volkano Xeon Series User manual

Xeon Series
INSTRUCTIONS
PLEASE READ AND RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
BLUETOOTH WIRELESS SPEAKER

• Outdoor Passive Bluetooth Speaker.
• Explosive bass and crystal clear sound.
• A2DP Bluetooth allows music streaming from any Bluetooth-enabled
device such as a mobile phone, tablet or computer.
• Secure simple pairing.
• 10m operating range.
• Supports USB and TF/Compact SD memory card.
• FM Radio.
• Line-In Function/ Aux-in 3.5mm Jack. Suitable for PC, Tablet, TV
and other audio devices.
• Double function buttons: backward/volume down and
forward/volume up.
• Built-in lithium rechargeable battery 1500mAh.
• Leather handle is included for easy carrying.
FEATURES
• Volkano Xeon speaker
• Charging cable
• Aux cable
• User manual
IN THE BOX

Bluetooth Wireless: V4.2
Profiles: A2DP / AVRCP
Bluetooth Range: 10m
Battery: 1500mA.h rechargeable Li-Ion
Playback Time: 3 - 4 Hours
Charge Time: 3 Hours
Charging: 5VDC, 2A
Main Driver: 4”, 12W, 4Ω
Frequency Response: 100Hz - 20kHz
Signal-to-Noise Ratio: 60dB
Product Size: Ø136mm x 254mm
1. Charging port
2. USB port
3. ON/OFF Switch
4. Backward/Volume Down
5. Mode (Switch between Bluetooth, USB flash disk, TF/Micro SD, FM
Radio and Aux-In)
6. Forward/Volume Up
7. LED Indicator
8. Aux-in port
9. TF/Micro SD slot
10. Play/Pause and FM Radio Channel Auto Search
SPECIFICATIONS
IDENTIFYING PARTS

DC5V
AUX
USB
TF
OFF/ON
1
7 8 9 10
2 3 4 5 6
M

1. Turn the power button “ON”.
2. Insert USB flash disk or TF/Micro SD card into the slot, the blue LED
light will flash. The music stored will be played automatically.
3. Music tracks can be selected with the control buttons on the Speaker.
Press “backward” or “forward” to select songs you would like to play.
4. Press “Play/Pause” to play and pause the music.
5. Turn the power button “OFF”, when not using the Speaker.
NOTE: In Bluetooth mode, inserting a USB flash disk will disconnect the Bluetooth and switch to playing
from the USB flash disk. Press mode “M” button to switch back to Bluetooth mode.
PLAYING MUSIC FROM USB DISK
AND TF/MICRO SD CARD
1. Turn the power button “ON”. The LED light will flash blue and beep
twice.
2. Activate Bluetooth on the mobile phone/device and search for device
“Xeon” then connect. The blue LED light will flash and will beep three
times once connected successfully.
3. You can now play music from your device.
4. Music tracks can be selected either by the control buttons on the speaker
or via the connected device. Press “backward” or “forward” button on the
speaker or mobile phone to select songs you would like to play.
5. Press “play/pause” on the speaker or mobile phone to play and pause
the music.
6. Volume can be controlled on the speaker by pressing and holding the
“backward” or “forward” buttons. For volume up, press and hold the
“forward” button. For volume down, press and hold the
“backward” button.
BLUETOOTH

