VP Networks MultiAP 700G User manual

C OPYRIGHT & T RADEMARKS
Specifications are subject to c ange wit out notice. Copyrig t © 2012 ValuePoint Networks. All Rig ts Reserved. ValuePoint and
t e VP logo are trademarks of ValuePoint Networks. Ot er brands or products mentioned may be trademarks or registered
trademarks of t eir respective owners.
MultiAP 700G
User Manual
Aug-12

Table of Contents
1 INTRODUCTION AND SCOPE .................................................................................... 3
2 PRODUCT FEATURES ................................................................................................ 3
3 INSTALLATION............................................................................................................. 4
5.1 I NSTALLATION P ROCEDURES .................................................................................................. 4
5.2 Q UICK S TART ........................................................................................................................ 6
4 INFORMATION.............................................................................................................. 6
6.1 S YSTEM ................................................................................................................................ 6
6.2 W IRELESS ............................................................................................................................. 7
6.3 WDS.................................................................................................................................... 8
6.4 E VENT L OG ........................................................................................................................... 8
6.5 N EIGHBOR AP S ..................................................................................................................... 9
5 CONFIGURATION ...................................................................................................... 10
7.1 S YSTEM S ETTINGS .............................................................................................................. 10
7.2 W IRELESS N ETWORKS S ETTINGS ......................................................................................... 16
7.3 A DVANCED S ETTINGS .......................................................................................................... 26
7.4 WDS S ETTINGS .................................................................................................................. 30
7.5 SNMP S ETTINGS ................................................................................................................ 32
7.6 W EB A DMIN S ETTINGS ......................................................................................................... 35
6 DIAGNOSTIC TOOLS................................................................................................. 37
7 COMMANDS................................................................................................................ 38
8 PER USER VLAN TAGGING ..................................................................................... 40
APPENDIX A..................................................................................................................... 41
APPENDIX B..................................................................................................................... 42

1 In roduc ion and Scope
MultiAP 700G is a carrier-grade 802.11b/g Wi-Fi access point wit centralized management system. It is
a powerful solution for building wireless networks for Wireless Internet service, w olesalers and
enterprises. Eac MultiAP 700G is loaded wit essential features suc as Multiple SSID (virtual AP wit
distinct ESSID and BSSID), VLAN, and a ig -gain antenna.
One MultiAP 700G can masquerade up to 16 different access points. Eac virtual access point can ave
its own security policy (e.g. WPA, WPA2, etc.) and aut entication mec anism (e.g. 802.1x, open, captive
portal, etc), to facilitate building your w olesale network muc faster, easier and more cost-effective t an
ever before. MultiAP 700G comes wit a ig -power Wi-Fi transmitter w ic greatly en ances coverage
and performance.
2 Produc Fea ures
Key features of MultiAP 700G:
 Designed for w olesale wireless networks wit multiple SSID and VLAN support
 Independent security policies and encryption mec anisms per virtual AP
 Centralized managed via web based MultiAP Central Management System (PCMS)
 Hig -power output en ances coverage and lowers cost of owners ip
 WMM (Wi-Fi Multimedia) and QoS (Quality of Service) Support
 WDS (Wireless Distribution System) Support
 Captive Portal Support
 Mes Connector Bridging

3 Ins alla ion
MultiAP 700G acts as a bridge between t e wireless and t e wired Et ernet interface. A typical setup is
as follows:
3.1 Ins alla ion Procedures
1. Attac t e antenna to t e MultiAP 700G unit.
2. Connect t e LAN port on t e unit wit t e backbone network using an Et ernet cable. T e port
could auto sense t e cable is straig t-t roug or cross-over.
3. Connect t e power adapter to t e power connector of t e unit, and t en plug in t e power
adapter.
4. Wait for t e status LED to turn green.
5. Connect a PC to t e backbone network, and configure t e IP address of t e PC to be any IP
address between 192.168.0.4 and 192.168.0.254 , wit subnet mask of 255.255.255.0 .
6. Wit Microsoft Internet Explorer 6 or above, or Mozilla Firefox 2.0 or above, connect to t e URL
ttps://192.168.0.3 .
7. W en prompted, enter t e default admin login ID and password: admin and public respectively.
T is default username and password can be c anged in t e web admin. Please refer to section
5.6.2 for details.
8. After logging in, t e following Main Menu page appears to facilitate furt er configuration of t e

MultiAP 700G unit:

