Vitek VTC-TTB42R2F User manual

VITEK
VITEK
FEATURES
• 1/3” 2.1 Megapixel Progressive Scan CMOS image sensor
• 2.1 MegaPixel Video Transmission over COAX cable at
distances of up to 1500’ using HD-TVI Technology*
• 2.8~12mm Varifocal Lens (VTC-TTB42R2V) / 3.6mm
Fixed Iris Lens (VTC-TTB36R2F)
• 42 Infrared LED’s with 150’ IR Range (VTC-TTB42R2V) /
36 Infrared LED’s with 120’ IR Range (VTC-TTB36R2F)
• Digital Wide Dynamic Range (D-WDR)
• True Mechanical Day/Night function by ICR
• 3D-DNR Noise Reduction
• IP66 Weather Resistance
• 12VDC Operation
VTC-TTB42R2F
VTC-TTB36R2V
2.1 Megapixel Indoor/Outdoor
HD-TVI IR Bullet Cameras

2 3
Safety Precaution
CAUTION: TO REDUCE THE RISK OF ELECTICAL
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
To prevent electrical shock and risk of fire hazards, do not expose this unit
to rain or moisture and only use specified power source..
Warning :
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
their own expense.
Caution :
Any changes or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user's authority
to operate the equipment.
Main power quality should be that of a typical commercial environment. If the user
of the model requires continued operation during power interruptions, it is
recommended that the device be powered from an uninterruptible power supply
(UPS).
The symbol is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature
accompanying the unit.
The symbol is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electrical shock.

3
Components and Accessories
Overview
This camera series supports both fixed and varifocal lenses. Please note
that the zoom and focus features mentioned below are only available on
the varifocal lens version.
3 4
1
2
56
*Optional
7
8
9
Lens
Sun Shield
Mount Lock
Mount Base
Video Cable
Power Cable
Lens Cover
Zoom*
Focus*
1
2
3
4
5
6
7
8
9
Screws
Drill Template
Camera
User Manual

4 5
Video Connection
Power Connection
Monitor
Video
Power 12VDC
Connect the power connecter to a 12 VDC power adaptor.
Connect the video connecter to a BNC patch cable.

5
Installation
Before start, please make sure that the wall or ceiling is strong enough
to withstand 3 times the weight of the camera. The mounting steps are
as follows:
1. Attach the drill template to
the place where you want to
install the camera, then drill
3 screw holes and 1 cable
hole (if you want to route the
cables through the mounting
base) according to the drill
template
2. Route the cables and connect the power & video cables, then secure
the mounting base to the ceiling or wall with screws.
Ceiling Mounted Wall Mounted

6 7
Installation
3. Loosen the mount lock to adjust the Pan and Tilt of the camera, then
tighten the mount lock to secure the viewing angle adjustments.
4. To adjust the lens, start by removing the Lens Cover, then adjust
the Focus and Zoom levers to achieve a clear image. Replace
the Lens Cover. (if your camera is Fixed lens, please skip this
step)
5. Carefully remove the protective film from the lens to complete the
installation.
90° Tilt
360° Pan
Zoom
Focus
Lens Cover

7
Detailed Specifications VTC-TTB42R2F VTC-TTB36R2V
Image Sensor
Video Compression
Resolution
Effective Pixels
Signal System
Synchronization
Lens
S/R Ratio
Auto Gain Control
Min Illumination
IR LEDs
IR Distance
Color-B/W Auto Switch
Electronic Shutter
White Balance
WB Range
ICR
BLC
WDR
Transmission Distance
Noise Reduction
Video Output
Weather Resistance
Power Supply
working Environment
Weight
Dimensions
1/3” CMOS (AR0330 + NVR2421 + TP2801)
Standard H.264
1080P (2 MegaPixel)
1920(H) x 1080(V)
PAL/NTSC
Internal
>52dB (AGC OFF)
OFF ~44.8dB
0 Lux (LED ON)
Yes
1/50s~ 1/67500s
AWB
2300~9600K
Yes
Yes
Digtial WDR
Up to 1500’ (Depending on cable characteristics & integrity)
Yes
BNC × 1
IP66
DC 12V (±10%)
-4~122 / 10%~90% Humidity
3.6mm Fixed
42
150’
20.81 oz. / 1.30 lbs. / 590g
3.43 x 8.62” (87mm x 219mm) Dia x L
2.8~12mm (Vari-Focal)
36
120’
21.16 oz. / 1.32 lbs. / 600g
3.43 x 8.62” (87mm x 219mm) Dia x L

VITEK
28492 Constellation Road ValenCia, Ca 91355
WWW.ViteKCCtV.CoM
Version 1.0
June 2015
LIMITED PRODUCT WARRANTY
VITEK products carry a three (3) year limited warranty. VITEK warrants
to the purchaser that products manufactured by VITEK are free of any
rightful claim of infringement or the like, and when used in the manner
intended, will be free of defects in materials and workmanship for a
period of three (3) years, or as otherwise stated above, from the date of
purchase by the end user. This warranty is nontransferable and extends
only to the original buyer or end user customer of a VITEK Authorized
Reseller.
The product must have been used only for its intended purpose, and
not been subjected to damage by misuse, willful or accidental damage,
caused by excessive voltage or lightning.
The product must not have been tampered with in any way or the
guarantee will be considered null and void.
This guarantee does not affect your statutory rights.
Contact your local VITEK Reseller should servicing become necessary.
VITEK makes no warranty or guarantee whatsoever with respect to
products sold or purchased through unauthorized sales channels.
Warranty support is available only if product is purchased through a
VITEK Authorized Reseller.
