 RACK MOUNT RECEIVER INSTALLATION
PART #   ,   
TOOLS REQUIRED
Phillips Head Screwdriver
INSTALLATION INSTRUCTIONS
1. Install clip/cage nuts on rack, to correlate with mounting holes and
captive screws on receiver.
2. Place receiver up to clip/cage nuts on rack, making sure they are
aligned (Figure A).
3. Tighten captive screws in a cross pattern to ensure even torque is
applied.
Figure A. Mounting 9050 Receiver.

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
3
INSTALLING  WITH VERTICAL HINGED MOUNTING FRAME
PART #   ,   
TOOLS REQUIRED
Phillips Head Screwdriver
/32 Allen Wrench
NOTE: Due to the weight of the VHMF (approx 15 lbs.) versus the receiver
(approx. 3 lbs.), it is recommended that the VHMF is attached to the test rack
first, followed by the receiver to the VHMF.
INSTALLATION
1. Determine an appropriate location on the rack to mount the VHMF and
receiver. Keep in mind that the cables connecting to the receiver need to
be long enough to allow the VHMF to hinge down.
2. Attach the VHMF to the rack in the desired location using the (8) 10-32 x 1”
mounting screws (Figure A). Tighten screws in a cross pattern to ensure
even torque is applied.
3. Using the 6 receiver mounting holes on the front of the Vertical Hinged
Mounting Frame (VHMF), attach the receiver with the 10-32 x 1” captive
screws, lock washers, and hex nuts included with the Receiver (Figure B).
4. When not in use, ensure that the receiver handle is closed (upward
position), and that the VHMF is in the closed position, secured with the
two screw knobs located at the top (Figure C).
Figure B. Receiver attached to VHMF using captive hardware x 6 provided
with receiver.
SECURED
RECEIVER
MOUNTING
HARDWARE X 
EACH SIDE
Figure A. Back of VHMF with rack mounting screw holes x 8 highlighted.
Image also available in product drawing for p/n 310104368.
Figure C. VHMF and receiver installed on rack and not in
use.
SCREW KNOBS SECURED
RECEIVER HANDLE IN CLOSED
POSITION

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
4
Figure B.
Figure D. Do not initially tighten down the 4 front and 4 rear
mounting screws on each tier of slides.
INSTALLING TR WITH SLIDE KIT
PART #   ,   ,   ,   
Dimensions shown: [millimeters]
inches
TOOLS REQUIRED
Phillips Head Screwdriver
/32 Allen Wrench
DETERMINE SLIDE KIT LENGTH
1. The slide kit should be chosen based on the distance from rail to rail inside the
rack. Measure dimension A to determine the proper slide kit length, ensuring
the slide length does not exceed dimensions A + B (Figure B).
SLIDE INSTALLATION
1. The height and weight of the 9050 and 9050TR require the use of 2 sets of
slides for full support. Determine the desired approximate rack location
to mount receiver and platform. The 9050TR (p/n 310104369) includes 2
instrument brackets, one for each tier, that can support a test chassis for
close proximity access (Figure A). Keep in mind when selecting a receiver
location that any system cables will need to be long enough to connect to
instrumentation and allow for slides to fully extend without putting tension
on the cables.
2. Install both sets of slides using manufacturer’s instructions (included with
slide packaging or online at accuride.com). A distance of 9.870 [250.70] is
required from the top rear screw hole of the top set of slides to the top rear
screw hole of the bottom set of slides (Figure C).
3. Make sure to horizontally match the location of the rack mounting holes
used for each tier of slides. Do not fully tighten down the 4 front and 4 rear
mounting screws at this time, on each tier of slides (Figure D).
Figure A. Each set of slides supports an instrument bracket (shelf)
for easy test chassis access.
Figure C. 9050TR side profile view. Measurements for vertical
distance between slides. See product drawing for p/n 310104369 for
more detail (available at vpc.com).
[190.06]
7.48
[250.70]
9.87
[31.75]
1.25
PLATFORM
RECEIVER
FRONT INSIDE RACK
10-32
MOUNTING
SCREWS-
4 x FRONT &
4 x BACK
MOUNTING
HOLE
LOCATIONS
MATCH
HORIZONTALLY
NOTE: The receiver platform is estimated to hold 180 lbs of weight.
However, the platform leg kit, is recommended to provide greater
stability and balance. The leg kit will allow for weight support of up to
350 lbs. The leg kit may be purchased via p/n 310113566.

