volkano Fabric Series User manual

Please read these instructions carefully and retain for future reference.
INSTRUCTION MANUAL
SPEAKER WITH
BLUETOOTH WIRELESS
FABRIC TRIM
Fabric Series
VK-3020-GRL-CF
VK-3020-GRD-CF

2
• Rechargeable Bluetooth Portable Speaker
• Fabric Trim Design with Detachable Handle
• Explosive Bass and Crystal Clear Sound
• Aux Line Input
HIGHLIGHTS
PACKAGE CONTENTS
• Volkano Fabric Bluetooth Speaker
• Micro USB to USB Charging Cable
• Aux Cable (3.5 mm Jack)
• Strap
• Instruction Manual
SPECIFICATIONS
• Bluetooth
Version: 5.0
Profiles: A2DP
Chipset: Bluetrum
Range: 10 m / 33 ft
• Charge Input: 5 V DC, 1 A
• Charge Time: 3 ~ 4 Hours
• Battery: 1200 mAh
• Battery Type: Li-Ion
• Playtime: 3 ~ 6 Hours
• Frequency Range: 90 Hz ~ 20 kHz
• Signal to Noise Ratio: 80 dB
• Sensitivity: 85 dB
• Total Power Output: 6 W
• Impedance: 4 Ω
• Product Size: 192 x 120 x 45 mm

On
Charging AUX
3
1. ON /OFF Switch
2. Red Charging LED Indicator
3. 5 V Charging Port
4. Bluetooth Conenction LED Indicator (Blue)
5. Aux In
IDENTIFYING PARTS
1
35
42

4
INSTRUCTIONS FOR USE:
• Turn your Bluetooth speaker on by sliding the power switch located on the back side of the speaker
to the ON position.
• The Blue Indicator Light will flash quickly. This indicates that the speaker is in pairing mode and
begins to search for a Bluetooth device.
• Turn on the Bluetooth function on your device, search for the speaker named “Fabric” and
select it. Your device will pair without a password. (If required, enter the password “0000” to
finalize the paring).The Blue Indicator Light will begin to flash slowly after pairing is complete.
• Start playing music on your device. Keep your device within 10 meters of your speaker.
• Adjust the volume of your device to a comfortable level.
• Turn off the unit when it is not in use.
For other music devices without Bluetooth, use the supplied Auxiliary Cable. Connect the Auxiliary
Cable into the speaker’s Auxiliary Port and plug the other end into your device’s auxiliary port.
The device will switch to Auxiliary Mode automatically.
All controls and functions are operated through your mobile device.
Disconnect the Auxiliary cable when not in use.
CHARGING
PLAYING MUSIC VIA BLUETOOTH
AUX MODE
Please fully charge your speaker before using it for the first time.
• To charge the battery, plug the Micro USB Charging Cable into the charging port located on the
back of the speaker and then plug the USB connector of the Charging Cable into the USB port
on a computer or laptop to charge.
• A Red Indicator Light will indicate charging has begun. When battery is full, the Red Indicator
Light will turn off automatically.
• Disconnect the USB Cable when it is fully charged.

45
1. My mobile phone can’t find any new Bluetooth devices?
a. Ensure the device has entered the pairing mode.
b. Ensure the device is within effective working range.
2. Bluetooth device can’t pair up?
Ensure your mobile phone allows new connections and has not reached the maximum
number of allowed devices.
4. The device does not play music or answer calls when it is connected to a Bluetooth
mobile phone?
a. Ensure your mobile phone supports A2DP and HSF (Hands-Free) profiles.
b. Ensure your mobile phone is within effective working range.
3. When paired with my computer, Windows®asks for a new driver. Can you supply this?
We recommend you find compatible drivers for your computer online.
4. Why can I not remotely control the Pause, Play, Previous and Next functions
when music is playing?
a. When you are using 3.5 mm aux connection, you can’t pause, change volume or skip tracks.
b. This feature needs the Bluetooth device paired with the speaker to support AVRCP (Audio /
Video Remote Control Profile). Please ensure your device supports this.
TROUBLESHOOTING
• Never use your speaker near water or in areas where it can come into contact with water.
• Never handle the speaker if it was dropped in water or any other liquid. If the product comes into
contact with water while switched off, but still plugged in, this is a safety hazard.
• Always make sure your hands are dry before touching the plug or power connections.
• Do not operate the product with a damaged cord or plug, or after it malfunctions, has been
dropped, or damaged in any manner.
• This speaker is not intended for use by children, or persons with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the device by a person responsible for their safety. Extreme caution
must be exercised.
• Children should be supervised to ensure that they do not play with the speaker. Packaging must
never be left within reach of children, as it is potentially dangerous.
SAFETY PRECAUTIONS

