EC-Declaration of conformity
Name of
issuing entity: Deutsche Vortex GmbH & Co. KG
Address: Kästnerstraße 6
71642 Ludwigsburg
Deutschland
Product name: Domestic hot water pump
Type designation: BWO 155 SL
The designated product complies with the provisions of
Directives:*
2006/95/EG
„Directive 2006/95/EC of the European Parliament and the
Council on the approximation of the laws of the Member
States relating to electrical equipment designed for use
within certain voltage limits“
and
2004/108/EG
„Directive 2004/108/EC of the European Parliament and
of the Council on the approximation of the laws of the
Member States relating to electromagnetic compatibility
and repealing Directive 89/336/EEC“.
* The conformity of the product with the provisions of the
Directives is proven by complete adherence to the
following standards:
Ludwigsburg, 01.01.2012

3
Declaration of conformity 2
Safety, product description 3
Technical specifications 5
Installation*6
Electrical connection*9
Venting*11
Speed adjustment*11
Mounting cable box 13
Self-learning module 16
Description of functions 17
Servicing*18
Replacement*20
Faults and remedies 22
These instructions are part of the product, are valid for all
series named and describe how to use the product safely
and correctly during all operating phases.
Danger! immediate acute
risk
fatal or serious
injury
Warning! potential acute risk fatal or serious
injury
Careful! potentially ha-
zardous situation light injury, damage
to device
Warning labels and symbols
Safety warning sign: Take note of all
information indicated by the safety
warning sign and follow the instructions
to avoid injury or death.
Information
Instruction
Contents Safety
Chapters marked with * contain illustrations of the pump BWO
155.
Warning label Risk level Consequences of
non-observance
Symbol Meaning

4
automatically identifies the consumer’s hot water
consumption patterns within a short time. It identifies
when hot water is needed and provides it proactively.
Using the button controller, the comfort setting can be
adjusted to the specific needs. LED indicators display the
current operating status of the pump.
automatically detects deviations from the “standard”
pattern, e.g. weekends, absence and daylight-savings
time.
automatically detects the time for the thermal
disinfection1.
switches the pump off as soon as the pump control
detects that hot water is available in the domestic hot
water (DHW) circuit.
The self-learning module
(also see chapter "Functional description" p. 17)
Product description
The pump BWO 155 SL BlueOne is a domestic hot water
pump with a highly-efficient electronically commutated DC
motor as drive source. It is built according to the original
VORTEX spherical motor principle and contains a perma-
nent magnetic rotor. The speed of the pump BWO 155 SL is
infinitely variable.
Installation of the pump may only be performed by quali-
fied personnel.
Keep the operating instructions and other applicable docu-
ments complete, in a legible condition and permanently
accessible.
Read the operating instructions and make sure you under-
stand them before working on the pump.
This pump is suitable for drinking water only.
Only operate the pump if it is in perfect technical condition;
only use it as intended, staying aware of safety and risks,
and adhering to the instructions in this manual.
Before carrying out any installation or maintenance work,
disconnect motor from power supply and ensure it cannot
be reconnected unintentionally.
General safety instructions

5
Pmax = 10 bar
P
m
~43 dB(A)
TF 95
(t1≤95 °C)
t2≤40 °C
t1≤95 °C
1~115–230 V
50–60 Hz
Technical specifications
In branched pipework without hydraulic balancing, the level
of convenience may be reduced.
The pump run times can be reduced to a minimum with the
BWO 155 SL. This does not contradict DVGW working paper
W 551, since the protection required against the growth of
legionellae is attained through regular thermal disinfec-
tion. This is performed automatically by the BWO 155 SL1.
Furthermore, if the consumer is absent, regular water
exchange in the pipework is ensured (daily flushing).
Scope of delivery
Gaskets and selected union set for pumps with V-type
pump housing
Insulating cover for pump housing
Operating instructions
Cable box with temperature sensor, sensor cable2and
detachable cable tie
3 cable ties for attaching the sensor cable
1Precondition: The hot water boiler has an anti-legionellae function.
2A 5m long sensor cable is available as an accessory.

6
≥50 cm
KV 150
RV 153
(1)
(2)
≥50 cm
Careful! Damage to device caused by water
intrusion.
►After mounting, ensure that the cable entry
or the cable is pointing downwards (see fig.).
Installation
A shut-off valve and a non-return valve are already built
into V-pumps (1).
►With R 1/2" pumps (2), build in an additional non-return
valve RV 153 and a ball shut-off valve KV 150.

