Vivotek SD7151 User manual

EN-1
English
Warning Before Install
Contact your distributor when
such cases happen.
Refer to your user's manual for the
operating temperature.
Power off the Network Camera
as soon as it is found smoking or
smelt unusual.
Do not touch the Network Camera
when it's lightening.
Do not disassemble the Network
Camera.
Do not drop the Network Camera.
Do not insert any object into the
Network Camera, such as needles.
Do not manually pan and tilt the
Network Camera when the power is
on.

EN-2
Package Contents
1
Power adapter
Software CD
SD7151
O-ring and screws
Warranty card
Black cover / Dome cover
Wall mount bracket
RJ45 female/female coupler Quick installation guide
Alignment sticker

EN-3
English
Inner view
Reset button
Lens
Outer view
Physical Description
2
Status LED
Ethernet 10/100
RJ45 plug
Audio out (green)
Microphone in (pink)
Power cord socket (black)
General I/O
terminal block
Earth

EN-4
Hardware Installation
3
Mounting the Network Camera
1. Attach the alignment sticker to the wall.
2. Drill four pilot holes into the wall.
3. Attach the black cover to the Network Camera using the supplied four black screws.
4. Fix the dome cover to the Network Camera and secure it by rotating it clockwise.
5. Loosen the three screws on the front opening of the wall mount bracket.
6. Place the O-ring on the front opening of the wall mount bracket.
7. Feed the cables through the front opening of the wall mount bracket and pull them
from wall outlet.
8. Attach the Network Camera to the wall mount bracket by tightening the three
screws on the front opening of the wall mount bracket.
9. Fasten the wall mount bracket to the wall.
1
2
3
4
5
678
9

EN-5
English
Network Deployment
4
P
OWE
RC
OLLIS
ION
LINK
R
ECEIVE
P
ARTITION
12345
1. If you have external devices such
as sensors and alarms, make
connection from general I/O terminal
block.
2. Use the supplied RJ45 female/female
coupler to connect the Network Camera
to a switch.
Use Catagory 5 Cross Cable when
Network Camera is directly connected
to PC.
3. Connect the power cable from the
Network Camera to a power outlet.
G N D : Ground
DI4: Digital Input
DI3: Digital Input
DI2: Digital Input
DI1: Digital Input
G N D : Ground
N.O. : RELAY_NO
COM. : RELAY_COM
+12V : Power, 12V DC
(AC 24V 2A)

EN-6
1. Install the "Installation Wizard 2" under the Software Utility directory from software CD.
2. The program will conduct analyses on your network environment. After your network is
analyzed, please click on the "Next" button to continue the program.
3. The program will search the VIVOTEK Video Receivers, Video Servers or Network
Cameras on the same LAN.
4. After searching, the main installer window will pop up. Click on the MAC that
matches the one labeled on the side of the camera lens or S/N number on the
label of carton to connect the Internet Explorer to the Network Camera.
0002D17151CD
1
2
Model No.:SD7151
P/N: 100043690G
F/W Ver.: 0100G
CARTON OF NO. 01
MAD E I N TAIWAN
!!0!!
Q 't y: 1 PC S
EAN: 4712123671550
S/N: 0002D17151CD
RoHS
0002D17151CD
Installation
Wizard 2
IW
2
Assigning IP Address
5

EN-7
English
For further setup, please refer to user's manual on the software CD.
Ready to Use
6
1. Access to the Network Camera from the Internet.
2. Retrieve live video through web browsers or recording software.
