volkano Ignite Series User manual

INSTRUCTION MANUAL
Please read these instructions carefully and retain for future reference.

PACKAGE CONTENTS
• Volkano Ignite Series Speaker
• Micro USB Charging Cable
• User manual
• Aux Cable
SPECIFICATIONS
• Bluetooth Version: V4.2
• Chip Set: JL AC6901A
• Profiles: A2DP/AVRCP/HFP
• Bluetooth Range: 10m
• Product Size: 300 x 167 x 375mm
• Battery: 3.7V, 2,200mAh Li-Ion
• Charge Input: 5V DC/ 1A
• Charge Time: 3 - 4 Hours
• Max Size for SD Card: 32GB
• Max Size for USB input: 32GB
• Playtime: >5 Hours @ 80%
• Frequency Range: 100Hz - 17kHz
• Signal to Noise Ratio: >70dB
• Sensitivity: 90dB
• Speaker Size: 5.25”
• Power Output: 10W RMS
FEATURES
• Bluetooth Wireless
• Rechargeable Built-in Li-Ion Battery
• FM Radio
• SD Card Input
• USB Input
• MIC Input and FX controls
• Repeat songs
• Shuffle

DESCRIPTION OF PARTS
1. On/Off Switch
2. Micro USB Charging Port
3. Charging LED Indicator
4. USB Port
5. Micro SD Card Slot
6. Aux In Port
7. Mic In Port
8. Mode Button
9. LED Lights Button
10. Record Button
11. EQ/Echo Button
12. FM Channel/Repeat Button
13. Mic Volume Control
14. FM Down/Previous Button
15. FM Auto Scan/Play/Pause Button
16. Main Volume Control
17. FM Up/Next Button

CHARGING
Please fully charge the Ignite Speaker before using for the first time.
Connect the supplied Power cable into the IEC power input on the back of the speaker, then plug the
IEC Plug into a main wall plug. The power LED light will be lit Red while the speaker is charging and
will turn Green when the speaker is ready for use.
INSTRUCTION FOR USE
TURNING ON AND OFF
To turn on, flick the power switch to the “On” position. The speaker LED display will say “Lod” then
go into AUX mode. To turn off, flick the power switch to the “Off” position.
PAIRING WITH BLUETOOTH DEVICEST
Your speaker must be paired to a Bluetooth device before it can be used. It is only
necessary to pair your speaker once with each device.
1. Open the Bluetooth menu on the device you wish to pair. Some devices require you to select
“search for devices” or “add new device” in order to create a Bluetooth pairing.
2. With the speaker turned off, flick the power switch to the “On” position. Navigate to Bluetooth by
pressing the mode button, the LED Display will say NO-b.
3. Wait until you see “Ignite” on your device screen.
4. Select “Ignite” on your device and follow any further prompts to pair. Once pairing is complete and
a connection is established, the LED Display will say.
NOTE: If you are unsure on how to access your Bluetooth menu on your device, please refer to your
device’s instruction manual.
CONTROLS
To navigate between the USB, SD Card, Bluetooth, FM and Aux Modes short press the “Mode”
button.

1. Adjusting the Volume
Function Operation
Increase/Decrease Mic
Volume
Rotate the “Microphone Volume Control”
• Clockwise to Increase the Volume
• Counter Clockwise to Decrease the Volume
Increase/decrease
Volume
Rotate the “Main Volume Control”
• Clockwise to increase the Volume
• Counter clockwise to decrease the Volume
2. Audio Control
Function Operation
Navigate to Next Track (Works with Bluetooth, USB,
SD card modes)
Short press the “FM Up/Next”
button
Navigate to Previous Track (Works with Bluetooth,
USB, SD card modes)
Short press the “FM Down/
Previous” button
Play or Pause Track (Works with Bluetooth, USB,
SD card modes)
Short press the “FM Auto Scan/
Play/Pause” button
Repeat One /Repeat All Tracks (Works with USB, SD card
modes)
Short press the “FM Channel/
Repeat” Button
Change the EQ Mode (Works with USB, SD card modes) Short press the “EQ/Echo” Button
To configure the Microphone Echo Feature press and hold
the “EQ/Echo” button until the display says ECHO, then set
the echo level to your preferred setting. And short press the
“EQ/Echo” button to exit the Echo configuration Mode
Short press the “FM Up/Next”
button to increase the Echo
Short press the “FM Down/
Previous” button to decrease the
Echo
The Record Function
Make sure a USB stick or a Micro
SD card is inserted. Put the speaker
in random mode (using the “FM
Channel/Repeat” Button) then
press and hold the “Record” button
to start recording. Once you are
finished recording short press the
“Record” button.

