Visionhitech VPD200SM2i Manual

Page 1
/
HA
VPD
2


/
15
RD
W
2
00SM2i
W
ARE
FULL
INS
TA
HDNET
W
TA
LL
A
W
ORKP
T
A
TIO
N
T
ZCame
Rel
e
N
GUI
ra
e
asedon
1
Visio
n
DE
Versio
n
1
st
ofJun
e
n
Hitech
C
n
1.0.0
e
.,2012

C
o.,Ltd.





Page 2 / 15
PRECAUTIONS

Byselectingthisproduct,youhavedecidedtouseaprofessionaldevicethatguaranteeshighestqualityand
reliability.Wewouldliketothankyouverymuchforyourconfidenceandkindlyaskyoutoreadthefollowing
instructionscarefullybeforeinstallationandoperationinordertotakefulladvantageofallqualityfeatures
regardingthisproduct.


Thelightingflashwithanarrowheadsymbol,withinanequilateraltriangleisintendedtoalert
theusertothepresenceofnon‐insulateddangerousvoltagewithintheproduct’senclosure
thatmaybeofsufficientmagnitudetoconstituteariskofelectricshocktopersons.

Theexclamationpointwithinanequilateraltriangleisintendedtoalerttheusertothe
presenceofimportantoperatingandmaintenance(servicing)instructionsintheliterature
accompanyingtheappliance.

INFORMATION
ThisequipmenthasbeentestedandfoundtocomplywithlimitsforaClassAdigitaldevice,pursuanttopart15
oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferencewhen
theequipmentisoperatedinacommercialenvironment.Thisequipmentgenerates,uses,andcanradiate
radiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructionmanual,maycause
harmfulinterferencetoradiocommunications.Operationofthisequipmentinaresidentialareaislikelyto
causeharmfulinterferenceinwhichcasetheuserwillberequiredtocorrecttheinterferenceatitsown
expense.

WARNING
Changesormodificationsnotexpresslyapprovedbythemanufacturercouldvoidtheuser’sauthorityto
operatetheequipment.

CAUTION–Topreventelectricshockandriskofthefirehazards
‐DoNOTusepowersourceotherthanthatspecified.
‐DoNOTexposethisappliancetorainormoisture.

Trademarks
Allnamesusedinthismanualforhardwareandsoftwareareprobablyregisteredtrademarksofrespective
companies.

Thisinstallationshouldbemadebyaqualifiedservicepersonandshouldconformtoalllocalcodes.



Page 3 / 15
Tableofcontent


HardwareInstallationGuide

1.Precautions‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐4


2.Limitationofliability‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐4


3.Disclaimerofwarranty‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐4


4.PackageContents‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐5


5.CableConnection‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐6


6.Installation‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐7~13


7.Dimension(mm)‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐14


8.Specification‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐14
VPD200SM2i‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐15





















Page 4 / 15
1.Precautions
zPleasereadthemanualcarefullybeforetheinstallationinordertosetupthecameracorrectlyandto
obtainthebestpicturequality.

zPleasekeepthemanualingoodconditionforyourfuturereferenceandserviceapplication.

zInstallationandservicesshouldbeonlycarriedoutbyanauthorizedpersonnelaccordingtolocalsafety
regulations.

zIfanyliquidorsolidmattergetsintothehousing,immediatelydisconnectthecamerafrompowersupply
andhaveitcheckedbyyourauthorizeddealerbeforereusing.

zAvoidinstallingthecameraatextremelyhotorcoldplaces.

zIfyouarenotacertifiedperson,nevertrytodismantlethecamera.Toavoidelectricshock,neverremove
thescrewsorcovers.Therearenopartsinsidethatneedmaintenancebytheuser.Allmaintenanceshould
becarriedoutbyqualifiedpersonnel.

zAvoidinstallingthecameraataplaceofhighhumidity.

zAvoidinstallingthecameraattheplaceexposedtogasoroil.

zKeepthetopglassofthelensalwayscleaninordertoobtainthebestpicturequalityallthetime.Be
carefulnottobestainedbyfingerprint.

zDon'tfacethecameradirectlytowardsunlightorsunlightreflectingarea.CCDmaygodefectiveatthis
condition.

zPleasegiveaspecialattentiontokeeptheunitfromdangerousdroporexternalshockduringtheprocess
oftransportationorhandling.

zNevertrytotouchthecamerainwethand.Itmaycauseanelectricshock.

zDonotexposethecameratoradioactivity.ItcausesaseriousdamageontheCCD.

