Vision E-line solus VS220 User manual

INSTALLER INSTRUCTION MANUAL AND USER GUIDE
FOR ELECTRIC FIRE MODELS:
VS75 - VS100
-
VS130
-
VS150 - VS180 - VS220
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION
AND OPERATION. KEEP THEM IN A SAFE PLACE FOR FUTURE REFERENCE.
PREMIUM ELECTRIC FIRES
REV E 01/23

2
This appliance can be used with an LED mood lighting kit approved by Vision Fires
–The Solus Ambient Light Kit (available from your retailer). Other, non-approved
LED light kits must not be used as they may damage the appliance and invalidate
the warranty. The Solus Ambient Light Kit must only be used when connected
directly to the appliance using the pre- fitted connecting adaptor (this can be found
at the bottom right-hand corner of the appliance by the mains plug, see Fig. 1a).
The Solus Ambient Light Kit must not be adapted to be operated independently of
the appliance, such as modifying it to run on an independent 240v supply.
The Solus Ambient Light Kit is supplied as a 3m LED strip with adhesive tape
backing, a 2m extension cable (not illuminated) and a 2-way splitter which may be
used to attach two separate kits to the same appliance, allowing each kit to be
routed to different directions/locations.
The length of an individual kit may be extended by joining another kit using LED strip connectors (not supplied), but
only to a maximum of the appliance loadings, see table below for details.
APPLIANCE
VS75
VS100
VS130
VS150
VS180
MAX. LENGTH OF
LED STRIP ALLOWED
9 METRES
6 METRES
3 METRES
3 METRES
4.5 METRES
IMPORTANT: When fitting a Solus Ambient Light Kit into a Solus appliance that is built into a sealed fireplace (such
as a media wall), the kit must be fitted to the appliance during the initial build stage. The Solus Ambient Light Kit is
not a retrofit option as the connecting adapter on the appliance is often not accessible after installation in these
installation types.
Typically in such installations, the kit will be connected when the appliance is placed onto the wooden purpose built
base. The appliance should then be fixed to the wall or framework at that point, ready for the remainder of the
installation to be constructed around it to form the completed design. The LED strip can then be routed to its
designated area, with care not to damage the strip or cable during the process. Damage can occur if the strip or cable
is stretched or snagged on part of the structure/installation. If the cable is damaged at the point of the appliance, it
may need to be replaced completed and this would not fall within the scope of the warranty. It is best practice to test
that the Solus Ambient Light Kit is working correctly before the final boarding has been fitted to the installation. Once
you are satisfied that the lighting is correctly working in accordance with the controls on the remote control, the final
boarding or enclosure can take place and the installation can be finished.
When finishing the installation with a plaster, it is important to protect the appliance and ambient light kit from any
water or plaster that can be spilled during that process. Plaster can be difficult to remove when dried and can damage
the cable. Water must not be able to penetrate the cable or the appliance at any point during the installation build.
IMPORTANT INFORMATION –AMBIENT LIGHT KIT
6
FIG. 1a
FIG. 1b
3m LED STRIP
2m EXTENSION CABLE
2-WAY SPLITTER

3
Before installation, check that all parts included are undamaged. If the appliance is
damaged, check with the supplier before installation and operation. If the supply cord is
damaged, it must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
CAUTION: In order to avoid a hazard due to the inadvertent resetting of the thermal cut-out,
this appliance must not be supplied through an external switching device, such as a timer, or
connected to a circuit that is regularly switched on and off by the utility.
Do not use the appliance outdoors.
Do not use the appliance in the immediate surroundings of a bath, a shower or a swimming
pool.
Do not leave the appliance unattended during use.
Do not run the mains cable under carpet, rugs, etc.
Do not
locate the appliance immediately below or in front of a fixed socket outlet or connection
box.
Do not install the appliance using an extension cord.
Do not install the appliance in an open flue.
Do not insert any objects into the appliance.
Do not operate the appliance near flammable materials or fire.
Do not clean the appliance with abrasive cleaners.
Do not use this fire in rooms that have explosive gas in them (for example petrol), or if you
are using solvents, glue, aerosol spray or in flammable paints, as these may catch fire.
Do not use this appliance in small rooms when they are occupied by persons not capable of
leaving the room on their own, unless constant supervision is provided.
Do switch off and unplug the appliance from the main socket when not in use or before
cleaning and maintenance.
Do keep the appliance away at least 1 meter from furniture, curtains or other combustible
material when in use.
Do ensure the plug remains easily accessible after installation of the appliance.
Do use this appliance on a horizontal and stable surface.
IMPORTANT INFORMATION

