1 Product Introduction
1.1 General Information
A VoIP GSM Gateway enables direct routing between IP and GSM network without the use
of a FXO port or the PSTN network. With this device, the usage of VoIP is greatly
enhanced with significant savings on long distance and roaming charges.
1.2 Protocol
¾TCP/IP V4 (IP V6 auto adapt)
¾ITU-T H.323 V4 Standard
¾H.2250 V4 Standard
¾H.245 V7 Standard
¾H.235 Standard（MD5，HMAC-SHA1）
¾ITU-T G.711 alaw/ulaw, G.729A, G.729AB, and G.723.1 Voice Codec
¾RFC1889 Real Time Data Transmission
¾Proprietary Firewall-Pass-Through Technology
¾SIP V2.0 Standard
¾Simple Traversal of UDP over NAT (STUN)
¾Web-base Management

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
5
¾PPP over Ethernet (PPPoE)
¾PPP Authentication Protocol (PAP)
¾Internet Control Message Protocol (ICMP)
¾TFTP Client
¾Hyper Text Transfer Protocol (HTTP)
¾Dynamic Host Configuration Protocol (DHCP)
¾Domain Name System (DNS)
¾User account authentication using MD5
¾Out-band DTMF Relay: RFC 2833 and SIP Info
1.3 Hardware Specification
¾ARM9E Processor
¾DSP for voice codec and voice processing
¾Two 10/100 BaseT Ethernet ports with full compliant with IEEE 802.3
¾LEDs for Ethernet port status
¾Four GSM Channels’ Connection
1.4 Software Specification
¾LINUX OS
¾Built-in HTTP Web Server
¾PPPoE Dial-up
¾NAT Broadband Router Functions
¾DHCP Client
¾DHCP Server
¾Firmware On-line upgrade
¾PSTN Caller ID transmit
¾Multiple Language Support
¾Supported call divert
¾Supported PSTN auto call out to PSTN
¾Supported Multi_devices Cooperate Mode(Group Mode)
¾Supported SMS call out
1.5 List of the Package
a) One GoIP4 Gateway main unit
b) One DC12V/2000mA power adaptor
c) One Ethernet cable (3M)

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
6
1.6 Appearance

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
7
1）LAN
Connect this port to an Ethernet Switch/Router, the Ethernet of a DSL modem, or
other network access equipment.
2）PC
Connect a computer or other network device to this port.
3）POWER (DC12V/2000mA)
Connect the 12V/2000mAAdapter provided to this power jack.
4）Reset
Press this button to reset the GoIP4 Gateway to factory defaults.
2 Installation
2.1 Installation Steps
Please follow the connection diagram above to install the GoIP4 Gateway.
a) Insert a GSM SIM card in the SIM card compartment located at the bottom of the
GoIP4 Gateway’s.
b) Connect an Ethernet cable the LAN port of the GoIP4 Gateway and the other end to
your existing network equipment.
c) Connect an Ethernet cable to the PC Port of the GoIP4 Gateway and the other end to
a PC or other network device (Optional).

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
8
d) Connect the power adapter provided to the power jack of the GoIP4 Gateway.
2.3 LED Indicators
The following table defines the status of the LEDS located on the top case and on the
RJ-45 connectors.
LED DESCRIPTION
P0WER When GoIP4 Working, this LED will keep
light;
RUN 1. When the GoIP4 is booting，this LED will
flash 100ms ON and 100ms OFF.
2. When the GoIP4 is login your
softswitch, this LED will flash 1s ON and
1s OFF.
LAN When LAN port connecting to network,this
LED will light and flash when has data
through this port;
PC When has devices use PC port,this LED will
light and flash;
Channel 1 When the GoIP4’s GSM channel1 login to
ISP’s system, this LED will flash 1s ON and
1s OFF;
Channel 2 When the GoIP4’s GSM channel2 login to
ISP’s system, this LED will flash 1s ON and
1s OFF;
Channel 3 When the GoIP4’s GSM channel3 login to
ISP’s system, this LED will flash 1s ON and
1s OFF;
Channel 4 When the GoIP4’s GSM channel4 login to
ISP’s system, this LED will flash 1s ON and
1s OFF;
2.4 SMS Commands
GoIP4 supported some maintenance commands come from SMS.
FUNCTION SMS CONTENT REMARK
Obtain LAN Port Info
INFO Not distinguish majuscule and lowercase
Reset device RESET Password Not distinguish majuscule and lowercase