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
5
ALWAYS SUPPORT THE RECEIVER AND PLATFORM
WITH THE MOST ROBUST (MIDDLE) SECTION OF THE
SLIDES.
4. Remove the innermost section of each slide by extending the slides
fully, depressing the blue tab, and continuing to extend the inner
sections of each slide until it is free from the slide assembly (Figure E).
5. Install the included instrument brackets. The shorter bracket is to
be installed for use with the top tier of slides and the longer on the
bottom. To install, follow the instrument bracket instructions also in
this User Manual.
9050TR INSTALLATION
1. Install inner slides back into slide kit in the rack.
2. Attach the platform mounting flanges to the inner slide rails on the
bottom tier using (6) 8-32 button head screws provided with the
receiver (Figure F). Do not fully tighten the screws.
3. Attach the receiver mounting flanges to the top tier slides also using
(6) 8-32 button head screws. Ensure that the mounting surface
portion of the flange is directed outward as viewed from the front
(Figure F). Do not fully tighten the screws.
4. Install the 9050TR platform/receiver onto the platform mounting
flanges with (6) 8-32 screws (Figures E and F). Do not fully tighten the
screws.
5. Install the receiver mounting flanges on the top tier slides, to the back
of the receiver using the (4) receiver rack mounting screws provided.
6. Pull the platform/receiver out as far as possible. The slides will lock
in position. Push the blue tabs located on the middle section of the
slides. Apply pressure to push the receiver back in toward the rack.
The smaller inner slides will move into the middle section, which
should not move. Push receiver until it backs against the rack.
7. During regular use of the 9050TR, when not extended away from the
rack on the slides, the user should secure the receiver to the rack.
This prevents the unit from uncontrolled slide motion. To ensure the
receiver is correctly aligned with mounting hole locations on the test
rack, temporarily fasten the receiver to the rack using its captive 10-
32 screws. Be sure to provide support beneath the platform, liing it
slightly to ensure an even screw engagement.
8. Now, complete installation by fully tightening the previously installed
screws in this order:
1. 8-32 receiver mounting screws .
2. 8-32 button head platform mounting flange screws (Figure F).
3. Front slide mounting screws (from slide mounting procedures).
4. Rear slide mounting screws (from slide mounting procedures).
9. The receiver may now be unscrewed from the rack and moved out
from the rack on the slides, if desired.
Figure G.
Figure F. Attach platform mounting flanges to the inner slide rails.
Figure H.
A
SLIDE
RELEASE TAB
INNER SLIDE
INSTALLING TR WITH SLIDE KIT (CONT’D)
PART #   ,   ,   ,   
Figure E.

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
6
Figure D. Do not initially tighten down the 4 front and 4 rear
mounting screws on each tier of slides.
10-32
MOUNTING
SCREWS-
4 x FRONT &
4 x BACK
MOUNTING
HOLE
LOCATIONS
MATCH
HORIZONTALLY
Figure C. 9050 side profile view. Measurements for vertical distance
between slides. See product drawing for p/n 310104402 for more
detail (available at vpc.com).
Figure B.
Figure A. Each set of slides supports an instrument bracket (shelf)
for easy test chassis access.
Dimensions shown: [millimeters]
inches
TOOLS REQUIRED
Phillips Head Screwdriver
/32 Allen Wrench
DETERMINE SLIDE KIT LENGTH
1. The slide kit should be chosen based on the distance from rail to rail inside the
rack. Measure dimension A to determine the proper slide kit length, ensuring
the slide length does not exceed dimensions A + B (Figure B).
NOTE: If choosing 36” slides, 9050 Receiver p/n 310104483 must be chosen as it is
specially designed for this length of slide with the inclusion of a longer instrument
bracket.
SLIDE INSTALLATION
1. The height and weight of the 9050 and 9050TR require the use of 2 sets of
slides for full support. Determine the desired approximate rack location to
mount receiver and platform. The 9050 includes 2 instrument brackets, one
for each tier, that can support a test chassis for close proximity access (Figure
A). Keep in mind, when selecting a receiver location that any system cables
will need to be long enough to connect to instrumentation and allow for slides
to fully extend without putting tension on the cables.
2. Install both sets of slides using manufacturer’s instructions (included with
slide packaging or online at accuride.com). A distance of 9.88 [250.83] is
required from the top rear of the top set of slides to the top rear of the bottom
set of slides (Figure C).
3. Make sure to horizontally match the location of the rack mounting holes
used for each tier of slides. Do not fully tighten down the 4 front and 4 rear
mounting screws at this time, on each tier of slides (Figure D).
INSTALLING  WITH SLIDE KIT
PART #   ,   ,   ,   ,   