2.Limitationofliability

Thispublicationisprovided“ASIS”withoutwarrantyofanykind,eitherexpressorimplied,includingbutnot
limitedto,theimpliedwarrantiesofmerchantability,fitnessforanyparticularpurpose,ornon‐infringementof
thethirdparty'sright.Thispublicationcouldincludetechnicalinaccuraciesortypographicalerrors.Changes
areaddedtotheinformationherein,atanytime,fortheimprovementsofthispublicationand/orthe
correspondingproduct(s).

3.Disclaimerofwarranty

Innoeventshallsellerbeliabletoanypartyoranyperson,exceptforreplacementorreasonablemaintenance
oftheproduct,forthecases,includingbutnotlimitedtobelow:

(1)Anydamageandloss,includingwithoutlimitation,directorindirect,special,consequentialorexemplary,
arisingoutoforrelatingtotheproduct;


Page 5 / 15
(2)Personalinjuryoranydamagecausedbyinappropriateuseornegligentoperationoftheuser;

(3)Unauthorizeddisassemble,repairormodificationoftheproductbytheuser;

(4)Inconvenienceoranylossarisingwhenimagesarenotdisplayed,duetoanyreasonorcauseincludingany
failureorproblemoftheproduct;

(5)Anyproblem,consequentialinconvenience,orlossordamage,arisingoutofthesystemcombinedbythe
devicesofthirdparty.

(6)Anyclaimoractionfordamages,broughtbyanypersonororganizationbeingphotogenicsubject,dueto
violationofprivacywiththeresultofthatsurveillance‐camera'spicture,includingsaveddata,forsome
reason,becomespublicorisusedforthepurposeotherthansurveillance.

4.PackageContents


Note: Mount Brackets are optional.
zWall Mount Bracket zCeiling Mount Bracket
[Screws : Torx Secrew M4×18, Hex Lag #14×50] [Screws : Torx Screw M4×18, Anchor Bolt 3/8"×70]

zMain body & Dome Cover zAccessories
Main Cable Wrench Driver 2EA of BNC
Cross LAN Cable Audio Cable CD

Page 6 / 15

5.CableConnection


















• Dome Cover Do not detach protection vinyl from dome cover before finishing all
installation process to protect dome cover from scratches or dust.
• DIP Switch Sets up camera ID and protocol.
• Drop Prevention
Spring This part keeps the camera from dropping during installation and maintenance. After install the Bracket, please, hang the spring to
the drop prevention hook of main body as shown in picture for
further tasks.
• Mounting Screw
Hole This hole is for screws that assembles the main body with a bracket.
• IP Reset Switch Reset its network configuration to the factory defaults. You will lose
all data that had been entered previously. To initialize the system
to the factory default, press the reset button for more than 5
seconds.
• LAN Port Used for the Ethernet connection
• Audio Port Used for the audio in/out connection.
• Video (BNC) Used for the composite video out or HD-SDI video out connection
according to models
• Main Connector Used for the power wire, the RS-485 communication cable, alarm
in/out connection cable.






Page 7 / 15
6.Installation
DIP Switch Setup
When you control the camera through RS-485, before installation, you should set the DIP switches to
configure the camera ID, communication protocol.
Camera ID setup
ON
ON
12345678
zID numbers of camera are set up with binary numbers..
See the examples shown below
Pin 1 2 3 4 5 6 7 8
ID Value 1 2 4 8 16 32 64 128
ex) ID=5 on off On off off off off off
ex) ID=10 off on Off on off off off off
zThe camera ID range is 1~255. Camera ID must not be 0.
zFactory default of Camera ID is 1.
zMatch the camera ID with Cam ID setting of your DVR or Controller
to control the camera.

Page 8 / 15
Communication Protocol Setup
1234
ON
ON
zSelect the appropriate Protocol with DIP switch combination.
Switch State Protocol/Baud rate
P0
(Pin 1) P1 (Pin 2) P2 (Pin 3)
OFF OFF OFF PELCO-D, 2400 bps
ON OFF OFF PELCO-D, 9600 bps
OFF ON OFF PELCO-P, 4800 bps
ON ON OFF PELCO-P, 9600 bps
Otherwise Reserved
zIf you want to control using DVR or P/T controller, their protocol must
be identical to camera. Otherwise, you can not control the camera.
zAdjust the DIP switch after turning off the camera. If you changed the
camera protocol by changing the DIP switch, the change will be effective
after you reboot the camera.
zFactory default of protocol is “Pelco-D, 2400 bps”.

