Platinum Tools LANSeeker TP500C User manual

LANSeeker™Cable Tester
P/N TP500C
• Displays data cable test results on main
and remote units in less than 2 seconds
• Auto-on initiates test when a connection
is sensed between main and remote unit
9V Battery
Included
BACKER CARD
Product Part Number: TP500
Card P/N : BAKTP500-BC
Clamshell Part Number: ??
Card Size: 118.12778 x 206.12608 mm
(4.6507” x 8.1152”)
Corner Radius: R. 25” (x4)
Warranty: One Year
Cross sell: PNs EZ-RJ45 Connectors,
EZ-SnapJack, PoE Detector, RJ45
PortSaver
Instructions Inside
P/N TP500C
P/N
TP500C
visit
platinumtools.com
to see all of
our products
EZ-RJ45
®
CONNECTORS
RJ45
PORTSAVER
PoE DETECTOR
EZ-SNAPJACK
™
Platinum Tools
We Make
Connections EZ!
North Carolina,USA .platinumtools.comMade in U.S.A.
One Year Limited Warranty
Platinum Tools warrants this product to be free from defectsin
material and workmanship for one year from the date of purchase.
Liability is limitedto the repair and or replacement of the product.
Warranty excludesbatteries included with the product. NOIMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. Platinum Tools isnot liable for consequential damages.
P/N TP500C
®
The LANSeeker™is aneasy-to-use professional grade data
cable tester andtone generator. It automatically displays cable
test results usingLED indicator lights on the main and the
self-storedremote unit.
When the unit senses a connection between the mainand the
remote unit,the battery-saving auto-onfeature initiatestest
results within2 seconds. The tester automatically powers off
within 5 seconds of the cable being disconnected.
Features:
• Displays cable test results on main and the remote
unit in lessthan 2seconds
split pairs
• Auto-on initiatestest when a connection is sensed
between main and remote unit
• Debug mode diagnoses faults one pair at a time
• Built-in tone generator
• Auto-off to preserve battery power
(9-volt Alkaline battery included)
Applications:
• Installation and maintenance of twisted-pair
cabling for IPvoice, data and IPvideo
• Troubleshoot failing cables
• Generates tonefor tracing wires
LANSeeker™Cable Tester
WARNING: Cancer andreproductive harm – See
www.P65Warning.ca.gov for more information.
118.12778 mm
206.12608 mm

BACKER CARD LAYOUT- INSIDE FOLD
Product Part Number: TP500
Card P/N : BAKTP500-BC
Clamshell Part Number: ??
Card Size: 118.12778 x 206.12608 mm
(4.6507” x 8.1152”)
Corner Radius: R. 25” (x4)
Warranty: One Year
Cross sell: PNs EZ-RJ45 Connectors,
EZ-SnapJack, EZ-Datalock, EZ-RJ45 Port
Saver
EXAMPLES OF WIRING ERRORS ETHERNET UP-LINK CABLE EXAMPLE
1-2 and 3-6 swapped
Pair connected from
1-2 to 3-6 (miswire)
Pair connected from
3-6 to 1-2 (miswire)
Pair connected from
4-5 to 4-5 (good)
Pair connected from
7-8 to 7-8 (good)
Not for use with RJ11 connectors. Use of the RJ11 plugs will
damage the jack on the LanSeeker Tester.
DO NOT plug energized network cables into LANSeeker Tester.
Energized network cables will damage the LANSeeker Tester.
WARNING: Cancer and reproductive harm. See
www.P65Warning.ca.gov for more information.
WARNINGS:
118.12778 mm
206.12608 mm