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
7
WHEN MOVING THE RACK OR ATTACHING AN ITA, ENSURE
THE SLIDES ARE FULLY COLLAPSED AND RECEIVER IS
SECURED TO RACK WITH .- UNF SCREWS.
Figure G.
Figure F. Attach receiver mounting flanges to the inner slide rails.
A
SLIDE
RELEASE TAB
INNER SLIDE
Figure E.
4. Remove the innermost section of each slide by extending the slides
fully, depressing the blue tab, and continuing to extend the inner
sections of each slide until it is free from the slide assembly (Figure E).
5. Install the included instrument brackets. The shorter bracket is to
be installed for use with the top tier of slides and the longer on the
bottom. To install, follow the instrument bracket instructions also in
this User Manual.
9050 INSTALLATION
1. Install inner slides back into slide kits in the rack.
2. Attach the receiver mounting flanges to the inner slide rails on both
tiers of slides using (6) 8-32 button head screws for each tier. On the
top tier use the taller of the two sets of flanges, included with the
receiver. Ensure that the mounting surface portion of the flanges are
directed outward as viewed from the front (Figure F).
3. Install the receiver mounting flanges on the top tier slides, to the back
of the receiver using the (4) receiver rack mounting screws provided
(Figure G). Then attach the flanges on the bottom tier to the receiver.
4. Now, fully tighten the slide mounting screws. First tighten the front
mounting screws, then tighten the rear slide mounting screws
(Figure D).
INSTALLING  WITH SLIDE KIT (CONT’D)
PART #   ,   ,   ,   ,   

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
8
SLIDE MOUNT NOTATION REGARDING U HEIGHT
PART #   ,   ,   
With certain receivers including the 9050/ 9050TR, the slide mechanism protrudes downward slightly into the next U height on both
sides of the receiver. Please make any necessary adjustments to U height when planning your test rack layout.
Measurements can vary per receiver, see table.

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
9
INSTALLING INSTRUMENT BRACKET
PART #   
TOOLS REQUIRED
5/32 Allen Wrench
Phillips Head Screwdriver
INSTALLATION
1. Depress the blue tab on one of the inner slides and remove from outer
slide.
2. Attach it to the instrument bracket using (2) 8-32 button head screws
in the front two holes. The front two holes on the instrument bracket
will align with the front two holes on any length slide kit.
3. Install the third 8-32 button head screw in the rear hole of the inner
slide and instrument bracket. (Figure A) The third hole alignment may
dier depending on which slide kit you are using.
4. Attach the remaining inner slide to the other side of the instrument
bracket.
5. Reinstall the inner slides to the rack installed slides.
• Slide the le mid-section of the slide all the way out, you will feel it
lock into position.
• Feed the matching inner slide into position and ensure the inner
section slides into place with the roller bearings seated in the
groove.
• Push the inner slide in about 6-8 inches and then pull out the right
side. Slide the track of the mid-section over the right side of the
inner slide.
• Pull the slide out until the position matches the le side.
• Reach to the back of the middle slides and release the spring
locking mechanism (Figure B).
6. At this time, both sides should be partially installed. This is indicated
when neither side is able to proceed into the rack because the support
tab on the instrument brackets is hitting the slide mounting bracket.
7. Rotate both instrument brackets inward so the support tabs can pass
the mounting brackets. Push and install both slides simultaneously
into position. Be sure to push in the blue tabs to allow the inner tabs to
travel into the middle slide section.
NOTE: The middle section will not go into the outer section until the
inner section has been fully installed into the middle section.
8. Tighten the slide mounting screws.
FRONT TWO HOLES
ALIGN UNIVERSALLY
ON ALL SLIDE LENGTHS
Figure A.
The slots on the instrument bracket are designed to accept a strap for
securing a test chassis, if desired.
Figure B. Spring-locking mechanism.
MAKE SURE ALL MOUNTING SCREWS HAVE
BEEN SECURELY TIGHTENED. ONLY USE
- BUTTON HEAD SCREWS.

