SLIDE KIT INSTALLATION
 SLIDE MOUNT RACK EXTENDER KIT INSTALLATION
 SLIDE MOUNT NOTATION REGARDING U HEIGHT
 INSTRUMENT BRACKET INSTALLATION
CABLE TRAY INSTALLATION
KEYBOARD TRAY KIT INSTALLATION
TABLETOP RECEIVER MOUNTING
REAR COVER INSTALLATION
 RACK MOUNT RECEIVER INSTALLATION
 RACK MOUNT EXTENDER BLOCK KIT INSTALLATION
 HANDLE REMOVAL AND REPOSITIONING
 G ITA ENCLOSURE ASSEMBLY
 GX ITA ENCLOSURE ASSEMBLY
 KEYING PIN KIT INSTALLATION
 ITA & RECEIVER ENGAGEMENT
 RECEIVER INSTALL/ UNINSTALL CAUTIONARY NOTE
 TROUBLESHOOTING
 PRECAUTIONARY NOTES
03/28/2022
Please note that any printed or downloaded User Manual may not reflect the most current revisions.
The information contained herein is subject to change.
For the most current information available, visit vpc.com.

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
1
SLIDE KIT INSTALLATION
PART #   ,   ,   ,   ,   
Figure B. The platform mounting brackets are threaded so washers
and nuts will not need to be locked.
G12 RECEIVER SUPPORTS
FOR MOUNTING PLATFORM
TO SLIDES SLIDE TO BRACKET
MOUNTING HARDWARE
PLATFORM
MOUNTING
BRACKETS
TOOLS REQUIRED
Phillips Head Screwdriver
Flat Head Screwdriver
/32 Allen Wrench
DETERMINE SLIDE LENGTH NEEDED
1. Measure dimension A as shown in Figure A to determine the proper
slide kit.
NOTE: Make sure the slide length does not exceed dimensions A plus B.
INSTALLATION
1. Install slides using manufacturer’s instructions. A hard copy is included
with the slide kit.
(Click here to access PDF version)
2. Attach platform mounting brackets to slides (Figure B).
NOTE: The screws will overhang the bracket holes by 3/8". These screws may
also be used to mount the keyboard tray kit, Part # 310 113 439.
3. Remove the rubber feet.
4. Attach the G12/G12x platform to the platform mounting brackets aer
removing the rubber feet (Figure C).
NOTE: If you are installing a cable tray or instrument brackets, do not attach
the platform until those accessories are installed.
5. Pull the receiver out as far as possible. The slides will lock in position. Push
the blue tabs located on the middle section of the slides (Figure D). Apply
pressure to push the receiver back in toward the rack. The smaller inner
slides move into the middle section, which should not move. Push receiver
until it backs into the rack. The mounting screws can now be used.
6. Secure receiver to rack.
29.50
749.30
TOP VIEW
[50.8]
2.00
DIMENSION B
DIMENSION A
DIMENSION C
[749.3]
29.50
[31.75]
1.25
FRONT OF RACK
Figure A. If dimension C exceeds 1" use the Rack Extender Kit, Part # 310 113
406 for G12 or Part # 310 113 519 for G12x.
Dimensions shown: [millimeters]
inches
Figure C. Use the existing #8-32 flat head screws, washers, and hex nuts to
secure the platform to the brackets.
BAR NUT
Figure D. Slides will support up to 180 pounds.
BLUE TAB
ALWAYS SUPPORT THE RECEIVER AND PLATFORM
WITH THE MOST ROBUST (MIDDLE) SECTION OF
THE SLIDES.
To ensure proper support when extending the receiver
and platform away from the rack, stop the receiver and
platform at approximately 6” from the rack. Reach around
to the rear of the receiver to the slides underneath on both
sides. Manually extend the middle section of the slides
forward until fully underneath the platform. The receiver
and platform may then be extended while holding this
middle slide in place. If completed properly, the middle
section of the slides will remain underneath the platform
and oer the strongest support.