4
CAUTION: Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
Children of less than 3 years should be kept away from the products unless continuous
supervised. Children aged from 3 years and less than 8 years shall only switch on/off the
appliance provided that it has been placed in its intended normal operating position and they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children aged from 3 years and less than 8 years shall not
plug in, regulate and clean the appliance or perform user maintenance.
NOTE: A dedicated, properly fused 13 Amp circuit is required, rated for the appropriate
voltage (230-240V). An isolation switch should also be incorporated in cases where the
product plug is inaccessible after installation.
NOTE: This appliance must be earthed.
WARNING! Construction and wiring (including electrical safe zones) must comply with local
building codes and other applicable regulations to reduce the risk of fire, electric shock and
injury to persons.
WARNING! To reduce the risk of fire, electric shock or injury to persons, always use a licensed
electrician.
WARNING! Information for authorized person or service center only: A non-rewireable plug
fitted with a 13A fuse is supplied. Should the fuse or plug need replacing, and you are
competent to do so, it must be replaced with a 13A fuse or plug being 13A BS1363A approved.
WARNING: In order to avoid overheating, do not cover the heater or air vents located on the
appliance or obstruct the air circulation around the appliance.
IMPORTANT INFORMATION

5
VS75 VS100 VS130 VS150 VS180
Weight (kg) See outer packaging.
See outer packaging. See outer packaging. See outer packaging. See outer packaging.
Dimensions (mm) H848xW780xD296 H548xW1030xD296 H548xW1330xD296 H548xW1530xD296 H548xW1830xD296
Supply Voltage 230-240V AC/50Hz 230-240V AC/50Hz 230-240V AC/50Hz 230-240V AC/50Hz 230-240V AC/50Hz
Max. Power Consumption 2000W 2000W 2000W 2000W 2000W
Power for Flame Effect 28W 40W 50W 52W 62W
Power for Ambient Light Kit 30W 20W 15W 10W 15W
HEAT OUTPUT SYMBOL VALUE UNIT
Nominal Heat Output Pnom 1.8-2 kW
Minimum Heat Output Pmin 1 kW
Maximum Continuous Heat Output Pmax 2 kW
AUXILIARY ELECTRICITY CONSUMPTION
At Nominal Heat Output elmax 12.5 W
At Minimum Heat Output elmin 12 W
In Standby Mode elSB 1.1 W
TYPE OF HEAT OUTPUT / ROOM TEMPERATURE CONTROL YES / NO
Single stage heat output and no room temperature control NO
Two or more manual stages, no room temperature control NO
With mechanic thermostat room temperature control NO
With electronic room temperature control YES
Electronic room temperature control plus day mer YES
Electronic room temperature control plus week mer YES
OTHER CONTROL OPTIONS YES / NO
Room temperature control, with presence detecon NO
Room temperature control, with open window detecon YES
With distance control opon YES
With adapve start control YES
With working me limitaon NO
With black bulb sensor NO
ITEMS MAIN CONTROL BOARD WiFi MODULE REMOTE CONTROL
Hardware RC01-067A01-V0.0 WR3 V1.0 RF455H-V0.0
Software/Logic TC01-067A01-V1.0 / RCS20-V1.0
Frequency FSK 433.92MHz/2.4GHz 2.4GHz FSK 433.92MHz
Maximum Transmit Power 10mW 100mW 10mW
TECHNICAL INFORMATION
VS220
See outer packaging.
H548xW2230xD296
230-240V AC/50Hz
2000W
8
80W
15W