Page 9 / 15
Installation Camera with Brackets
Installation using Ceiling Mount Bracket
①Remove the ceiling tile from the ceiling and cut
a hole whose diameter is 30~40mm on the ceiling
tile to pass the wire(s) and cable(s) through to the
upside of the ceiling. (In case of the wiring and
cabling through the mounting surface only) Then
prepare the ceiling mount bracket. Pull the wire(s)
for the system as below. (Anchor Bolt 3/8"×70)
②Hook up “Drop Prevention Spring” on main
body to prevent camera from unexpected drop
and pull the wire(s) and cable(s) for the system
as below
③Line up the mold lines and assemble main
body to mount adaptor and turn it. And
assemble the main both with the camera
mount adaptor with the screws. (Torx screw
M4X18). Please make sure the screws are
tightly assembled for waterproof.
④Screw the dome cover to the main body and
remove the protection vinyl from the dome
cover.
Notice
zBefore starting the installation, make sure that the Camera ID and Protocol are set up properly.
zTo adjust the installation height from the mounting surface, the pipe and coupler should be
needed between the surface mount part of the ceiling mount bracket and the camera mount part
of the ceiling mount bracket. Note that they are not supplied by the manufacturer.

Page 10 / 15
Installation using Wall Mount Bracket
① Make a hole whose diameter is 30~40mm on
the mounting surface to pass the wire(s) and
cable(s) through the mounting surface. (In case of
the wiring and cabling through the mounting
surface only) Then prepare the wall mount
bracket. Pull the wire(s) and cable(s) for the
system as below. Attach the wall mount bracket to
the mounting surface. (Hex Lag #14×50)
② Hook up “Drop Prevention Spring” on main
body to prevent camera from unexpected
drop and pull the wire(s) and cable(s) for the
system as below.
③ Line up the mold lines and assemble main body to
mount adaptor and turn it. And assemble the main
both with the camera mount adaptor with the
screws. (Torx screw M4X18). Please make sure
the screws are tightly assembled for waterproof.
④ Screw the dome cover to the main body
and remove the protection vinyl from the
dome cover.
Notice
zBefore starting the installation, make sure that the Camera ID and Protocol are set up properly.

Page 11 / 15
Wiring/Cabling & Connecting
Port Description
zMain Cable
Port Pin Number (RJ45) Connector / Wire Color Signal
1 Black RS485 +
2 Brown RS485 −
3 Red DC 12V
4 Orange Ground
5 Yellow OUT COM (Relay Output Common)
6 Green OUT 2 (Relay Output 2)
7 Blue OUT 1 (Relay Output 1)
8 Violet IN COM (Sensor Input Common)
9 Gray IN 1 (Sensor Input 1)
10 White IN 2 (Sensor Input 2)
zAudio Cable
Port Pin Number Connector/ Wire Color Signal
1 RCA (Yellow) Audio IN
2 Audio GND
3 RCA (White) Audio OUT

Page 12 / 15
Connecting Power
1. Carefully check the voltage and current capacity of the rated power. The rated power is
indicated in the back of main unit.
2. After confirming the power source, connect power adaptor and connect the 12V DC
connector to the system
zFor the DC input models, be careful with the polarity of DC power. The system should be
permanently damaged by wrong DC input.
zIn case that the length of the power wire is very long, there may be voltage drop and the
system may not work properly. Make the length of the power wire as short as possible.
Connecting Network
1. Plug network cable to Ethernet port (RJ-45 network port).
Connecting Video
1. To display video through the composite connect each port to a monitor using BNC coaxial
cable
Connecting Audio
Audio is full-duplex. It is possible to set the mode as Tx-only, Rx-only or Tx-Rx.
1. Connect audio input and output ports to audio devices accordingly.
2. The Audio signal required is line level, so an audio equipment with an amp, mixer or other
amplifier should be used.
Connecting Serial Port (RS-485 Communication)
zFor PTZ control, connect the cable(s) to your keyboard or DVR. To connect multiple cameras
to a single controller, RS-485 communication should be connected in parallel as shown
below. If you are connecting a single camera to a controller, terminate the camera. When
connecting more than one camera to a single controller, terminate the last camera on the
communication line. The last camera means the camera farthest in cable length from the
controller. Note that the total length of the communication cable between a controller and the
camera(s) on the same communication line must be less than 1.2Km.