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
10
INSTALLING KEYBOARD TRAY
PART #   
MOVEMENT
12 INCH SLIDE
1.2
[30.48]
KEYBOARD WITH TOUCHPAD
KEYBOARD TRAY
12 INCH SLIDES
MOUNTING BRACKET, RIGHTMOUNTING BRACKET, LEFT
USB KEYBOARD
CONNECTOR.
RUBBER GROMMET
13.0
[330.2]
13.3
[337.82]
28.4
[721.36]
Figure A.
TOOLS REQUIRED
3/32 Allen Wrench
Dimensions shown: [millimeters]
inches

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
11
INSTALLING KEYBOARD TRAY (CONT’D)
PART #   
Figure A.
INSTRUCTIONS
1. Attach the keyboard mounting brackets to the existing platform
mounting brackets using with the supplied 8-32 flat head
screws, nuts, and lock washers. Align the keyboard mounting
brackets with the 3 screws that extend beyond the platform
mounting bracket (Figure A).
2. Use 6 of the 8-32 x .38 button head screws to attach the 12"
keyboard kit slides to the inner side of the keyboard brackets.
The manufacturer stamped identification on the slides should
be placed toward the rack. Fully extend the keyboard slides to
access the hole locations (Figure B).
3. Insert the keyboard into the keyboard tray. Wrap the plastic
strain relief around the cable near the back of the keyboard and
press into the hole provided on the keyboard tray.
4. Fully extend the 12” slides and mount the keyboard tray (Figure
C). Floating, self-locking fasteners in the keyboard mounting
brackets prevent the screws from backing out. This creates a
noticeably snug fit when tightening the screws.
Figure B. Fully extend the keyboard slides to access the mounting holes for the self-
locking fasteners.
Figure C. The dierent hole patterns allow for variations in the overall position of the
keyboard.
PLATFORM MOUNTING BRACKE
T
MOUNTING BRACKET, LEFT
SUPPLIED 8-32 SCRE
W,
LOCKING WASHER, AND NU
T
BOTTOM VIEW
SELF-LOCKING FASTENERS
BOTTOM VIEW

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
12
8-32 x .625" PLATFORM
MOUNTING SCREWS
TR PLATFORM REMOVAL AND REINSTALLATION
PART #   
TOOLS REQUIRED
5/32 Ball End Allen Wrench or Ball Driver
Phillips Head Screwdriver
Zip Ties
REMOVAL
1. Secure receiver to rack using the captive 10-32 mounting screws
(Figure A). The platform should only be removed from the receiver
aer the receiver has been secured to the rack.
2. Remove any optional accessories including keyboard tray, leg kit, and
instrument bracket.
3. With the receiver secured to the rack, remove the six 8-32 mounting
screws from the bottom of the 9050TR to remove the platform (Figure
B).
4. Remove the 8-32 screws that attach the platform brackets to the
slides. The platform will now be free from the receiver and slides. The
platform brackets do not need to be removed from the platform for
transportation.
5. To secure the slides for transport, return the slides to the closed
position and use zip ties to secure the 3 sections of each slide.
Figure A.
Figure B. The six mounting screws must be removed from the receiver
before the platform can be removed.
Figure C. The brackets will be securely attached to the slides aer the mounting
screws are installed.
REINSTALLATION
1. Remove the zip ties used to secure the slides.
2. Attach the platform with brackets to the slides using six 8-32
mounting screws (Figure C).
3. Slide the platform to the closed position and install the
six 8-32 mounting screws to re-attach the platform to the
receiver.
4. Reinstall any of the optional accessories.
5. Once the platform has been re-attached to the receiver
and slides, detach the receiver from rack by unscrewing the
captive 10-32 mounting screws.
Platform removal is recommended for safe transport should the rack
need to be moved or relocated.