7
++
VORTEX EF 150 = 20 Nm
6 7
98
4 5
3
1
2
Careful! Damage to bearings caused by dry-
running.
►Flush pipework thoroughly with water and
bleed (see figs. 1-12).
Installation

8
13
= 20 Nm
10 11 12
Careful! Damage to bearings caused by dry-
running.
►Flood the pump before connecting electric-
ity: Open all stop valves slowly (see fig. 13).
Installation

9230 V~
8,5 - 10 mm
3a 3b 3c
21
The drive of the pump is a DC motor. Thus a protective
conductor is not required.
For AC operation a transformer is integrated in the cap.
Electrical connection
Danger! Danger of electrocution.
►Have all electrical work carried out by
qualified electricians only.
►Turn off the power supply and safeguard it
against being switched back on (see fig. 1).
►Check to make sure the power is turned off.
Warning! Fire hazard due to electrical
ignition.
►Make sure that the pump is only connected
to the power supply specified on the name
plate.
Note: The pump deletes all commands for automatic starts
if the power supply is shut off.
►The pump requires an independent electrical power
supply. Do not connect the pump to an additional
controller or timer.
►A permanent power supply is possible, alternatively
use a mains plug with IP 44 rating (provide isolator that
separates all poles).
►Cable diameter 0.75 – 1.5 mm²
►Round cable with Ø 5 – 8 mm
►Connection with twisted wires, no wire end sleeves, no
tinned ends

10
10
8 9
230 V~
7
5
4
230 V~ 230 V~
230 V~
6
11
The pump will run continuously as long as the sensor
cable is not connected (see fig. 11).
Electrical connection

11
0 100 200 300 400 500 600 700
0,2
0,4
0,6
0,8
1,0
1,2
1,4
2
4
6
8
10
12
14
800 900
Q[l / h]
H [mWS]
n = 2000 - 3000 1/minBWO 155 V
n = 2000 - 3000 1/minBWO 155 R
[kPa]
5x
3 4
1 2
5
Venting
Warning! Hot surface on pump housing and
motor. Danger of burns!
►Avoid direct contact with pump housing and
motor.
►Ensure that the return line is air-free (see p. 7). Then
act as follows to bleed the pump until it runs noise-free
(alternately):
►Switch the pump on and off several times (see fig. 2).
►Open a hot water tap several times (see fig. 3).
Speed adjustment
Danger! Danger of electrocution.
►Before working on the pump, disconnect
power supply and ensure that it cannot be re-
connected unintentionally (see fig. 1, p. 12).
►Check to make sure the power is turned off.
Warning! Hot surface on pump housing and
motor. Danger of burns!
►Avoid direct contact with pump housing and
motor.
The speed is infinitely variable.

12
3
4
2
230 V~
7
56
1
Speed adjustment

13
20 - 50 cm
2
1
Mounting cable box
Note! Malfunctions of the self-learning module are possible
as a result of incorrect installation.
►Note order of assembly steps (installation sequence).
►Disconnect power supply and ensure that it cannot be
reconnected unintentionally (see fig. 1).
Installation conditions
The cable box must be mounted onto the supply line (hot
water pipe), independently from the type of hot water
generating system used.
Optimal distance of the cable box to the boiler: 20 to
50 cm.
If a mixer valve is present: The cable box can be installed
before or after the mixer valve.

14
AB
B
3 4 8
6 7
5
A
Warning! Danger of stumbling by loose sensor
cable.
►Secure the sensor cable with the cable ties
after laying (see figs. 6 and 14).
Installation sequence
Measure distance between pump and point of installa-
tion of cable box. Only pull as much sensor cable from
the cable box as required. The maximum length of the
sensor cable is 2.50 m. A 5m long sensor cable is avail-
able as an accessory.
The sensor cable can only be wound up or unwound
when plug A is still inside the cable box (see fig. 4).
Mounting cable box

15
910
11 12
13 14
A
15
Mounting cable box
►Fix cable box to supply line using the cable tie.
►Ensure there is sufficient thermal contact between the
sensor and the supply line.
Restart: As soon as the power supply has been restored,
the pump and the self-learning module will be ready for
operation, LED indicator 3 will be illuminated (basic set-
ting), and the learning process will begin.

