Vornadobaby Tempa User guide

whole room heater
Tempa
Hello, i’m
Own’s Handbk
read & save these important instructions

2English
Welce to Vnadobaby
Vornado began in 1945, continues to revolutionize airflow today and is now tailored for the nursery.
®
A THIRD
genati
NAME
Thank you for choosing to put a Vornadobaby product in your nursery. Our
goal is to provide healthy, comfortable air - through every season. Vornado has
been doing this for quite a while now. We’ve brought all our experience in air
health and comfort, and tailored it exclusively for your nursery.

3
English
Important Safety Instructions................................................................. 4
Safety......................................................................................................... 8
Tempa Controls........................................................................................ 9
Plug In & Placement .............................................................................. 10
How To Use............................................................................................. 12
Keeping Tempa Clean........................................................................... 14
Tips .......................................................................................................... 15
Troubleshoot .......................................................................................... 16
Warranty.................................................................................................. 18
Contents

4English
READ ALL INSTRUCTIONS BEFORE
USING THIS HEATER
IMPORTANT SAFETY INSTRUCTIONS
This owner’s guide and any additional inserts are considered
part of the product. They contain important information about
safety, use and disposal. Before using the product, please
familiarize yourself with all operating and safety instructions.
Please keep all documents for future reference and pass these
documents on, together with the product, to any future owner.
See www.vornado.com to view, download and print the most
current version of this owner’sguide.
INTENDED USE: This product is intended to heat and circulate
the air in indoor living spaces only. This product is not intended
for commercial or industrial use. This heater is not intended for
use in bathrooms, laundry areas, and similar damp locations.
The manufacturer assumes no responsibility for damage or
injury due to unauthorized use or product modification. Failure
to follow these directions will void the productwarranty. This
product is intended for floor use only.
When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electric shock,
and injury to persons, including the following:
WARNING: Risk to Children and Impaired Persons
- Extreme caution is required during the installation, operation,
cleaning and maintenance of this product by or around
children age 12 years and younger and anyone with reduced
physical, sensory or mental capabilities, and whenever the
heater is left operating and unattended. Children should be
supervised to ensure that they do not play with the appliance,
its parts and packaging material.
INSTALLATION WARNING — To reduce risk of fire, electrical
shock and injury to persons, observe thefollowing:
- A heater has hot and arcing or sparking parts inside. Do not
use it in areas where gasoline, paint, or flammable liquids are
used or stored.
- Do not use this heater in an RV, boat or during any application
where battery power is converted to AC power.
- Place this product at least 3 feet away on all sides from,
electrical outlets, furniture, pillows, bedding, papers, clothes,
curtains and other objects that may cause or catch on fire.
Do not place the heater near a bed because objects such
as pillows or blankets can fall off the bed and be ignited by
theheater.
- To prevent a possible fire, do not place the heater on soft
surfaces, like a bed, where air intakes or exhaust can be
blocked in anymanner.
- No part of this product (the appliance, power cord, plug,
packaging, etc.) should be placed near furnaces, fireplaces,
stoves or other high temperature heat sources. Do not use in a
window, on an uneven or unstable surface, or nearwater.
- Do not use this product on an elevated surface such as shelf
or desktop. Use only while placed on the floor. Operate only in
the upright position.
- The appliance, power supply, power cord and plug cannot