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
13
TR HANDLE ROTATION AND SIDE CHANGE
PART #   
NOTE: The 9050TR receiver handle requires approximately 90° of counter-
clockwise movement for engagement and 90° of clockwise travel for
disengagement of the ITA. This handle is removable and adjustable to
accommodate dierent mounting configuration needs and for transport
purposes.
TOOLS REQUIRED
3/32 Allen Wrench
ROTATION
1. Remove the handle screw with a 3/32 Allen wrench.
2. Remove the handle and reposition in 90˚ increments (Figure A).
3. Replace the screw and tighten until the handle is secured tightly.
SWITCHING HANDLE SIDES
1. Using the 3/32 Allen wrench, remove the handle screw and handle (Figure B).
2. Using the 3/32 Allen wrench, remove the screw and handle washer on the le side of
the receiver (Figure B).
3. Install the handle into the le side hole at the preferred 90°position (Figure C).
4. Replace the screw and handle washer into the cavity on right side of the receiver.
Figure A. 9050TR Receiver handle can be rotated in 90 de-
gree increments to support test station set up needs.
Figure B. Remove handle from standard right side.
Figure C. Install handle on le side.

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
14
TOOLS REQUIRED
Phillips Head Screwdriver
REMOVAL
1. Disengage the ITA from the receiver (remove the ITA completely).With the receiver
handle still in the open position (handle is down), unscrew the two plate retaining
screws (using a Phillips screwdriver) that are located immediately below the top right
engaging mechanism/slot - this will expose the microswitch.
2. Remove the necessary modules so that the microswitch retaining screws may be
accessed.
3. Unscrew the retaining screws (using a Phillips screwdriver), removing each as they are
loosened (caution should be used so that the screw(s) do not fall into the system).
4. Carefully remove the microswitch for continuity testing.
INSTALLATION
For microswitch installation, repeat steps 1 - 5 above, in reverse order.
AS WITH ALL ELECTRICAL SYSTEMS - DISCONNECT ALL
ELECTRICAL SUPPLIES TO THE SYSTEM PRIOR TO REMOVAL OF
THE MICROSWITCH.
MICROSWITCH REMOVAL AND INSTALLATION
PART #   
NOTE: A microswitch may be used in VPC receivers to determine
the presence (or absence) of an engaged ITA in the system. It
is typically configured so that power to the interface is turned
o when there is no ITA present. An integrated microswitch is
standard on the 25 and 50 module receivers.

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
15
ITA ENCLOSURES
PART #   ,   ,   ,   
Figure A. Enclosures must be flush with the bottom of the ITA frame to ensure
mating with the 9050TR receiver. The width of the enclosure may grow with
customer needs, as long as the extended width is oset to the side opposite the
engagement handle. There is no limit to the height of the enclosure.
NOTE: VPC oers several standard ITA enclosures, as well as custom
enclosures. The 9025, 25 module ITA enclosure, is compatible with the
9050 if a smaller ITA enclosure is desired. Visit vpc.com for all available
options for the 9050 and 9025 ITA.
TOOLS REQUIRED
3 mm Allen Wrench
Phillips Head Screwdriver
STANDARD ENCLOSURES
1. To mount ITA frame, align frame with enclosure.
2. Insert screws and tighten with Allen Wrench. Torque 6-8 in. -
lbs. for 4-40 screws.
CUSTOM 9050TR ENCLOSURES
When building a customized ITA enclosure, these guidelines
should be followed to ensure proper mating with the 9050TR
receiver (Figure A):
• When mounting, the ITA frame must be flush with the
bottom of the enclosure
• The width of the enclosure may longer than the ITA frame,
as long as the extended width is oset to the opposite side
of the receiver’s engagement handle
• There is no limit to the height of the enclosure.
Opposite side of ITA on standard ITA Enclosure with hinged
cover for easy interior access.
ITA side of standard ITA Enclosure ITA frame ready for
mounting.