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
2
SLIDE MOUNT RACK EXTENDER KIT INSTALLATION
PART #   ,   
NOTE: This kit is for test rack rails that are recessed more than 1” and
it accommodates a maximum depth of 2.5".
TOOLS REQUIRED
5/32 Allen Wrench
Phillips Head Screwdriver
INSTALLATION
1. To determine if a Rack Extender Kit is needed, verify that the distance between the front of the
rack enclosure and the rail is between 1" and 2.5" (Figure A).
2. Attach the mounting rack mating surface on the extender brackets to the recessed rail with the
cap screws. Do not fully tighten until the cover plate is attached.
3. Attach the cover to the brackets with the flat head screws.
4. With the extender kit in place, secure the G12 receiver to the mating surface on the extender
brackets with #10-32 cap screws (provided with the G12).
[101.6]
4.00
DIMENSION C
Figure A.
DIMENSION C
2.5“[63.5mm]

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
3
SLIDE MOUNT NOTATION REGARDING U HEIGHT
PART #    ,   
NOTE: When using a slide kit for the part numbers listed above, the slide
mechanism protrudes slightly downward into the rack’s next U height on
both sides of the receiver.
For the above receivers, Dimensions A in the drawings below is .46” or
11.7 mm.

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
4
INSTRUMENT BRACKET INSTALLATION
PART #   
NOTE: Only compatible with slide kits 28” or larger.
TOOLS REQUIRED
5/32 Allen Wrench
Phillips Head Screwdriver
INSTALLATION
1. Depress the blue tabs on the inner slides and remove.
2. Attach one of the brackets to the slide using 3 #8-32 button head
screws. The brackets are identical parts and only the front two holes
on each bracket are designed to line up with the slides. The le
bracket assembly is shown in Figure A.
3. Attach the remaining bracket to the other inner slide.
4. Reinstall the inner slides.
- Slide the le mid-section of the slide all the way out, you will feel it
lock into position.
- Feed the matching inner slide into position and ensure the inner
section rides into place with the roller bearings seated into the groove.
- Push the inner slide in about 6-8 inches and then pull out the right
side. Slide the track of the mid-section over the right side of the inner
slide.
- Pull the slide out until the position matches the le side.
- Reach to the back of the middle slides and release the spring locking
mechanism (Figure C).
NOTE: At this time, both sides should be partially installed. This can be
observed when it will not proceed into the rack because the support
tab on the instrument brackets will hit the slide mounting bracket.
5. Rotate both instrument brackets inward so the support tabs
can pass the mounting brackets. Continue to push (install slides
simultaneously) into position. Remember to push the blue tabs to
allow the inner slide to continue to travel into the middle slide section.
NOTE: The middle section will not go into the outer section until the
inner section has been fully installed into the middle section.
6. Retighten the slide mounting screws.
Figure A.
Figure B. The slots on the instrument brackets are designed to accept a strap
should you want to secure your chassis.
MAKE SURE ALL SCREW HEADS HAVE BEEN SECURELY
TIGHTENED. ONLY USE #- BUTTON HEAD
SCREWS.
Figure C. Spring-locking mechanism.

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
5
CABLE TRAY INSTALLATION
PART #   
NOTE: The cable tray is used for strain relief and cable management with
the horizontal and vertical flanges providing tie down options.
NOTE: Not compatible with 20” or 24” slide kits or the instrument bracket
kit with strain relief.
INSTALLATION
1. Loosen the slide mounting screws with one turn.
2. Depress the blue tab and remove the inner slides.
3. Attach the cable tray to the slides with #8-32 screws ( Figure A). The angled side of the cable
tray should face the G12/G12x receiver, and with shorter slide kits the cable tray will sit below
the lip of the instrument brackets.
4. Tighten the slide mounting screws.
Figure A.
TOOLS REQUIRED
3/32 Allen wrench

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
6
Dimensions shown: [millimeters]
inches
Continued on next page...
KEYBOARD TRAY KIT INSTALLATION
PART #   
NOTE: This optional keyboard mounts below the platform on the
G12 or G12x receiver. The kit includes a keyboard with touchpad,
58" USB cable with connector, keyboard tray, and 12" slides.
MOVEMENT
12 INCH SLIDE
1.2
[30.48]
KEYBOARD WITH TOUCHPAD
KEYBOARD TRAY
12 INCH SLIDES
MOUNTING BRACKET, RIGHTMOUNTING BRACKET, LEFT
USB KEYBOARD
CONNECTOR.
RUBBER GROMMET
13.0
[330.2]
13.3
[337.82]
28.4
[721.36]
Figure A.

