Vision V18-310 User manual

V18-310
TV/SATELLITE
DCPowerTester

1
Contents
Introduction ............................................................................... Page 2
Test the 12V supply to a masthead amplier ............................ Page 5
Test the LNB input of a satellite receiver .................................. Page 7
Test the LNB input of IRS ......................................................... Page 9
Test the PSU and load on IRS installation ................................ Page 11
Test the voltage and current on large IRS ................................ Page 13

2
VISIONTV/SATPowerTester-V18-310
Instructions
• This innovative tester will assist professional installers of
domestic TV and satellite systems, commercial and
communalIRS,CATVandMATV.
• It will accurately simultaneously measure the DC voltage
(30vMax)andDCcurrent(10Amax)passingthrougha75
ohmcoaxialcable.Itwillalsosimultaneouslyindicateifa
22kHz signal is present on the coax cable in satellite
systems connected to: legacy satellite receivers SKY+,
Sky+HD,SkyQ,Freesat,FreesatHD,dSCR,SCRandDiSEq
installationsetc.
• IMPORTANT:TheV18-310TV/SATPowerTesterrequires
a PP3 (6LR61, MN1604) 9V battery and the press to test
button operated to make accurate current
measurements, but for convenience it will indicate an
approximatecurrentvaluewhenlinepoweredand/orthe
presstotestbuttonisnotoperated.
• TheV18-310TV/SATPowerTesterwillpassRFfrequencies
with minimal attenuation so that voltage and current
measurements can be made while operating TV and
satelliteequipment.
Introduction

ReadallinstructionsinthisUserManualandonthe
productcarefullyBEFOREoperatingthisdevice.
• The latest version of this handbook can be found at
www.vision-products.co.uk
• Many Vision products are intended for indoor use only.
Under no circumstances must these products be used
outdoorsunlessexplicitlystatedotherwise.
• Clean the exterior of the product with a clean and dry,
non-abrasivecloth.Donotusesolventsorliquidstoclean
theproduct.
• There are no user replacement parts inside the product.
Do not open the product for any reason. This will
invalidate your Manufacturer Warranty and may impair
thesafetyfeaturesoftheproduct.
• Do not use the product if you suspect it has been
damaged in any way, including being dropped, is
malfunctioning or has been exposed to liquids or
moisture.
• Theunitmustberepairedbyanauthorisedservicecentre
only.
• Manufacturer Warranty is void if unit is opened or
adaptedinanyway.
• Iftheproductappearstobemalfunctioningoroperating
inanunexpectedmanner,stopusingtheunitimmediately
andcontactyoursupplier.
• Neverlift,moveorcarrytheproductbyanyothermeans
otherthanthecaseasawholeorhandleifprovided.
ThisproductcomplieswiththerelevantclausesoftheEuropean
Directive2002/96/EC.Theunitmustberecycledordiscarded
accordingtoapplicablelocalandnationalregulations.
Equipmentintendedforindooruseonly.VisionProducts(Europe)
Ltdconfirmsthatthisproductisinaccordancetofollowingnorms
ofEUEMCnormEN50083-2andsafetynormEN60065.
3
Please note this product may be improved or updated without notice. Please refer to your
supplier before purchasing. Examples shown and the possible faults indicated in those
examples are suggestions only. It is the operator’s sole responsibility to ensure the correct
conclusions are drawn from any tests or test results.
Coax cables, electronic products and connectors etc. may not be able to sustain the maximum
operating parameters of this tester and great care must be taken to ensure the specications
and limitations of peripheral items are not exceeded. E&OE.