3.2 Quick S ar
By default, an access point is preset wit SSID: wireless
T e default access point bridges t e Wi-Fi interface to t e Et ernet port, wit bot encryption and VLAN
tagging disabled.
To access t e backbone network connected via t e Et ernet port of t e unit, establis a session at t e
Wi-Fi interface wit a Wi-Fi client. After establis ing a Wi-Fi client session, information about t e
establis ed Wi-Fi session appears at t e Web Administration Interface of MultiAP 700G, under t e
section at Information-> Wireless.
4 Informa ion
4.1 Sys em
Sys em Informa ion
AP Name T is field s ows t e name of t e system entered in t e configuration.
Loca ion T is field s ows t e location entered in t e configuration.
Domain Name T is s ows t e domain name used for t is system.
Ne work IP Mode T is field can be set in Configure > System. T e t ree options available are:
DHCP, S a ic IP and PPPoE (Rou er Mode only).
Ne work IP Address T is s ows t e current IP used on t e system.
Ne work Subne
Mask T is s ows t e current subnet mask used on t e system.
Ne work Ga eway T is s ows t e detected/assigned network gateway of t e device.
Ne work DNS T is s ows t e detected/assigned network DNS of t e device.
Sof ware Versions T is s ows t e current firmware version running on t e system.
Serial Number T is s ows t e serial number of t e device.
Up Time T is s ows t e time as been up since boots up.
Sys em Time T is s ows t e time of day in respect to t e time zone selected.
Time Zone T is s ows t e time zone t e system is using.
Mac Address T is s ows t e LAN MAC address of t is system.
L2TP Tunnel
S a us T is s ows t e status of t e L2TP service.
Tunnel IP Address T is s ows t e IP acquired in t e establis ed tunnel.
Commen :
Commen :
Commen :

Tunnel Ne mask T is s ows t e subnet mask acquired in t e establis ed tunnel.
Firmware / Flash
Firmware Version T is s ows t e firmware version loaded into t e flas partitions.
Flash S a us T is s ows t e firmware status on t e flas partitions.
Boo from T is indicates w ic flas partition boots up t e system.
Firmware Upgrade
Targe T is s ows w ic flas partition is used for firmware upgrade.
4.2 Wireless
Wireless Informa ion
Name T is s ows t e system name defined in previous section.
Number of WLANs T is s ows number of added SSIDs.
Curren Clien s T is indicates t e number of associated clients.
Curren Channel T is s ows w ic 802.11 c annel t e system is using.
Curren S a us T is s ows t e current status of t e device.
Connec ed Clien s
Manufac urer T is s ows t e manufacturer based on t e MAC prefix.
MAC address T is s ows t e client MAC address.
WLAN SSID T is s ows w ic SSID t e client is associated.
VID T is s ows t e VLAN ID used on t e SSID.
Type T is s ows t e radio mode of t e client.
Au hen ica ion T is s ows t e client aut entication.
S a us T is s ows t e association status and t e associated duration.
De ails T is links to t e detailed page of eac client.
For information about t e Clients Details, please refer to section 5.2.
Commen :
? any ot er t an On?

4.3 WDS
Au o WDS S a us
Bssid T is s ows t e wireless MAC address of t e device.
Paren T is s ows t e parent node of t e device.
Channel T is s ows t e c annel of t e existing Bssid.
Level T is s ows t e op level of t e device.
S a e T is s ows t e state of t e node: wired or wireless.
Neighbor WDS APs
Bssid T is s ows t e wireless MAC address of t e Neig bor WDS node.
Paren T is s ows t e parent node of t e Neig bor WDS node.
Channel T is s ows t e c annel of t e existing Bssid.
RSSI T is s ows t e signal strengt of t e node.
Level T is s ows t e op level of t e node.
S a e T is s ows t e state of t e node: wired or wireless.
4.4 Even Log
Upon selecting Event Log from t e navigation bar on t e left- and-side of t e Main Menu, t e system
log is displayed. T e system log is intended to provide information to aid troubles ooting in t e event of
operational issues.

