Voscom VOS-4FOM-D422T Series User manual

VOS-4FOM-D422T/R series
4-Channel Duplex Rs422 Data Transmission
Installation Manual
Fiber Optic Transmission Systems
VOSCOM TECHNOLOGIES CO.,LIMITED
WWW.VOSCOM.COM
TM

Important Safety Instructions EN_1
1. Readthese instructions. Keep these instructions. Heed allwarnings. Follow all instructions.
5. Donot use this apparatus near water. Cleanonly with dry cloth.
7. Donot block any ventilation openings. Install in accordance with the manufacturers
instructions.
8. Donot install near any heat sources such as radiators, heatregisters, stoves,or other
apparatus (includingamplifiers) that produce heat.
9. Donot defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has twoblades withone wider than the other. Agrounding type plug has two blades and a third
grounding prong. The wideblade or the third prong are provided for your safety. Ifthe provided
plug doesnot fitinto your outlet consult an electrician for replacement of the obsolete outlet.
10. Protectthe power cord from being walked on or pinched particularly at plugs,convenience
receptacles, andthe points where they exit from the apparatus.
13. Referall servicingto qualifiedservice personnel. Servicing is required when the apparatus
has beendamaged in any way, suchas power-supply cord or plug is damaged, liquid has been
spilled or objects havefallen into the apparatus,the apparatushas been exposed to rain or
moisture, doesnot operatenormally,or has been dropped.
14. Apparatusshall not be exposed to dripping or splashing and that no objects filled with liquids,
such asvases shall be placed on the apparatus.
15. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatusto rain or
moisture.
16. Installation should be done only by qualified personnel and conform to all local codes.
20. CAUTION: These servicing instructions arefor useby qualified service personnel only.To
reduce therisk of electric shock do not perform any servicing other than that contained in the
operating instructionsunless youare qualifiedto do so.
Website:www.voscom.com

Product Overview En_2
Video
The VOS-4FOM-D422T/R can transmission4-Ch
duplex rs422 data oversinglemode or multimode
optical cable. Stand-alone orrack-mount. The cards
can beinserted into our 14 slots,19inch 4U or 6U
rack-mountable card cage (VOS-CH04 or VOS-CH06).
The card of this model require two slots widths.
Model Number
Transmitter Receiver Fiber Mode Wavelengths Optical
Power
Budget
Maximum
Transmission
Distance
Multi-Mode 1310nm/1550nmVOS-4FOM-D422MRVOS-4FOM-D422MT
•The OpticalPower Budgetdata fitMulit-mode(62.5/125 m),Single-Mode(9/125 m).
•When using50/125 m multimode fiber, subtract3 dBfrom the optical power budget.
•Optical transmissiondistance is limited to optical loss of thefiber and any additional loss introduced by connectors,
splices andpatch panels.
•Maximum transmissiondistance is also limited by fiber bandwidth.
•Power adapteris manufactured by thirdparty and is supplied with fitted screw-terminal outputcables.Power
adapter included(for standalone) US, European, UK or Australian powerplug.
•Please feelfree to consult factory for anyspecial requirement and customization
Note:
16dB 2km
Single-Mode
VOS-4FOM-D422SRVOS-4FOM-D422ST 12dB 20km
VOS-4FOM-D422ST-4
VOS-4FOM-D422ST-6
VOS-4FOM-D422SR-4
VOS-4FOM-D422SR-6
Single-Mode
Single-Mode
18dB
25dB
40km
60km
Models and Optical Power Budget:
•Multi-mode Fiber Support forDistances up to 2 km
•Single-Mode Fiber Support forDistances up to 100 km
•No EMIor RFIand no ground loops
•Stand aloneor rack-mount
•Duplex Rs422Data transmission over onefiber
Features:
Audio
1310nm/1550nm
1310nm/1550nm
1310nm/1550nm
Data
44
Fiber optic Cable
VOS-4FOM-D422T
Transmitter VOS-4FOM-D422R
Receiver
4 x Data
RS-422
4 x Data
RS-422
System Diagram:
Note: More detailspecification please find inthe datasheetor our website: www.voscom.com

