Vitek VTC-IRLED30A User manual

BLACKYELLOWMAGENTACYAN
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VTC-IRLED30A Long Range Infrared Day/Night Bullet
Camera w/480 TVL 24VAC
•1/3" Color CCD with 480 TV Lines Resolution
•30 Infrared LEDs enable Viewing in Total
Darkness up to 80 Feet
•Heavy Duty Weather/Vandal Resistant
Aluminum Construction
•24 VAC Power Input
•Sunshield and Mounting Bracket Included
FEATURES

BLACKYELLOWMAGENTACYAN
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VTC-IRLED30A Long Range Infrared Day/Night Bullet
Camera w/480 TVL 24VAC
Detailed Specifications
Pick up Element
Effective Pixels
Resolution
Minimum lllumination
S/N Ratio
Electronic Shutter
Gamma
Iris Mode
White Balance
Video Output
Lens
BLC
IR LED
Storage Temperature
Operation Temperature
Power Source
Power Consumption
Weight
1/3” Color CCD Image Sensor
771 x 492
480 TV Lines
0 Lux (IR On) / 0.5 Lux @ f2.0 (IR Off)
More than 48dB(AGC off)
1/60 to 1/100,000 sec.
0.45
AES
AWB
1.0 Vp-p composite, 75 Ohm
Standard 6mm (4mm, 8mm, 12mm, and 16mm Optional)
Auto
30 850nm IR LED’s
-22°~140° F (-30°~60° C)
14°~122° F (-10°~50° C)
24VAC
90 mA (IR Off) / 270 mA (IR On)
17.64 oz. / 500g