6
VS100
76 394 78 296
1030
281
260
548
1101000
750 110
VS75
296694 7876
848
281
260
780
TECHNICAL INFORMATION

7
TECHNICAL INFORMATION
VS150
1530
2967839476
1500
281
260
548
110
VS130
1330
281
260
548
110
2967839476
1300

8
TECHNICAL INFORMATION
1830
1800
2967839476
281
260
548
110
VS180
394 7876 296
110
548
260
281
2230
2200
VS220

9
PART DESCRIPTION AND QUANTITY PART DESCRIPTION AND QUANTITY
1 SIDE GLASS TRIM (TOP/BOTTOM) X 4 12 SHELF SUPPORT BRACKET (SHORT) X 2
2 SIDE GLASS TRIM (SIDE) X 2 13
(NOT SHOWN) ORANGE GLASS SUCKER X 2
3 METAL SIDE PANEL X 2 14
(NOT SHOWN) MAGNET TOOL X 1
4 SIDE GLASS PANEL X 2 15
(NOT SHOWN) POWER CABLE X 2 (UK & EU)
5 APPLIANCE X 1 16
(NOT SHOWN) REMOTE CONTROL HANDSET X 1
6 WALL MOUNTING BRACKET X 1 17
(NOT SHOWN) AAA BATTERY X 2
7 POWER CABLE SECURING BRACKET X 1 18
(NOT SHOWN) ST4*8 SCREW X 19 (17 for VS75)
8 MAGNETIC SIDE DECORATIVE PANEL X 2 19
(NOT SHOWN) DECORATIVE FUEL LOGS X 1
9 SMALL MOUTING BRACKET X 4 20
(NOT SHOWN) BAG OF GLASS EMBERS X 1
10 FRONT GLASS PANEL X 1 21
(NOT SHOWN) BAG OF VERMICULITE GRANULES X 1
11 SHELF SUPPORT BRACKET (LONG) X 1 22
(NOT SHOWN) INSTRUCTION MANUAL X 1
CONTENTS LIST

10
Before installation, check that all parts are included and undamaged. If the appliance is damaged, check with the
supplier before installation and operation. If the mains power supply lead is damaged in any way, it must be replaced
by a suitable equivalent approved by the manufacturer.
The main box contains the appliance, 2 x suction cups and 1 x magnet tool. Packed with the appliance (behind the
glass panel) are additional boxes each with a contents list printed on the outside of each box.
GLASS REMOVAL –ACCESSING PARTS
To gain access to various contents required for installation follow steps shown in Fig.1 through to Fig.4 to remove the
glass panel on the front of the appliance.
REMOVAL OF WALL MOUNTING BRACKET
The wall mounting bracket is secured to the rear panel of the appliance. Remove the screws and the wall mounting
bracket and put aside for later use –see Fig. 5.
POWER CABLE
After inserting the power cable into the socket on the bottom right side of the appliance, secure in place using the
power cable securing bracket and ST4*8 screw (found inside Box #1) –see Fig.6.
INSTALLATION
PREPARING THE APPLIANCE
FIG. 1
FIG. 2
FIG. 4
FIG. 3
FIG. 2

11
ASPECT TYPE
The appliance can be installed in three different aspects:
•Front (1 glass panel)
•Corner (2 glass panels)
•Panoramic (3 glass panels)
Front Aspect
Your appliance will arrive in a front aspect with metal side
panels already fitted –see Fig. 7.
Corner Aspect
For a corner aspect, choose which side you want to
feature a glass panel and remove the 7 screws that secure
the metal side panel to the appliance –see Fig. 8. Carefully
remove the panel and keep the screws in a safe place.
Using the removed screws, take 2top/bottom side glass
edge trims and 1side side glass edge trim and screw them
to the appliance as shown below –see Fig. 9.
Panoramic Aspect
For a panoramic aspect, repeat the corner aspect procedure
on the opposite side of the appliance –see Fig. 10.
FIG. 5
FIG. 6
FIG. 7
FIG. 8
FIG. 9
FIG. 10
INSTALLATION

12
The manufacturer does not accept any liability for any injuries or damages that may occur due to improper handling
or installation. Ensure that the wall upon which the appliance is to be installed and any wall fixings used are
sufficiently strong enough to hold the weight of the appliance (appliance weight can be found printed on the
packaging). Plasterboard alone is not considered a structural material and it is not recommended to reply solely on
plasterboard fittings to support the weight of the appliance. If the appliance or any structure linked to the appliance
is to be fitted to a wall with a timber frame construction, adequate wooden supporting members must be fitted
using appropriate fixings. If this is not possible then steps must be taken to strengthen the wall before installation.
WALL MOUNTED
The appliance is supplied with a wall bracket which is
secured to the rear of the appliance.
Step 1
Remove the bracket from the rear of the appliance, place
the bracket in the desired position ensuring it is level,
mark the fixing points and use appropriate fixings to secure
to the wall.
Step 2
Attach the bottom mounting brackets to the appliance
using x4 ST4 screws see Fig 11 the appliance then can be
lifted on to the wall bracket to enable the bottom bracket
fixing points to be marked on the wall. Then use suitable
fixings to secure the bottom mounting brackets to the
wall.
Note See details of the weight of the appliance in
the technical information to help determine the correct
fixings.
SUITE ELEMENTS
Suite elements can be fitted to the appliance using the
shelf support brackets –see Fig. 12. The brackets can be
adjusted up or down to suit a range of shelf material
thicknesses from 15-24mm. Once the correct thickness
has been set, offer the shelf to the appliance in a smooth
manner.
STUD/FEATURE WALL
Ensure that the stud wall has a supporting header –the
weight of the finished wall should not rest on the top of
the appliance. The base of the stud work must be able to
take the full weight of the appliance.
The 4 small mounting brackets can be fitted to the
appliance as shown in Fig. 13 for securing to a timber frame.
INSTALLATION TYPES
INSTALLATION
FIG. 11
FIG. 12
FIG. 13

