Volaris S7 SMART User manual

Guarantee
Volaris grants two years guarantee on the S7. The guaran-
tee, however, does not cover wear parts like handles, wires
and wheels. Further the guarantee is not valid, if the rolla-
tor has been exposed to abnormal handling or has been
altered without our consent.
Manufactured in Sweden
S7 is developed and manufactured in Sweden to enable us
toguarantee for function and quality. It is manufactured
from care-fully chosen material and components. S7 is
recoverable to 95 %.
S7 complies with all prevailing standards such as SS-EN
1441, SS-EN 1985, SS-EN 12182 as well as ISO 11199-
2:2005 and is approved by Hjælpe Middle Institute, Den-
nmar
This is the way your
new rollator works
Volaris S7
Call 01423 740450
Doability Limited
Unit I7B, Hornbeam Park Oval
Hornbeam Park, Harrogate, HG2 8RB
P 01423 740450
F 0113 3410395
E [email protected]
W www.doability.co.uk

Congratulations to your new
rollator!
The Volaris S7 will in many ways simplify your daily life. Acquaint
yourself with your new rollator by carefully studying the directions for
increased safety and longer life of your S7.
The S7 provides excellentsupport for your moving around and
should be used exclusively as a walking aid. The seat is guaranteed to
be able to carry people weighing up to 140 kg. The size of the S7, folded
and unfolded, you can see further down. You can equip your S7 with
several accessories for your safety and comfort.
Contents
Mounting the handles page 3
Adjusting the handles page 4
Adjusting the seat page 4
Unfolding the S7 page 5
5egap7SehtgnidloF
6egapgnikarB
Adjusting the brake page 7
Recommendations for travel page 8
01egapecnanetniaM
11egapgnicarttluaF
Accessories for your safety page 12
Accessories for your comfort page 13
41egapeetnarauG
738 590 230
440
760-1000
460/480/520/560/600
Mounting the Handles
When delivering directly to the customer we normally supply the S7
with loose handles in order to allow for a less spacious transport
package. In case you have received the S7 from an aid agency the
handles are already mounted.
Take out
the S7 from
the carboard
box. Take
out the
handles from the
bag and insert them
into the tubes as
shown in the sketch.
The handle should
point backwards. Check
that the wire is situated
on the outside.
Fix the handles by means of the
provided screws as shown by the
sketch.
Doability Limited, Unit I7B, Hornbeam Park Oval, Hornbeam Park, Harrogate, HG2 8RB P 01423 740450, F 0113 3410395, E [email protected], W www.doability.co.uk
2 3
Call 01423 740450

Adjusting the height of the handles
By pulling the orange-coloured button you
can adjust the height of the handles to
between 100 and 76 cm.
Stand close to the S7. The height is
correct, when your hands are on level with
out, if you want further adjustments. The
purpose is that you feel comfortable when
you walk with your S7.
Adjustment of seat height
Change one side at a time.
Pull out the orange-coloured
button underneath the seat.
At the same time lift the seat or
push it down to the required height.
Feel that the button makes “click”
again. This means the seat is now
locked.
Repeat the procedure on the
other side.
It is important that the seat is in
horizontal position, before you use
the rollator again. Push down the
centre plate in the seat.
1
2
3
1
22
Unfolding the S7
1. Grip one handle with one hand and
tilt the S7 slightly in the same
direction causing the wheel lift a few
centimetres.
2. Pull at the handle on the other side. A
spring helps you to unfold the S7.
3. Push down
the centre
plate on the
seat to lock
the rollator.
Folding
the S7
Take away
the basket.
1.Lift the
orange-coloured
strip.
2. Press the S7
together with the
handles on the side.
Doability Limited, Unit I7B, Hornbeam Park Oval, Hornbeam Park, Harrogate, HG2 8RB P 01423 740450, F 0113 3410395, E [email protected], W www.doability.co.uk
4 5
Call 01423 740450