ReadallinstructionsinthisUserManualandonthe
productcarefullyBEFOREoperatingthisdevice.
• The latest version of this handbook can be found at
www.vision-products.co.uk
• Many Vision products are intended for indoor use only.
Under no circumstances must these products be used
outdoorsunlessexplicitlystatedotherwise.
• Clean the exterior of the product with a clean and dry,
non-abrasivecloth.Donotusesolventsorliquidstoclean
theproduct.
• There are no user replacement parts inside the product.
Do not open the product for any reason. This will
invalidate your Manufacturer Warranty and may impair
thesafetyfeaturesoftheproduct.
• Do not use the product if you suspect it has been
damaged in any way, including being dropped, is
malfunctioning or has been exposed to liquids or
moisture.
• Theunitmustberepairedbyanauthorisedservicecentre
only.
• Manufacturer Warranty is void if unit is opened or
adaptedinanyway.
• Ifthe product appears tobe malfunctioning or operating
inanunexpectedmanner,stopusingtheunitimmediately
andcontactyoursupplier.
• Neverlift,moveorcarrytheproductbyanyothermeans
otherthanthecaseasawholeorhandleifprovided.
ThisproductcomplieswiththerelevantclausesoftheEuropean
Directive2002/96/EC.Theunitmustberecycledordiscarded
accordingtoapplicablelocalandnationalregulations.
Equipmentintendedforindooruseonly.VisionProducts(Europe)
Ltdconfirmsthatthisproductisinaccordancetofollowingnorms
ofEUEMCnormEN50083-2andsafetynormEN60065.
4

5
EXAMPLE1:
Totestthe12VsupplytoaTVmastheadamplifier.
1. Disconnectthemastheadamplifierfromthepower
supply.
2. ConnecttheTV/SATPowerTestertothepowersupply
(source).
3. Checkthevoltageiscorrect
4. Ifthevoltageiscorrect,connectthemastheadamplifierto
theTV/SATPowerTester(Load).
5. Presstheredtestbutton.Checkthevoltageandcurrent
display
6. Ifthevoltagedisplayedisnowlowerthanat{step4.}or
thecurrentishigherthanthemastheadamplifierratings
label,thereisafaultintheinstallation.
7. Thefaultismostlikelyfoundataconnection,suchasa
whiskerofcoaxialcablebraidshortingacrossthecentre
conductor.ThefaultcouldalsobeafaultyPSUor
mastheadamplifier.

6
EXAMPLE1:
Totestthe12VsupplytoaTVmastheadamplifier.
1. Disconnectthemastheadamplifierfromthepower
supply.
2. ConnecttheTV/SATPowerTestertothepowersupply
(source).
3. Checkthevoltageiscorrect
4. Ifthevoltageiscorrect,connectthemastheadamplifierto
theTV/SATPowerTester(Load).
5. Presstheredtestbutton.Checkthevoltageandcurrent
display
6. Ifthevoltagedisplayedisnowlowerthanat{step4.}or
thecurrentishigherthanthemastheadamplifierratings
label,thereisafaultintheinstallation.
7. Thefaultismostlikelyfoundataconnection,suchasa
whiskerofcoaxialcablebraidshortingacrossthecentre
conductor.ThefaultcouldalsobeafaultyPSUor
mastheadamplifier.

7
EXAMPLE2:
TotesttheLNBinputofasatellitereceiver
1. DisconnectthesatellitereceiverfromthewallsocketorLNB
feedcable.ConnecttheTV/SATPowerTesterDCIN(Source)to
thesatellitereceiverinput1orinput2.
2. Checkthevoltageiseither18Vforhorizontalor13Vforvertical
polarity.IfusingaSkyQreceivercheckthereis12Vfromeither
input.
3. Ifthevoltageiscorrect,connecttheTV/SATPowerTesterDC
OUT(Load)tothewallsocketorLNB.Presstheredtestbutton.
Checkthevoltageandcurrentdisplay.
4. Ifthevoltagedisplayedisnowlowerthanat{step3.}orthe
currentishigherthantheequipmentratingslabel,thereisa
faultintheinstallation.Checkthe22KHzLEDisilluminatedifa
high-bandsignalisselected.
5. Anyfaultismostlikelyfoundataconnectionpoint,suchasa
whiskerofcoaxialcablebraidshortingacrossthecentre
conductorinthewallsocketorataconnector.Thefaultcould
alsobeafaultyLNBorlineamplifier.
Note:SkyHDreceivershave2inputs.Eachcanindependentlysupply
13Vor18VDCuptoacombinedmaximumof275mA.
Note:SkyQreceivershave2inputs.Eachinputcansupplyonly12VDC
uptoacombinedmaximumupto275mA.