5
English
come into contact with water. Do not use this product on wet
surfaces. Do not use this product in a bathtub or shower or
position product where it may fall into a bathtub, laundry,
swimming pool or other water container. Do not use this
product outdoors or expose it to weather orelements.
- Do not run cord under carpeting. Do not cover cord with throw
rugs, runners, or similar coverings. Do not route under furniture
or appliances. Arrange cord away from traffic area and where it
will not be tripped over. The cord should not hang over edges
of counters or be placed where it can be crimped or closed in
doors. Place appliance near an easily accessible outlet so the
product can be unplugged quickly during an emergency.
- Do not modify the product with any aftermarket accessory.
SAFE USE WARNING — To reduce risk of fire, electrical shock
and injury to persons, observe the following:
- Use this heater only as described in this manual. Any other use
not recommended by the manufacturer may cause fire, electric
shock, or injury to persons.
- Extreme caution is required at all times a heater is in operation.
Always unplug heater when not in use. Vornado does not
recommend unattended and unsupervised use of this heater.
- This heater is hot when in use. To avoid burns, do not let bare
skin touch hot surfaces. If provided, use handles when moving
thisheater.
- Always plug heaters directly into a wall outlet/receptacle.
Never use with an extension cord or relocatable power
tap (outlet/power strip). Do not use this heater on a surge-
protected unit or Ground Fault Circuit Interrupted (GFCI)
outlet.
- Before plugging power cord into electrical outlet, be sure that
all electrical information on the rating label, including voltage,
is compatible with your outlet’s power supply.
- WARNING: To reduce likelihood of circuit overload, fire and
electric shock, do not operate with a solid state speed device,
such as a dimmer control switch. Use of this appliance on the
same electrical circuit as another high energy use product,
such as a vacuum cleaner, blender, variable speed fan or
circular saw is not advised. Do not use this heater with a timer
designed to automatically turn the unit on or off, as this may
accidentally disable the heater’s thermal cutout safety feature.
- Risk of fire. Do not operate any heater with a damaged cord
or plug or after the heater malfunctions, has been dropped or
damaged in any manner. Discard heater, or return to a Vornado
authorized service facility for examination and/or repair.
- Never use the cord as a handle or otherwise yank, strain or
stretch the power cord.
- While the product is plugged in, do not insert or allow foreign
objects to enter any ventilation or exhaust opening as this may
cause an electric shock or fire, or damage theheater.
- Check your heater cord and plug connections. A loose fitting
outlet can cause the plug to overheat or cause a fire. Be sure
plug fits tight in the outlet. Check frequently during use to
make sure plug and outlet are not hot. If so, discontinue using
heater and have outlet replaced by a qualified electrician.
- Never ignore the signs of an electrical problem, such as: warm
outlet coverplates, sparks when plugging in or operating, lights
flickering/dimming during operation. Immediately turn off
and unplug the appliance if any such problems are noticed.
Contact a qualified electrician to investigate possible causes

6English
before operating the applianceagain.
- Note: Heaters draw more current than small appliances,
overheating of the outlet may occur even if it has not occurred
with the other appliances.
- This product’s power cord is equipped with a three-prong,
grounded plug that must be inserted into a grounded
receptacle. Connect to properly grounded outlets only.
- This heater is for use with 120 volt electrical outlets. Connect
to properly grounded outlets only. The cord has a plug as
shown at A in Figure 68.1, below. An adapter as shown at C is
available for connecting three-blade grounding-type plugs to
two-slot receptacles. The green grounding lug extending from
the adapter must be connected to a permanent ground such
as a properly grounded outlet box. The adapter should not be
used if a three-slot grounded receptacle isavailable.
- Before moving, repositioning, servicing, cleaning and when
not in use, use the product controls to turn off the power
and then unplug. To disconnect from outlet, grasp and pull
only the plug. Also, power off and unplug if the product will
be left unattended for an extended period of time or during
electricalstorms.
- If your heater suddenly stops working:
• This heater is equipped with a thermal cutout safety feature
designed to automatically shut off when overheating is
detected. See the “RESET HEATER” instructions in this guide
to determine how to check and reset the heater.
• If the heater and other electrical products suddenly stop
working at the same time, your home circuit breaker
or fuse may have tripped due to an overload of power.
Consider only running your heater on the “low” setting,
only running one heater at once and unplugging all
other electrical products while running the heater, and/or
hiring an electrician to install an additional circuit to your
home’selectrical system.
SERVICING WARNING — To reduce risk of fire, electrical shock
and injury to persons, observe the following:
- Clean your product regularly, only as is instructed in this
manual. Prior to cleaning, turn off the power on your product
and unplug. Do not use gasoline, thinners, solvents, ammonias
or other chemicals for cleaning. Refer to the CLEANING
instructions provided.
- Do not open appliance housing while product is plugged in.
To avoid risk of shock, all service and/or repairs must be done
by a Vornado Authorized Service Center.
SAVE THESE INSTRUCTIONS
Figure 68.1

7
English

8English
Plug It In Safely! Your Tempa has a 6 ft. power cord, covered for additional safety. Vornado
recommends placing product as close to an outlet as possible and securing the remaining cord.
Safety
Finger Friendly Design
Resists curious fingers.
Topple Protection
Tempa will automatically shut off if
tipped over.
Cool Touch Case
Safe to touch, even on high
heat setting.
Auto Shutoff
If airflow becomes blocked
and overheating occurs, the
heating element will shut off.
Child Locking Switch
Keeps Tempa Off when not
in use.
Covered Power Cord
Storage
Safely store power cord inside
base of Tempa.

