can be metered to the bushings as a lubricant.
Liquid leaking past the cone bushings drains out the back of the cone (at the air cylinder end
of the press). Almost always it is minimal compared to the flow of press cake. However, a
pan can be provided to collect this liquid and drain it into the main flow of press liquor.
Screw / Screw Configurations
Most Vincent screw presses use the Interrupted Screw Flight design. The interruptions leave
room for stationary resistor teeth that are mounted outside of the screen. These teeth go
through the screen and reach almost to the shaft of the screw. This design of screw press
stands in contrast to a Continuous Screw design. The main advantage of the interrupted
design is that solids material must accumulate in the interruptions until sufficient consistency
is reached for the solids to be pushed toward the cake discharge. There is a reduced tendency
for the material being pressed to co-rotate with the screw. Also, there is more agitation
within the press and, consequently, quicker and more thorough dewatering. Pushing the
material through the compression zones past the resistor teeth will also shred the material a
little.
Interrupted Flight Screw with Resistor Bar
For applications where tramp material is more likely to enter the press, a continuous-flighted
screw is often used. Typically, if maximizing dryness is a priority, the screw shaft is tapered
to provide increased compression.

13
Screw with Tapered (Conical) Shaft
All screws start with a feeder section of continuous flights. This picks up material in the inlet
hopper and pushes it into the screen section. The feeder section ends at the first resistor
tooth. This feeder section of the screw is followed by compression stages where the flights
have reduced pitch. The reduction in pitch of the flights results in compression of the
material going through the press.
A screw configuration referred to as Sterile Butterfly is occasionally used. Sterile is a
reference to a company, not cleanliness. There are a reduced number of flights on this screw,
and the flights do not wrap as far around the shaft as is normal. This screw design is good
for high throughput of materials which are easily dewatered and might jam the press.
Wing Feeders
Sometimes there are blades welded to the outside tips of the last two flights of the screw.
Called "Wing Feeders", these are mounted parallel to the discharge screen surface. Care
must be taken that wing feeders are not made so long that they hit the face of the cone when
the cone is in the closed position.
Wing feeders can serve two purposes. (1) In the case of materials that want to channel out
the discharge of the press, like pineapple and spent brewer's grains, long wing feeders break
up the channeling flow. (2) For abrasive applications, short knobby wing feeders are
provided as sacrificial wear elements.
When certain materials are fed through a screw press, clumps of dry material may get
between the wing feeders and the screen. This buildup can cause wear of the screen. Should
the problem occur, grind off the wing feeders.

14
Long Wing Feeder Knobby Wing Feeder

15
Notches
Sometimes it is necessary, during press operation, to have the screw wipe the screens clear of
blinding material. This is best achieved by having notches in the outer edge of the screw.
Fibrous material accumulates in the notches and brushes away slimy material which may be
blinding the screens. Shallow notches (1/16" wide by 1/16" deep, 1-1/2" apart) in the outer
edge of the screw flights work well. Notching is easy to do while in the field, using a grinder
with cutting wheel or a portable band saw. Typically, notching is done from the B plate to
the second resistor tooth. Most Vincent presses are supplied with notches.
Grinding Notches on Screw Flights
Resistor Teeth
The interrupted screw design press has stationary teeth that protrude into the flow of material
as it passes through the press. These fit into the gaps of the screw where there is no flighting.
They stop just short of the shaft of the screw. These resistor bars are on top and bottom of
the screens and the screens bolt up to them.
Rarely, the resistor teeth are shortened, usually by half, to increase the capacity of the press.
Removing the teeth altogether will result in co-rotation and jamming. Occasionally, the
resistor teeth are drilled so that fluid can be injected into the press during operation.
Resistor Teeth and Screw

16
Screens
The screen of the press is made either of wedgewire or profile bar (slotted screen) or
perforated stainless sheet (round holes).
Screens made of wedgewire come standard with 0.015" to 0.020" slot width; they are also
available with slots that range from 0.008" to 0.060" wide. With slot widths less than 0.012"
there is a tendency for the screen to blind (be covered over) with the material being pressed.
However they work well in alcohol and oil separation. Changing the slot width generally
has little impact on the clarity of the press liquor or the dewatering capacity of the press.
These screens are reversible as most wear will occur at the discharge end. This doubles the
life of the screen. When worn, the entire assembly must be replaced.
Perforated metal screens are usually a simple sleeve made from rolled perforated plate which
is held in the screen assembly. These are less durable but usually only the inner screen (the
screen insert, must be replaced, reducing cost).
The most common damage to a wedgewire screen is for part of the surface to be smeared
over from being rubbed by the screw. This rarely is bad enough to affect press performance.
Profile bar screens generally work satisfactorily with 30% or even more of their surface
smeared over. Smeared screens can be remedied by running a box cutter blade through the
slots. Small holes can just be patched with sheet metal to extend life. In cases of severe
wear or damage, it is common to patch a screen. Stainless sheet metal is used for this. The
reduction in drainage surface is of little consequence as the screens have ample open area.
Standard perforated screens have a hole size of .094" diameter, although material with
0.050", 0.033", down to 0.023" holes can be supplied. Surprisingly, usually there is little
difference in the degree of filtration achieved by either changing hole size or going to a
slotted profile bar screen.
Frequently, increased press capacity can be achieved by changing a perforated screen to one
with smaller holes. This unexpected result arises from a combination of factors: (1) smaller
hole screens are made of thinner sheet metal, so that the press liquor has a shorter distance to
travel before it falls free from the screen, reducing the chance of blinding and (2) particles
which fall into and plug a larger hole will roll over a smaller hole. Minor rubbing between
the screw and screen is normal, although, obviously, hard rubbing will cause wear and
premature failure of the screen. With a clearance greater than 3/16", the dewatering
performance of the press can start to deteriorate; this depends a lot on the nature of the
material being dewatered.
The most common cause of screen failure ties to failure of the outboard support bearing. If
the bearing holding the end of the screw wears out, it can let the screw move enough to rub
against the screen.