8
EXAMPLE2:
TotesttheLNBinputofasatellitereceiver
1. DisconnectthesatellitereceiverfromthewallsocketorLNB
feedcable.ConnecttheTV/SATPowerTesterDCIN(Source)to
thesatellitereceiverinput1orinput2.
2. Checkthevoltageiseither18Vforhorizontalor13Vforvertical
polarity.IfusingaSkyQreceivercheckthereis12Vfromeither
input.
3. Ifthevoltageiscorrect,connecttheTV/SATPowerTesterDC
OUT(Load)tothewallsocketorLNB.Presstheredtestbutton.
Checkthevoltageandcurrentdisplay.
4. Ifthevoltagedisplayedisnowlowerthanat{step3.}orthe
currentishigherthantheequipmentratingslabel,thereisa
faultintheinstallation.Checkthe22KHzLEDisilluminatedifa
high-bandsignalisselected.
5. Anyfaultismostlikelyfoundataconnectionpoint,suchasa
whiskerofcoaxialcablebraidshortingacrossthecentre
conductorinthewallsocketorataconnector.Thefaultcould
alsobeafaultyLNBorlineamplifier.
Note:SkyHDreceivershave2inputs.Eachcanindependentlysupply
13Vor18VDCuptoacombinedmaximumof275mA.
Note:SkyQreceivershave2inputs.Eachinputcansupplyonly12VDC
uptoacombinedmaximumupto275mA.

9
EXAMPLE3:
TotesttheLNBinputofanIRSinstallationwhen
poweredbyanEV5-100Tlaunchamplifierorsimilar
1. Werecommendthistestisaccomplishedwiththeoutputofthe
amplifierdisconnectedfromthesystemnetwork.Disconnect
thefourLNBfeedsfromthedish.
2. ConnecttheTV/SATPowerTesterDCIN(Source)tothe
amplifierinputmarkedH:Lo(green).Checkthevoltagedisplay
isshowing18V.
3. Ifthevoltageiscorrect,connecttheTV/SATPowerTesterDC
OUT(Load)totheLNBfeedmarkedH:Lo(greencable).
4. Presstheredtestbutton.Checkthevoltageandcurrentdisplay
5. Ifthevoltagedisplayedisnowlowerthanatpointc)orthe
currentishigherthantheratingslabeloftheLNB,thereisa
faultintheinstallation.
6. Thefaultismostlikelyfoundataconnectionpoint,suchasa
whiskerofcoaxialcablebraidshortingacrossthecentre
conductorataconnector.ThefaultcouldalsobeafaultyLNB.
7. Ifthevoltagedropsbelow18VwhentheLNBisconnecteditis
alsopossiblethatthepowersupplyhasfailedasitisunableto
deliverenoughpower.

10
EXAMPLE3:
TotesttheLNBinputofanIRSinstallationwhen
poweredbyanEV5-100Tlaunchamplifierorsimilar
1. Werecommendthistestisaccomplishedwiththeoutputofthe
amplifierdisconnectedfromthesystemnetwork.Disconnect
thefourLNBfeedsfromthedish.
2. ConnecttheTV/SATPowerTesterDCIN(Source)tothe
amplifierinputmarkedH:Lo(green).Checkthevoltagedisplay
isshowing18V.
3. Ifthevoltageiscorrect,connecttheTV/SATPowerTesterDC
OUT(Load)totheLNBfeedmarkedH:Lo(greencable).
4. Presstheredtestbutton.Checkthevoltageandcurrentdisplay
5. Ifthevoltagedisplayedisnowlowerthanatpointc)orthe
currentishigherthantheratingslabeloftheLNB,thereisa
faultintheinstallation.
6. Thefaultismostlikelyfoundataconnectionpoint,suchasa
whiskerofcoaxialcablebraidshortingacrossthecentre
conductorataconnector.ThefaultcouldalsobeafaultyLNB.
7. Ifthevoltagedropsbelow18VwhentheLNBisconnecteditis
alsopossiblethatthepowersupplyhasfailedasitisunableto
deliverenoughpower.

