Vinotemp VT-12TSP - 2Z User manual

A PROUD HERITAGE OF EXPERIENCE & QUALITY
12-Bottle Dual
-
Zone
Thermoelectric Mirrored
Wine Cooler
V
T-12TSP
-
2Z (12 bottle)
OWNER’S MANUAL
WWW.VINOTEMP.COM

Your Wine Cooler
This unit can be used for storage and/or service. The unit has a glass door
and soft interior light that you can leave on to elegantly display your wine.
Serving Wines
Storing wines at the proper temperature is important. To preserve them as
long as possible, wine should be stored at approximately 55° Fahrenheit.
However, the chart below suggests the optimal drinking temperature for the
different styles of wine.
°C °F Wine Style
19 66 Armagnac, Brandy, Cognac
18 64 Full Bodied Red wines, Shiraz
17 62 Tawny Port
15 59 Medium Bodied Red Wines
14 57 Amontillado Sherry
13 55 Light Bodied Red Wines
12 54 Full Bodied White Wines
11 52 Medium Bodied White Wines
10 50 Rosé, Light Bodied White Wines
9 48 Vintage Sparkling
8 46 Fino Sherry
7 45 Non Vintage Sparkling
2
WWW.VINOTEMP.COM

General Operating Instructions
Remove all packaging and labels from your wine cooler. Be sure that all
parts have been included before discarding any packaging materials. You
may want to keep the box and packing materials for use at a later date.
Upon receipt and inspection of unit, the supply cord must be replaced if it is
damaged. Contact our customer service at 1-800-777-8466 or
[email protected].
Please read and follow all safety rules
and operating instructions before using.
-Save these instructions-
To register your product, visit:
http://www.vinotemp.com/Warranty.aspx
Register your warranty within 10 days of receiving the unit.
Please be sure to retain your proof of purchase.
3
17621 South Susana Road, Rancho Dominguez, California 90221
[e-mail]

TABLE OF CONTENTS
IMPORTANTSAFETYINSTRUCTIONS........................................................................5
ELECTRICALCONNECTION........................................................................................6
CIRCUITDIAGRAM...................................................................................................6
COOLERDIAGRAM...................................................................................................7
TECHNICALDATA.....................................................................................................7
INSTALLATION..........................................................................................................8
OPERATINGYOURWINECOOLER............................................................................8
CAREANDMAINTENANCE.......................................................................................9
PROBLEMSWITHYOURWINECOOLER..................................................................10
TROUBLESHOOTINGGUIDE...................................................................................10
TERMSOFSALEANDWARRANTY..........................................................................11
SERVICE&IMPORTANTNOTICE.............................................................................12
4
WWW.VINOTEMP.COM

IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, electrical shock or injury when using your appliance, follow these basic
precautions:
•Ensure that the wine cooler stays in the upright position during transportation.
•Place the wine cooler on a strong, level surface.
•This wine cooler is designed for indoor, household use only. Any other use will void the warranty.
•Avoid placing the wine cooler in moist areas, near any heat source including direct sunlight, or near
any hazardous or flammable material.
•This unit must be freestanding and cannot be used as a built-in cooler.
•This cooler is designed to store wine bottles and should not be used to store food or other items.
•An empty cooler can be a dangerous attraction to children. If disposing of the cooler, remove gaskets,
latches, lids or the entire door from your unused appliance, or take other action to ensure the cooler is
harmless. Leave shelves in so that children may not easily climb inside.
•Do not place any other objects on top of the wine cooler.
•Never lift or carry the wine cooler by the cord.
•Use of an extension cord for the wine cooler is not recommended. Directly connect the wine cooler to
an electrical outlet.
•This wine cooler is an electrical appliance. To avoid injury or death from electrical shock, do not
operate the wine cooler with wet hands, while standing on a wet surface or while standing in water.
•To avoid injury or death from electrical shock, do not operate the wine cooler with wet hands, while
standing on a wet surface or while standing in water.
•To ensure proper internal air circulation, do not overfill the wine cooler.
•Never clean appliance parts with flammable fluids. The fumes can create a fire hazard or explosion.
5
17621 South Susana Road, Rancho Dominguez, California 90221
[e-mail]

ELECTRICAL CONNECTION
Improper use of the grounded plug can result in the risk of electrical shock.
If the power cord is damaged, frayed or shows cracks or abrasions across
its length, have it replaced at an authorized service center.
For your protection, this unit is equipped with a 3-conductor cord set that has a molded 3-prong
grounding-type plug, and should be used in combination with a properly connected grounding-type outlet.
•Do not under any circumstances cut or remove the third ground prong from the power cord
supplied. For personal safety, this appliance must be properly grounded.
•The cord should be secured behind the unit and not left exposed or dangling to prevent
accidental injury.
•When a standard 2-pin wall outlet is encountered, it is your responsibility to have it replaced with
a properly grounded 3-pin wall outlet.
•Never unplug the unit by pulling the power cord. To disconnect the
appliance, always grip the plug firmly and pull straight out from the
wall outlet. When moving the unit, be careful not to damage the
power cord.
•The unit should always be plugged into its own individual electrical
outlet with a voltage rating that matches the rating label on the unit.
•Do not pinch or kink the power supply cord.
•Repair or replace all power cords that have become frayed or
damaged. Do not use a cord that shows cracks or abrasion
damage along its length or at either end. When moving the
appliance, be careful not to damage the power cord.
Extension Cord
CAUTION: It is strongly recommended that you do not use an adapter
or an extension cord with this unit.
CIRCUIT DIAGRAM
6
WWW.VINOTEMP.COM

