Vox BTMOTOF4 User manual

BTMOTOF4
Bluetooth Headset for Motorcycle
Features
VOX Technology
A2DP Music Streaming
Auto-Volume Level Adjusting
1

6
A. PRODUCT DESCRIPTION:
SUPERTOOTH BTMOTOF4 is a Bluetooth Headset designed for motorcycle
rider or passenger who wishes to have reliable hands-free, wireless and clear
communications while driving. This headset is equipped with hi-tech features
such as: V X Technology, A2DP (Advance Audio Distribution Profile) music
streaming and Auto-Volume Level Adjusting.
1. MFB or Multi-Function Button
(power on & off / pairing / answer /
hang-up / reject / voice dial / etc.)
2. Hea set Plug
3. Volume Up
4. Volume Down
5. Status In icator
6. Left/Right (L/R) Ear Speaker
7. Microphone ( n the flexible boom)
8. Charger an Hea set Socket
9. Hook
B. CHARGING:
1. When the Status In icator (5) turns Red, the battery is low. Charge the
unit using the provided charger.
2. Connect the charger’s plug to the Charger Socket (8) of the SUPERTOOTH
BTMOTOF4. Then, plug the charger to an external power source. ( ote:
Status Indicator (5) turns Red when charging).
3. When the Status In icator (5) turns Green,
charging is complete.
4. Disconnect the charger.
C. POWER ON OR OFF:
Power On: Press the MFB (1) until Status In icator (5) turns blue. r press for
approximately 3 seconds, a beep will be heard.
Power Off: Press the MFB (1) until Status In icator (5) turns red. r press for
approximately 5 seconds, a beep will be heard.
D. PAIRING TO YOUR BLUETOOTH MOBILE PHONE:
1. From FF, press and hold the MFB (1) of the SUPERTOOTH BTMOTOF4
until the Status In icator (5) turns blinking red/blue.
2. While the headset is in pairing mode, access the Bluetooth menu of your
phone. Turn on the Bluetooth function then execute a Bluetooth search. (See
your phone’s manual).
3. When the phone displays the list of Bluetooth devices, select ST MOTO then
enter 0000 and press ok. Pairing is successful if the alternating red/blue
lights of the Status In icator (5) changes to blinking blue.
2
1
23
4
5
7
9
6
Charger and Headset Socket
8

ote: Some phones do not connect automatically to the kit after pairing. You
need to press the MFB (1) (1st beep) to connect.
Or use the menu of your phone:
Go back to Bluetooth > Paired devices > highlight the name of this
headset (ST MOTO) > press Options > then press Connect.
The SUPERTOOTH BTMOTOF4 is now ready to use.
E. BASIC OPERATION:
IMPORTANT:
The SUPERTOOTH BTMOTOF4 needs to be ‘paired’ with your Bluetooth mobile
phone before you can use the following functions. (See Pairing to your
Bluetooth Mo ile Phone on section D.)
Make a Call:
- Dial the number using your phone. Audio will automatically be on the
headset.
ote: With some phones, audio is always on the phone during an outgoing call.
You will need to press the MFB (1) to transfer the audio to your headset.
Answer a Call:
-Assuming the VOX is activated: Accept a call by loudly saying a word within
10 seconds. (Example: When you receive the ring tone, Say loudly ”Ok!”)
The call will be answered. Audio will be on the headset. (See VOX
Activation / Deactivation on section F.)
-You also have the option to answer the call normally by pressing the MFB
(1) for 1 second (1st beep).
En a Call:
-Press the MFB (1) for 1 second to end the call (1st beep).
Reject a Call (For Handsfree Profile Phones only):
-Assuming the VOX is activated: Reject a call by being silent for 10 seconds.
The call will automatically be rejected. (See VOX Activation / Deactivation
on section F.)
-You also have the option to reject the call normally by pressing the MFB (1)
for 3 second (2nd beep).
Voice Dial:
IMPORTANT: First, make sure to activate the voice dial function of your phone.
Record at least one voice tag. (Kindly refer to the procedure in your phone’s
manual.)
3

ote: Voice dialing entries must be stored in the phone’s memory, not on the
SIM card!
1. Press the MFB (1) for 1 second (1st beep) to make a voice dial. A voice dial
tone/ beep will be heard on the headset prompting the user to say the voice
tag of the contact to call.
2. Say the voice tag. The voice will be played back to you, and then the phone
will dial the number automatically.
Re ial:
-Press the MFB (1) for 3 seconds (2nd beep). The last dialed number will be
redialed.
Au io Transfer (For Handsfree Profile Phones only):
-During an ongoing call, you can transfer the audio.
Hea set to Phone: Press and hold the MFB (1) for 3 seconds (2nd
beep) and the audio will be transferred to the phone.
Phone to Hea set: Press the MFB (1) for 1 second (1st beep) and the
audio will be transferred to the headset.
ote: For some phones, you may need to accept a connection prompt on the
phone before automatic transfer takes place.
Set the Volume:
-Press the Volume Up (3) or Down (4) button repeatedly until the desired
level is reached.
F. SPECIAL FEATURE: VOX Activation / Deactivation:
- When activated, the user can accept a call by saying any word within 10
seconds. The user can also reject a call by being silent for 10 seconds.
-When deactivated, use the MFB (1) to answer a call.
The Voice Answer Mo e can be enable or disable when the kit is in standby
mode (no ongoing call and close any multi media player).
Activation:
1. From Connected and standby, press and hold the Volume Up (3)
button for 5 seconds.
2. A beep will be heard. Then release.
Deactivation:
1. From Connected and standby, press and hold the Volume Down (4)
button for 5 seconds.
2. A beep will be heard. Then release.
4

G. STREAM MUSIC FROM YOUR A2DP BLUETOOTH MOBILE PHONE:
If a phone supports A2DP, you can stream music from your phone to the
SUPERTOOTH BTMOTOF4.
ote: The SUPERTOOTH BTMOTOF4 needs to be ‘paired’ with your Bluetooth
mobile phone before you can use the following functions. (See Pairing to your
Bluetooth Mo ile Phone on section D.)
Using A2DP Music Streaming
To Stream Music:
-Go to your phone’s music player and play a track via A/V bluetooth. (See
your phone’s manual).
-Or Double Short Press the MFB (1) to play/pause music streaming.
To Choose Music File:
- Long press the Volume Up (3) button for 3 seconds, music will go to the
next music file.
- Long press the Volume Down (4) button for 3 seconds, music will go
back to the previous music file.
To Set the Volume:
-Press the Volume Up (3) or Down (4) button repeatedly until the desired
level is reached.
5

Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modifications not ex ressly a roved by the art res onsible for
com liance could void the user’s authority to o erate the equi ment.
15.105(b)
This equi ment has been tested and found to com ly with the limits for a Class B digital device, ursuant
to art 15 of the FCC rules. These limits are designed to rovide reasonable rotection against harmful
interference in a residential installation. This equi ment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a articular
installation. If this equi ment does cause harmful interference to radio or television rece tion, which can be
determined by turning the equi ment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the se aration between the equi ment and receiver.
-Connect the equi ment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an ex erienced radio/TV technician for hel .
Operation is subject to the following two conditions:
1) this device may not cause interference and
2) this device must acce t any interference, including interference that may cause undesired o eration of
the device.
FCC RF Radiation Exposure Statement:
This equi ment com lies with FCC radiation ex osure limits set forth for an uncontrolled environment.
End users must follow the s ecific o erating instructions for satisfying RF ex osure com liance. This
transmitter must not be co-located or o erating in conjunction with any other antenna or transmitter.
6