9
English
Fan ( )
Heat ( )
Tempa Controls
Thermostat (1-7)
Power ( )
Lock Arm ( )
1
2
3
4
5
1 2 3 4
5

10 English
Power Cord Storage
For your convenience and safety the Power Cord
Storage keeps the power cord neat and out of
harms way.
1. Lift the Power Cord Storage flap to locate
plug, then unwind the power cord stored
inside.
Safety Tip: Power cords increase strangulation
risks. Secure as much excess cord as possible
inside the Power Cord Storage.
Plug In & Placement
Power Cord
Storage flap
Note: Place power
cord through slotted
opening on bottom
of Tempa to ensure
stability of heater.

11
English
Set Up
1. Position Tempa so the vortex beam of air is
directed across the room, unobstructed.
2. Plug power cord into grounded wall outlet.
Safety Tip: It is best to position Tempa close to
the power outlet and store excess power cord
inside the Power Cord Storage.
Place Tempa away from walkways, doorways
and anywhere it may pose a tripping hazard.

12 English
Locking Controls
1. To unlock this feature first pivot the Lock Arm
( ), then press the Power switch ( ) On. The
red light will illuminate when On.
2. To disengage this feature press the Power
switch Off and the Lock Arm will automatically
protect the Power switch.
Operation
1. Select Heat setting ( ). Low Heat (I) 450 watts
or High Heat (II) 900 watts.
Note: It is normal for the exit air from the heater
to feel cooler on low heat than on high heat.
2. Select Fan setting. In the Auto position ( ),
the fan will cycle on and off with the heating
element. In the Continuous position ( ),
the fan will run continuously and the heating
element will cycle on and off.
How To Use

13
English
3. Set Thermostat. Turn knob to desired comfort
level. Monitor the desired setting and adjust
Thermostat accordingly.
4. For fan use only without heat, select Fan Only
on the Thermostat and Continuous on the Fan.

14 English
Keeping Tempa Clean
Cleaning the Grille
1. Power Tempa Off and unplug.
2. Use the brush attachment on your household
vacuum cleaner to vacuum any accumulated
dust on the unit or wipe down the entire
surface with a soft, dry cloth.
Note: Do not use gasoline, thinners, solvents or
other chemicals for cleaning.
Note: Do not modify Tempa with any aftermarket
accessory.
You should periodically blow out Tempa
with pressurized air to keep heat element
and motor clear of dust, hair and debris that
can build up inside the heater as it moves air
during use. This also eliminates unwanted
odors caused by accumulation of these
particles inside the unit.
Always unplug Tempa before starting any part of the cleaning process.
Because Tempa moves a substantial amount of air, it will need regular cleaning. Cleaning the outside
of the heater is recommended on a weekly basis.

15
English
Tips
• During the off-season or after extended
periods of non-use, you may choose to store
Tempa. To ensure long life of the product, it
is recommended to store Tempa by following
these instructions:
• Always set Power switch to Off and unplug
Tempa before cleaning.
• After unplugging unit, wrap cord neatly inside
the Power Cord Storage.
• Thoroughly clean Tempa. Use the brush
attachment on your household vacuum
cleaner to vacuum any accumulated dust on
Tempa or wipe down the entire surface with a
soft, dry cloth.
• Cover, or place Tempa back into retail carton
if available. This will prevent Tempa from
accumulating dust over time.
• Store Tempa in a cool and dry location.
• The motor is permanently lubricated and
requires no oiling. Do not use gasoline, thinners,
solvents or other chemicals for cleaning.
Resetting Your Vornado Heater
Your Vornado Tempa has a multi-level
safety shut-off system designed to prevent
overheating. If this happens, the safety shut-
off system will cut power to the heat element
and you will need to manually reset Tempa.
1. Press Power Switch Off and unplug Tempa.
2. Remove any obstructions and wait 5 –10
minutes, allowing Tempa to cool down.
3. Plug in Tempa and press Power Switch to
On. Your Vornado Tempa is ready.
Note: If the safety shut-off system repeatedly
shuts off Tempa or if it will not reset, DO
NOT ATTEMPT TO DISASSEMBLE Tempa.
Call Vornado Consumer Services toll-free at
1-800-234-0604.

