Von Duprin PS9 SERIES User manual

1.0 SPECIFICATIONS:
Input: 120VAC, .2 amperes, 50/60 Hz
Output: 9VDC,.3amperes,regulatedoutputprotectedwith foldback currentlimiting
Enclosure: 10”highx10” wide x 4” deep hinged cover box, six (6) 1/2” knockouts total
onsides andback, (optionalkeylock available)
Battery Backup: Backup time - 12 hours at .3A (or 2 ALKs in alarm)
Battery- one (1) 1.2AH or 1.3AH leadacidbattery
Temperature: 0º to 120º F
2.0 MOUNTING:
For proper ventilation, power supply must be mounted upright in an area which allows free air circulation.
Mountwith appropriate hardware (screws orbolts)througheach of the four (4)mountingholesinthe rear
ofthe enclosure.
3.0 WIRING: (refer to FIGURE 1)
3.1 EnsureACbreakeris open before connectingAC power to the power supply.
3.2 Forallsupplyconnections,usewiressuitableforatleast90º C(194º F)temperature.
3.3 Inputconductors must be segregated from theoutputconductors,theymust not intermingle.
3.4 Connect the load to the DC OUTPUT terminals+(positive) and -(negative).
3.5 ConnectAC input to theAC input wires using insulated connectors.
Secure the field ground conductor under the chassis ground nut.
3.6 Close breaker to turn on the power supply, the red POWER ON LED should be illuminated.
INSTALLATION INSTRUCTIONS
PS9SERIESPOWER SUPPLY
941062_00(1) Page 1 of 2
This supply cannot be
used to operate Von
Duprin EL or CX exit
devices.
Note:*
CAUTION - Connect only to
circuitsprotected bya 20amp
or less fuse breaker
CACA
CACA
CAUTIONUTION
UTIONUTION
UTION
!
DANGER - High Voltage
present on AC input
DD
DD
DANGERANGER
ANGERANGER
ANGER
!
Copyright © 2003 Ingersoll-Rand. All rights reserved.

4.0 BATTERY INSTALLATION:
The battery backup consists of one (1) 12V 1.2 or 1.3AH lead acid battery. Connect the red and black wires
to the battery, being careful to connect red to +(positive) and black to -(negative) terminals on the battery.
Place the battery in the bottom of the enclosure in an upright position only to complete the installation.
5.0 KEYLOCK:
The keylock option (PS9) consists of a one (1) piece lock with two (2) keys. Use the following installation
stepsto properly install thisoption.
5.1 Removethe keylock knockoutlocatedon theenclosuredoorwith ascrewdriver.
5.2 Rotatethekey fully clockwise in the lock theninsertthelockthroughthe knockout with the
locking lever pointing toward the right hand side of the door. Snap into place.
941062_00(1) Page 2 of 2
Figure 1.
PS9Typical WiringApplication
ELECTRIC HINGE OR
POWER TRANSFER
BLK RED
PS9 POWER SUPPLY
DEVICE
Wire colors are
intentionally
swappedat the
splices.
Note:*
AC
GROUND
LUG
DANGER - Charge only Von Duprin specified
leadacid battery. Other types ofbatteries may
burst causing personal injury and damage.
Observe the proper polarity when connect-
ing the battery. See Figure 1.
DD
DD
DANGERANGER
ANGERANGER
ANGER
!
