Vogue Premium St User manual

Model:
CR164/DA328/DA329/DA330/DA331/DA332/DA333/
DA337/DA338/DA339/DA340/DA341/DA342/DA343
Vogue Premium St/St 304 Table
Assembly Instructions
CR164_DA328-DA333_DA337-DA343_AUS_A5_v1_170714.indb 1 2017/7/14 13:42

ix1 iv x1
ii x4 vx1
iii x12
A B
C
D E F
Note: For Models DA332/DA333/DA342/DA343, there are 6 legs and 18
screws.
CR164_DA328-DA333_DA337-DA343_AUS_A5_v1_170714.indb 2 2017/7/14 13:42

AU
Safety Tips
Whilst all care has been taken to remove sharp
edges, care must be taken when cleaning or
handling the table to prevent risk of injury from
exposed metal edges.
Do not overload the table top or shelf causing it to
bend.
Product Description
• CR164 - Vogue Premium St/St 304 Table -
600x600x900mm
• DA328 - Vogue Premium St/St 304 Table -
900x600x900mm
• DA329 - Vogue Premium St/St 304 Table -
1200x600x900mm
• DA330 - Vogue Premium St/St 304 Table -
1500x600x900mm
• DA331 - Vogue Premium St/St 304 Table -
1800x600x900mm
• DA332 - Vogue Premium St/St 304 Table -
2100x600x900mm
• DA333 - Vogue Premium St/St 304 Table -
2400x600x900mm
• DA337 - Vogue Premium St/St 304 Table with
100mm Upstand - 600x600x1000mm
• DA338 - Vogue Premium St/St 304 Table with
100mm Upstand - 900x600x1000mm
• DA339 - Vogue Premium St/St 304 Table with
100mm Upstand - 1200x600x1000mm
• DA340 - Vogue Premium St/St 304 Table with
100mm Upstand - 1500x600x1000mm
• DA341 - Vogue Premium St/St 304 Table with
100mm Upstand - 1800x600x1000mm
• DA342 - Vogue Premium St/St 304 Table with
100mm Upstand - 2100x600x1000mm
• DA343 - Vogue Premium St/St 304 Table with
100mm Upstand - 2400x600x1000mm
Assembly
Note: Be sure to check all
packaging materials for any
small parts that may have come
loose during transportation
1. Remove all protective film, taking care to avoid
scratching the surfaces.
2. Place the shelf (i) on it’s side on the floor.
3. Insert the legs (ii) into the sockets situated at
each corner of the shelf, lining up the socket
with the line marked on the leg [A].
4. Use grub screws (iii) to loosely fix the shelf
to the legs with the Allen key (iv), then stand
upright [B, C, D].
5. Position the table top (v) onto the legs,
ensuring each leg is firmly located in its
corresponding corner socket [E].
6. Fix the table top in place using the remaining
grub screws. Ensure the table top is both level
and securely fixed [F].
Note: Adjust the feet if
necessary to level the table
Before using for the first time VOGUE recommend
the table is cleaned thoroughly with a suitable
cleaning agent. Remove all cleaning residues and
dry thoroughly.
Cleaning
• Clean the table regularly using a cleaning
agent suitable for use with stainless steel.
• Always remove cleaning agent residue. This
can discolour the surface of the table.
• Never leave the table surface damp as this can
cause discolouration.
All rights reserved. No part of these instructions may be
produced or transmitted in any form or by any means,
electronic, mechanical, photocopying, recording or
otherwise, without the prior written permission of VOGUE.
Every effort is made to ensure all details are correct at the
time of going to press, however, VOGUE reserve the right to
change specifications without notice.