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
9
Reboot device REBOOT Password Not distinguish majuscule and lowercase
Note：In command Reset and Reboot, the Password is the GoIP4 device’s admin
password.
The command keywords can use majuscule and lowercase, but the password must
distinguish majuscule or lowercase.
3 Configuration Guide
To configure the GoIP4 Gateway, you must login to its Web server via the LAN or PC port.
The LAN port is factory preset to obtain an IP from the local DHCP host and the PC port is
set to the fixed IP 192.168.8.1.
If a local DHCP host is available, the LAN will obtain an IP address automatically. To listen
to the IP address assigned, just dial a call via the GoIP4 Gateway’s SIM card phone
number. When the call is connected, you will hear a dial tone. Just dial “*01#” for
English voice prompt on the LAN IP and “*00#” for Chinese voice prompt on the LAN IP.
The LAN IP Address can also be obtained by sending a SMS message to the GSM phone
number. The GoIP4 will then reply with a SMS message containing the LAN IP address.
If you want obtained LAN port IP by sending a SMS message, please send” INFO “or”
info”.
If a local DHCP host is not available, you can then access the GoIP4 Gateway via the PC
port. You will need to change your computer’s LAN configuration via the Network
Connections under the Control Panel.
Windows: Control Panel--ÆNetwork Connections--ÆLocal
Connectionism’s Property--ÆTCP/IP Protocol’s Property

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
10
Set an unused IP address that is in the same segment as the PC port address.
Once either the IP address of the LAN or PC port is known, you are now ready
to access the Web server of GoIP4 Gateway.
3.1 Web Configuration Menu
If your computer is connected to the GoIP4 Gateway via the LAN port network segment,
you need to type the LAN IP address of the GoIP4 Gateway in your Web Browser to access
the Web server of the GoIP4 Gateway. If not, you should type GoIP4’s PC port IP address
(192.168.8.1) in the Web Browser.
If the connection is correct, the Web Browser will prompt you to enter the “User name”
and “Password” as shown below.

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
11
Enter the User name and Password and the press OK to access the GoIP4 Gateway Web
Server. The default for both user name and password is “admin”.
3.2 Status
The Status page shown below is the default / home page of the GoIP4 Web server.
3.2.1 Phone Information
A. Serial Number
Each Gateway has a unique serial number assigned by the factory such as
GOIP409100019.This number is important for centralized configuration, technical
support, and warranty. This number is printed on the bottom of the Gateway and is
associated with your software license.
B. Firmware Version
Firmware version identifies the firmware version of the Gateway such as
GHS-4.01-1.

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
12
C. Hardware Mode
This field shows terminal’s hardware type.
D. Phone Status
This field shows the status of Line’s connection status. If the connection is successful,
this field displays LOGIN; otherwise, it displays LOGOUT.
3.2.2 Network Information
A. LAN Port Configuration
This field displays the status of the LAN port.
B. PC Port Configuration
This field displays the status of the LAN port.
C. PPPoE
If PPPoE is enabled, it displays its status.
D. Default Route
This field displays the IP address of the default routing Gateway.
E. DNS Server
This field displays the IP address of the Domain Name Server.
3.2.3 GSM Module Information
A. GSM Module
This field displays the GSM module type.
B. GSM Signal
This field displays the GSM signal status.
C. GSM Status
This field shows the status of GSM connection status. If the connection is successful,
this field displays LOGIN; otherwise, it displays LOGOUT.
3.3 Configurations
Click on the “Configurations” tab on the left hand column to access the device
configuration menu: Preference, Network, Call Settings, Call Divert, Save Changes,
and Discard Changes.

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
13
Click on “Preference” in the left menu of the configuration web, and the screen will be
displayed as below:
3.3.1 Language
Currently GoIP4 supports English, Simplified Chinese and Traditional Chinese. Select
the language desired and the Web page will be shown in the language selected
accordingly.

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
14
The language can also be selected at the top of the web page. Once selected, the
webpage language is refreshed immediately. However, the language selection is not
saved until the Save Changes icon is clicked.
3.3.2 Time Zone and Time Server
The GoIP4 Gateway supports Network Time Protocol (NTP) to obtain the date and time
information from an NTP server (Time Server). The time zone is specified as in GMT ±
offset. For example, the Pacific Standard Time is GMT-8, and the Pacific Daylight Time
is GMT-7.
Note: The GoIP4 Gateway supports CDR and Billing Information, it is important to set up
these two parameters properly.
3.3.3 DTMF Min Detect Time Gap
This parameter use to limit two same DTMF digit’s minimum time gap, the range is 60ms
to 120ms, default is 80ms.
If you encounter double digit problem, gain it to more, if you encounter lose digit, then
gain it to less.
3.3.4 Auto-Provision
The GoIP4 Gateway supports Auto Provisioning which enables configuration parameters