Page 13 / 15
zRS-485 of VPD200SM2i can be connected to external equipment such as PT receiver etc.
PC client can send PT commands to the external equipment via the serial port.
When a decoder system instead of PC client is connected to VPD200SM2i, the serial port
and that of the decoder system works in pass-through mode. That is, data from at one port is
delivered to the other port, vice versa
Connecting Sensor and Alarm
Connect sensor and alarm devices to corresponding terminals accordingly.
zSensor Input
zRelay Output
Maximum allowable electrical load of relay is shown bellow table.
Drive Power DC Power AC Power
Max. Load Max DC 24V, 1A Max AC 125V, 0.5A
IN COM
IN 1
IN 2
Sensor 1
Sensor 2
V+
OUT
1
AC or DC
LOAD
Internal
OUT
2LOAD
OUT COM

Page 14 / 15
7.Dimension(mm)



8.Specification
8.1.VPD200SM2i
Model Specification
Image sensor 1/2.8" SONY progressive sc an CMOS image sensor for excellent image quality
Day & Night Auto/Color/BW(ICR)
Environment OUTDOOR(IP66)
Optical Zoom 20X
Digital Zoom 12X
Lens 20x AF zoom ( f4.7~94mm (F1.6~F3.5))
Min. illumination /
Light sensitivity (Lux) 0.5 Lux (B/W) / F1.8 with 50 IRE
Pan Tilt
Operation Pan 360 Endless (400 deg/sec)
Tilt 0~90 deg (400 deg/sec)
WDR/BLC On/Off
Noise Reduction 2DNR
AE Mode Auto, Manual, Bright, Shutter Priority, Iris Priority, Spot
GAIN Control Auto / Manual (-3 ~ 28dB)
Shutter Control Auto / Manual (1/1 ~ 1/10,000 sec)
WhiteBlance Auto / Manual (Red, Blue Gain Adjustable)
Video Compression H.264 baseline profile, Motion JPEG
Resolutions Up to 1920 x 1080
Frame rate H.264 Up to 15fps with 1920x1080
MJPEG Up to 30fps with 720p resolution
Video streaming Support multi stream with H.264, MJPEG
Adjustable frame rate
VBR/CBR in H.264
Image setting Day & Night
Auto White Balance
Auto Exposure
Effect - Color, Sharpness, Mirror/V-Flip, etc.
BNC x1, 1.0Vp-p, 75 ohm Composite Video, NTSC/PAL
Privacy Mask
Effect - Color, Sharpness, Mirror/V-Flip, etc.
Output BNC x1, 1.0Vp-p, 75 ohm Composite Video, NTSC/PAL

Page 15 / 15
Audio
Audio streaming Two-way, full duplex
Compression G.711
Sample Rate 8KHZ
Data Rate 64Kbps
Audio input Microphone input /1 x Line-In (Mono)
Audio output Line output/ 1 x Line-Out (Mono)
Network Security Password protection
User access log
HTTPS encryption
Supported
protocol HTTP, HTTPS, FTP, SMTP, UPnP, DNS, DynDNS, NTP
RTSP, RTP, TCP, UDP, ICMP, DHCP
System
integration Intelligent video Motion detection up to 1920x1080 with 32x24 blocks
Alarm trigger Motion detection
External input/Normal Open/Close Type
Alarm events File upload via ftp, e-mail
Notification via email, FTP and TCP
Video buffer 16MB pre-alarm and post-alarm
Recording Save to Micro SD card with event mode and continuous mode
Firmware
upgrade Remote upgrade via network
API CGI Interface document
ActiveX Interface(ocx(dll) + document)
Physical RESET Button 1 x Factory Reset Button
Power Source DC 12V/5.0A
Power
Consumption Max. 36W
Weight (Appr.) 3,800g (Wall) / 3,200 g (Ceiling)
LED's Power, Network Connection
Dimension(mm) 185(Ø) x 193.5(H)
Environ-
ment Operating Temperature -25 degree~50 degree Celsius (-13F~122F)
Storage
Temperature -25 degree~60 degree Celsius (-13F~140F)
Software Included
Software NVR Lite (16 Channel), IP Installer (Windows Only)
Package Contents Network Camera, Use Manual, External Power Adaptor, Software CD


