Vintage Electric TRACKER S User manual

Let us help get you started.
Welcome to your
TRACKER S

TRACKER S
Old soul, new school.

CONTROLS
Display
Power Modes
Front Brake
vintageelectricbikes.com
On / Off

Rear Brake
Throttle
vintageelectricbikes.com

DISPLAY
vintageelectricbikes.com
Light Indicator
Power Level
Speed
Battery Indicator
Power Level Up
HOLD -Turn Lights On
Power Level Down
HOLD- Walk Mode
On / Off
On-Tap Once
Off-Hold Three Seconds

POWER LEVELS
AND RANGE
vintageelectricbikes.com
Street
Mode
Race
Mode Street
Mode
Race
Mode Street
Mode
Race
Mode Street Mode
Race
Mode
Street
Mode
Race
Mode
Mile Range Mile Range Mile Range Mile Range Mile Range
75
60
60
40
50
30
45
25
40
20

QUICK TIPS
vintageelectricbikes.com
Charging
•Never charge your bike below 35 ºF or above 115 ºF
•Fully charge your battery monthly
Riding
•Never ride your bike below 5 ºF or above 120 ºF
•Check tire pressure before riding
•Avoid salted roads or salt water
Storage
•Never store your bike below 15 ºF or above 110 ºF
for longer than one month
•Store your bike in a protected environment
•If storing for multiple months place cardboard
between your tires and concrete ooring

MAINTAIN YOUR RIDE
vintageelectricbikes.com
Store your bike out
of the elements when
possible
Have a qualied
mechanic inspect
your brakes every 3-6
months
Have all service work
done by your local
bike shop
Keep tires inated
between 30-40 psi
Lube chain once a
month with bicycle
chain lube only
Charge battery at least
once a month

REAR WHEEL REMOVAL
vintageelectricbikes.com
Tools Needed
10mm
22mm
5mm
Step 1 Step 2 Step 3
•Disconnect the motor wire
connectors
•Remove axle nuts
•Remove the disc brake
caliper using a 5mm hex key
•Remove chain tensioners
using a 10mm wrench
•Slide the rear wheel out

FRONT WHEEL REMOVAL
vintageelectricbikes.com
Step 1 Step 2 Step 3
•Loosen and remove
axle retaining bolt
using a 5mm hex key
•Loosen all 4 pinch
bolts using a 4mm
hex key
•Remove axle
completely from hub
and dropouts
•Slide wheel out
5mm 4mmTools needed
