VOCA TC-X User manual
TC-X with Touch Faucet
Installaon Instrucon
IMPORTANT!
• Please read all instrucons carefully before installing or using the appliance.
• Please make sure you check your household water pressure before installing the appli-
ance. The recommended water pressure is between 1-3 kg.
• Due to the nature of the installaon and the requirement to operate on the household’s
plumming system, we recommend that any installaon work is being carried out by
competent and qualified individuals.
• Before proceding with the installaon please make sure that the area is safe and proper-
ly cleaned.
• In the event that a new hole needs to be drilled for the faucet, adequate tools will need
to be used depending on the area and environment.
• Please ensure that the mains water is turned off during the whole procedure and unl
sasfied that there will be no issues or leakage.
• Please ensure to install the unit in a safe place, away from dirt, water, rain and excessive
sunlight. Cables and pipes should not be squeezed or bent to avoid damage. Please hook
the appliace using the holes on the back as indicated and make sure it is in a straght and
vercal posion (it is not recommended to install the appliance horizontally).
• To ensure maximum efficiency and durability, the appliance has a ± 10% quanty
tolerance when releasing the water.
• The warranty offered on the appliace does not cover consumables and installaon parts
(tubes, pipes, juncon connectors, valves, etc).
• As walls and environments can vary, wall screws are not supplied. Please make sure that
you choose suitable opons depending on the situaon.
• Before proceeding with the installaon please make sure that everything is in order. If
the goods have been damaged during shipping, please contact the customer support
immediately.
• Please follow the installaon instrucons and the user manual on how to operate the
appliance carefully. Failure to adhere to this will cause the warranty to be void.
• This appliance is intended for households and similar applicaons (e.g. staff kitchen
areas in shops/offices/etc, rural properes, for clients in hotels/motels/etc, bed and
breakfast).
• Please pay parcular aenon immediately aer using the appliance/water tap (espe-
cially with higher temperature sengs) as residual heat may be present for some me
aer use.
Checklist
IMPORTANT!
• Please read all instrucons carefully before installing or using the appliance.
• Please make sure you check your household water pressure before installing the appli-
ance. The recommended water pressure is between 1-3 kg.
• Due to the nature of the installaon and the requirement to operate on the household’s
plumming system, we recommend that any installaon work is being carried out by
competent and qualified individuals.
• Before proceding with the installaon please make sure that the area is safe and proper-
ly cleaned.
• In the event that a new hole needs to be drilled for the faucet, adequate tools will need
to be used depending on the area and environment.
• Please ensure that the mains water is turned off during the whole procedure and unl
sasfied that there will be no issues or leakage.
• Please ensure to install the unit in a safe place, away from dirt, water, rain and excessive
sunlight. Cables and pipes should not be squeezed or bent to avoid damage. Please hook
the appliace using the holes on the back as indicated and make sure it is in a straght and
vercal posion (it is not recommended to install the appliance horizontally).
• To ensure maximum efficiency and durability, the appliance has a ± 10% quanty
tolerance when releasing the water.
• The warranty offered on the appliace does not cover consumables and installaon parts
(tubes, pipes, juncon connectors, valves, etc).
• As walls and environments can vary, wall screws are not supplied. Please make sure that
you choose suitable opons depending on the situaon.
• Before proceeding with the installaon please make sure that everything is in order. If
the goods have been damaged during shipping, please contact the customer support
immediately.
• Please follow the installaon instrucons and the user manual on how to operate the
appliance carefully. Failure to adhere to this will cause the warranty to be void.
• This appliance is intended for households and similar applicaons (e.g. staff kitchen
areas in shops/offices/etc, rural properes, for clients in hotels/motels/etc, bed and
breakfast).
• Please pay parcular aenon immediately aer using the appliance/water tap (espe-
cially with higher temperature sengs) as residual heat may be present for some me
aer use.
Checklist
IMPORTANT!
• Please read all instrucons carefully before installing or using the appliance.
• Please make sure you check your household water pressure before installing the appli-
ance. The recommended water pressure is between 1-3 kg.
• Due to the nature of the installaon and the requirement to operate on the household’s
plumming system, we recommend that any installaon work is being carried out by
competent and qualified individuals.
• Before proceding with the installaon please make sure that the area is safe and proper-
ly cleaned.
• In the event that a new hole needs to be drilled for the faucet, adequate tools will need
to be used depending on the area and environment.
• Please ensure that the mains water is turned off during the whole procedure and unl
sasfied that there will be no issues or leakage.
• Please ensure to install the unit in a safe place, away from dirt, water, rain and excessive
sunlight. Cables and pipes should not be squeezed or bent to avoid damage. Please hook
the appliace using the holes on the back as indicated and make sure it is in a straght and
vercal posion (it is not recommended to install the appliance horizontally).
• To ensure maximum efficiency and durability, the appliance has a ± 10% quanty
tolerance when releasing the water.