11
EXAMPLE4:
TotestthepowersupplyandloadonanI
RS
installation
1. DisconnecttheEV5-034powersupplyfromtheDCauxiliary
inputoftheEV5multiswitch.
2. ConnectthepowersupplytotheDCinput(source)onthe
meter.
3. Checkthevoltagereads18V.
4. ConnecttheTV/SATPowerMeterDCout(load)totheAuxiliary
DCinputofthemultiswitch.
5. Pressandholdthered“test”button.
6. Checkthevoltageremainsat18Vwhenunderload.
7. Addthecurrentratingforeachdeviceonthesystemincluding
allmultiswitches,theLNBandanyamplifier.
8. Checkthecurrentdisplayedmatchesthetotalsystemload
9. Ifthevoltageunderloadisbelow18Vcheckthepowersupplyis
notfaulty.
10. Ifthecurrentdisplayedissignificantlyhigherthanthe
calculatedcurrent,checkforfaultyconnections(whiskersof
braid)andalsoforfaultyequipment.Useaprocessof
illuminationtocheckforfaultyequipment.

12
EXAMPLE4:
TotestthepowersupplyandloadonanIRS
installation
1. DisconnecttheEV5-034powersupplyfromtheDCauxiliary
inputoftheEV5multiswitch.
2. ConnectthepowersupplytotheDCinput(source)onthe
meter.
3. Checkthevoltagereads18V.
4. ConnecttheTV/SATPowerMeterDCout(load)totheAuxiliary
DCinputofthemultiswitch.
5. Pressandholdthered“test”button.
6. Checkthevoltageremainsat18Vwhenunderload.
7. Addthecurrentratingforeachdeviceonthesystemincluding
allmultiswitches,theLNBandanyamplifier.
8. Checkthecurrentdisplayedmatchesthetotalsystemload
9. Ifthevoltageunderloadisbelow18Vcheckthepowersupplyis
notfaulty.
10. Ifthecurrentdisplayedissignificantlyhigherthanthe
calculatedcurrent,checkforfaultyconnections(whiskersof
braid)andalsoforfaultyequipment.Useaprocessof
illuminationtocheckforfaultyequipment.

13
EXAMPLE5:
TotestthevoltageandcurrentinalargerIRS
installation
1. Disconnectall5cablesofthetrunkfromtheamplifier/power
source.
2. Connectthe18VfromH:LooftheEV5-100TtotheDCIn
(source)connectoroftheTV/SATPowerMeter.
3. Checkthedisplayreads18V.
4. Ifthedisplayislessthan18V,check/replacethepowersupply.
5. ConnecttheDCOUTconnectoroftheTV/SATPowerMeterto
theH:Loterminalofthenextpieceofequipmentinthetrunk
networktopowerthesystem.
6. Pressandholdtheredtestbutton.
7. Readthecurrentconsumptionofthesystem.Doesthereading
matchtheratingsplatecalculationforthesystem?
8. Ifthecurrentreadingishigherorlowerthanexpected,check
theconnectionsforawhiskerofbraidataconnectorthen
checkeachpieceofequipmentbysubstitution.
9. Breakthesystemintosectionsbydisconnectingthetruck
cablesatconvenientpoints.Thencomparethecurrent
consumptiononeachsection.

EXAMPLE5:
TotestthevoltageandcurrentinalargerIRS
installation
1. Disconnectall5cablesofthetrunkfromtheamplifier/power
source.
2. Connectthe18VfromH:LooftheEV5-100TtotheDCIn
(source)connectoroftheTV/SATPowerMeter.
3. Checkthedisplayreads18V.
4. Ifthedisplayislessthan18V,check/replacethepowersupply.
5. ConnecttheDCOUTconnectoroftheTV/SATPowerMeterto
theH:Loterminalofthenextpieceofequipmentinthetrunk
networktopowerthesystem.
6. Pressandholdtheredtestbutton.
7. Readthecurrentconsumptionofthesystem.Doesthereading
matchtheratingsplatecalculationforthesystem?
8. Ifthecurrentreadingishigherorlowerthanexpected,check
theconnectionsforawhiskerofbraidataconnectorthen
checkeachpieceofequipmentbysubstitution.
9. Breakthesystemintosectionsbydisconnectingthetruck
cablesatconvenientpoints.Thencomparethecurrent
consumptiononeachsection.
14

©2017VisionProducts(Europe)LtdRedbournePark,Brackmills,NorthamptonNN47DT.
www.vision-products.co.uktechnical@vision-products.co.uk01604664758
V18-310
TV/SATPowerTester