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
16
Prior to engaging an ITA with the receiver for the first time, ensure all modules (ITA and receiver) are properly installed. This includes inspection of modules to
ensure proper mounting and to verify module positioning. Modules must be installed so that Pin 1 of each respective mating receiver and ITA module pair are
adjacent. VPC recommends that Pin 1 be positioned to the le in the receiver and ITA frames. All ITA modules must match the respective receiver modules. It is
crucial for all modules to be installed properly.
ENGAGEMENT
1. The receiver should be checked for any foreign objects that may interfere with engagement.
2. Aer inspection, the ITA is ready for engagement with the receiver. The ITA may be placed onto the receiver platform and properly positioned relative to the
receiver guide pins. Ensure that the ITA roller bearings are aligned with the receiver slide openings when the receiver handle is in the open position.
3. Carefully rotate the handle forward to actuate the receiver slide engagement mechanisms, which will draw the ITA into engagement position with the
receiver. Once the handle reaches a positive stop at the end of its travel and latches into place, the modules are engaged.
4. Upon completing use of the ITA, rotate the receiver handle to the open position, remove the ITA, reinstall the receiver protective cover and rotate the handle
to the closed position.
5. Always protect the contacts when the system is not in use. The receiver contacts are protected when either the ITA or receiver protective cover is engaged.
VPC recommends use of both receiver and ITA protective covers to avoid potential contact damage.
ITA AND RECEIVER ENGAGEMENT
9050 Receiver and ITA.
A A
B B
C C
D D
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DO NOT SCALE DRAWING
310104369
SHEET 1 OF 1
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:4
WEIGHT:
REV
DWG. NO.
D
SIZE
TITLE:
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
FINISH
MATERIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
APPLICATION
USED ON
NEXT ASSY
PROPRIETARYAND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
<INSERT COMPANY NAME HERE>. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
<INSERT COMPANY NAME HERE> IS
PROHIBITED.
M
D
U
L
E
P
O
S
I
T
I
O
N
23
O
D
L
E
P
O
S
I
T
I
O
N
14
O
U
M
13
N
O
I
T
I
S
O
P
E
L
U
D
O
M
12
N
O
I
T
I
S
O
P
E
L
U
D
O
M
11
N
O
I
T
I
S
O
P
E
L
U
D
O
M
10
N
O
I
T
I
S
O
P
E
L
U
D
O
M
I
I
O
N
M
O
D
U
L
E
P
O
S
6
T
8
O
M
O
D
U
L
E
P
O
S
I
T
I
N
7
S
O
P
E
L
U
D
O
M
N
O
I
T
I
M
L
E
P
O
S
I
T
I
O
N
4
O
D
U
M
L
E
P
O
S
I
T
I
O
N
3
O
D
U
9
N
O
I
T
I
S
O
P
E
L
U
D
O
M
D
M
L
E
P
O
S
I
T
I
O
N
17
O
U
M
O
D
U
L
E
P
O
S
I
T
I
O
N
25
O
21
N
O
I
T
I
S
O
P
E
L
U
D
MM
U
L
E
P
O
S
I
T
I
O
N
15
O
D
24
O
M
O
D
U
L
E
P
O
S
I
T
I
N
M
O
D
U
L
E
P
O
S
I
T
I
O
N
22
O
16
N
O
I
T
I
S
O
P
E
L
U
D
M
M
U
L
E
P
O
S
I
T
I
O
N
2
O
D
M
19
N
O
I
T
I
S
O
P
E
L
U
D
O
U
D
O
18
N
O
I
T
I
S
O
P
E
L
M M
O
D
U
L
E
P
O
S
I
T
I
O
N
20
N
5
I
T
I
S
O
P
E
L
U
D
O
M
O
M
O
D
U
L
E
P
O
S
I
T
I
O
N
1
M
D
U
L
E
P
O
S
I
T
I