• The warranty offered on the appliace does not cover consumables and installaon parts
(tubes, pipes, juncon connectors, valves, etc).
• As walls and environments can vary, wall screws are not supplied. Please make sure that
you choose suitable opons depending on the situaon.
• Before proceeding with the installaon please make sure that everything is in order. If
the goods have been damaged during shipping, please contact the customer support
immediately.
• Please follow the installaon instrucons and the user manual on how to operate the
appliance carefully. Failure to adhere to this will cause the warranty to be void.
• This appliance is intended for households and similar applicaons (e.g. staff kitchen
areas in shops/offices/etc, rural properes, for clients in hotels/motels/etc, bed and
breakfast).
• Please pay parcular aenon immediately aer using the appliance/water tap (espe-
cially with higher temperature sengs) as residual heat may be present for some me
aer use.
Checklist
1x Touch Faucet 1x
1x lter
Faucet installation
components:
1x black O-ring seal
1x pressure regulator
1x O-ring seal
1x black washer
1x metal washer
1x hex nut
Mains water adapter: Push-in adapters:Water hammer prevention:
Touch Faucet Main Unit Filter pack: Water tube:
1x wall mount
1x lter head
1x T-joint adapter
1x ball valve
1x T-adapter
3x corner
adapter
1x
(will need to be cut to connect
dierent sections)
W
A
L
L
Drilling the hole for the faucet
Find a suitable place on the counter/surface (about 5cm
away from the sink). Drill a hole of 12mm ø.
Approx.
5cm
Wear safety glasses at all times! It is recommended to use
suitable tools and materials depending on surface require-
ments.
1
Follow the order described in the picture on the right.
Tighten the bolt enough to make sure the faucet is
steady and in place, making sure not to overtighten it to
avoid damaging the rubber seal.
Please take care not to damage or twist the faucet cables
during this process!
Find a safe place where the Main Unit can be installed
(aprox. 20cm below the countertop). Also make sure
there is enough space underneath the Main Unit to avoid
bending the cable (aprox. +5cm).
Drive two wall screws (not supplied) at the appropriate
distance (for convenience, you can use this paper as a
guide).
Hang the Main Unit using the holes on the back. Please
make sure that the unit is straight and stable.
Connect the water tube from the Faucet to the Main
Unit’s water outlet connector.
Connect the Faucet control cable into the appropiate
connector on the Main Unit.
Please install the Main Unit in a safe place away from
possible hazards like sources of heat, dust and water.
Make sure that the power supply is suitable for the safe
operation of the Voca TC-X.
When deciding the position of the Main Unit, please allow
some extra space for the filter as explained in the next
steps.
01
02
03
2x
(not supplied)
Installing the faucet
Installing the Main Unit
Free space
for filter
Note:
2 3
Note:
Note:
04
Please read the filter manufacturer’s instructions
carefully before proceeding.
Find a suitable and safe place, ideally keeping a short
distance for each section.
When deciding the location, please allow enough space
underneath the filter for future cartridge substitutions.
Attach the wall mount to the filter head with 4x screws.
Please take care not to damage the filter head when
applying the screws.
Apply the wall mount/filter head to the chosen location
with 2x suitable screws (not supplied).
Please consider the water tube path both from the water
mains to the filter and from the filter to the Voca TC-X Main
unit. Make sure that the path is safe and free from
obstacles.
Only chose suitable wall screws depending on the environ-
ment. Make sure that the area is safe and that both the
filter and the Voca TC-X can be easily accessed.
Wall
mount
Filter
head
Filter
element
05
4x
Warm water
mains
Cold water
mains
To original tap
To filter
Make sure that the mains water is turned off by testing the
existing tap!
To avoid any leakage or damage to the plumbing system it
is recommended to seek qualified professional help.
When securing the T-joint please ensure it is tight enough,
but don’t overtighten it to avoid damaging the gum seal.
Make sure that the household mains water is turned off
before proceeding with the next step!
Using appropriate tools, unfasten the cold water tap
junciton. Place the O-ring seal inside the T-joint and
fasten both ends making sure no leakage will occur
(please take care not to overtighten it).
06
To regulate pressure shocks and avoid water hammer
effects, we recommend to add the pressure regulator
between the T-joint and the filter element.
Please find a suitable location (ideally not too far from
the filter) and secure the pressure regulator with 2x
screws (not supplied).
Pressure regulator
2x (not supplied)
(top view)
Make sure that
the filter head is
being installed in
the correct order
following the
intended water
flow direction!
Please ensure that the household’s pressure is within the
range outlined in the Voca TC-X specifications (1-3 kg).
If the mains pressure is too low, a booster pump may need
to be installed.
Installing the Filter
Adding the T-joint component
Adding the pressure regulator
2x (not supplied)
Note:
Note:
Note:
W
A
L
L
Rear view of Voca TC-X Main Unit
07
The supplied water tube will need to be cut in order to
connect each section. Proceed one section at a time and
where needed use the supplied push-in corner adapters.