Do not dispose of electrical appliances as unsorted municipal waste, use separate
collection facilities. Contact your local government for information regarding the
collection systems available. If electrical appliances are disposed of in landfills
or dumps, hazardous substances can leak into the groundwater and get into the
food chain, damaging your health and well-being.
ENVIRONMENTALLY FRIENDLY DISPOSAL
Before Cleaning: Ensure that your Volkano Fabric Series Speaker is turned off before cleaning or
maintaining it.
Cleaning: Wipe down the surface of your Volkano Fabric Series Speaker using a soft, slightly
damp cloth.
Do not use any harsh or abrasive cleaning chemicals or materials on your Volkano Fabric Series
Speaker as doing so may damage or scratch the surface finish.
Do not expose Volkano Fabric Series Speaker to direct sunlight or high temperatures for extended
periods of time.
Do not store in temperatures over 60°C. Do not expose the battery to excessive heat such as
sunshine, fire or the like. Store in a cool, dry place.
CLEANING AND CARING INSTRUCTIONS
6
DISCLAIMER
All product and company names are trademarks™ or registered®trademarks of their respective
holders. Use of them does not imply any affiliation with or endorsement by them.

7
WARRANTY
This Volkano Fabric Series Speaker comes with a standard 12-month limited warranty against
manufacturing defects and faults. Should your Fabric Series Speaker be unboxed with any faulty parts,
poor finishing, visible damage or fail to perform due to a manufacturing defect or poor workmanship,
please return it with your proof of purchase (till slip or invoice) to the store of purchase for an
exchange or repair, depending on the store’s returns policy.
This warranty commences from the date of purchase.
Kindly retain your proof of purchase as well as the packaging for your warranty period.
NOTE:
The warranty does not apply to product that:
a.) Has failed due to excessive wear and tear beyond what is considered to be reasonable.
b.) Has been misused or neglected.
c.) Has been damaged accidentally or by Force Majeure including fire and flooding.
d.) Has been used or operated contrary to operating or maintenance instructions outlined
in this manual.
Should you require any further assistance or have any questions on your warranty, please contact the
store of purchase.

Veuillez lire ces instructions attentivement et les conserver pour
consultation ultérieure.
MANUEL D’INSTRUCTIONS
BLUETOOTH AVEC
HAUT-PARLEUR SANS FIL
GARNITURE EN TISSU
VK-3020-GRL-CF
VK-3020-GRD-CF

POINTS SAILLANTS
CONTENU DE L’EMBALLAGE
• Haut-parleur Volkano Bluetooth – tissu
• Câble de chargement micro USB à USB
• Câble auxiliaire (prise de 3,5 mm)
• Sangle
• Manuel d’instructions
CARACTÉRISTIQUES
• Bluetooth
Version: 5.0
Profils: A2DP
Jeu de puces: Bluetrum
Portée: 10 m / 33 pi
• Entrée de recharge: 5 V c.c., 1 A
• Temps de recharge: 3 ~ 4 Heures
• Batterie: 1200 mAh
• Type de batterie: Li-Ion
• Temps d’écoute : 3 ~ 6 Heures
• Gamme de fréquences: 90 Hz ~ 20 kHz
• Rapport signal/bruit: 80 dB
• Sensibilité: 85 dB
• Puissance totale: 6 W
• Impédance: 4 Ω
• Dimensions du produit: 192 x 120 x 45 mm
2
• Haut-parleur portable bluetooth rechargeable
• Conception à garniture en tissu avec poignée amovible
• Des graves explosives et un son limpide
• Entrée de ligne auxiliaire.

On
Charging AUX
3
1. Interrupteur MARCHE/ARRÊT
2. Voyant DEL rouge de recharge
3. Port de recharge de 5 V
4. Indicateur DEL de connexion Bluetooth (bleu)
5. Entrée auxiliaire
IDENTIFICATION DES PIÈCES
1
35
42