O
N
23
O
D
L
E
P
O
S
I
T
I
O
N
14
O
U
M
13
N
O
I
T
I
S
O
P
E
L
U
D
O
M
12
N
O
I
T
I
S
O
P
E
L
U
D
O
M
11
N
O
I
T
I
S
O
P
E
L
U
D
O
M
10
N
O
I
T
I
S
O
P
E
L
U
D
O
M
I
I
O
N
M
O
D
U
L
E
P
O
S
6
T
8
O
M
O
D
U
L
E
P
O
S
I
T
I
N
7
S
O
P
E
L
U
D
O
M
N
O
I
T
I
M
L
E
P
O
S
I
T
I
O
N
4
O
D
U
M
L
E
P
O
S
I
T
I
O
N
3
O
D
U
9
N
O
I
T
I
S
O
P
E
L
U
D
O
M
D
M
L
E
P
O
S
I
T
I
O
N
17
O
U
M
O
D
U
L
E
P
O
S
I
T
I
O
N
25
O
21
N
O
I
T
I
S
O
P
E
L
U
D
MM
U
L
E
P
O
S
I
T
I
O
N
15
O
D
24
O
M
O
D
U
L
E
P
O
S
I
T
I
N
M
O
D
U
L
E
P
O
S
I
T
I
O
N
22
O
16
N
O
I
T
I
S
O
P
E
L
U
D
M
M
U
L
E
P
O
S
I
T
I
O
N
2
O
D
M
19
N
O
I
T
I
S
O
P
E
L
U
D
O
U
D
O
18
N
O
I
T
I
S
O
P
E
L
M M
O
D
U
L
E
P
O
S
I
T
I
O
N
20
N
5
I
T
I
S
O
P
E
L
U
D
O
M
O
M
O
D
U
L
E
P
O
S
I
T
I
O
N
1
A A
B B
C C
D D
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
DO NOT SCALE DRAWING
410104538
SHEET 1 OF 1
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:2
WEIGHT:
REV
DWG. NO.
D
SIZE
TITLE:
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
FINISH
MATERIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
APPLICATION
USED ON
NEXT ASSY
PROPRIETARYAND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
<INSERT COMPANY NAME HERE>. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
<INSERT COMPANY NAME HERE> IS
PROHIBITED.
M
D
U
L
E
P
O
S
I
T
I
O
N
23
O
D
L
E
P
O
S
I
T
I
O
N
14
O
U
M
13
N
O
I
T
I
S
O
P
E
L
U
D
O
M
12
N
O
I
T
I
S
O
P
E
L
U
D
O
M
11
N
O
I
T
I
S
O
P
E
L
U
D
O
M
10
N
O
I
T
I
S
O
P
E
L
U
D
O
M
I
I
O
N
M
O
D
U
L
E
P
O
S
6
T
8
O
M
O
D
U
L
E
P
O
S
I
T
I
N
7
S
O
P
E
L
U
D
O
M
N
O
I
T
I
M
L
E
P
O
S
I
T
I
O
N
4
O
D
U
M
L
E
P
O
S
I
T
I
O
N
3
O
D
U
9
N
O
I
T
I
S
O
P
E
L
U
D
O
M
D
M
L
E
P
O
S
I
T
I
O
N
17
O
U
M
O
D
U
L
E
P
O
S
I
T
I
O
N
25
O
21
N
O
I
T
I
S
O
P
E
L
U
D
MM
U
L
E
P
O
S
I
T
I
O
N
15
O
D
24
O
M
O
D
U
L
E
P
O
S
I
T
I
N
M
O
D
U
L
E
P
O
S
I
T
I
O
N
22
O
16
N
O
I
T
I
S
O
P
E
L
U
D
M
M
U
L
E
P
O
S
I
T
I
O
N
2
O
D
M
19
N
O
I
T
I
S
O
P
E
L
U
D
O
U
D
O
18
N
O
I
T
I
S
O
P
E
L
M M
O
D
U
L
E
P
O
S
I
T
I
O
N
20
N
5
I
T
I
S
O
P
E
L
U
D
O
M
O
M
O
D
U
L
E
P
O
S
I
T
I
O
N
1
M
D
U
L
E
P
O
S
I
T
I
O
N
23
O
D
L
E
P
O
S
I
T
I
O
N
14
O
U
M
13
N
O
I
T
I
S
O
P
E
L
U
D
O
M
12
N
O
I
T
I
S
O
P
E
L
U
D
O
M
11
N
O
I
T
I
S
O
P
E
L
U
D
O
M
10
N
O
I
T
I
S
O
P
E
L
U
D
O
M
I
I
O
N
M
O
D
U
L
E
P
O
S
6
T
8
O
M
O
D
U
L
E
P
O
S
I
T
I
N
7
S
O
P
E
L
U
D
O
M
N
O
I
T
I
M
L
E
P
O
S
I
T
I
O
N
4
O
D
U
M
L
E
P
O
S
I
T
I
O
N
3
O
D
U
9
N
O
I
T
I
S
O
P
E
L
U
D
O
M
D
M
L
E
P
O
S
I
T
I
O
N
17
O
U
M
O
D
U
L
E
P
O
S
I
T
I
O
N
25
O
21
N
O
I
T
I
S
O
P
E
L
U
D
MM
U
L
E
P
O
S
I
T
I
O
N
15
O
D
24
O
M
O
D
U
L
E
P
O
S
I
T
I
N
M
O
D
U
L
E
P
O
S
I
T
I
O
N
22
O
16
N
O
I
T
I
S
O
P
E
L
U
D
M
M
U
L
E
P
O
S
I
T
I
O
N
2
O
D
M
19
N
O
I
T
I
S
O
P
E
L
U
D
O
U
D
O
18
N
O
I
T
I
S
O
P
E
L
M M
O
D
U
L
E
P
O
S
I
T
I
O
N
20
N
5
I
T
I
S
O
P
E
L
U
D
O
M
O
M
O
D
U
L
E
P
O
S
I
T
I
O
N
1
IMPROPER INSTALLATION WILL DAMAGE THE
MODULES, AND POSSIBLY THE ITA AND/OR
RECEIVER.
IN THE EVENT OF COMPLICATIONS, A TRAINED
TECHNICIAN SHOULD BE NOTIFIED IMMEDIATELY
TO AVOID ANY DAMAGE TO THE SYSTEM. THIS
APPLIES TO ANY DIFFICULTIES THAT MAY BE
EXPERIENCED DURING ENGAGEMENT.