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
7
PLATFORM MOUNTING BRACKET
MOUNTING BRACKET, LEFT
EXISTING #8-32 SCREWS
Figure B.
INSTRUCTIONS
1. Attach the keyboard mounting brackets to the existing platform
mounting brackets. Use the #8-32 nuts and lock washers to
secure the keyboard mounting brackets to the three screws
extending from the platform mounting brackets (Figure B).
2. Use the #8-32 button head screws to attach the 12"slides to the
inner side of the keyboard brackets. The manufacturer stamped
identification on the slides should be placed toward the rack.
You need to adjust the position of the slides to access the hole
locations .
3. There are floating, self-locking fasteners in the keyboard
mounting brackets which prevent the screws from backing out.
There will be a snug fit when tightening the screws (Figure C).
4. Insert the keyboard into the keyboard tray. Wrap the plastic
strain relief around the cable near the back of the keyboard and
press into the hole provided on the keyboard tray.
5. Fully extend the 12” slides and mount the keyboard tray, (Figure
). The remaining 4 #8-32 button head screws are used to attach
the keyboard tray to the slides. The dierent hole patterns
allow for variations in the overall extension of the keyboard tray.
Figure D.
KEYBOARD TRAY KIT INSTALLATION (CONT’D)
PART #   
Figure C.
TOOLS REQUIRED
3/32 Allen wrench

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
8
TABLETOP RECEIVER MOUNTING
PART #   ,   ,   ,   ,   
PERMANENT MOUNTING
1. Remove rubber feet from ¼-20 tapped holes beneath the platform.
2. Prepare the mounting surface using the dimensions provided in Figure A or B,
and drill 0.257" [6.53 mm] minimum thru holes.
3. Secure the receiver to the mounting surface with ¼-20 screws and washers.
Figure A. Receiver with 15" Platform Figure B. Receiver with 20" Platform
85.60
.65
16.51
17.70
449.58
3.37
11.50
292.10
449.58
17.70
16.50
419.10
85.60
3.37
.65
16.51
449.58
17.70
85.60
16.50
419.10
3.37
.65
16.51
Dimensions shown: [millimeters]
inches

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
9
INSTALLATION
1. The rear cover is to be used on tabletop configurations and is
designed to protect wiring from the receiver to the instruments.
2. Use the /32 Allen wrench with the provided #8-32 screws and washers to attach
the rear cover to the G12/G12x receiver. An exploded view of the assembly is
provided in (Figure A).
TOOLS REQUIRED
/32 Allen Wrench
Figure A.
ALTERNATE INSTALLATION METHOD
1. Rear covers can be permanently mounted to the tabletop using the dimensions provided in Figure B. Hardware for this is not included.
2. Rubber feet included with rear cover are not necessary when permanently mounting the G12/G12x receiver.
REAR COVER INSTALLATION
PART #   ,   
287.19
11.307
1.35
34.29
15.00
381 .26 TY
P
6.60
Figure B.
Dimensions shown: [millimeters]
inches

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
10
INSTALLATION
1. This rack mount version of the 15” G12 includes a base shelf which can support
up to 275 lbs. total in combination with the mounted G12 receiver.
2. Place receiver over clip/cage nuts on rack, making sure they are aligned (Figure A).
3. Tighten screws in a criss-cross pattern to ensure even torque is applied.
Figure A.
RACK MOUNT RECEIVER INSTALLATION
PART #   
The 15” G12 Receiver provides a platform for use with large fixtures.
When this Receiver is fixed mounted, it can support up to 275 lbs.
TOOLS REQUIRED
5/32 Allen Wrench

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
11
RACK MOUNT EXTENDER BLOCK KIT INSTALLATION
PART #   
NOTE: The Rack Mount Extender Block Kit is used for mounting receivers to
racks with recessed mounting rails. It allows for a maximum rack depth of 3.5”.
TOOLS REQUIRED
5/32 Allen Wrench
Phillips Head Screwdriver
Flat Head Screwdriver
INSTALLATION
1. Verify that the distance from the front of the
rack enclosure to the rail is between 1" and 3.5"
(Figure A).
2. Attach the mounting rack mating surface on the
extender brackets (Figure B), to the recessed rail
with the cap screws. Do not fully tighten until the
cover plate is attached.
3. Attach the cover to the brackets with flat head
screws.
4. With the extender kit in place, secure the G12
receiver to the mating surface on the extender
brackets with #10-32 cap screws (provided with
the G12).
Figure B.
*For a larger and easier-to-read drawing please
consult the oicial drawing online at vpc.com.
Enter part # 310113413 and select the drawing link .
Figure B.
4-40 FLAT HEAD SCREWS FOR MOUNTING
EXTENDER KIT TOP TO RECEIVER.
1.015
25.78
.276
7.01
88.90
3.500
88.90
3.500
44.45
1.750
44.45
1.750
44.45
1.750
88.90
3.500
9.91
.390
.276
7.01
482.09
LEFT EXTENSION
RIGHT EXTENSION
18.980
10-32 THREADS X .5 DEEP TO BE USED WITH
SCREWS PROVIDED WITH RECEIVERS.
10-32 X .75 BUTTON HEAD SOCKET SCREWS
TO SECURE TO RACK. 4 PLCS.
M6 X 20 CAP SCREWS MAY ALSO BE USED.
(NOT INCLUDED)
10-32 x .75 Button Head Socket
Screws to secure
rack. 4 places.
M6 x 20 screws may also be
used (not included).
Le Extension
RIght Extension
4-40 Flat Head Screws
for mounting Extender
Kit Top to receiver
[101.6]
4.00
DIMENSION C
Figure A. Rack Extender Kits are used when the rails are recessed more than 1".
DIMENSION C
3.5“[88.9mm]