To connect, simply push the tube in until it is safely
secured. Test the tube steadiness by pulling slightly: it
should not come off. To release the tube, push the
connector’s collet and pull the tube.
When cutting each section please allow the extra lenght
needed to secure the tube inside the connector.
Please follow the instructions below for added details.
Before cutting the water tube, please make sure that each
section is short enough so that they add up to the total
lenght of the tube.
When cutting the tube, please use a precision tool and cut
a straight vertical line to ensure a correct water flow.
Once finished, ensure each section is secure and free from
any leakage.
to attach tube
to release tube
Push-in
connector Water tube
07.1
07.2
Unfasten the nut and attach the water tube to the
T-joint, making sure it is properly connected all the way.
Slide the nut through the tube and gently fasten it back
to secure it. Cut two sections of the tube and connect:
T-joint to pressure regulator, then to filter.
Depending on the location of each component the corner
adapters can be used to assist with the process.
When cutting the water tube, please take into consider-
ation the extra lenght needed to secure the tube inside
each connector.
Gently fasten the nut
to secure the tube
Keep the T-joint valve and
the mains water closed at
all times during installation!
An additional release path between the filter and the
Voca TC-X can be installed. It will allow for filter rinse
and manual filtered water (at original temperature) in
case of power disruptions. Make use of the T-adapter
and the ball valve as instructed.
To avoid leakage and damages, please make sure that the
ball valve is properly functioning when closed.
By leaving this
part for last,
the remaining
part of the
water tube can
be used after
the rest of the
installation is
complete.
Push-in
connector
Water tube
Connecting each section with the water tube
Mains to filter (via pressure regulator)
Adding the additional release path
Note:
Note:
Note:
08
VOCA TC-X Main Unit
(wall mounted)
Existing
faucet
Mains water
(cold)
T-joint
Pressure
regulator
Filter (wall mounted)
T-adapter
Ball valve
Additional
release
path
Corner
adapter
Faucet control cable
Faucet water tube
Power
Plug
07.3
Remove the protective cap from the Main Unit and
attach the tube. If necessary the corner adapters can be
used to avoid eccessive bending of the tube.
Once happy with the installation, turn on the mains
water and carefully check for any leakage or weak
points. Turn off the water immediately if any issue is
detected.
We reccomend to rinse the filter before operating the
Voca TC-X.
Once certain that no leak or issue is present, plug in the
Voca TC-X and follow the calibration process from the
user manual.
The protective cap
can be applied to the
additional release
path’s ball valve for
added safety.
Only turn on the mains water once completely reassured
that every step has been completed and no problems or
leakage will happen.
If any issue arises or if in any doubt, it is recommended to
seek professional assistance to avoid damages.
Connecting to the Voca TC-X Main Unit
Final overview
Touch
Faucet
Water inlet
Water
outlet
Faucet control
connector
Note:
IMPORTANT!
• Please read all instrucons carefully before installing or using the appliance.
• Please make sure you check your household water pressure before installing the appli-
ance. The recommended water pressure is between 1-3 kg.
• Due to the nature of the installaon and the requirement to operate on the household’s
plumming system, we recommend that any installaon work is being carried out by
competent and qualified individuals.
• Before proceding with the installaon please make sure that the area is safe and proper-
ly cleaned.
• In the event that a new hole needs to be drilled for the faucet, adequate tools will need
to be used depending on the area and environment.
• Please ensure that the mains water is turned off during the whole procedure and unl
sasfied that there will be no issues or leakage.
• Please ensure to install the unit in a safe place, away from dirt, water, rain and excessive
sunlight. Cables and pipes should not be squeezed or bent to avoid damage. Please hook
the appliace using the holes on the back as indicated and make sure it is in a straght and
vercal posion (it is not recommended to install the appliance horizontally).
• To ensure maximum efficiency and durability, the appliance has a ± 10% quanty
tolerance when releasing the water.
• The warranty offered on the appliace does not cover consumables and installaon parts
(tubes, pipes, juncon connectors, valves, etc).
• As walls and environments can vary, wall screws are not supplied. Please make sure that
you choose suitable opons depending on the situaon.
• Before proceeding with the installaon please make sure that everything is in order. If
the goods have been damaged during shipping, please contact the customer support
immediately.
• Please follow the installaon instrucons and the user manual on how to operate the
appliance carefully. Failure to adhere to this will cause the warranty to be void.
• This appliance is intended for households and similar applicaons (e.g. staff kitchen
areas in shops/offices/etc, rural properes, for clients in hotels/motels/etc, bed and
breakfast).
• Please pay parcular aenon immediately aer using the appliance/water tap (espe-
cially with higher temperature sengs) as residual heat may be present for some me
aer use.
Checklist
For informaon and to download a
digital copy of this manual, please visit:
www.vocafresh.com
Other manuals for TC-X
1
Table of contents