4.5 Neighbor APs
Neighbor APs
Neighbor AP
Discovery
T is s ows t e feature Neig bor AP Discovery is enabled. To disable or
configure t e Scanning Interval and Scanning Time options, please refer to
section 5.3.2.
Scanning In erval T is s ows t e scanning interval for Neig bor AP Discovery.
Scanning Time T is s ows t e scanning time for Neig bor AP Discovery.
Neighbor APs
Manufac urer T is s ows t e manufacturer based on t e MAC prefix.
SSID T is s ows t e ESSID of t e scanned access point.
Ch T is s ows t e c annel of t e scanned access point.
RSSI T is s ows t e signal strengt of t e access point.
Securi y T is s ows t e encryption type of t e access point used.
BSSID T is s ows t e wireless MAC address of t e access point.
Las Seen T is indicates t e time stamp of t e access point scanned.
S a us T is s ows w et er t e access point can be detected or not.
Commen :

5 Configura ion
5.1 Sys em Se ings
General Access Poin Se ings
AP Name A user-specified name for t e access point.
T is value can be retrieved via SNMP.
Loca ion A user-specified name for t e location of t e access point.
T is value can be retrieved via SNMP.
AP Mode
T is option enables t e access point running as a bridge or a rou er. W en
t e access point runs as a router, t e Management VLAN ID is ignored and
t e LAN settings appear for proper network setup.
Domain Name Domain name can be set for wireless clients to ave a readable name for bot
web management and captive portal redirection URLs.
Server IP
T is specifies t e unique IP address for t e MultiAP 700G unit to communicate
on t e Et ernet segment.
T is IP address is distinct from t e admin IP address 192.168.0.3 on t e
Et ernet segment.
If Keep Defaul IP is set, t e default IP would be available on t e system
along wit t e Server IP setting.
If DHCP is set, t e IP address of t e MultiAP 700G unit is t en acquired from a
DHCP server on t e Et ernet segment.
If S a ic IP is set, it is required to enter t e information related to t at static IP,
including S a ic IP address, Subne Mask, Defaul Ga eway and DNS
Server.
If PPPoE is set, it is required to enter t e information related to t at PPPoE
connection: PPPoE Username, PPPoE Password, PPPoE Service Name.
T is option is only available wit Rou er mode.
Managemen VLAN
ID
T is specifies t e VLAN from w ic management sessions are allowed. T e
establis ment of management sessions is restricted only to t e specified
VLAN ID. If Managemen VLAN ID is set to zero, no VLAN restriction is
applied.
T e default value of t is setting is zero. It means no tagging is enabled
(instead of tagged wit zero).
T is option is only available in Rou er mode.
Timezone T is option specifies t e time region to be used for representing t e time on
t e system.
NTP Server
T is is t e Network Time Protocol (NTP) Server ostname to be used for
sync ronizing system clock of MultiAP 700G.
T e default value of t is setting is pool.ntp.org .

STP
Spanning Tree Protocol, STP can be enabled to prevent pat redundancy.
Wit t is enabled, two more options are provided: Bridge Priori y and
E herne Pa h Cos .
Bridge Priori y (If STP is enabled,) t e parameter is set to give t e likeliness for root switc
election.
E herne Pa h Cos (If STP is enabled,) t is gives t e preference to provide t e best pat from t e
switc to t e root switc .
5.1.1 LAN Se ings
LAN Settings will only be available w en t e AP Mode in t e previous section ad been selected as
Rou er mode. You can use t e 700G as a DHCP server for ot er devices be ind.

5.1.2 L2TP Tunnel Se ings
L2TP Tunnel Se ings
L2TP Tunnel Enabling L2TP option on t e system would start t e tunnel establis ment from
t e access point to t e server for centralized traffic management.
L2TP Server
Address T is specifies t e L2TP server IP address for t e access point to connect to.
L2TP/PPP
Username T is specifies t e L2TP/PPP Username for tunnel aut entication purpose.
L2TP/PPP Password T is specifies t e L2TP/PPP Password for tunnel aut entication purpose.
Tunnel IP Address
T is specifies t e unique IP address for t e MultiAP 700G unit to communicate
over t e tunnel.
If From DHCP is set, t e IP address of t e MultiAP 700G unit is t en acquired
from a DHCP server over t e tunnel. Tunnel IP Address and Tunnel Subnet
Mask will be disabled automatically.
Tunnel Subne Mask
T is setting specifies t e subnet mask of t e MultiAP 700G unit over t e
tunnel.
Tunnel Managemen
VLAN
T is specifies t e VLAN from w ic management sessions are allowed over
t e tunnel. T e establis ment of management sessions is restricted only to
t e specified VLAN ID. If Managemen VLAN ID is set to zero, no VLAN
restriction is applied.
T e default value of t is setting is zero. It means no tagging is enabled
(instead of tagged wit zero).

