DU6693Z
Remote Communicaton
Manual

DU6693Z DLP Projecto
r
Remote Communication Manual
1
RC66930718EN01
Table of Contents
The Serial Interface RS-232 Command ........................................................................................2
Communication parameter.........................................................................................................2
Operation commands.................................................................................................................2
Operation command syntax .................................................................................................2
List of operation commands .................................................................................................3
Simulated IR remote controller commands ..............................................................................14
List of simulated IR remote controller commands ....................................................................14
Control the Projector Through a Network..................................................................................15
Cable connection .....................................................................................................................15
Set up the projector for networking ..........................................................................................16
Control the projector through a network ...................................................................................17
Control the projector through a web browser .....................................................................17
Control projector with TCP/IP communication protocol ......................................................20
About Vivitek Support .................................................................................................................21

DU6693Z DLP Projecto
r
Remote Communication Manual
2
RC66930718EN01
The Serial Interface RS-232 Command
This projector supports to control by RS-232 command, there exists two types of RS-232 serial commands:
Operation command: The commands are listed by the OSD menus structure as PICTURE,SIGNAL, SETUP,
INSTALLATION and SERVICE.
Simulated IR remote controller commands: Controls projector via RS-232 command, the commands simulate IR
remote controller and its control keys.
Communication parameter
You can use the serial control command to input commands for projector control or retrieve its operational data
through Windows client terminal software, e.g. Hyper Terminal, with ASCII characters. You need to set up the following
communication parameters in advance:
Item Parameter:
Bit per Second 9600, 19200, 38400 bps
Data Bit 8-bit
Parity None
Stop Bit 1
Flow Control None
Port 7000
The terminal software does not return every command input character.
The transmission performance varies with the length of RS-232 cable, please set the baud rate per
the cable length.
Operation commands
Operation command syntax
An operation command is prefixed by character "op", followed by control commands and settings separated by
space blank [SP], and ended by carriage return pair "CR" and "ASCII hex 0D".Syntax of serial control
commands:
op[SP]<operation command>[SP]<Setting Value>[CR]
op :
A constant indicating this is an operation command.
[SP] :
Indicate one blank space.
[CR] :
Indicate the command ending carriage return pair "CR" and "ASCII hex 0D".
Setting value : Settings of operation command
Types of setup strings Characters of settings Description
Query current setup ? Question mark "?" indicates querying current setup
Setup = <settings> Syntax: Symbol "=" suffixed with setup values
Increase the value + Some settings are changed in steps. Symbol "+"
indicates changing one step up
Decrease the value - Some settings are changed in steps. Symbol "-"
indicates changing one step down
Execute operation command None Certain operation commands execute after input
without further setting or regulators.
Examples:
Control items Input command Projector return message
Query current brightness op bright ? [CR] OP BRIGHT = 101
Set brightness op bright = 127 [CR] OP BRIGHT = 127
Set input signal source to HDMI op input.sel = 0 [CR] OP INPUT.SEL = 0
Reset projection lens to
center position
lens.center
When sending the multiple commands, make sure the return message of the last command is
received before sending out the next one.

DU6693Z DLP Projecto
r
Remote Communication Manual
3
RC66930718EN01
List of operation commands
OSD Function Operation
command
Settings/Return Values Available when
Picture Mode pic.mode ?
=
0 = High Bright
1 = Presentation
2 = Video
3 = User 1
4 = User 2
Projector is turned on.
Input signal is detected
3D mode is turned off.
Brightness Bright ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Contrast contrast ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Saturation saturat ?
=
+
--
0-200
Projector is turned on.
Input signal is detected
Input signal is YUV.
Hue tint ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Input signal is YUV.
Sharpness sharp ?
=
+
-
0-31
Projector is turned on.
Input signal is detected.
Noise Reduction nr ?
=
+
-
0-15
Projector is turned on.
Input signal is detected.
Color Temperature color.temp ?
=
0 = 5400K
1 = 6500K
2 = 7500K
3 = 9300K
4 = Native
Projector is turned on.
Input signal is detected
3D Mode is turned off.
Gamma gamma ?
=
0 = 1.0
1 = 1.8
2 = 2.0
3 = 2.2
4 = 2.35
5 = 2.5
6 = S-Curve
7 = DICOM
Projector is turned on.
Input signal is detected.
Advance/Input Balance
/Red Offset
red.offset ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.