1
1
2
Fiber OpticConnector, FC/PC or ST/PC
Stand-alone Power supply Connector, DC5V3A Input.
Panel & Cable Connection En_3
NOTE1: Digital video optic transmitterand receivershould be used in pairs, one is Transmitter
(LED is red), theother is Receiver (LED is green).
NOTE2: Avoid simultaneously connecting video signals to both the front BNC and rear BNC of the
same channel.Also, since each video channel is factory terminated to 75 ohm, unused BNCs
should notbe used for loop-through video connections.
3Rs422 DataConnector, Terminal Block,duplex data input /output.
FRONT PANEL
FTX
REAR PANEL
DC5V
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
EXT1 EXT2 EXT3 IP/EXT
12
None
3

Panel & Cable Connection En_4
Transmitter (Rs422): 4-Channel RS422 Data (In/Out)
1-CH RS422TX+
1-CH RS422TX-
Input
8 Pin Terminal Block
1
2
3
4
5
6
7
8
None
PIN
None
2-CH RS422TX+
2-CH RS422TX-
1-CH RS422RX+
1-CH RS422RX-
Input
1 2 3 4 5 6 7 8
EXT1
Output
Output
Input
Input
Transmitter EXT1/EXT2/ EXT3 Terminal Block Connection
8 Pin Terminal Block
1 2 3 4 5 6 7 8
EXT2 3-CH RS422TX+
3-CH RS422TX-
Input
1
2
3
4
5
6
7
8
None
PIN
None
3-CH RS422RX+
3-CH RS422RX-
2-CH RS422RX+
2-CH RS422RX-
Input
Output
Output
Output
Output
8 Pin Terminal Block
1 2 3 4 5 6 7 8
EXT3 4-CH RS422TX+
4-CH RS422TX-
Input
1
2
3
4
5
6
7
8
None
PIN
None
None
None
4-CH RS422RX+
4-CH RS422RX-
Input
Output
Output

Panel & Cable Connection En_5
Receiver (Rs422): 4-Channel RS422 Data (In/Out)
1-CH RS422RX+
1-CH RS422RX-
Output
8 Pin Terminal Block
1
2
3
4
5
6
7
8
None
PIN
None
2-CH RS422RX+
2-CH RS422RX-
1-CH RS422TX+
1-CH RS422TX-
Output
1 2 3 4 5 6 7 8
EXT1
Input
Input
Output
Output
Receiver EXT1/EXT2/ EXT3 Terminal Block Connection
8 Pin Terminal Block
1 2 3 4 5 6 7 8
EXT2 3-CH RS422RX+
3-CH RS422RX-
Output
1
2
3
4
5
6
7
8
None
PIN
None
3-CH RS422TX+
3-CH RS422TX-
2-CH RS422TX+
2-CH RS422TX-
Output
Input
Input
Input
Input
8 Pin Terminal Block
1 2 3 4 5 6 7 8
EXT3 4-CH RS422RX+
4-CH RS422RX-
Output
1
2
3
4
5
6
7
8
None
PIN
None
None
None
4-CH RS422TX+
4-CH RS422TX-
Output
Input
Input

Stand-alone Installation En_8
The VOS-4FOM-D422T transmitter/VOS-4FOM-D422R receivercan be mounted into a rackor can be
used as a stand-alonemodule. As a stand-alone module, the unit can be placed on a desktop or
can bemounted toa wall.
NOTE: Before mounting the VOS-4FOM-D422T transmitter/VOS-4FOM-D422R receiver, please
ensure that there is adequate space at both ends forviewing the front-panel LEDsand for making
the variousrear-panel cableconnections.
Stand-alone Mounting Size: 176.5mm x 158mm x 59mm
Website:www.voscom.com

