Vivotek IB8156-C User manual

1
M
icro
SD
Reset button
Lens
Fastening ring
MicroSD card slot
IB8156-C/8168-C; IB8156-G/8168-G
Quick Installation Guide
Before you begin:
You can connect the Ethernet
cable to a PC or laptop for a live
view. (See page 5). Raise the
camera to the estimated position,
and evaluate the eld of view by
turning the mount bracket and
the shooting angle.
1. The camera can only be powered by Power over Ethernet
(PoE).
2. The camera can only be installed in an indoor environment.
3. Install the SD card if local storage is preferred.
NOTE:
Part no.: 625025300G
All manuals and user guides at all-guides.com
all-guides.com

2
30mm
Mounting Procedure:
1. Attach the alignment sticker to a preferred location.
3. Install the mount bracket using the self-tapping screws (use
anchors with hard surfaces.)
2. Drill a 30mm cabling hole if preferred.
All manuals and user guides at all-guides.com

3
4. Pass the Ethernet cable through the cabling hole or along the
wall.
Below is the sample screen for IB8156-G and IB8168-G.
All manuals and user guides at all-guides.com

4
5. If the camera is installed upside down, re-install the front cover
so that the protruding edge is on top.
All manuals and user guides at all-guides.com

5
Connect the camera to a PC or laptop. Install and use the IW2
utility to discover your camera on LAN. Double-click on the
camera entry to open a web session.
Watching the video:
0002D1730202
00-02-D1-73-02-02 192.168.5.151 FD8168
IW2
Browser
All manuals and user guides at all-guides.com

6
