Vivotek AM-105 User manual

IP Surveillance
Installation Guide
VIVOTEK Fixed Dome Series
AM-105 Recessed-mount Bracket
Rev. 1.0
Corresponding part number: 900026800G

2
AM-105 Recessed-mount Bracket Mechanical Drawing
205
146
90
66.2
71.5
Compatible VIVOTEK Cameras
I
Fixed Dome series FD8167, FD8138-H
You may also refer to VIVOTEK's website for the list of supported models. Support for other models can
be available through time.
77.3°
5M
121°
5M
Before installing your camera, make sure the built-in PIR (Passive Infrared Sensor) can be
directed toward the area of interest, where possible intrusion may occur. (The sensitivity
of PIR sensor depends on the object size and temperature differences between the object
and the background environment.)
Top View Side View
IMPORTANT:
Package Contents
• Recessed-mount bracket
• Screws: 3x round head M4x8L; 3x truss head
M3x8L .
• 3x adhesive foam washers
• Alignment sticker
Revision History
• Rev. 1.0: Initial release.
• Screwdriver: T10 stardriver

3
English
Installation
II
190mm
24mm
Up to
Ceiling Hole Template Sticker
186mm
Mounting Hole Denitions
1. Determine a secure location for the recessed-mount bracket.
2. Drill or cut a 190mm hole (in diameter). The maximum thickness of the ceiling/board is
24mm. The ceiling should be able sustain at least a weight of 1.4kg.
3. Remove dome cover from the
camera using the stardriver
included in kit.

4
5-1. Install camera to the recessed-mount bracket by driving 3 screws.
4. Use the included stardriver to detach the dome cover from the recessed mount bracket.
FD8182, FD9171-HT, FD9181-HT, FD816B

5
English
NOTE:
1. Connect and route cables before you secure the recessed-mount bracket to a ceiling.
2. For details on the cable connections with each camera, please refer to their Quick
Installation Guide.
FD8167 and FD8138-H
5-2. Attach foam washers to the top of
screw holes.
5-3. Install camera to the bracket.
Foam washers • 3x round head M4x8L

6
7. Use a #2 Phillips screwdriver to loosen the clamping plates (see drawing below) and
insert the recessed-mount bracket through the hole in the ceiling.
6. Pass cables through the routing hole and connect cables to the camera.

7
English
8. Use a #2 Phillips screwdriver to move the clamping plates down so that the ceiling/
boardiscaughtbetweentheclampsandtheangeontheothersideoftheceiling.
Clockwise Counter-
clockwise
9. Adjust shooting angle and check for a satisfactory image over a web session. When
you have a satisifactory live view, tighten the tilt screw, and secure the dome cover
from below the ceiling using the T10 stardriver.

8
10. You are done with the installation.