13
MAGNETIC SIDE DECORATIVE PANELS
The appliance is supplied with 2 magnetic panels that
can be fitted when installing in a panoramic or corner
aspect. These panels are simply positioned against the
side of the appliance, behind the side glass edge trim –
see Fig. 14.
LOG AND EMBER ARRANGEMENT
The logs can be arranged freely on the fire allowing you
to create your own unique appearance. For the best
results it is recommended to position the logs across
the fuel bed first; experiment with position angles and
overlapping the logs so that some rest on each other –see. Fig. 15. Then, when you are happy with the layout,
carefully scatter the glass embers around all the logs, ensuring that all visible areas of the fuel bed, including
underneath and behind the logs, are covered –see Fig. 16. Finally, in a similar manner, carefully scatter the
vermiculite granules over the glass embers ensuring good coverage –see Fig. 17
FIG. 14
FIG. 15
FIG. 16
FIG. 16
INSTALLATION - FINISHING

14
The appliance can be operated conveniently in 3 different ways: manually, via the remote control handset or via the
dedicated iOS/Android app.
Each time a button is pressed on the appliance or on the remote control an audible beep is emitted. To turn off this
feature hold your finger on the Preset Mode button (on the appliance) for 3 Seconds.
On/Off
Press to turn on power to the appliance. Button pushed in indicates power is on, button pushed out indicates power
is off.
Wifi On/Off
Press to turn wifi on or off. An illuminated LED on the button indicates that wifi is turned on. Hold button for 3
seconds to enter device pairing mode.
Standby
Turns on the appliance with the last used settings without any heat. Places the appliance into standby mode with all
features turned off.
Heat Mode
1 press = cool blow. 2 press = low heat setting. 3 press = high heat setting. 4 press = no heat/no cool blow.
Preset Mode
Press repeatedly to cycle through the 6 fire preset modes (+3 user defined presets if programmed).
OPERATION
MANUAL CONTROL
FIG. 17
Preset Mode
Heat Mode
Standby
Wifi On/Off
On/Off

15
Ensure that 2 AAA batteries are inserted into the remote
control handset. The battery power level is indicated by
the column of bars to the right side of the temperature
display when the appliance is in standby mode. 5 bars
indicates the batteries are full, 1 bar indicates the batteries
are empty and need to be replaced immediately.
Remote Control Setup
Press and hold the Standby button on the appliance until
you hear two beeps, release the button. Press Standby
button on the remote control handset and you will hear
one beep. The remote is connected with the appliance.
Button 1: Preset Mode
Repeatedly press to cycle through the 6 preset fire modes
(+ 3 user defined presets if programmed).
On screen Pr.1 = Autumn Campfire
On screen Pr.2 = Ember Glow
On screen Pr.3 = Inferno
On screen Pr.4 = Noir
On screen Pr.5 = Fire & Ice
On screen Pr.6 = Nebula
On screen Pr.7 = User Preset
On screen Pr.8 = User Preset
On screen Pr.9 = User Preset
There are 3 preset slots allocated for the user to save
personalised e-fire creations. Simply choose the flame
colour and brightness level, the fuel bed colour and brightness level and fuel bed down light colour and brightness
level. One you have selected your desired combination, press and hold the Preset Mode button for 3 seconds until
the LCD displays Pr.7. Press –and + buttons to select a slot number between 7-9. Press and hold the Preset Mode
button for 3 seconds to confirm the preset.
Button 2: Standby
Turns on the appliance with the last used settings without any heat. Places the appliance into standby mode with all
features turned off.
Button 3&9: Minus & Plus
Use to navigate through different on-screen menus.
Button 4: Flame Speed
Press once to enter flame speed menu –SPd will show on the LCD screen. Press the plus and minus buttons to adjust
the flame speed. The flame speed is indicated on screen by bars –1 bar is the slowest setting; 5 bars is the fastest
setting.
FIG. 18
IMPORTANT: The remote control handset must
be left in the same room as the appliance as it
houses the thermostat that regulates heat output.
OPERATION
REMOTE CONTROL

