Viso Systems LabSpion User manual

VISO SYSTEMS
LabSpion
Assembly Manual
Revision: 2020-09

Congratulations on purchasing your new Viso Systems product. Before using this
product, please read the Safety Information.
This manual contains descriptions and troubleshooting necessary to install and
operate your new Viso Systems product. Please review this manual thoroughly to
ensure proper installation and operation.
For news, Q&A and support at Viso Systems, visit our website at
www.visosystems.com
© 2020 Viso Systems ApS, Denmark
All rights reserved. No part of this manual may be reproduced, in any form or by any means,
without permission in writing from Viso Systems ApS, Denmark. Information subject to change
without notice. Viso Systems ApS and all affiliated companies disclaim liability for any injury,
damage, direct or indirect loss, consequential or economic loss or any other loss occasioned by
the use of, inability to use or reliance on the information contained in this manual.

3
Contents
1. Package content and weight ................................................................... 4
Main components/assemblies......................................................................................4
Other components included in the package:................................................................5
Assembly parts and cables............................................................................................5
2. Package dimensions and weight.............................................................. 7
3. Assembly................................................................................................ 8
3.1. Mount Base on Stand..............................................................................................8
3.2. Assemble C-Plane Gonio –Lamp Bracket ................................................................9
3.3. Attach Steel Pins to Tower.................................................................................... 10
3.4. Tower + C-Plane Gonio.......................................................................................... 11
3.5. Level Base............................................................................................................. 12
3.6. Slide Tower onto the Base .................................................................................... 12
3.7. Mount Sensor on Tripod ....................................................................................... 13
3.8. Cable connections................................................................................................. 14

4
1. Package content and weight
Main components/assemblies
Base –25Kg
Tower –13Kg
Stand –20kg
C-Plane Head 6Kg
Tripod –5kg
C-Plane Bracket –3Kg
Cali T50 –3kg
Sensor –2Kg

5
Other components included in the package:
Lamp Holder E27 –0,5kg
Cross Hair Laser 0,5kg
Laser Distance Plate 0,1kg
Assembly parts and cables
1 x IEC 2m Cable
1 x USB 5m Cable
1 x RJ45 3m Cable
1 x RJ45 25m Cable

6
2 x Steel Rod with angle
1 x Steel Rod
4 x Caps for Steel Rod
3 x Handles for base
2 x Handles for Lamp Brackets
2 x Lamp Brackets
2 x Spacer for Lamp Brackets
8 x Spacer for C-Plane
3 x Screws for Base
8 x Screws for C-Plane
2 x Thumb screws for Laser
distance Plate
Adaptors: E14, B22, GU10

7
2. Package dimensions and weight
Shipping Packages
Shipping Dimensions
Shipping Volume
Weight
1. Sensor + Cali
560 x 565 x 350 mm
0.111 m3
6 kg
2. Base
510 x 510 x 220 mm
0.057 m3
27 kg
3. Bracket + Tripod +
Assembly Parts
1,655 x 295 x 320 mm
0.156 m3
8 kg
4. Tower + C-plane Gonio
455 x 350 x 1,180 mm
0.188 m3
25 kg
5. Stand
610 x 605 x 820 mm
0.814 m3
24 kg
Total shipping weight: 90 kg.
Total shipping CBM: 1,814 m3
The shipment is done in a total of 5 packages.
Dimensions on a single pallet: L:168 W:90 H:120

8
3. Assembly
3.1. Mount Base on Stand
3 x
3 x

9
3.2. Assemble C-Plane Gonio –Lamp Bracket
7 x
7 x
Countersunk holes away
from C-Plane Head
2 x

10
3.3. Attach Steel Pins to Tower

11
3.4. Tower + C-Plane Gonio

12
3.5. Level Base
Low High
3.6. Slide Tower onto the Base

13
3.7. Mount Sensor on Tripod

14
3.8. Cable connections
Below is a connection diagram showing the cable configuration. Please refer to the
user manual for further details.
Lamp Power
Mains In