5.1.3 Securi y Se ings
Securi y Se ings
Layer 2
Communica ion
Layer 2 is in reference to t e second layer in t e ISO Open System
Interconnect model.
W en t is option is disabled, clients on t e same VLAN, SSID or subnet are
not allowed to communicate directly via t e Layer 2 Protocol(s). Traffic is
passed to upper communication layer(s).
Wit t is option enabled, clients on t e same VLAN are allowed to
communicate wit eac ot er directly. (Windows network resources browsing
will be possible.)
By default, t e setting is enabled.
802.1X Version
T is setting selects between v1 or v2 of t e 802.1x EAPOL.
W en v1 is selected, bot v1 and v2 clients can associate wit t e access
point. However, w en v2 is selected, only v2 clients can associate wit t e
access point.
Most modern wireless clients support v2. In t e event t at t ere are stations
t at do not support v2, select t e option v1.
By default, t e value of t e setting is v2.
Managemen from
Wireless Clien s
Wit t is option enabled, Web Admin is accessible from t e Wi-Fi segment of
MultiAP 700G.
By default, it is enabled.
Syslog o Remo e
Server
Wit t is option enabled, logs are sent to an external Syslog server.
By default, t is option is disabled.
Syslog Server
Address / Por
W en t e Syslog o Remo e Server is enabled, t is option is enabled for
entering t e Syslog server IP address and por number.
By default, t e port number is 514.

5.1.4 Radius Server Se ings
Radius Server Se ings
Primary Au hen ica ion
Server
W en 802.1x aut entication is configured, t e Radius server specified by
t is setting will be used for aut entication.
Secondary
Au hen ica ion Server
T is setting specifies t e Radius server to be used for aut entication in t e
event t at t e ost specified by Primary Host is unavailable.
Secre T is is t e secret for accessing t e Radius server.
Au hen ica ion Por T is specifies t e UDP port number for t e Aut entication port of t e
Radius server.
Primary Accoun ing
Server
W en 802.1x aut entication is configured, t e Radius server specified by
t is setting will be used for accounting.
Secondary Accoun ing
Server
T is setting specifies t e Radius server to used for accounting in t e event
t at t e ost specified by Primary Host is unavailable.
Secre T is is t e secret for accessing t e Radius server.
Accoun ing Por T is specifies t e UDP port number for t e Accounting port of t e Radius
server.
Re-au hen ica ion Time T is is t e re-aut entication time interval. Enter 0 to disable re-
aut entication. By default, it is set as 0 (disable).
Maximum
Re ransmission
T is specifies t e maximum number of retry for RADIUS aut entication. By
default, it is set as 3.
Radius Reques In erval T is specifies t e time interval in second between eac RADISU request
attempt. Note t at t e request time interval would be doubled every

retransmission. By default, it is set as 3s.
5.1.5 802.11b/g Profile
802.11 b/g Profile
Radio Policy
T ree options are available:
• 802.11b/g (Mixed Mode): MultiAP 700G accepts bot 802.11b and
802.11g client association requests.
• 802.11b Only: MultiAP 700G accepts only 802.11b client association
requests.
• 802.11g Only: MultiAP 700G accepts only 802.11g client association
requests.
Coun ry
T is setting specifies t e country / region w ose regulations t e MultiAP 700G
unit s ould follow.
Users are required to c oose t eir operating country based on t eir actual
location. Laws, restrictions and regulations of use of electronic goods apply to
different countries.
Available RF c annels and Maximum transmission power options rely on t e
selected operating country.
By default, Uni ed S a es is selected.
RF Channel
T is option selects t e 802.11 c annel to be utilized.
Available options for 802.11b and 802.11g are from 1 to 11 and from 1 to 13
respectively, depend on t e operating country selected in t e previous option.
Tx Ou pu Power
T is option selects t e transmit output power of t e 700G device.
Available options are from 26 dBm to 17 dBm and 20 dBm to 11 dBm, depend
on t e operating country selected in t e previous option.
By default, Tx Output Power is configured to be 26 dBm.
An enna Selec ion
For MultiAP 700G Outdoor units, t e ardware may be equipped wit two
antennas for transmit and receive diversity.
If t e MultiAP 700G unit is equipped wit two antennas, users can select Main,
Auxiliary and Bo h (Diversi y) wit antenna diversity.
By default, Main antenna is selected.
Commen : New feature