DU6693Z DLP Projecto
r
Remote Communication Manual
4
RC66930718EN01
Advance/Input Balance
/Green Offset
green.offset ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/Input Balance
/Blue Offset
blue.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/Input Balance
/Red Gain
red.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/Input Balance
/Green Gain
green.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/Input Balance
/Blue Gain
blue.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/ HSG
/Red Gain
hsg.r.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/ HSG
/Green Gain
hsg.g.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/ HSG
/Blue Gain
Hsg.b.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/ HSG
/Cyan Gain
hsg.c.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/ HSG/
Magenta Gain
hsg.m.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/ HSG
/Yellow Gain
Hsg.y.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/ HSG
/Red/Saturation
hsg.r.sat ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/ HSG
/Green/Saturation
hsg.g.sat ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/ HSG
/Blue/Saturation
Hsg.b.sat ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.

DU6693Z DLP Projecto
r
Remote Communication Manual
5
RC66930718EN01
Advance/ HSG
/Cyan/Saturation
hsg.c.sat ?
=
+
-
0-200
Projector is turned on.
Input signal is detected.
Advance/ HSG
/Magenta/Saturati on
hsg.m.sat ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
OSD Function Operation
command
Settings/Return Values Note
Advance/ HSG
/Yellow/Saturation
Hsg.y.sat ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Advance/ HSG
/Red/Hue
hsg.r.hue ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Advance/ HSG
/Green/Hue
hsg.g.hue ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Advance/ HSG
/Blue/Hue
Hsg.b. hue ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Advance/ HSG
/Cyan/Hue
hsg.c. hue ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Advance/ HSG
/Magenta/Hue
hsg.m. hue ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Advance/ HSG
/Yellow/Hue
Hsg.y. hue ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Advance/ HSG
White/Red Gain
hsg.wr.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Advance/ HSG
/White/Green Gain
hsg.wg.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Advance/ HSG
/White/Blue Gain
Hsg.wb.gain ?
=
+
-
0-200
Projector is turned on.
Input signal is detected
Advance/ HSG
Reset
hsg.reset (execute) Projector is turned on.
Input signal is detected

DU6693Z DLP Projecto
r
Remote Communication Manual
6
RC66930718EN01
SIGNAL
OSD Function Operation
command Settings/Return Values Note
Input Select input.sel ?
= 0 = HDMI I
1 = DisplayPort
2 = DVI-D
3 = VGA
4 = Component / BNC
5 = HDBaseT
Projector is turned on.
EDID Mode
HDMI
Edid.mode.hdmi ?
=
0 = Default
1 = 1024x768@60
2 = 1280x720@60
3 = 1280x800@60
4 = 1280x1024@60
5 = 1600x1200@60
6 = 1680x1050@60
7 = 1920x1080@60
Projector is turned on.
Adjustment is for current input
source.
EDID Mode
DisplayPort
Edid.mode.dp ?
=
0 = Default
1 = 1024x768@60
2 = 1280x720@60
3 = 1280x800@60
4 = 1280x1024@60
5 = 1600x1200@60
6 = 1680x1050@60
7 = 1920x1080@60
Projector is turned on.
Adjustment is for current input
source.
EDID Mode
DVI-D
Edid.mode.dvi ?
=
0 = Default
1 = 1024x768@60
2 = 1280x720@60
3 = 1280x800@60
4 = 1280x1024@60
5 = 1600x1200@60
6 = 1680x1050@60
7 = 1920x1080@60
Projector is turned on.
Adjustment is for current input
source.
EDID Mode
VGA
Edid.mode.vga ?
=
0 = Default
1 = 1024x768@60
2 = 1280x720@60
3 = 1280x800@60
4 = 1280x1024@60
5 = 1600x1200@60
6 = 1680x1050@60
7 = 1920x1080@60
Projector is turned on.
Adjustment is for current input
source.
EDID Mode
HDBaseT
Edid.mode.hdbt ?
=
0 = Default
1 = 1024x768@60
2 = 1280x720@60
3 = 1280x800@60
4 = 1280x1024@60
5 = 1600x1200@60
6 = 1680x1050@60
7 = 1920x1080@60
Projector is turned on.
Adjustment is for current input
source.
Auto Source auto.src ?
= 0 = Off
1 = On
Projector is turned on.