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
12
HANDLE REMOVAL AND REPOSITIONING
PART #   ,   ,   ,   ,
  ,   ,   ,   ,   ,   
NOTE: The G12/G12x receiver handle requires approximately 90° of counter-
clockwise travel for engagement and 90° of clockwise travel for disengagement
of the ITA. This handle is removable and adjustable to accommodate dierent
mounting configuration requirements and for transport purposes.
TOOLS REQUIRED
3/32 Allen Wrench
REMOVAL
1. Remove the handle set screw with a 3/32 Allen wrench.
2. Remove the handle and reposition in 90˚ increments.
3. Replace the screw and tighten until the handle is secured tightly.
22.06
560.32
19.41
493.01
HANDLE CAN BE LOOSENED AND
ROTATED IN 90 DEGREE INCREMENTS.
16.93
430.10
14.28
362.79
HANDLE CAN BE LOOSENED AND
ROTATED IN 90 DEGREE INCREMENTS.
310104325, 310104286, 310104408 & 310104409, : G12/G12x receiver
with a 15” platform show with handle in the
standard disengaged position.
310104334, 310104385, 310104410 & 310104411, : G12/G12x receiver
with a 20” platform show with handle in the
standard engaged position.
Dimensions shown: [millimeters]
inches

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
13
G ITA ENCLOSURE ASSEMBLY
PART #   ,   
Figure A. Enclosures must be flush with the ITA bottom to ensure the proper function of the G12 system.
1.75
44.45
3.34
84.84
ENCLOSURE MUST BE FLUSH TO BOTTOM OF ITA
FRAME. THE WIDTH MAY GROW TO CUSTOMERS
NEEDS WITH A SIMPLE ADJUSTMENT OF THE HANDLE
ON THE RECEIVER. THERE IS NO LIMIT TO THE HEIGHT
OF THE ENCLOSURE.
TOOLS REQUIRED
3 mm Allen Wrench
Phillips Head Screwdriver
Dimensions shown: [millimeters]
inches

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
14
GX ITA ENCLOSURE ASSEMBLY
PART #   ,   
Figure A. Enclosures must be flush with the ITA bottom to ensure the proper function of the G12x system.
TOOLS REQUIRED
3 mm Allen Wrench
Phillips Head Screwdriver
5.37
136.40
1.25
31.75
ENCLOSURE MUST BE FLUSH TO BOTTOM OF IT
A
FRAME. THE WIDTH MAY GROW TO CUSTOMER
S
NEEDS WITH A SIMPLE ADJUSTMENT OF THE HANDLE
ON THE RECEIVER. THERE IS NO LIMIT TO THE HEIGH
T
OF THE ENCLOSURE.
Dimensions shown: [millimeters]
inches