5.2 Wireless Ne works Se ings
Upon selecting Wireless Networks under Configure section from t e navigation bar on t e left, t e
following s ows t e configured SSID available on t e system:
General Wireless Ne works Se ings
Wireless Ne work
SSID T e SSID of t e virtual Access Point (AP).
Defaul VLAN ID
T is setting specifies t e VLAN ID to be tagged on all outgoing packets
generated from t e virtual AP (i.e. packets t at travel from t e Wi-Fi segment,
t roug t e MultiAP 700G unit to Et ernet segment via t e LAN port).
If 802.1x is enabled, a per-user VLAN ID can be specified in t e aut entication
reply from t e Radius server. If it is set, t e value specified via Default VLAN
ID will be overridden.
Admin S a us T is option s ows w et er t e virtual AP is enabled or disabled.
Securi y Policies T is option s ows t e configured wireless aut entication and encryption
met ods.
BSSID T is field s ows t e detailed BSSID.
Wireless Ne works De ails
Enable Select Yes to enable t e virtual AP, or No to disable t e virtual AP.
By default, t e virtual AP is enabled.
Wireless Ne work
SSID
T is setting specifies t e SSID of t e virtual AP to be scanned by Wi-Fi clients.
T e value is not case sensitive.
By default, t e value is Mul iAP_XXXX, w ere t e substring XXXX in t e SSID
is replaced by t e last four ex digits of t e LAN MAC address of t e unit.
Defaul VLAN ID
T is setting specifies t e VLAN ID to be tagged on all outgoing packets
generated from t e virtual AP (i.e. packets t at travel from t e Wi-Fi segment,
t roug t e MultiAP 700G unit to Et ernet segment via t e LAN port).
If 802.1x is enabled and a per-user VLAN ID is specified in t e aut entication
reply from t e Radius server, t en t e value specified via Defaul VLAN ID will
be overridden.
T e default value of t is setting is 0. T at means VLAN tagging is disabled
(instead of tagged wit zero).
Broadcas SSID
T is setting specifies w et er or not t e ESSID of t e virtual AP can be
scanned by Wi-Fi clients.
Note t at t e BSSID (i.e. t e MAC address of t e virtual AP) cannot be idden
from t e scan. To associate wit t e virtual AP, clients must specify t e correct
ESSID upon association.

Broadcast SSID is enabled by default.
Mul icas Fil er T is setting enables t e filtering of multicast network traffic to t e wireless
SSID. By default, it is set as enabled.
Mul icas Ra e T is setting specifies t e transmit rate to used for sending multicast network
traffic.
Da a Ra e
T ere are two options on data rate: Fixed, Au o
Fixed will forced all data packets to be transmitted into t e selected transmit
rate. Au o will automatically select t e best transmit rate wit a condition to use
t e selected transmit rate as t e minimum auto transmit rate.
Defaul Quali y of
Service
T e 802.1p QoS value to be marked on all outgoing packets generated from t e
virtual AP (i.e. packets t at travel from t e Wi-Fi segment, t roug t e MultiAP
700G unit to Et ernet segment via t e LAN port).
If per-user or per-domain QoS value is specified, t e Default Quality of Service
value will be overridden.
Possible values are Gold, Silver and Bronze.
DHCP Server Type
T is setting selects among t e following options:
• None: DHCP requests will be passed to t e Et ernet segment, and will
not be processed by MultiAP 700G.
• Relay: MultiAP 700G will forward DHCP requests to a specified DHCP
Server. T is option prevents broadcast messages from being
propagated on t e Et ernet segment. Upon selecting t is option, t e
DHCP Server IP address will be prompted.
• Server: MultiAP 700G will allocate and offer IP addresses locally. For
furt er details, please refer to Section
•
• DHCP Server
•
Please refer to t e following sections, 5.2.1 and 0 for details.
Securi y Policy
T is setting configures t e wireless aut entication and encryption met ods.
Available options are: None, S a ic WEP, 802.1x and WPA.
Selecting None disables encryption.
For details on t e ot er options, please refer to t e following sections:
• 5.2.3 - S a ic WEP Parame ers
• 0 - 802.1x Parame ers
• 5.2.5 - WPA Parame ers
Maximum
Associa ed Clien s
T is setting limits t e number of associations allowed to t e SSID.
T e default value zero would be treated as unlimi ed.
Access Con rol
T e settings allow administrator to control t e access t roug Mac address
filtering.
Available options are: None, Deny all excep lis ed, Accep all excep lis ed.
For details on t e ot er options, please refer to Section 5.2.6 - Access Control.