DU6693Z DLP Projecto
r
Remote Communication Manual
7
RC66930718EN01
OSD Function Operation
command Settings/Return Values Note
Color Space color.space ?
= 0 = Auto
1 = YPbPr (Rec 709)
2 = YcbCr (Rec 601)
3 = RGB-PC (0-255)
4 = RGB-Video (16-
2
35)
Projector is turned on.
The source is detected.
Aspect Ratio aspect ?
= 0 = 5:4
1 = 4:3
2 = 16:10
3 = 16:9
4 = 1.88
5 = 2.35
6 = LetterBox
7 = Source
8 = Native
Projector is turned on.
The source is detected.
Overscan zoom ?
= 0 = Off
1 = On
Projector is turned on.
The source is detected.
Background background ?
= 0 = Logo
1 = Black
2 = Blue
Projector is turned on.
Test Pattern pattern ?
=
0 = Off
1 = CrossHatch
2 = Color Bar
3 = Checkboard
4 = H Burst
5 = V Burst
6 = White
7 = Red
8 = Green
9 = Blue
10 = Black
Projector is turned on.
3D model is not enabled.
VGA Setup/H Total h.total ?
=
+
-
0-200
Projector is turned on.
The source is detected.
The source is from VGA or
Component/BNC Input.
VGA Setup/H Start h.pos ?
=
+
-
0-200
Projector is turned on.
The source is detected.
The source is from VGA or
Component/BNC Input.
VGA Setup/H Phase h.phase ?
=
+
-
0-31
Projector is turned on.
The source is detected.
The source is from VGA or
Component/BNC Input.
VGA Setup/V Start v.pos ?
=
+
-
0-200
Projector is turned on.
The source is detected.
The source is from VGA or
Component/BNC Input.
Auto Sync auto.img (execute) Projector is turned on.
The source is detected.

DU6693Z DLP Projecto
r
Remote Communication Manual
8
RC66930718EN01
SETUP
OSD Function Operation
command Settings/Return Values Note
Language lang ?
= 0 = English
1 = French
2 = Spanish
3 = German
4 = Portuguese
5 = Chinese Simplified
6 = Chinese Traditional
7 = Japanese
8 = Korean
Projector is turned on.
Laser Mode laser.mode ?
=
0 = ECO
1 = Normal
2 = Power Level
Projector is turned on.
Custom Power Level laser.power ?
= 35 - 100
Projector is turned on.
Laser mode is set to Power
Level.
Custom Power Level is set to Off
Constant Brightness Laser.cbc.enable ?
=
0 = Off
1 = On
Laser model is set to Power Level
Startup Logo Startup.logo ?
=
0 = Off
1 = On
Projector is turned on.
Projector is not at ECO standby
mode.
Dynamic Black dblack ?
=
0 = Off
1 = On
Projector is turned on.
Projector is not at 3D mode.
Constant Brightness is set to Off.
Laser Off Timer laser.off.timer ?
=
0 = Disable
1 = 0.5 seconds
2 = 1.0 seconds
3 = 1.5 seconds
4 = 2.0 seconds
5 = 3.0 seconds
6 = 4.0 seconds
Projector is not at 3D mode
Constant Brightness is set to Off
3D
3D Format
3d.format = ? 0 = Off
1 = Auto
2 = Side-By-Side (Half)
3 = Top-And-Bottom
4 = Frame Sequential
Projector is turned on.
3D
DLP Link
3d.dlplink ?
=
0 = Off
1 = On
Projector is turned on.
3D Format is not set to Off or
A
uto.
3D
Eye Swap
3d.swap ?
=
0 = Normal
1 = Reverse
Projector is turned on.
3D Format is enabled.
3D
3D 24Hz Display
3d.144hz ?
=
0 = 96Hz
1 = 144Hz
Projector is turned on.
3D Format is enabled.
The option is for 24Hz 3D timing
only
3D
Sync Reference
3d.syncref ?
=
0 = Internal
1 = External
Projector is turned on.
3D Format is enabled.
3D
sync delay
3d.syncdelay ?
=
0 – 100 Projector is turned on.
3D Format is enabled.