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
15
INSTALLATION
1. Determine which locations in the receiver and ITA will have
keying pins installed and which will be open (Table 1).
2. Install the required keying pin combination with the required
Allen Wrench (Figure A).
NOTE: One keying pin kit will allow 6 variations. Using together with a
second keying pin kit, allows up to 36 variations.
TOOLS REQUIRED
/32 Allen Wrench
Figure A.
KEYING PIN KIT INSTALLATION
PART #   
A
DETAIL A
SCALE 1 : 1.5
B
DETAIL B
SCALE 1 : 1.5
KEYING PIN LOCATIONS
PATTERN 1 PATTERN 4
RECEIVER ITA RECEIVER ITA
PIN A
INSTALLED PIN C INSTALLED SCREW A OPEN SCREW C OPEN PIN A OPEN PIN C OPEN SCREW A INSTALLED SCREW C INSTALLED
PIN B
OPEN PIN D OPEN SCREW B INSTALLED SCREW D INSTALLED PIN B INSTALLED PIN D INSTALLED SCREW B OPEN SCREW D OPEN
PATTERN 2 PATTERN 5
RECEIVER ITA RECEIVER ITA
PIN A
INSTALLED PIN C OPEN SCREW A OPEN SCREW C INSTALLED PIN A OPEN PIN C INSTALLED SCREW A INSTALLED SCREW C OPEN
PIN B
INSTALLED PIN D OPEN SCREW B OPEN SCREW D INSTALLED PIN B INSTALLED PIN D OPEN SCREW B OPEN SCREW D INSTALLED
PATTERN 3 PATTERN 6
RECEIVER ITA RECEIVER ITA
PIN A
OPEN PIN C INSTALLED SCREW A INSTALLED SCREW C OPEN PIN A INSTALLED PIN C OPEN SCREW A OPEN SCREW C INSTALLED
PIN B
OPEN PIN D INSTALLED SCREW B INSTALLED SCREW D OPEN PIN B OPEN PIN D INSTALLED SCREW B INSTALLED SCREW D OPEN
Figure B.
Table 1.

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
16
1. Prior to engaging an ITA with the receiver for the first time, ensure all modules (ITA and receiver) are properly installed.
- Inspect modules to ensure proper mounting and verify module positioning. Module positions are shown in Figures A and B.
- Modules must be installed so that Pin 1 of each receiver and ITA module pair are mateable.
- All ITA modules must match their respective receiver modules. It is crucial for all modules to be installed properly.
*G12x Only: The lower four module rows share the same description as on G12 (i.e. A1-A4). The extended tier of the G12x is
considered to be rows 5 or 6.
2. The receiver should be checked for any foreign objects that may interfere with engagement.
3. Aer inspection, the ITA is ready for engagement with the receiver. The ITA may be placed onto the receiver platform and properly positioned relative to the
receiver guide pins. Ensure that the ITA roller bearings are aligned with the receiver slide openings when the receiver handle is in the open position (upward/
vertical).
4. Carefully rotate the handle forward to actuate the receiver slide engagement mechanisms, which will draw the ITA into engagement position with the
receiver. Once the handle reaches a positive stop at the end of its travel and latches into place, the modules are engaged.
5. Upon completing use of the ITA, rotate the receiver handle to the open position (upward/vertical), remove the ITA, reinstall the receiver protective cover and
rotate the handle to the closed position (downward/horizontal).
6. Always protect the contacts when the system is not in use. The receiver contacts are protected when either the ITA or receiver protective cover is engaged.
VPC recommends use of both receiver and ITA protective covers to avoid potential contact damage.
IMPROPER ENGAGEMENT WILL DAMAGE THE
MODULES, AND POSSIBLY THE ITA AND/OR
RECEIVER.
ITA & RECEIVER ENGAGEMENT
IN THE EVENT OF COMPLICATIONS, A TRAINED
TECHNICIAN SHOULD BE NOTIFIED IMMEDIATELY TO
AVOID ANY DAMAGE TO THE SYSTEM. THIS APPLIES TO
ANY DIFFICULTIES THAT MAY BE EXPERIENCED DURING
ENGAGEMENT.
G12 ITA shown from the wiring side (non-mating side).
MODULE POSITION A1
MODULE POSITION A2
MODULE POSITION A3
MODULE POSITION A4
MODULE POSITION B1
MODULE POSITION B2
MODULE POSITION B3
MODULE POSITION B4
MODULE POSITION C1
MODULE POSITION C2
MODULE POSITION C3
MODULE POSITION C4
MODULE POSITION A1
MODULE POSITION A2
MODULE POSITION A3
MODULE POSITION A4
MODULE POSITION B1
MODULE POSITION B2
MODULE POSITION B3
MODULE POSITION B4
MODULE POSITION C1
MODULE POSITION C2
MODULE POSITION C3
MODULE POSITION C4
G12x receiver shown from the mating side.
MODULE POSITION B4
MODULE POSITION A1
MODULE POSITION A2
MODULE POSITION A3
MODULE POSITION A4
MODULE POSITION B3
MODULE POSITION B1
MODULE POSITION B2
MODULE POSITION C6
MODULE POSITION C4
MODULE POSITION A3
MODULE POSITION A2
MODULE POSITION A1 MODULE POSITION B1
MODULE POSITION B2
MODULE POSITION B3
MODULE POSITION B4
MODULE POSITION C1
MODULE POSITION C2
MODULE POSITION C3
MODULE POSITION C4
MODULE POSITION C1
MODULE POSITION C2
MODULE POSITION C3
MODULE POSITION A5
MODULE POSITION A4
MODULE POSITION A6
MODULE POSITION A6
MODULE POSITION A5
MODULE POSITION B6
MODULE POSITION B5
MODULE POSITION B6
MODULE POSITION B5
MODULE POSITION C6
MODULE POSITION C5
MODULE POSITION C5
Figure A. G12
G12 Receiver shown from the mating side
Figure B. G12X
G12X ITA shown from the wiring side (non-mating side).