17
Perforated Screen Assembly
Profile Bar / Wedgewire Screens

18
Cord Cutter and Stripper Pins
Sometimes long stringy material will be pinched where the feeder portion of the screw goes
through the hole in the B Plate. This material will co-rotate with the screw and build into a
bundle which reduces flow through the press.
A groove, like a keyway that is 3/8" deep, is cut half way through the hole in the B plate. We
call this a Cord Cutter. Material trapped between the flight and the hole in the B plate will
pop up slightly as it passes the Cord Cutter. The result is that the material is sheared loose.
A part called Brian's Stripper may be welded to the B Plate, inside the inlet hopper. It goes
in a position so that the flight lightly kisses the stripper as it goes past. This strips the
material away. Strippers are made of square bar.
Cord Cutters on the outside, Stripper Pin in the middle
Motor / Gearbox
Vincent presses are almost always supplied with a motor. Standard motors are 60Hz,
Inverter Duty, TEFC, 230/460V. We will supply whatever motor is called for where the
press is headed, 575V, 50Hz, whatever. Motors used are standard, off the shelf motors,
easily replaced if needed from your local motor distributor.
Specialty motors are available upon request, including stainless, washdown, explosion-proof,
etc.
A motor manual is supplied toward the end of this manual.
Standard gearboxes supplied are NORD shaft-mounted. Gearboxes are supplied with the oil
at the right level for horizontal mounting. If the press is mounted off horizontal, a change
could be required in oil level. Sometimes, to increase capacity, the press is sped up to 120Hz

19
or a 3600RPM motor is installed. If your press is going to be run at high speeds, NORD
recommends changing the oil to synthetic.
A gearbox manual is supplied toward the end of this manual.
A-Plate Shaft Seal
Consult the Parts List contained in this manual to determine what type of seal plate assembly
you have. The Seal Plate is bolted to the A Plate. This housing may be solid UHMW (ultra
high molecular weight polypropylene or polyethylene) or it may contain one or two Johns
Manville (JM Clipper) lip shaft seals. There may be a grease fitting on this plate; the grease
is used to reduce leakage and to help prevent fibrous material from entering and damaging
the screw shaft.
Generally, seals are allowed to drip once they start leaking. They are replaced only in
conjunction with major maintenance, as when the screw is removed from the press.
In some cases we have found that leakage from a shaft seal can be stopped by simply
selectively loosening or tightening the four bolts holding the seal housing to the A plate.
A-Plate Seal Assemblies
Variable Frequency Drives (VFD's)
In this era of dropping costs, Vincent recommends the use of an inverter VFD to be used to
start, protect, and operate the screw press. With a VFD it is possible to establish the optimal
combination of screw speed and discharge cone air pressure. The VFD also can be used to
reverse the press in case of a jam or to slow it down or speed it up during upset conditions.
VFD's can be programmed to automatically stop and reverse the screw at set intervals. This
is a good feature when the material tends to blind the screen. Reversing the screw will wipe
the screen clear and liquid draining will return to normal. The auto-reverse function is also

20
useful for applications where long stringy material wraps itself around the screw. The
reversing action will knock free (untie) the stringy material.
Vincent is also more frequently using level controls, particularly in those applications where
the flow to the press can vary substantially. The level controls can be tied to the VFD or a
control system to speed up the press when it reaches a certain level or to gradually increase
screw speed or decrease back pressure to increase press throughput.
Vincent Cone Timer (VCT's)
For some applications a timer is used to periodically open the cone. There are two timer
settings on the cone timer. Timer 1 determines the interval between cone openings. Timer 2
determines how long the cone remains open. Both of these are set by trial and error,
manually opening and closing the cone using the three-position valve and then setting the
timers accordingly to make it automatic.
Cone timers are most frequently used when there is no level sensor. With abrasive materials,
low flow to a press maintained under compression will prematurely wear the screw and
screen at the discharge. As an example, we had a location where flow to the press would
stop for hours and the wood waste material would get completely dry, creating a "Presto
Log". When the flow started again, the presto log would freeze, blowing out the screens and
bending back screw flights.
Alternatively, the cone timer is used with slippery or slimy press cake that cannot be
dewatered to sufficient firmness to force the cone open.
Cone Timer panels are available from Vincent at no charge.