DU6693Z DLP Projecto
r
Remote Communication Manual
9
RC66930718EN01
OSD Function Operation
command Settings/Return Values Note
Trigger1 trig.1 ?
=
0 = Off
1 = On
Projector is turned on.
Trigger2 trig.2 ?
=
0 = Off
1 = On
Projector is turned on.
Control Panel Lock keypad.lock ?
=
0 = Off
1 = On
Projector is turned on.
Security Lock security.lock ?
=
Password is composed of
four characters, U, D, L
and R as cursor.
U: Up
D: Down
L: Left
R: Right
Projector is turned on.
Disable Security Lock security.unlock (execute) Projector is turned on.
Projector ID Control control.id ?
=
0 = Disable ID Control
1 - 99 = Enable ID control
and set Control ID
Projector is turned on.
Menu Position osd.menupos ?
=
0 = Center
1 = Top Left
2 = Top Right
3 = Bottom Left
4 = Bottom Right
Projector is turned on.
INSTALLATION
OSD Function Operation
command Settings/Return Values Note
Projection Mode proj.mode ?
=
0 = Front
1 = Rear
2 = Ceiling + Front
3 = Ceiling + Rear
4 = Auto-Front
Projector is turned on.
High Altitude altitude ?
=
0 = Sea Level
1 = A1(4000ft/1219m)
2 = A2(8000ft//2438m)
Projector is turned on.
Standby Mode Standby.mode ?
=
0 = Network Standby
1 = Eco
Projector is turned on.
Remote sensor is not set to
HDBaseT
RS-232 Channel is not set to
HDBaseT
Remote Sensor ir.enable =
?
0 = Front / Back
1 = Front
2 = Back
3 = HDBaseT
4 = Off
Projector is turned on.
Front and rear IR receivers are
disabled when the option is set to
HDBasT or Off.

DU6693Z DLP Projecto
r
Remote Communication Manual
10
RC66930718EN01
OSD Function Operation
command Settings/Return Values Note
Network
IP Address net.ipaddr ?
=
<string>
Projector is turned on.
Network
Subnet Mask net.subnet ?
=
<string>
Projector is turned on.
Network
Gateway net.gateway ?
=
<string>
Projector is turned on.
Network
DNS net.dns ?
=
<string>
Projector is turned on.
Network
DHCP net.dhcp ?
=
0 = Off
1 = On
Projector is turned on.
Network
MAC adress
net.mac ? <string> Projector is turned on.
Lens Setting
Lens Lock
lens.lock ?
=
0 = Off
1 = On
Projector is turned on.
Lens Setting
Lens Control
zoom.in Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
zoom.in.2 Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
zoom.in.3 Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
zoom.out Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
zoom.out.2 Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
zoom.out.3 Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
focus.near Projector is turned on.
Lens Lock is set to Off(0).
Lens Setting
Lens Control
focus.near.2 Projector is turned on.
Lens Lock is set to Off(0).
Lens Setting
Lens Control
focus.near.3 Projector is turned on.
Lens Lock is set to Off(0).
Lens Setting
Lens Control
focus.far Projector is turned on.
Lens Lock is set to Off(0).
Lens Setting
Lens Control
focus.far.2 Projector is turned on.
Lens Lock is set to Off(0).
Lens Setting
Lens Control
focus.far.3 Projector is turned on.
Lens Lock is set to Off(0).
Lens Setting
Lens Control
lens.up Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
lens.up.2 Projector is turned on.
Lens Lock is set to Off (0).