16 English
Unit is not plugged in. Plug Power Cord into electrical outlet.
Household circuit breaker / ground fault interrupter has tripped or
blown a fuse. Reset circuit breaker / ground fault interrupter, or replace
fuse (See IMPORTANT SAFETY INSTRUCTIONS).
The unit has overheated. Automatic Safety Shut-Off has initiated (See
RESETTING YOUR VORNADO HEATER).
Unit is damaged or in need of repair. Cease usage and unplug.
Contact Consumer Service for assistance.
Ensure unit is set to High Heat and thermostat is set to highest
temperature setting.
Close all doors and windows to contain heat.
Allow the unit to fully circulate the heat throughout the room, may take
several minutes.
Unit fails to
power on.
Unit is not
producing
sufficient
amount of heat.
Troubleshoot

17
English
Power off and unplug the unit. On the bottom of the unit, there is a
gray tip over switch. Push in 4-5 times ensuring it is not stuck. Set unit
down on flat surface. Be sure power cord is not under unit. Plug unit in
and power on. Turn to highest heat setting.
Unit powers on
but there is no
heat.

18 English
HappyPent Guantee Call Tl Free
800.234.0604
vornado.com
[email protected]
Vornado Air LLC (“Vornado”) warrants to the original consumer or purchaser this Vornadobaby® Tempa Whole Room Heater (“Product”) is free from defects in material
or workmanship for a period of five (5) years from the date of purchase. If any such defect is discovered within the warranty period, Vornado, at its discretion, will repair
or replace the Product at no cost.
For warranty or repair service:
Call 1-800-234-0604 or email [email protected] to obtain a Return Authorization (“RA”)
form. Please have or include your Product’s model number and serial number, as well as
your name, address, city, state, zip code and phone number when contacting Vornado for
warranty service.
After receiving the RA form, ship your Product to:
Vornado Air LLC Attn: Warranty & Repair 415 East 13th Street Andover, KS 67002 For
your convenience, please have your model number and serial number when contacting
Vornado with service inquiries. To assure proper handling, packages must be clearly
marked with the RA number. Packages not clearly marked with the RA number may be
refused at the receiving dock. Please allow 1-2 weeks for repair and return of your Product
after the Product is received.
Product registration available online at www.vornado.com
Repairs not covered by the warranty or outside the warranty period will require a fee to
cover the cost of materials, labor, handling and shipping. This warranty does not apply
to defects resulting from abuse of the Product, modification, alteration, mishandling,
improper maintenance, commercial use or repair or service of the Product by anyone
other than Vornado; damages which occur in shipment or are attributed to acts of God.
Improper product use, which includes using an external device that alters or converts
the voltage or frequency of electricity, or shipping a Vornado product to a country
not intended for use will void all warranties. Any unauthorized product modification,
repair by unauthorized repair center or use of non-approved replacement parts is not
recommended and any consequences will not be covered by support services or product
warranties. The product warranty will be honored only on models that are being used in
the country intended. REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY
IS THE EXCLUSIVE REMEDY OF THE CONSUMER. VORNADO SHALL NOT BE LIABLE FOR
ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION
OF THIS WARRANTY. Some states do not allow the exclusion or limitation of incidental
or consequential damages, or allow limitations on how long an implied warranty lasts,
so the above limitations or exclusions may not apply to you. This warranty gives you
specific legal rights, and you may have other rights that vary from state to state. The
manufacturer assumes no responsibility for damage or injury caused by failure to follow
these instructions, improper product use or unauthorized product modifications. Any such
actions will invalidate the product warranty.
All company names and product names are trademarks of their respective owners. ©
All rights reserved. All technical information, data and instructions for the installation,
connection and operation contained in these instructions for use correspond to the latest
available information at time of printing. The contents of this manual may differ slightly
from the actual product. Observe any additional supplements.
If you’re not satisfied with this product, let us know. We’ll go the extra mile to ensure you’re a happy Vornadobaby parent!
© 2020 Vornado Air LLC Andover, KS 67002 Patent US 9,620,311 B2 and U.S. Patent D780,301. Specifications
subject to change without notice. Vornado® and Vornadobaby® are trademarks owned by Vornado Air LLC.
Designed, engineered and supported in Andover, KS

CL3-0617 R-, V01
Speak your mind vornado.com/reviews
Hable con franqueza vornado.com/reviews
Exprimez-vous! vornado.com/reviews
Vornado Air, LLC
415 East 13th Street, Andover, Kansas 67002
800.234.0604
vornado.com
[email protected]