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
15
to be set automatically without human intervention. The Auto Provisioning supports both
HTTP and TFTP protocols. For higher security, encrypted configuration file is also
supported. This feature requires external Auto Provisioning Server. Please contact
your service provider for further information on this.
3.3.5 Network Tone
Network Tones are a set of tones used for VoIP calls. Select one of the countries
defined or customized to define your own Network Tones.
You can configure the Network Tones as Customized option:
Each tone listed above is defined in the following format:
nc, rpt, c1on, c1off, c2on, c2off, c3on, c3off, f1, f2, f3, f4, p1, p2, p3, p4
Where: nc is the number of cadences
rpt is the repeat counter(0 - infinite, 1~n - repeat 1~n times)
c1on is the cadence one on (in milliseconds)
c1off is the cadence one off (in milliseconds)
c2on is the cadence two on (in milliseconds)
c2off is the cadence two off (in milliseconds)
c3on is the cadence three on (in milliseconds)
c3off is the cadence three off (in milliseconds)
f1 is the tone #1 frequency (300Hz-3000Hz)
f2 is the tone #2, frequency (300Hz-3000Hz)

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
16
f3 is the tone #3 frequency (300Hz-3000Hz)
f4 is the tone #4 (300Hz-3000Hz)
p1 is the attenuation index for f1, 0~31(0=3dB, -1dB increments)
p2 is the attenuation index for f2, 0~31(0=3dB, -1dB increments)
p3 is the attenuation index for f3, 0~31(0=3dB, -1dB increments)
p4 is the attenuation index for f4, 0~31(0=3dB, -1dB increments)
For example, the tone definition for a tone of 450Hz with a cadence of 700 ms on and
1000 ms off is 1,0,700,1000,0,0,0,0,450,0,0,0,20,0,0,0
3.3.6 GSM Caller ID Anonymous
Some GSM ISP allows the caller disable it phone number, it must GSM ISP supported;
3.3.7 GSM Band
GoIP4 Supported quad GSM bands;
Note: About GSM bands supported, it base as which model GSM module we was used, some old
GoIP gateway just supported two bands, so it will different at differ batch’s GoIP devices;
3.3.8 GSM ISP
When GoIP searched more ISP signaling it can use, GoIP will show you a GSM ISP list, you
can choice any one ISP and the GoIP will lock itself just register to your choice one;
3.3.9 Auto Reboot
This option enable GoIP4 auto reboot each day, GoIP4 will auto reboot itself at Reboot
Time. If meet a current called, the action will auto delay after the call finish.

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
17
3.4 Call Settings
Click on the “Call Settings” to configure the VoIP call settings. The first thing to set is
the Endpoint Type: H.323 or SIP.
3.4.1 H.323 Phone
For H.323 protocol, 2 Endpoint Modes are supported: Direct Mode and Gatekeeper
Mode.
3.4.1.1 Direct Mode
In Direct Mode, GoIP4 running at H.323 P to P type.
A. H.323 Phone Number
H.323 phone number: fill the login number (E164) here.
B. Display Name
Display name is the name to be displayed on the called VoIP party.
C. H.323 ID
If the system requires an H.323 ID as a method of Authentication, enter the H.323 ID
provided.
D. Default Voice Gateway

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
18
This field assigns the IP address or the domain name of the gatekeeper or other VoIP
gateway. The port number can be added with the colon “:” symbol. For example:
192.168.1.70:8080.
GoIP4 will send out all VoIP calls to this address.
3.4.1.2 Gatekeeper Mode
The “Gatekeeper Mode” mode allows a user to setup the GoIP4 Gateway by registering
to the gatekeeper with one H.323 account.
A. H.323 Phone Number
H.323 phone number: fill the login number (E164) here.
B. Gateway Prefix
If login with a Prefix method fill the prefix number (do not fill the Phone number).
C. Display Name
Display name is the name to be displayed on the called VoIP party.
D. H.323 ID
If the system requires an H.323 ID as a method of Authentication, enter the H.323 ID
provided.
E. Gatekeeper Address
This field assigns the IP address or the domain name of the gatekeeper. The port
number can be added with the colon “:” symbol. For example: 192.168.1.70:8080.
F. Enable Authentication
If H.235 Authentication is required, enable this field and fill in the values as
provided.

VOPTech Document Four Channel’s GSM VoIP Gateway
Copyright@2009 VOPTel Technology Co., Ltd All Rights Reserved.
19
GoIP4 has three types configure modes in Gatekeeper Mode;
Configure By Single: All four channels use same one H.323 account connect to
gatekeeper;
Configure By Line: Each channel will use a single account connect to H.323
gatekeeper;
Configure By Group: Each VoIP channel will register to Gatekeeper base differ
Group;
3.4.1.3 Advance Settings
Click “Advance Settings” to access additional H.323 parameters as shown below.
A）RAS Port
RAS Port is an unreliable channel which is used to convey the registration, admissions,
bandwidth change, and status messages between two H.323 entities.
B）Q.931 Port （Call Signaling Port ）
Call Signaling Port is a reliable channel which is used to convey the call setup and
release messages between two H.323 endpoints.
C）H.245 Port （Media Control Ports ）
Media control port is the port or port range used by the H.245 media control
protocol.
D）Fast Start
Enable or disable the Fast Start in H.225.0. Most H.323 terminals or Gateways
support the Fast Start feature.
E）Register Mode