DU6693Z DLP Projecto
r
Remote Communication Manual
11
RC66930718EN01
OSD Function Operation
command Settings/Return Values Note
Lens Setting
Lens Control
lens.up.3 Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
lens.down Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
lens.down.2 Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
lens.down.3 Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
lens.right Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
lens.right.2 Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
lens.right.3 Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
lens.left Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
lens.left.2 Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Control
lens.left.3 Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Lens Type lens.type ?
=
0 = non-UST
1 = UST lens
Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Center Lens lens.center (execute)
Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Load memory setting lens.load = 0 to 7
Memory 1 to 8
Projector is turned on.
Lens Lock is set to Off (0).
Any memory set has been stored
in the pro
j
ector.
Lens Setting
Save memory setting lens.save = 0 to 7
Memor
y
1 to 8
Projector is turned on.
Lens Lock is set to Off (0).
Lens Setting
Clear memory setting lens.clear = 0 to 7
Memory 1 to 8
Projector is turned on.
Lens Lock is set to Off (0).
Any memory set has been stored
in the projector.
Keystone
Horizontal h.keystone
?
=
+
-
-30 to 30
Projector is turned on.
Adjusting Keystone will reset the
settings of Corner Adjustment.
Keystone
Vertical v.keystone
?
=
+
-30 to 30
Projector is turned on.
Adjusting Keystone will reset the
settings of Corner Adjustment.
Keystone
Reset keystone.reset (execute)
Projector is turned on.

DU6693Z DLP Projecto
r
Remote Communication Manual
12
RC66930718EN01
OSD Function Operation
command Settings/Return Values Note
Corner Adjustment
Horizontal direction of
upper left corner
4corner.ulx ?
=
+
-
0 to 60 Projector is turned on.
Adjusting Corner Adjustment will
reset the settings of. Keystone.
Corner Adjustment
Vertical direction of
upper left corner
4corner.uly ?
=
+
-
0 to 60 Projector is turned on.
Adjusting Corner Adjustment will
reset the settings of. Keystone.
Corner Adjustment
Horizontal direction of
upper right corner
4corner.urx ?
=
+
-
0 to 60 Projector is turned on.
Adjusting Corner Adjustment will
reset the settings of. Keystone.
Corner Adjustment
Vertical direction of
upper right corner
4corner.ury ?
=
+
-
0 to 60 Projector is turned on.
Adjusting Corner Adjustment will
reset the settings of. Keystone.
Corner Adjustment
Horizontal direction of
lower left corner
4corner.llx ?
=
+
-
0 to 60 Projector is turned on.
Adjusting Corner Adjustment will
reset the settings of. Keystone.
Corner Adjustment
Vertical direction of
lower left corner
4corner.lly ?
=
+
-
0 to 60 Projector is turned on.
Adjusting Corner Adjustment will
reset the settings of. Keystone.
Corner Adjustment
Horizontal direction of
lower right corner
4corner.lrx ?
=
+
-
0 to 60 Projector is turned on.
Adjusting Corner Adjustment will
reset the settings of. Keystone.
Corner Adjustment
Vertical direction of
lower right corner
4corner.lry ?
=
+
-
0 to 60 Projector is turned on.
Adjusting Corner Adjustment will
reset the settings of. Keystone.
Corner Adjustment
Reset
4corner.reset (execute) Projector is turned on.
RS-232
Baud Rate
rs232.speed ?
=
0 = 38400
1 = 19200
2 = 9600
Projector is turned on.
RS-232
Channel
rs232.channel ?
=
0 = Local
1 = HDBaseT
Projector is turned on.
Auto Power Off auto.powoff ?
= 0 = Off
1 = On
Projector is turned on.
Auto Power On auto.powon ?
=
0 = Off
1 = On
Projector is turned on.
Message Box osd.msgbox ?
=
0 = Off
1 = On
Projector is turned on.
Screen Format screen.format ?
=
0 = 16:10
1 = 16:9
2 = 4:3
Projector is turned on.
Screen Fit screen.shift ?
=
A
djustable range if screen
format is set to
16:10 : 0
16:9 : -60 ~ 60
4:3 : -160 ~160
Projector is turned on.

