INSTALLATION GUIDE FOR THE
VOPEX-SV-2-LC
INTRODUCTION
The VOPEX-SV-2-LC S-Video Splitter allows two S-Video displays to be driven
from the same S-Video source. The S-Video may come from sources such as
a PC, DVD player, satellite receiver, or VCR to name a few. With 150 MHz
bandwidth, the VOPEX-SV-2 supports standard S-Video resolution–up to 800 x 600.
INSTALLATION
1. Turn OFF power to source and display(s).
2. Disconnect the S-Video cable from the source and reconnect it to the female connector labeled "S-VIDEO OUT 1" on the
VOPEX-SV-2-LC.
3. Install one male end of the SVEXT-3-MM cable (supplied) into the source’s S-Video output connector.
4. Install the other male end of the SVEXT-3-MM cable into the female connector labeled "S-VIDEO IN" on the VOPEX-SV-2-LC.
5. An additional display may be plugged into the remaining female connector labeled "S-VIDEO OUT 2" as required.
6. Plug in the AC adapter and connect it to the VOPEX-SV-2-LC.
7. Turn ON power to the source and display(s).
Note: Additional S-Video cable lengths (SVEXT-xx-MM where xx is the length of the cable in feet) may be ordered from Video Products
Inc by calling [phone] (U.S) or 330-562-7070 or visit our website at www.vpi.us.
TROUBLESHOOTING
PROBLEM SOLUTION
No Video • Connect power to VOPEX-SV-2-LC
• Cable connections not secure
Poor Resolution • Make sure the display is plugged into S-
VIDEO IN on the VOPEX-SV-2-LC
Right End View of VOPEX-SV-2-LC
Left End View of VOPEX-SV-2-LC
Tel: [phone]
www.vpi.us
1275 Danner Drive
Fax: [phone]
VPI VIDEO
PRODUCTS
INCORPORATED
Aurora,Ohio 44202
SVEXT-3-MM
(supplied) PC, DVD, Satellite,
or VCR
S-VIDEO
IN
S-VIDEO
OUT 2
S-VIDEO
OUT 1
5V
0.5A
VOPEX-SV-2-LC
VPI R
Vi deo Pro du cts I nc
AC Adapter
(supplied)
S-Video Cable
(not supplied)
Top View of VOPEX-SV-2-LC
S-Video Cable
(not supplied)

Technical Specifications
WARRANTY INFORMATION
The warranty period on this product (parts and labor) is one (1) year from date of purchase. Please contact Video Products Inc at [phone]
or 330-562-7070 for information regarding repairs and/or returns. A return authorization number is required for all repairs/returns.
COPYRIGHT
Copyright 2003 by Video Products Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Video
Products Inc, 1275 Danner Drive •Aurora, OH 44202.
CHANGES
The material in this guide is for information only and is subject to change without notice. Video Products Inc reserved the right to make changes in
the product design without reservation and without notification to its users.
MODEL NO: VOPEX-SV-2-LC
SERIAL NO: _________________________
DATE: _________________________
INSPECTED BY: _________________________
MAN040 Revised 7/17/2003
Input / Output Signals
Pin # Signal Pin # Signal
1 Y-Ground 3 Y
2 C-Ground 4 C
General
Description Specification
Signal Type S-Video
Connector 4-pin miniDIN
Max. Input Levels Y:
C: 1.0 Vp-p 0.286 Vp-p
Max. Output Levels Y:
C: 1.0 Vp-p, +/- 2% 0.286 Vp-p +/- 2%
Input / Ouput Impedance 75 Ohms
Maximum Resolution 800 x 600
Power 110 or 220VAC at 50 or 60 Hz-
5VDC/.5A AC adapter
Size (In.) W x D x H 3.7 x 2.1 x 1.15
