Vision V2/100/A Assembly Instructions

Model Number: V2/100/A (remote control)
DECORATIVE ELECTRIC FIRE
INSTALLATION & USER INSTRUCTIONS
IMPORTANT INFORMATION INSIDE. PLEASE READ BEFORE USE
These instructions must be left with the appliance for
future reference and maintenance information.
V2/100 Rev.1 (Feb 2012) VISION FIRES
GB IE
VISION FIRES
IMPERIAL POINT, EXPRESS TRADING ESTATE, STONEHILL ROAD,
FARNWORTH, BOLTON. BL4 9TN.

IMPORTANT INFORMATION
TECHNICAL SPECIFICATIONS
MODEL: V2/100/A VOLTAGE: 220-240 FREQUENCY: 50Hz
POWER: 2000W LAMP: 1 X MAX. 3W
DIMENSIONS: OVERALL INSERT
WIDTH 482 407
HEIGHT 600 560
DEPTH 117 74
FIREPLACE OPENING SIZE: MINIMUM MAXIMUM
WIDTH 415 430
HEIGHT 570 590
DEPTH 75 N/A
GENERAL NOTES
 Before installation, fully read these instructions and follow all directions.
 Do not place the appliance directly underneath a fixed socket outlet.
 The electrical socket used must always be accessible so that disconnection is possible when
performing maintenance or cleaning tasks.
 When performing maintenance tasks or cleaning, always disconnect the appliance from the mains
supply.
 Always make sure that the appliance is secured firmly in order to avoid tipping.
 Always use a fireguard if the appliance will be used around young children, elderly or infirm
persons.
 The appliance should not be operated by children or persons with reduced physical, sensory or
mental capabilities, unless they have been given supervision or instruction concerning the correct use
by a person responsible for their safety.
 Never obstruct or cover the air inlet or heat outlet vents as this will cause the appliance to overheat.
 Never use this appliance in or near a swimming pool, a bath or a shower.
 Never use this appliance with a timer or any other device that automatically switches it on.
 Wait until the heater is completely cooled before storing.
 If the power chord is damaged it must be repaired by the manufacturer or a qualified person.
 Do not place the appliance directly onto a carpeted area. The heat may cause discolouration.
 Do not use aerosols or steam cleaners near the appliance.
 Do not install the appliance close to curtains or other combustible materials.
 Never use the appliance to dry clothes.
2

INSTALLATION
STEP 1
Determine the type of decorative frame or fascia
that will be fitted to the appliance. If it’s a
separate steel, 3 sided trim and cast iron fret,
move directly to step 2. If it’s a one piece cast
iron frame (with removable ash pan cover), then
the appliance canopy will need to be removed.
To do this remove the four screws indicated in
Fig. 1 and gently lift the canopy away from the
appliance. This component is no longer required.
STEP 2
Carefully lift the appliance into the opening/
fireplace, ensuring that the power cable reaches
a suitably positioned electrical outlet.
To secure the appliance mark through the four
holes located on the outer appliance flanges
(see Fig. 2). Carefully remove the appliance
and, using a suitable bit, drill and plug the
marked areas. Refit and secure the appliance
with four appropriate screws.
STEP 3
Fit the decorative frame or fascia.
3 sided trim and cast iron fret - fit the trim to the
fire using the magnets provided, then place the
cast iron fret in front of the ‘fuel bed’.
1 piece cast iron frame - before fitting, bend
down the two ‘hooks’ at the top of the appliance.
Hook the frame onto these hooks and secure by
screwing into the bottom of the appliance using
the two short screws and 2 washers provided (see
Fig. 3).
Complete installation by arranging the pebbles
or coals on the top of the fuel bed,
3
Fig. 1
Fig. 2
Fig. 3

OPERATING INSTRUCTIONS
The appliance can be operated manually using the rocker switch to the left of the heat outlet, or by remote
control. To operate, first press the left master switch (located to the left of the heater under the canopy) to the
‘I’ position then perform the following actions:
FLAME EFFECT ONLY (NO HEAT)
Manual -Press the rocker switch on the appliance once.
Remote - Press the button marked ‘ON/OFF’, followed by the button marked ‘EFFECT’ on the handset.
FLAME EFFECT WITH 1KW OF HEAT
Manual -Press the rocker switch on the appliance twice.
Remote - First press the button marked ‘EFFECT’ (this must always be pressed first in order to activate heat
settings). Then press the button marked ‘HEAT 1’. (You can change to 2kW at this stage by pressing the
button marked ‘HEAT 2’)
FLAME EFFECT WITH 2KW OF HEAT
Manual -Press the rocker switch on the appliance three times.
Remote - First press the button marked ‘EFFECT’. Then press the button marked ‘HEAT 2’.
STANDY MODE - NO HEAT OR FLAME EFFECT
Manual -Press the rocker switch on the appliance four times.
Remote - Press the button marked ‘ON/OFF’
To turn the fire off completely, press the left master switch to the ‘O’ position.
NOTE: The remote control handset uses 2x AAA batteries. Make sure the batteries are installed correctly.
Do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-
cadmium) batteries.
AUTOMATIC CUT-OFF
If the appliance overheats it will automatically switch itself off as a precautionary measure. To reset the cut-
off switch you must turn off or disconnect the fire from the mains supply and leave to cool for approximately
20 minutes.
BULB REPLACEMENT
Always switch off the appliance and disconnect from the mains before replacing the bulb.
Replacement bulb specification: G45 Globe LED, 3W, E27, Warm White, 220-240V, 50-60Hz
To replace the bulb, first remove the decorative frame/fascia and remove all of the pebbles or coals from the
top of the fuel bed. Next remove the two screws that secure the fuel bed to the appliance and carefully lift
the fuel bed away. Unscrew the expired bulb whilst taking care not to displace any of the flame ribbons
and replace with a new one. Re-fit the fuel bed and secure with the two screws removed earlier. Replace
the pebbles/coals and re-fit the frame/fascia.
CLEANING
Always switch off the appliance and disconnect from the mains before cleaning.
Clean the outside of the appliance with a dry soft cloth. Do not use furniture polish or abrasive materials.
4