Al erna ive Radius
Server Se ing
T e settings provide an alternative Radius setting for t e SSID. Wit t is
enabled, t e settings would overwrite t e Radius settings under system in
section Configure.
For details on t e ot er options, please refer to Section 5.1.4 Radius Settings.
Cap ive Por al
T is setting enables t e captive portal capability on t e access point to do URL
redirection wit different aut entication. For details on t e ot er options, please
refer to Section 5.2.7 Captive Portal Settings.
Bandwid h
Managemen
T is option enables t e settings to control upstream and downstream limits.
For details please refer to Section 5.2.8 – Bandwidt Management.
Al erna ive Layer 2
Communica ion
Se ing
Wit t is option enabled, 3 more options for Layer 2 Communication settings
will be available.
For details, please refer to Section 5.2.9 – Alternative Layer 2 Communication
Settings.
Wireless Ne work
Fil er
T is option enables t e access point to filter network traffic based on t e users’
defined rules. Users can use MAC address, IP address and protocol to form
t e matc ing rules to perform eit er drop or accept policy.
For details please refer to Section 5.2.10 – Wireless Network Filters.
WMM T is option enables t e Wi-Fi Multimedia (WMM), as known as Wireless
Multimedia Extensions (WME) on t e access point.
Mesh Connec or
Bridging
T is option enables t e transparent bridging functionality wit MultiAP Mes
Connector to ac ieve true layer two transparency. T is option s ould be
c ecked if users want to bridge traffic from a 700G to Mes Connector.
5.2.1 DHCP Server
For t e setting DHCP Server Type, if t e value Server is selected, DHCP Server Parameters are entered
via t e following screen up selection:
Commen :

DHCP Server Parame ers
IP S ar Range T is setting specifies t e first address in t e range of IP addresses to be
assigned to DHCP clients.
IP S op Range T is setting specifies t e last address in t e range of IP addresses to be
assigned to DHCP clients.
Subne Mask T is setting specifies t e subnet mask to be used by DHCP clients.
Broadcas Address T is setting specifies t e broadcast address to be used by DHCP clients.
Ga eway T is setting specifies t e default routing gateway to be used by DHCP clients.
DNS 1 T is setting specifies t e IP address of t e primary DNS Server to be offered
to DHCP clients.
DNS 2 T is setting specifies t e IP address of t e secondary DNS Server to be
offered to DHCP clients.
DNS 3 T is setting specifies t e IP address of t e tertiary DNS Server to be offered to
DHCP clients.
Domain T is setting specifies t e domain name of t e Wi-Fi segment.
Lease Time
T is setting specifies t e lengt of time t roug out w ic an IP address of a
DHCP client remains valid. Upon expiration of t e Lease Time, t e assigned IP
address will no longer be valid and t e renewal of t e IP address assignment
will be required.
5.2.2 DHCP Relay
For t e setting DHCP Server Type, if t e value Relay is selected, DHCP relay parameters will be
available via t e following screen up selection:
DHCP Relay Parame ers
DHCP Server IP T is setting specifies t e IP address of t e DHCP server.
Commen :

5.2.3 S a ic WEP
T e configuration of Static WEP parameters enables pre-s ared WEP key encryption. Aut entication is
not supported by t is met od.
T e security level of t is met od is known to be weak.
Static WEP parameters are entered via t e following screen upon selection:
S a ic WEP Parame ers
Key Size T e setting can be configured as eit er 40 bi s (64-bi WEP), 104 bi s (128-
bi WEP) or 128 bi s (152 bi WEP).
Key Forma T e setting can be configured as eit er ASCII or HEX.
Passphrase Combination of words and c aracters used to generate an encryption key.
Click Genera e Key to create t e key.
Encryp ion Key
T is setting specifies a user-specified encryption key value.
For ASCII format, key lengt is eit er 5 or 13.
For HEX format, key lengt is eit er 10 or 26.
Shared Key
Au hen ica ion
T is setting enables t e use of s ared key aut entication. Open
aut entication is t e default aut entication.
5.2.4 802.1x Parame ers
T e configuration of 802.1x parameters enables Radius-based 802.1x aut entication wit a dynamic
WEP key. T e configuration screen is as follows:
802.1x Parame ers
Dynamic Key
Encryp ion
C eck t e box to enable t e Dynamic Key Encryption. Key Size and Re-
keying Period will be enabled automatically.
Key Size T e setting can be configured as eit er 40 bits or 104 bits.
Re-keying Period
T is setting specifies t e lengt of time t roug out w ic t e broadcast key
remains valid. Upon expiration of Re-keying Period, t e broadcast key will no
longer be valid and t e renewal of t e broadcast key will be required.
Commen :
Commen :
