Vision SP-1800 User manual

1
SP-1800_manual_en
SP-1800 OWNERS MANUAL
www.visionaudiovisual.com/techaudio/sp-1800

2
SP-1800_manual_en
DECLARATION OF CONFORMITY
Where applicable Vision products are certified and comply with all known local regulations to a
‘CB Certification’ standard. Vision commits to ensure all products are fully compliant with all
applicable certification standards for sale in the EU and other participating countries.
The product described in this owner manual is in compliance with RoHS (EU directive
2002/95/EC), and WEEE (EU directive 2002/96/EC) standards. This product should be returned
to the place of purchase at the end of its useful life for recycling.
WARNINGS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be
of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle, is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
All products are designed and imported into the EU by ‘Vision’ who is wholly owned by ‘Azlan
Logistics Ltd.’, Registered in England Nr. 04625566 at Lion House, 4 Pioneer Business Park,
Clifton Moor, York, YO30 4GH. WEEE Registration: GD0046SY
DECLARATION OF ORIGIN
All Vision products are made in the People’s Republic of China (PRC).

3
SP-1800_manual_en
PLACE OF INSTALLATION
Avoid installing this product under the following conditions:
• Moist or humid places
• Places exposed to direct sunlight or close to heating equipment
• Extremely cold locations
• Places subject to excessive vibration or dust
• Poorly ventilated places
Do not expose this product to dripping or splashing. DO NOT PLACE OBJECTS FILLED WITH
LIQUIDS ON OR NEAR THIS PRODUCT!
PACKAGING
Save all packing material. It is essential for shipping in the event the unit ever needs repair.
NOTE: If original packaging is not used to return the unit to the service centre, damage in
transit will not be covered by warranty.
POWER HANDLING
Power rating with regards to loudspeakers denotes how much power the loudspeaker can
handling for a sustained period of time without distortion. These speakers are rated to accept
up to 50 watts RMS.
WATTS
The most consistent standards for measuring watts are “Program Power” and “RMS” because
these measure average sustained levels. Any low impedance amplifiers with an output of 2 x
10w - 2 x 50w (@ 8 ohms) are suitable for use with these speakers.
NOTE: The power output from an amplifier depends on the number of loudspeakers attached.
8 ohms normally denotes two loudspeakers attached
4 ohms normally denotes four loudspeakers attached

4
SP-1800_manual_en
INSTALLATION
1. FIT BRACKETS TO WALL Position brackets over load-bearing studs and use appropriate
screws to fix brackets to wall or ceiling. Ensure they are level.
NOTE: Do not position the top of bracket closer than 140mm to cornice.
2. FIT LOUDSPEAKERS TO MOUNTS Lower loudspeakers onto brackets as shown.

5
SP-1800_manual_en
3. TERMINATE CABLES TO LOUDSPEAKERS Connect speaker cables from amplifier to screw
terminals on rear of loudspeakers. Use unshielded speaker cable with gauge of 0.75mm or
higher.
4. TIGHTEN BRACKET SCREWS Set desired angle and lock off side screws.
TROUBLESHOOTING
If your system is not operating properly, please refer to the following information. If the
problem persists, disconnect from power and contact your AV reseller immediately.
Problem
Correction
Sound only coming out
one side
•Turn off amplifier and switch output connections. If the side
changes the amplifier is okay and the fault is with one of the
loudspeakers.
•Switch input connections and check input cabling.
Sound very quiet
•Have you used unshielded speaker cables? Use cable with
gauge of 0.75mm or higher. Note: Phono or minijack cable is
shielded and is not appropriate.

6
SP-1800_manual_en
SPECIFICATIONS
PRODUCT DIMENSIONS: 240 x 178 x 193 mm /9.45″ x 7″ x 7.6″ (length x width x height for
each speaker)
PACKAGED DIMENSIONS: 465 x 205 x 270 mm / 18.3″ x 8.1″ x 10.63″
PRODUCT WEIGHT: 4.2 kg /9.26 lbs (per pair)
PACKAGED WEIGHT: 4.67 kg /10.23 lbs (per pair)
CONSTRUCTION MATERIAL: ABS
COLOUR: White
TECHNICAL DETAILS:
Power Handling: 50 watts (RMS)
Woofer: 5.25″
Tweeter: 0.5″ + Piezo 1″
Input Terminals: Binding post
Output Impedance: 8 ohms
Sensitivity: 89dB (1w/1m)
Frequency response: 80Hz-20kHz
ACCESSORIES INCLUDED:
2 x Wall brackets
WARRANTY 2-year return to base
COMPLIANCE: RoHS, WEEE, RCM/CE/LVD/EMC/FCC/IEC

7
SP-1800_manual_en
WARRANTY
This product comes with a 2-year return to base warranty, effective from the date of purchase.
This warranty applies only to the original purchaser and is not transferable. For the avoidance of
doubt, this will be taken from the information held by the appointed national distributor at the
point of sale. If the product is DOA (dead on arrival), you have 21 days from purchase date to
notify the national distributor via your AV reseller. The liability of the manufacturer and its
appointed service company is limited to the cost of repair and/or replacement of the faulty unit
under warranty, except for death or injury (EU85/374/EEC). This warranty protects you against
the following:
• Failure of any components, including the power supply.
• Damage when the product is first removed from its packaging if reported within 24 hours of
purchase.
If you find you do have a problem with this product, you should contact the AV reseller you
purchased this product from. The original purchaser is responsible for shipment of the product
to the manufacturer’s appointed service centre for repair.
We will endeavour to return repaired units within 5 working days, however this may not always
be possible, in which case it will be returned as soon as practicably possible. In line with our
WEEE commitments, the manufacturer endeavours to replace the faulty parts of the product
rather than replacing the whole unit. This warranty does not protect this product against faults
caused by abuse, misuse, incorrect installation, unstable or faulty power input, which might be
caused by ignoring the guidelines set out in this manual.
LEGAL DISCLAIMER: Because we are committed to improving our products, the details above
may change without prior warning. This User Manual is published without warranty and any
improvements or changes to the User Manual necessitated by typographical errors, inaccuracies
of current information, or improvements to programs and/or equipment, may be made at any
time and without notice. Such changes will be incorporated into new editions of the User
Manual.