Braking
Parking Brake
The parking brake is activated by
turning the orange-coloured lever in
forward direction and lock it by a click.
The brake is released by
turning the lever straight upward until
you hear a clicking sound. See the
sketches.
Travelling Brake
The brake is
activated by
upward
pushing the
bottomside
of the
handles
2 mm
1
2
3
Adjusting the brake to obtain correct function
The braking power can be
adjusted by changing the length
of the wire.
1. Turn up the parking brake.
2. Loosen the locking nut as shown
by the sketch.
3. Slacken the adjusting screw, if you
want to increase the braking power.
Screw home the adjusting screw , if you
want to reduce the braking power.
4. Check the distance between the brake shoe and the wheel. The
distance should be approx. 2 mm. If you adjust the brake too tight the
5. Tighten the locking nut again.
Doability Limited, Unit I7B, Hornbeam Park Oval, Hornbeam Park, Harrogate, HG2 8RB P 01423 740450, F 0113 3410395, E [email protected], W www.doability.co.uk
6 7
Call 01423 740450

Recommendations for Travel
The S7 is built with a ”comfort chassis” which makes it pass gently
across uneven parts of the way. If you have to pass a larger obstacle or
to get onto a pavement, you can obtain help by the tilting aid sitting on
the rear wheels.
Step upon one of the
pedals and lift the rollator by
the handles at the same time.
Do not lift by the seat when
you pass an obstacle. The
rollator will then collapse!
Learn the ”scissor technique”.
Push diagonally towards the obstacle. Brake one side. Tilt the S7
slightly backwards making the front wheels lift. Lift the front wheels
over the obstacle. It works fast once you have learnt the lesson.
For your safety!
Before you sit down on the S7,
apply the parking brake!
Note! Never have anybody
sitting on the seat when push-
ing the rollator.
Doability Limited, Unit I7B, Hornbeam Park Oval, Hornbeam Park, Harrogate, HG2 8RB P 01423 740450, F 0113 3410395, E [email protected], W www.doability.co.uk
8 9
Call 01423 740450

Lubricating the Wire
After the cleaning lubricate the braking wire up at the handle and
down at the rear wheel. Lift the travelling brake handle and apply a few
drops of oil on the wire showing above the adjusting screw. Lubricate
also the wire inside the spring at the rear wheel.
Fault Tracing
If the rollator pulls to the right or to the left, check that all wheels
rotate smoothly and that the wheel forks turneasily. Check that wheels
and forks are tightened properly. Make sure that no dirt is gathered
between the wheels and the brake shoes
If the Brake does not work :
to the brake arm.
• Check that, when braking, the brake arm is pressed against the
wheel and there is no dirt between the brake arm and the wheel.
• Adjust the wire.
No or unequal braking action
that the spring at the brake arm is not broken. Check when braking that
the brake shoe is pressed against the wheel, equally on both sides.
Adjust the wire, see page 7.
Maintenance
Cleaning
Leniently remove the dirt using a moist cloth and detergent.
Make sure that no dirt is gathered between the wheels and the
brake shoes. Dirt might jeopardize the braking power.
Flushing from above by means of jet cleaning or a garden hose is
recommended. Wipe dry afterwards.
Doability Limited, Unit I7B, Hornbeam Park Oval, Hornbeam Park, Harrogate, HG2 8RB P 01423 740450, F 0113 3410395, E [email protected], W www.doability.co.uk
10 11
Call 01423 740450

Accessories for your safety
Slow Down Brake
A brake with adjustable continuous friction, can be
mounted afterwards.
Lamp
Are clamped onto the
frame. Red rear light, white front
light. Battery driven. Easy to
Cane Holder
Two parts to be on screwed
in place. Holds stick, crunch
or drip rack in place.
Holder for Oxygen
Bottle
Sturdy steel basket
to be hooked onto
the seat including
holder. Easy to take
Backrest
Strong support for
your back providing a
feeling of safety.
Fastened by
two screws
onto existing
holders.
Accessories for your Comfort
Bottle Holder
Holder of strong plastic material for
bottle. Accommodates 0.5 litre tins and
bottles. Suspended on handle.
Anatomic Handgrip
Handle for anatomic
support of the hand.
Distributes the
pressure against the
palm. To be mounted
on top of theexisting
handles.
Fabric Bag
A soft fabric bag of
woven nylon. Can
remain even when the rollator is folded.
Net Basket
A sturdy basket of
metallic net. Easy to hook
upon the S7. Carrying handles.
Parasol
Protects against sun and rain. Is
clamped onto the frame. Can be
rotated in all
directions.
Tray
White-coloured tray, to be
placed on the seat of the
rollator.