16
Button 5: Flame Colour
Repeatedly press to cycle through flame colour menu. Whilst in the flame colour menu, press the plus and minus
buttons to increase and decrease the flame brightness - 1 bar is the dimmest setting, 5 bars is the brightest setting.
On screen FL.0 = Flame off
On screen FL.1 = Red
On screen FL.2 = Orange
On screen FL.3 = Yellow
On screen FL.4 = Green
On screen FL.5 = Light Blue
On screen FL.6 = Dark Blue
On screen FL.7 = Violet
On screen FL.8 = White
On screen FL.9 = Multi-colour change
Button 6: Fuel Bed Colour
Repeatedly press to cycle through fuel bed colour menu. Whilst in the fuel bed colour menu, press the plus and
minus buttons to increase and decrease the fuel bed brightness - 1 bar is the dimmest setting, 5 bars is the brightest
setting.
On screen Fb.0 = Flame off
On screen Fb.1 = Red
On screen Fb.2 = Orange
On screen Fb.3 = Yellow
On screen Fb.4 = Green
On screen Fb.5 = Light Blue
On screen Fb.6 = Dark Blue
On screen Fb.7 = Violet
On screen Fb.8 = White
On screen Fb.9 = Multi-colour change
Button 7: Timer Mode
Repeatedly press to cycle through timer options. Select an amount of time for the appliance to operate then
automatically turn off. Choose between .5, 1, 2, 3, 4, 5, 6, 7, 8, 9 hours.
Button 8: Fuel Bed Down Light
Repeatedly press to cycle through fuel bed down light colour menu. Whilst in the fuel bed down light colour menu,
press the plus and minus buttons to increase and decrease the fuel bed brightness - 1 bar is the dimmest setting, 5
bars is the brightest setting.
On screen dL.0 = Flame off
On screen dL.1 = Red
On screen dL.2 = Orange
On screen dL.3 = Yellow
On screen dL.4 = Green
On screen dL.5 = Light Blue
On screen dL.6 = Dark Blue
On screen dL.7 = Violet
On screen dL.8 = White
On screen dL.9 = Multi-colour change
OPERATION
OPERATION

17
Button 10: Heater Mode
Press to cycle through the heat output options.
1 press: Co.A = Cool blow setting
2 press: H.Lo = Low heat setting
3 press: H.HI = High heat setting
4 press: no.H = No Heat
Whilst in heater mode after selecting low or high heat setting, press the –and + buttons to select the temperature
you want the room to reach. Note: if the room temperature is already higher than the temperature selected, the
heater will not activate. To switch between ℃/℉hold down the –and + buttons for 3 seconds.
Open Window Detection is an innovative eco feature that detects a rapid drop in room temperature caused by an open
window. The warning word "OPn" will be displayed on the screen and the heater will be turned off. If the room
temperature rises or the remote control is operated manually, the heater will return to its normal working state.
Button 11: Sound Effect
Press to open the open the sound effect menu.
1 press: S.on = Sound effect on
2 press: no.S = Sound effect off
Whilst in the sound effect menu, press the plus and minus buttons to increase and decrease the volume - 1 bar is the
quietest setting, 5 bars is the loudest setting.
Button 13: Ambient Lighting (if appliance is fitted with optional Ambient Lighting Kit)
Repeatedly press to turn on ambient lighting and cycle through the different colour options.
Button 14: Eco Mode eco
Press to activate Eco mode. This mode will reduce the brightness of all lighting modes and limit the heat output to
low setting, resulting in reduced energy consumption. Press the button a second time to exit Eco mode.
Visit your device app store (iOS or Android) to download the TUYA SMART APP. Once installed follow the procedure
below to pair the device with your appliance.:
Step 1. Start the app and click “Add Device” on screen. Select “Small Home Appliance” from the list, then select
“Heater (Wi-Fi)”.
Step 2. Ensure the appliance is powered on then press and hold the button on the appliance until you hear 3
beeps. At the same time the button will flash and the fuel bed will flash.
Step 3. Follow the instructions on the app to input your home network details. Note, your device must also be
connected to the same home network you wish to connect the appliance to.
Once connected you can fully control your appliance and also programme a weekly timer that features Adaptive
Start Control –a smart home device that gauges the current temperature of the room and anticipates the time
required to heat it to a desired temperature. When in weekly timer mode, the appliance will automatically
determine the time to turn on the heater to ensure that the set temperature is met at the time required (up to 45
minutes prior to the set time).
OPERATION
APP CONTROL