 USER MANUAL VPC
07/19/2022
For more information visit vpc.com
RETURN TO INDEX
17
ITA will not properly engage with receiver.
ITA is possibly out of alignment or module are mismatched.
• Remove and inspect the ITA for proper alignment.
• Check for foreign objects/tools obstructing mating.
• Inspect module configuration. Ensure ITA module placement and type match that of each receiver module.
• Inspect for any bent or incorrectly placed pins.
• Verify the orientation of the receiver and ITA modules.
Excessive force is needed to engage the handle.
(Typical contact load- approximately 35 lbs. force)
ITA is possibly out of alignment or module are mismatched.
• See above troubleshooting steps
ITA will not engage with the receiver aer attempting above troubleshooting steps.
Contact VPC – unauthorized user adjustments to the system will void the warranty.
No continuity upon engagement.
• When replacing an ITA contact, the mating contact on the receiver side should also be inspected and replaced if necessary.
• Check wiring and replace if necessary.
• Contact not secured in module.
• Contact damage. Visually inspect all contacts for damage to potentially isolate damaged pin prior to checking for continuity with a multi-meter.
A “short ” in the wiring upon engagement.
• Damaged contact(s) may cause high resistance. Upon replacing a contact in the ITA, the mating contact on the receiver side should also be inspected and
replaced, if necessary.
• Check wiring and replace, if necessary.
Receiver and ITA will not disengage.
Engagement mechanism within the receiver may be faulty.
Contact VPC – unauthorized user adjustments to the system will void the warranty.
Handle feels/appears loose.
• Refer to drawing for tightening instructions:
TROUBLESHOOTING
LEFT HANDLE RIGHT HANDLE
TIGHTEN SCREW TO DESIRED
SETTING WITH FLATHEAD
SCREWDRIVER
TIGHTEN SCREW TO DESIRED
SETTING WITH FLATHEAD
SCREWDRIVER