COOLER DIAGRAM
1. Plastic Cover
2. Stainless Steel Handle
3. Control Panel
4. Wire Shelf with Wood Trim
5. Leveling Leg
6. Hinge Cover
7. LED Light
8. Fan Mask
9. LED Light
10. Fan Mask
TECHNICAL DATA
Model No. VT-12TSP-2Z
Capacity 12 Bottles
Volume 34 liters
Voltage AC 110V
Frequency 60 HZ
Input Power 130W
Power Consumption (kWh/24h) 1.5
Temperature Range 45°-65°F
Net Weight / Gross Weight 32 Lbs / 36.3 Lbs
Unit Size (W×H×D) 13.58” x 21.26” x 19.29”
Packing Size (W×H×D) 15.16” x 22.05” x 20.67”
*Note: This wine cooler is designed to store standard Bordeaux 750 ml bottles. Storing large and/or oddly shaped bottles (including
champagne and sparkling wine bottles) will decrease the capacity of your wine cooler.
17621 South Susana Road, Rancho Dominguez, California 90221
[e-mail]
7

INSTALLATION
•Remove all packing material before using your cooler. Check to be sure all parts are included and
that the cooler is in good condition.
•Clean the interior surface with lukewarm water using a soft cloth before first use.
•Position the cooler in a dry and airy place. The recommended ambient temperature should be
between 50° and 80°F.
•Place your cooler on a solid, level surface (other than carpet). This will ensure vibration and noise-
free operation.
•When positioning the cooler, 6 inches of space at the back and 10-12 inches of space both sides are
suggested to ensure proper air circulation to cool the cooling system. There also must be unlimited
clearance at the top of the cooler to ensure proper air circulation.
•Upon plugging the cooler into an electrical outlet, let the unit run for at least 30 minutes before making
any adjustments.
•This wine cooler uses thermoelectric refrigeration technology (no compressor) and is not designed for
storage in hot areas like garages, warehouses or outdoors since it is designed to operate at a
maximum of 30 degrees below the ambient temperature.
•The unit is designed for freestanding installation only. It is not designed to be installed under a
counter, inside a cabinet, or in any location that does not allow the proper clearances on all sides, as
stated above.
OPERATING YOUR WINE COOLER
The wine cooler has an electric temperature control panel and two temperature zones. When first turned
on, the LCD will show the ambient temperature, followed by the internal cabinet temperature.
The upper zone temperature can be set between 45° and 65°F. The lower zone can be set between 45°
and 65°F. Pressing the “UP” button on the control panel will increase the temperature by 1°F and
pressing the “DOWN” button will lower it. Upon choosing your desired temperature, the display will flash
the selected temperature setting for 5 seconds before reflecting the current internal cabinet temperature.
The “LIGHT” button turns the interior light on or off. The C/F button alternates the temperature reading
between Celsius and Fahrenheit.
8
WWW.VINOTEMP.COM

9
17621 South Susana Road, Rancho Dominguez, California 90221
[e-mail]
CARE AND MAINTENANCE
Cleaning your Wine Cooler:
•Unplug the wine cooler and remove the bottles and shelves.
•Wash the inside with warm water or a baking soda solution. The solution should be about 2
tablespoons of baking soda to a quart of water.
•The outside of the wine cooler should be cleaned with mild detergent and warm water. Clean the
back and bottom of the wine cooler thoroughly to ensure efficient operation.
•Wipe dry with a soft cloth. Dry all surfaces before use.
Moving your Wine Cooler:
•Remove all the bottles.
•Securely tape down all loose items inside your wine cooler.
•Turn the leveling legs up to the base to avoid damage.
•Tape the door shut.
•Be sure the wine cooler stays in the upright position during transportation.

10
WWW.VINOTEMP.COM
PROBLEMS WITH YOUR WINE COOLER
You can solve many common wine cooler problems easily, saving you the cost of a possible service call.
Try the suggestions below to see if you can solve the problem before contacting Vinotemp at
[email protected].
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE
Wine cooler does not
operate •Check if unit is plugged in.
•Check voltage level.
•Check for broken fuse.
Wine cooler is not cold
enough •Check the temperature control setting.
•Ensure the wine cooler is away from heat sources and direct
sunlight.
•The wine cooler does not have the correct clearance on all sides of
the wine cooler.
•Ensure door is properly closed and fans are operating correctly.
Light does not work •Call the service center.
Wine cooler makes too
much noise •The wine cooler is not level.
•Check the fans inside the cooler and at the back of the unit.
•Check for proper ventilation and clearance.
Internal light is flashing •Check that selected temperature is not higher than internal cabinet
temperature.
•Automatic defrost function has started. This is a normal function.
Wine cooler has started to
frost •Excess humidity or very low temperatures may cause frost to build.
Unplug the cooler and allow it to defrost or defrost by hand.
Door will not close properly •The wine cooler is not level.
•The doors were not properly installed.
•The seal is weak.
•The shelves are out of position.
Temperature LCD display is
blank •Main control board does not work.
•The Power Control Board is not functioning.
•There is some problem with the plug (no power supply).
Temperature LCD display
error •Temperature sensor is cut off.
•Display suffered too much wear and tear.
Buttons are not functional •Temperature control panel is damaged.