Rack-mount Installation En_9
Installation Instructions
Typical Configurations:
1:Install the video card into a standard 19inch rack, usinguser-supplied rack-mounting
hardware. Becareful to not damage exposed objects on the back of the card cage unit.
2:If asecondary earth ground connectionis needed, a grounded wire with a ground lug can be
attached to the rackusing the protruding screw provided on the right side of the chassis.
3:If desired, blank panels may beinstalled tocover unused slots. A single blank panel coversa
single slot opening.
4:Each fiber optic plug-in module is equipped with a POWER LED indicator that illuminates
when power is applied to the rack unit.
5:Fiber optic plug-in modules(video cards) can be installed into anyof theavailable 14slots
of thecard cage. Most modules require onlya single slot width, but others, such as the 8-Ch
video Series, require two slot widths.
VOS-CH04:
19 inch4U,14 video card slots, suit for 1-ch,2-ch,4-ch,8-ch(two slots)video cards.
Support oneslide-in power supply AC100V~AC240V
VOS-CH06:
19 inch6U,16 video card slots, suit for 1-ch,2-ch,4-ch,8-ch(two slots)video cards.
Support two slide-in power supply AC100V~AC240V, one for redundancy.
Website:www.voscom.com
The VOS-4FOM-D422Ttransmitter/VOS-4FOM-D422R receivercan be installed into our rack mount
chassis, VOS-CH04or VOS-CH06, which can be mounted into an industry-standard 19-inch
equipment rack.

Troubleshooting En_10
Indicator Status Meaning Possible Cause Corrective Action
Power LED
Light Power isbeing applied
to the module. --- No actionrequired.
Not Light Power isnot being
applied to the module.
Check powerconnection.
If moduleis rackmounted,
reseat moduleor power
supply asnecessary.
Power connectionis
faulty.
Power supplyhas failed. Replace powersupply.
Loss ofpower occurs due
to trippedcircuit
breaker(s), blownfuse(s),
or faultyelectrical
service.
Check circuit breaker(s),
fuse(s), orelectrical
service asnecessary.
LED indicators on thefront-panel of the transmitter/receiverallow youto monitor signal status,
laser status,data activity, contact closure activation, and operatingpower. Table A~D provide
information aboutthe front-panelindicators and associated troubleshooting guidelines.
Table A: Power Links
Indicator Status Meaning Possible Cause Corrective Action
Video LED(VIDEO 1,VIDEO 2....)
Light Incoming video signal
is present on thechannel. --- No actionrequired.
Not Light
on Transmitter Incoming video signal is not present on the
channel.
Check power connection
to the video source.
Video source is not
powered on.
Video source is not
connected to the
transmitter.
Check BNC connections.
Coaxial cable is
defective. Replace cable.
Table B: Video Links
Not Light
on Receiver Incoming video signal is not present on the
channel.
Optical signal is not
being receivedfrom the
transmitter. Optic Fault
LED is also not light.
Refer tothe Optic Fault
LED section in this table.
Video source is not
powered on. Check power connection
to the video source.
Video source is not
connected to the
transmitter.
Check BNC connections.
Coaxial cable connected
to the transmitter is
defective.
Replace cable.
Website:www.voscom.com

Troubleshooting En_11
Indicator Status Meaning Possible Cause Corrective Action
Data(RS485/RS232/RS422) LED
Flashing
Data is being transmitted
onto the fiber by the data
port or is being received
from thefiber by the
data port.
--- No actionrequired.
Table C: Data Links
Indicator Status Meaning Possible Cause Corrective Action
Optic LED
Light The optical signal is being
received andlaser is
operatingproperly.
--- No actionrequired.
Not Light
Table B: Optic Links
Not Light
Data isnot being
transmitted ontothe
fiber bythe data port or
is notbeing received
from thefiber by the
data port.
Data isnot present on
the channel. No actionrequired.
Data connectionis faulty. Check dataconnections.
Data communication
cable isdefective. Replace cable.
The optical signal is
not beingreceived.
Remote fibermodule is
not poweredon. Check power connections.
Replace powersupply if
necessary.
Fiber optic cable is not
connected. Check fiberoptic
connections.
Fiber optic cable
connectors aredirty or
are damaged.
Clean, polish, or replace
fiber opticcable
connectors asnecessary.
Fiber optic cable is
defective. Replace cable.
A problemexists with
the optical power
budget.
Verify thatlosses infiber
optic cable do not exceed
the optical power budget
specification of the fiber
optic link. If the losses do
exceed theoptical power
budget, contactProduct
Support.