DU6693Z DLP Projecto
r
Remote Communication Manual
13
RC66930718EN01
SERVICE
OSD Function Operation
command Settings/Return Values Note
Model model ? <String> Projector is turned on.
Serial Number ser.no ? <String> Projector is turned on.
Software Version sw.ver ? <String> Projector is turned on.
Signal Information
Signal Format
signal ? <String> Projector is turned on.
Signal Information
H/V Refresh Rate
h.refresh
v.refresh
? <String> Projector is turned on.
Signal Information
Pixel Clock pixel.clock ? <number>
Projector is turned on.
Filter Hours filter.hours ? <string> Projector is turned on.
Power On Time proj.runtime ? <number> Projector is turned on.
Factory Reset fact.reset (execute) Projector is turned on.
Others
Function Operation
command
Settings/Return Values Note
Power On power.on (execute) Projector is set to Network
Standby
Power Off power.off (execute) Projector is turned on.
Projector Status status ? 0 = Standby
1 = Warm Up
2 = Imaging
3 = Cooling
Projector is turned on or set to
Network Standby
Blank/Shutter shutter ?
=
+ => Close the shutter
- =>Open the shutter
Projector is turned on.
Freeze freeze 0 = Unfreeze
1 = Freeze
Projector is turned on.
The source is detected
Error Detection errcode ? <string> Projector is turned on.
Note: The projector returns string "NA" when the input command does not apply to current projector status or setup.

DU6693Z DLP Projecto
r
Remote Communication Manual
14
RC66930718EN01
Simulated IR remote controller commands
This control command simulates the IR remote controller and its control keys. It shares the same syntax of
operation command. It begins with characters "ky", followed by control commands and settings separated by
space blank [SP], and ended by carriage return pair "CR" and "ASCII hex 0D".Control command syntax:
ky[SP]<operation command>[CR]
Examples:
Power On ky power.on [CR]
Power Off ky power.off [CR]
List of simulated IR remote controller commands
Item Function Operation
command Description
1 Power On power.on Power On
2 Power Off power.off Power Off
3 Menu menu Display OSD menu
4 Exit exit Exit
5 Enter enter ENTER key
6 Up up Move cursor upward or change upward
7 Down down Move cursor downward or change downward
8 Left left Move cursor to the left or change to the left
9 Right right Move cursor to the right or change to the right

DU6693Z DLP Projecto
r
Remote Communication Manual
15
RC66930718EN01
Control the Projector Through a Network
This projector supports the following methods in remotely controlling the projector through a network:
Control projector through web browser.
Control projector with RS-232 control or simulated IR commands via TCP/IP communication protocol.
Cable connection
You may connect the projector to a PC by a RJ-45 cable or through a certified HDBaseT transmitter for controlling the
projector.
Connect the projector to a personal computer
For connection through LAN, connect the hub through to the projector's HDBaseT/LAN port as below illustration.
Connect with a certified HDBaseT transmitter
You may connect the projector to a certified HDBaseT transmitter to transmit video and networking control signal by
one RJ-45 cable. Please connect the PC to the transmitter with one RJ-45 cable or RS-232 cable, then connect
HDBaseT transmitter to the HDBaseT/LAN terminal of the projector by one RJ-45 cable, please refer to below
illustration.