WARNINGS
1. Turn the power button “ON”. The LED light will flash blue and beep
twice.
2. Activate Bluetooth on the mobile phone/device and search for device
“Xeon” then connect. The blue LED light will flash and will beep three
times once connected successfully.
3. You can now play music from your device.
4. Music tracks can be selected either by the control buttons on the speaker
or via the connected device. Press “backward” or “forward” button on the
speaker or mobile phone to select songs you would like to play.
5. Press “play/pause” on the speaker or mobile phone to play and pause
the music.
6. Volume can be controlled on the speaker by pressing and holding the
“backward” or “forward” buttons. For volume up, press and hold the
“forward” button. For volume down, press and hold the
“backward” button.
1. The audio cable is to be used as an antenna. When using FM mode,
ensure the audio cable is plugged into the speaker to receive FM radio
signal.
2. Once the device has been turned on, press the mode “M” button to
switch to FM radio mode.
3. Use the play/pause button to search for all available FM channels and
store them automatically.
4. To navigate through channels, use the forward and backward buttons.
NOTE: Inserting the audio cable while the speaker is in on FM mode, will cause the speaker to automatically
switch to Aux mode. Pressing the mode “M” button again will change back to FM mode.
To play audio from other devices, use the audio cable provided. Plug the
audio cable into the compatible device’s “Line-out” and then into the
“Aux-In” of the speaker. Press mode “M” button to switch the speaker to
Aux mode and enjoy your music.
FM RADIO
AUX-IN
1. Switch the speaker “OFF”. A micro USB charging cable has been
provided. Plug the cable into the speaker (DC 5V socket) and into a USB
port on a computer or 5V USB adaptor (not included). The red charge
indicator will light up indicating that the speaker is charging.
2. When charging while the speaker is on, 2 lights will flash, red and purple
indicating that the speaker is on while charging. Please note that using the
Speaker while charging it will lengthen the required charge time.
HOW TO CHARGE

1. The audio cable is to be used as an antenna. When using FM mode,
ensure the audio cable is plugged into the speaker to receive FM radio
signal.
2. Once the device has been turned on, press the mode “M” button to
switch to FM radio mode.
3. Use the play/pause button to search for all available FM channels and
store them automatically.
4. To navigate through channels, use the forward and backward buttons.
NOTE: Inserting the audio cable while the speaker is in on FM mode, will cause the speaker to automatically
switch to Aux mode. Pressing the mode “M” button again will change back to FM mode.
• Place the unit on a level surface away from sources of direct sunlight or
excessive heat.
• Clean your unit with a soft cloth moistened only with mild soap and
water. Stronger cleaning agents, such as benzene, thinners or similar
materials can damage the surface of the unit.
CARE & MAINTENANCE
• The unit should not be used near water. For example: near a bathtub,
washbowl, kitchen sink, laundry tub, swimming pool or in a
wet basement.
• The unit should be situated so that its location or position does not
interfere with its proper ventilation. For example, it should not be
situated on a bed, sofa, rug or similar surface that may block
ventilation openings.
• Also, it should not be placed in a built-in installation, such as a
bookcase or cabinet, which may impede the flow of air through the
ventilation openings.
WARNINGS
3. Charge time should be 3-5 hours. When fully charged, the red LED
indicator light will switch off.
4. In order to prolong the battery life, do not charge for more than 8 hours.
NOTE:
1. The speaker will operate without the wired connection using the lithium battery. The amount of battery life
depends on how often the Speaker is used, and how media is played. IE; heavy music, high volume and
excessive bass music will use more battery power than spoken word.
2. The built-in rechargeable battery is not replaceable. Do not remove or replace it, and please dispose of in
an environmentally friendly manner.
3. When cleaning the product, use a soft dry cloth. For more severe stains, please dampen the cloth with
water only.

ENVIRONMENTALLY FRIENDLY DISPOSAL
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
Contact your local government for information regarding
the collection systems available. If electrical appliances are disposed of in
landfills or dumps, hazardous substances can leak into the groundwater
and get into the food chain, damaging your health and well being.
• The unit should be situated away from heat sources such as radiators,
heat registers, stoves or other appliances (including amplifiers) that
produce heat.
• The unit should be connected to a power supply only of the type
described in the operating instructions or as marked on the appliance.
• Do not use attachments not recommended by the product manufacturer.
materials can damage the surface of the unit.
• Please do NOT attempt to change the battery yourself. If the battery has
died and you do not want us to replace your battery, you should follow
the disposal instructions below:
• Never dispose of used batteries/electronics with ordinary solid wastes,
since they contain toxic substances.
• Always dispose of used batteries/electronics in accordance with the
prevailing community regulations that apply to the disposal of
batteries/electronics. If there are no local regulations concerning
battery/electronics disposal, please dispose of the device in a waste bin
for electronic devices.
DISPOSAL OF UNIT