3. FM Controls
Function Operation
Navigate to Next Station Short press the “FM Up/Next” Button
Navigate to Previous Station Short press the “FM Down/Previous” Button
Auto Search for FM Stations Press and hold the “FM Auto Scan/Play/Pause” Button
Switch Between Chanel and
Frequency Mode
Short press the “FM Channel/Repeat” Button
AUX MODE
Plug an RCA cable into the RCA input on the back of the speaker and plug the other end of the cable
into the device that you wish to play audio from.I
Note: The Audio Control buttons on the back of the speaker will not work in AUX mode, only the
Volume controls will work.
LED EFFECTS LIGHTS
The Ignite has built in LED Effects lights which shine on the speaker drivers, to turn them on simple
press the LED Lights Button on the top of the speaker and to turn them off simply press the button
again.
TROUBLE SHOOTING
1. My mobile phone can’t find any new Bluetooth wireless devices?
• Ensure the device has entered the pairing mode.
• Ensure the device is within effective working range.
2. Bluetooth wireless device can’t pair up?
• Ensure your mobile phone allows new connections and has not reached the maximum number
of allowed devices.
• Ensure the pairing password has been entered correctly “0000”. If you are using a Bluetooth
wireless transmitter device, ensure the password is set to 0000.
3. The device does not play music or answer calls when it is connected to a Bluetooth wirelss
mobile phone.
• Ensure your mobile phone supports A2DP and HSF (hands-free) profiles.
• Ensure your mobile phone is within effective working range.
4. When paired with my computer, windows asks for a new driver. Can you supply this?
• We recommend you find compatible drivers for your computer online.
5. Why can I not remotely control the pause, play, previous and next functions when music is playing?
• When you are using 3.5mm AUX connection, you can’t pause, change volume or skip tracks.
• This feature needs the Bluetooth wireless device paired with the speaker to support AVRCP
(Audio/Video Remote Control Profile). Please ensure your device supports this.

SAFETY PRECAUTIONS
• The product should only be used with the parts provided by the manufacturer.
• Never use the speaker near water or in areas where it can come into contact with water. Never
handle the speaker if it is dropped in water or any other liquid. If the product comes into contact
with water while switched off, but still plugged in, this is a safety hazard.
• Always make sure your hands are dry before touching the plug or power connections.
• Do not operate the product with a damaged cord or plug, or after it malfunctions, has been
dropped, or damaged in any manner.
• The speaker is intended for personal use only. Commercial use invalidates the warranty and the
supplier cannot be held responsible for injury or damage caused when using the device for any
other purpose than that which it was intended for.
• This speaker is not intended for use by children, or persons with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the device by a person responsible for their safety. Extreme
caution must be exercised.
• Children should be supervised to ensure that they do not play with the speaker. Packaging must
never be left within reach of children, since it is potentially dangerous.
ENVIRONMENTALLY FRIENDLY DISPOSAL
Do not dispose of electrical appliances as unsorted municipal waste, use separate
collection facilities. Contact your local government for information regarding the
collection systems available. If electrical appliances are disposed of in landfills or
dumps, hazardous substances can leak into the groundwater and get into the food
chain, damaging your health and well-being.