DU6693Z DLP Projecto
r
Remote Communication Manual
16
RC66930718EN01
Set up the projector for networking
Before performing projector control by network, please configurate the network setting and make sure Standby
Power is set to On.
Network and RS-232 control are disabled if Standby Power is set to off for reducing the standby power
consumption (less 0.5W). Please make sure Standby Power is set to On before controlling the
projector via RS-232 or LAN.
IP Address: Set DHCP “OFF” and specify an IP address manually. Use the ◄► button to select the number in the
address to change. Use the ▲▼ button to increase or decrease the number in the IP address.
Subnet Mask: Set the sub mask. The input method is the same as the setting for IP address.
Gateway: Set the gateway. The input method is the same as the setting for IP address.
DNS: Set the DNS. The input method is the same as the setting for IP address.
DHCP: Enable or disable the DHCP service. When DHCP is set to ON, the DHCP server of the domain will assign
an IP address to the projector. The IP address will appear in the IP address window and you don't need to set the
IP address. Otherwise, the domain does not or cannot assign any IP address, and 0. 0. 0. 0 is shown on the IP
address window.
Apply: Confirm the changes on this menu page.
MAC Address: Show projector’s MAC Address.

DU6693Z DLP Projecto
r
Remote Communication Manual
17
RC66930718EN01
Control the projector through a network
Control the projector through a web browser
Open the web browser of your control PC; type the projector's IP address. The left of the web page shows below four options:
Projector Status: Display current projector status and software information.
Crestron: Display Crestron web control page.
Alert Mail Setup: Settings for projector abnormality email reminders. In case of any abnormality the project
sends emails to preset users.
Projector Status
This page shows the current status of the projector.
System
Model : Projector model name
Software Version : The version of the software installed in the projector
System Status : Current projector startup status
Display Source : Display the current input source.
Laser Hours : Display current laser light source usage.
Error Status : Display current projection mode
Network Information (RJ45 version)
LAN Version Ethernet software version.
IP address Current IP address setting of the projector
Subnet mask Current subnet mask setting of the projector
Default gateway Current default gateway setting of the projector
DNS server Current DNS server setting of the projector
MAC address Current MAC address of the projector

DU6693Z DLP Projecto
r
Remote Communication Manual
18
RC66930718EN01
Crestron RoomView
This page shows Crestron control page for projector control, the available options are as below options.
Power: Press this button to turn power on or off.
Source List: Switch projector input sources. Press the ▲or ▼arrow key to scroll through the dropdown list of
available input sources
Image adjust options
Press the ◄or ►arrow key to scroll through available adjustment options.
Freeze: Freeze current projection screen. The projection screen prompts the "Still open" message after the freeze
function enabled. Press the Freeze button again to unfreeze the screen.
Contrast: Click this button and the adjustment window displays. Click the ◄► arrow keys to adjust contrast.
Brightness: Click this button and the adjustment window displays. Click the ◄► arrow keys to adjust brightness.
Sharpness: Click this button and the adjustment window displays. Click the ◄► arrow key to adjust sharpness.
Zoom: Zoom the projection image. Click the "+" key to zoom in and "-" to zoom out. You may click the four
arrow keys in the window to move the zoomed projection image.

DU6693Z DLP Projecto
r
Remote Communication Manual
19
RC66930718EN01
Control key window
This window simulates keys on the remote controller and control panel.
Enter: Confirm and select function options
Menu: Press to display OSD menu. Press again to exit it.
Auto: Run the auto image adjustment function.
Blank: Pause the image projection, i.e. the projection image is masked. Press again to resume the projection.
Source: The signal source menu displays. Press to display signal source in the projection screen.
Tools: Check Crestron equipment for its setup
Info: Display current projector status and Crestron setup.
Alert Mail Setup
This projector can send emails with projector abnormality messages to preset users. Set up the projector
before enabling this function:
SMTP Server : Set up SMTP server name.
Port : Set up port name.
User Name : Input user name for the projector to send the reminding message through a SMTP
server
Password : Input password.
E-mail Alert : Enable or Disable reminding message
From : Set up sender’s email address
To : Set up receiver’s email address
CC : Set up email address of the email send a copy of a business letter or an e-mail to
someone
Projector Name : Set up projector name or ID.
Location : Set up projector installation location.
A
pply : Press this button
t
o confirm changes you have made.
Send Test Mail : Send test email. Press this button to validate email settings after setup is completed.