16
4
3
5
6
112
Button and LED indicators :
Legend for fig. 1:
1Select the operating mode (clockwise):
2Comfort setting
3Continuous pump run
4Pump stop
5Pump is running (LED is illuminated green) or it is
switched off (LED is not illuminated)
6Sensor fault (LED is illuminated red, see p. 23)
Step 1: Maximum energy savings, minimum pump
run times
Step 2: Normal comfort, short pump run times
Step 3: Basic setting – good comfort, average pump
run times
Step 4: Very high comfort, normal pump run times
Step 5: Maximum comfort, increased pump run times
►Press 1until the desired operating mode is illuminated.
It will be active immediately.
Changing the operating mode:
Comfort settings:
Press 1for 5 seconds. All acquired switch-on commands
will be deleted, comfort setting 3 will be set again.
Restoring the factory default settings (reset):
Self-learning module
After establishing a connection to the electric power
grid, the comfort setting 3 will be set (LED 2is illumi-
nated). This comfort setting is optimal for the majority of
the applications.
►We recommend to wait three weeks before altering the
comfort settings.
►If no hot water is available immediately after opening a
tap, close tap again and wait until circulation has started.
The comfort setting is retained (non-volatile) in case of
power failure.

17
How does the pump learn?
A hot water tap is opened. The supply line heats up. This
is detected by the pump through the external temperature
sensor and the point in time of the hot water tap is learned.
For periodic (typical) taps the pump will proactively execute a
pump run (approx. 5 to 15 minutes prior to that point in time).
When does the pump start to run?
For reasons of comfort and independent of DHW drawings,
the pump starts frequently during the first 2 weeks (early
part of the learning phase).
Afterwards, the pump starts in the following cases:
- proactively (at the typical "learned" points in time),
- when hot water is tapped (at not yet learned points in time),
- for a flushing or disinfection cycle (see below).
The pump calculates the need for a pump run individually
every single day (Mon to Sun) based on the previous hot-
water taps of the last 2 weeks.
How long does the pump run?
The pump will run until the circulation loop is supplied with
warm water (detection through a thermostat in the pump).
The run time depends on the size of the circulation system.
How long does the pump run per day?
The daily runtime depends on the size of the circulation
system, the comfort setting and the tapping behavior of
the consumer. Typically, the pump will run between 1 and 5
hours daily.
Description of functions
How does the disinfection cycle recognition work?
The highest flow temperature measured in a given week is
interpreted as the disinfection temperature. At this point in
time, the pump will run for 30 minutes (once per week). If at
any other time of the week a higher supply temperature is
detected, the pump will shift the disinfection cycle to that
point in time.
How is absence detected (vacation detection)?
If no hot water is tapped within 24 hours, the pump will
determine an absence. Proactive pump runs will no longer
occur. A detected disinfection cycle will still be performed
(once per week). Otherwise, the pump will perform a daily
flushing cycle (duration: 15 minutes).
How will the return from the absence be recognized?
With 2 hot water tappings within an hour the previously
learned cycle will come into effect again.
How do you delete the learned tappings (reset)?
The self-learning module erases all learned switch-on
commands if the power is interrupted or the button 1is
pressed for 5 seconds.

18
6
4
7 8
3
5
2
1
Danger! Danger of electrocution.
►Before working on the pump, disconnect power
supply and ensure that it cannot be recon-
nected unintentionally (see fig. 2).
►Check to make sure the power is turned off.
Note: Damage of sensor cable.
►When removing the motor from the pump housing, pay
attention to the sensor cable (fixed with cable ties).
Servicing

19
5x
16
17
910
11 13
14
12
15
= 20 Nm
►Technical support is available from your heating and
sanitary specialist or from Deutsche Vortex.
Servicing
►Every time the motor is opened, replace the sealing
ring (see fig. 9).
►Insert the new sealing ring into the groove in the pump
housing and press slightly into place (see fig. 10).

20
11
567
8910
= 20 Nm
1 2
3 4
Danger! Danger of electrocution.
►Before working on the pump, disconnect
power supply and ensure that it cannot be
reconnected unintentionally (see fig. 1).
►Check to make sure the power is turned off.
Motor
Replacement