18
IMPORTANT: ALWAYS DISCONNECT THE APPLIANCE FROM THE POWER SUPPLY AND ALLOW TO COOL BEFORE
CLEANING.
Any repairs or maintenance should only be carried out by a suitably qualified competent person.
The appliance should be occasionally cleaned using a dry cloth. Do not use detergents, abrasive cleaners of furniture
polish.
To clean the glass, use a lightly damp cloth and ensure any moisture is dried fully using a lint free cloth.
Ensure that the heater vent is kept dust free by occasionally vacuuming the area using a brush attachment.
Resetting the Thermal Cut Out
The appliance is fitted with an Electronic Safety Control (E.S.C.). This is a safety device which switches off the fire if,
for any reason, the appliance overheats, e.g. when covered. If the heater stops operating while the flame effect
continues working normally, this indicates that the E.S.C. is in operation. The E.S.C. can only be reset after the
appliance has cooled down and the appliance has been reset. Re-setting of the E.S.C. procedure is as follows:
1. Switch off the appliance (Manual On/Off switch) and leave it off for approximately 10-15 minutes.
2. Remove any obstruction to the fan heater outlet or fan blades etc. Make sure that the power supply is disconnected
with the plug socket outlet while doing this.
3. Switch on the appliance and the E.S.C. will be reset.
4. Ensure that the appliance is functioning correctly. If the E.S. Control operates again, the appliance should be checked
by a competent electrician.
PROBLEM
POSSIBLE CAUSE
SOLUTION
Appliance will not turn on.
Problem with power supply.
Check that the appliance is plugged
in to the power supply and switched
on.
Check and replace fuse in the plug if
necessary.
Check that the main power switch
on the appliance is turned on.
Remote control does not work.
Batteries have expired.
Replace batteries.
Remote has de-synched with
appliance.
Ensure that the appliance is turned
on. Re-synch the remote by
pressing the -button and the +
button at the same time and holding
for 3 seconds.
No heat
Incorrect thermostat setting.
Increase the desired temperature
higher than the current room
temperature.
Overheating may have engaged the
E.S.C. feature.
See above for reset procedure.
Heat turns off before desired
temperature is reached.
Open window detection has
activated.
Check that any windows in the room
are closed.
CLEANING & MAINTENANCE
TROUBLESHOOTING

19
Vision E-Line Solus appliances come with a standard 1-year warranty (parts & labour) when purchased through an
authorised dealer. This can be extended for free to two years (parts only for year 2) by registering your appliance
within 60 days of purchase.
Visit www.visionfires.co.uk/warranty to register your appliance, activate the free warranty extension, or to see
details about the 6 year Premium Protect warranty package.
WARRANTY

20
Electrical appliances should not be disposed as household waste. Separate collection facilities should be used in the disposal of
electrical appliances. Contact your local government for information about the available collection systems. If electrical appliances
are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging
your health and well-being.
This fire complies with the Safety Standards EN 60335-1 and EN60335-2-30 which covers the essential requirements of the Low
Voltage Directive 2014/35/EU and the EMC standards EN55014-1; EN55014-2; EN61000-3-2 and EN61000-3-3 which covers the
essential requirements of the European Electro Magnetic Compatibility 2014/30/EU, and the RED standards EN300220-2, EN30148
9-1, EN301489-3 and EN6247 which covers the essential requirements of the European Radio Equipment Directive 2014/53/EU.
This fire complies with the Safety Standards BS 60335-1 and BS 60335-2-30 which covers the essential requirements of the
Electrical Equipment (Safety) Regulations 2016 (S.I.2016/1101) and the EMC standards BS 55014-1; BS 55014-2; BS 61000-3-2 and
BS 61000-3-3 which covers the essential requirements of the Electro Magnetic Compatibility Regulations 2016 (S.I.2016/1091).and
the RED standards BS300220-2, BS301489-1,BS301489-3 and Bs6247 which covers the essential requirements of the European
Radio Equipment Regulations 2017.
