Vonets VRP5G User instructions

VONETS——VRP5G
1
WiFi Repeater
VRP5G
Quick Setting Guide

VONETS——VRP5G
2
Declaration
Copyright © 2015 Shenzhen HouTian Network Communication Technology
Co., Ltd
All rights reserved, with retained ownership
Without Shenzhen HouTian Network Communication Technology Co., Ltd written
authorization, any company or personal can’t copy, writer or translation part or all
contents. Can’t do commodity distribution for any commercial or profitable purposes
by any ways (electricity, mechanical, photoprint, record or other methods).
VONETS is the registered trademark of Shenzhen HouTian Network Communication
Technology Co.,Ltd. The other all trademarks or registered trademarks mentioned in
this documents are belong to the individual owners. The product specifications and
information technology mentioned in this manual are just for reference, if any updates,
without other notice. Except for special agreements, this manual is just for user
guidance, any statements, information and so on in this manual can’t constitute the
warranty of any forms.

VONETS——VRP5G
3
Chapter 1 Quick Setting Guide
1. VRP5G connect to power, the device will automatically boot.
Tips: VRP5G support 110-240V power supply.
2. Connect VRP5G by terminal device.
Users can adopt the connection by wired, connect one side of the ethernet to
ethernet port of VRP5G, another side to computer ethernet port.
Users can wireless connect 2.4G hot spot by notebook, smart phone, IPAD and
other terminal devices.
Tips:
2.4G hot spot SSID is : VONETS_the last six characters of MAC address_2.4G
Password: 12345678.
If you configure it by computer, please set computer IP address to obtain an IP address
automatically, please see the words in the red circle of the following picture:

VONETS——VRP5G
4
Tips:
1) If users wireless connect VRP5G by computer, please disable the Local Area
Connection and other adapters.
2) If users wired connect VRP5G by computer, please disable the Wireless Network
Connection and other adapters.
3. Open the IE browser, enter http://vonets.cfg virtual domain name setting(VDNS)
or http://192.168.254.254
Tips:
1) The default login user name and password is admin.
5. Scan Hotspots
After entering the IE browser, the WiFi hotspots window will appear, can search the
WIFI hotspots signal that opened SSID broadcast around. If you want to connect
2.4G hot spot, please choose “2.4G WiFi Search”; please see the following:
Choose a correct WiFi signal, then click Next, the following interface will appear:

VONETS——VRP5G
5
Enter the correct password, confirm it is correct one, then click Apply button.
Click Apply button, the above interface will appear, the configured parameters
have been saved successfully, please make sure the password input is correct,
turn off and reboot the device.
Tip:
1) After configured successfully, 2.4G hot spot name of the device is “the source hot
spot name_the last two character of MAC address_2.4G”; WiFi password, encryption
method and channels and other parameters are the same as the source hot spot.
User can manually turn off 2.4G hot spot in WiFi Repeater column, also can change
SSID (WiFi name) and password.
2) The password of 2.4G hot spot is the same.

VONETS——VRP5G
6
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Shenzhen Houtian Network Communication Technology Co.,Ltd
http://www.vonets.com
The distance between user and products should be no less than 20cm