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
17
RECEIVER INSTALL/UNINSTALL CAUTIONARY NOTE
PART #   ,   ,   ,   ,
  ,   ,   ,   
When installing or removing the G12/G12x Receiver to a rack, be sure the handle is not in the
disengaged/vertical position (Figure A). Tension springs are located inside the mounting holes used to
mount the receiver to the rack. While the handle is in the disengaged/ vertical position, these springs
are present in the mounting holes and can be damaged by the introduction of mounting screws.
Damage to these springs will cause reduced resistance and tension in the handle.
When the receiver is engaged/ horizontal position (Figure B), the springs are lowered and allow a clear
path to install/remove the receiver using mounting screws.
Figure A.
Figure B.
BEFORE INSTALLING RECEIVER TO RACK

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
18
ITA Frame is not lined up when in the process of engagement with receiver
• This may indicate that the ITA is out of alignment or that a module is not mating with its intended module.
• Remove and inspect the ITA for alignment.
• Check for foreign objects/tools.
• Inspect the matching of modules -power ITA module to mate with power receiver module, etc.
Excessive force is needed to engage the handle
• With a typical contact load, approximately 35lbs force is needed to engage the handle. Consult with VPC for detailed contact loading information.
• If excessive force is required, this may indicate that the ITA is out of alignment or that a module is not mating with its intended module.
• Remove and inspect the ITA for alignment. Contact VPC– unauthorized user adjustments to the system will void the warranty.
• Check for foreign objects/tools.
• Contact damage may cause noticeable resistance. Upon replacing a contact in the ITA, the mating contact on the receiver side should also be inspected and
replaced, if necessary.
• Verify the orientation of the receiver and ITA modules.
• Inspect the matching modules - power ITA module to mate with power receiver module, etc.
ITA will not engage with the receiver aer diagnosing the above problems
• Contact VPC – unauthorized user adjustments to the system will void the warranty.
No continuity upon engagement
• When replacing an ITA contact, the mating contact on the receiver side should also be inspected and replaced, if necessary.
• Check wiring and replace if necessary.
• Contact not secured in module.
• A contact may be damaged. Visually check all contacts for damage to potentially isolate damaged pin prior to checking for continuity with a multi-meter.
A “short ” in the wiring upon engagement
• A damaged contact may cause high resistance. Upon replacing a contact in the ITA, the mating contact on the receiver side should also be inspected and
replaced, if necessary.
• Check wiring and replace if necessary.
Receiver and ITA will not disengage
• This may indicate that the engagement mechanism within the receiver is faulty -contact VPC immediately- user adjustments to system, unless authorized,
will void the warranty.
TROUBLESHOOTING
FORCEFUL ENGAGEMENT OF THE RECEIVER AND
THE ITA WILL RESULT IN SERIOUS DAMAGE TO
MULTIPLE PARTS OF THE SYSTEM (MODULES,
RECEIVER, ITA AND CONTACTS).

G/GxUSER MANUAL VPC
03/28/2022
For more information visit vpc.com.
RETURN TO INDEX
19
• Never probe a contact without using a mating patchcord as a test lead.
• Never forcefully engage a system if there is an excessive amount of resistance on the handle.
• Never allow an ITA to drop as this may cause misaligned engagement and/or irreparable damage.
• Always insert and extract a contact insertion/extraction tool in line with the contact. Never apply pressure to the side as this may break either the
contact or tool.
• It is advisable that power to the interface system be disconnected prior to handling and maintenance.
• Caution should always be used when engaging, making sure that all foreign objects are removed from the system.
PRECAUTIONARY NOTES
