VQ Radio Control Model Swallow User manual

Wing span approx : 35.8 in.
Length approx : 25.0 in.
Propulsion Set
Brushless for
Swallow
# C5542
INSTRUCTION MANUAL / MONTAGEANLEITUNG
SPECIFICATION TECHNISCHE DATEN
Spannweite :910mm
Lange : 635mm
Antriebsset
Brushless für
Swallow
# 5542
!
RADIO CONTROL MODEL / RC FLUGMODELL
ARF BY

Attach the Horizontal Stabilizer
Incorrect
Correct
AA’
A=A’
AA’
A=A’
/
Check the alignment of the horizontal
stabilizer by measuring from a fixed point
along the center line of the fuselage to the
leading edge on each side of the horizontal
stabilizer. The distance must be equal on
both sides. If not, adjust the stabilizer until
the measurements are the same.
1-Trial fit the horizontal stabilizer in place . Check the alignment
of the horizontal stabilizer. When you are satisfied with the
alignment, use a pencil to trace around the bottom of the stabilizer
where it meets the fuselage.
2-Remove the horizontal stabilizer from the fuselage. Using the
sharp hobby knife, carefully cut away the covering inside the
lines which were marked above.
3-Spread epoxy (30 minute) onto the bottom of the horizontal
stabilizer along the area where the covering was removed
and to the fuselage where the horizontal stabilizer mounts.
4-Install the horizontal stabilizer into the fuselage and adust the
alignment as described in steep 1.Allow the epoxy to cure
before proceeding to next step.
1
2&3
4
1
AB
TOP VIEW
Draufsicht
BOTTOM - VIEW
Unteransicht
TOP VIEW
Draufsicht
SIDE-VIEW
Seitenansicht Horizontal
stabilizer Elevator
Fuselage
1- Horizontal Tail / Hohenruder
Cut away only
the covering

Cut away only
the covering
Cut 31/64”(12mm) long
slots along the centerline
for the rudder hinge.
Cut away
only the covering
on both side.
AB
S5
L/R
CA
TOP VIEW
Draufsicht
Securely glue together. If coming off
during flight, you lose control of your
air plane.
2- Vertical Tail / Seitenruder
S1
S2
S3
S4
S5
2.5mm plywood parts

S1
S2
CA
Cut away only
the covering
Securely glue together. If
coming off during flight,
you lose control of your
air plane.
CA
Securely glue together. If
coming off during flight,
you lose control of your
air plane.
1- Push the elevator pushrod into the white
nylon pushrod guider.
2- Insert the elevator pushrod into the elevator control horn.
3- Place the elevator control horn onto the elevator and
carefully cut away the covering where the elevator control
horn meets the elevator.
4- Secure the elevator control horn in
place using CA glue.
CA
Securely glue together. If coming off
during flight, you lose control of your
air plane.
BOTTOM - VIEW
Unteransicht
BOTTOM - VIEW
Unteransicht
BOTTOM - VIEW
Unteransicht
INSTALLATION RUDDER CONTROL HORN
1- Push the rudder pushrod into the
white nylon pushrod guider.
2- Insert the rudder pushrod into the rudder
control horn.
3- Place the rudder control horn onto the
rudder and carefully cut away the
covering where the rudder control
horn meets the rudder.
4- Secure the rudder control horn in
place using CA glue.
TOP VIEW
Draufsicht
3- Linkage / Ruderanlenkung

S3
S4
CA CA
CA
BOTTOM - VIEW
Unteransicht
TOP VIEW
Draufsicht
RED POWER
LITHIUM POLYMER BATTERY
800 - 7.4V
Rudder servo
Elevator servo
4- Wooden parts installation
5- Radio installation
Höhenruderservo
Seitenruderservo
X
Pushrod
3mm set Screw
2 mm
Rudergestänge
Madenschraube M3
4mm O dowel.

CA
RED POWER
LITHIUM POLYMER BATTERY
800 - 7.4V
CA
Motor mount (3mm plywood) Motor mount
1- Insert the Motor mount (3mm
plywood) onto the motor. Secure it
in place using four screw ( included
with motor set).
2- Trial fit the Motor in place. Check
the alignment of the Motor. When
you are satisfied with the alignment,
secure the Motor mount with fuselage
using CA glue.
TOP VIEW
Draufsicht
6- Motor installation
7- Canopy / Kabinenhaube
Propulsion Set
Brushless for
Swallow
# C5542
Antriebsset
Brushless für
Swallow
# 5542
Rubber band

CA
8- Wooden part installation
CG
WARNING ! Securely install the receiver and power pack, ensuring they will not come loose or rattle during flight.
Never fly before checking the Cg’s required position.
ELEVATOR STROKE RUDDER STROKE
25/32”(20mm)
5/16”(8mm)
5/16”(8mm) 25/32”(20mm)
9- Balance / Schwerpunkt
Hohenruderausschlag
Seitenruderausschlag
Do not try to fly an out-of balance model!
Uberprufen Sie vor dem Flug den Schwerpunkt.
38mm
TEST GLIDING
Test glide by launching over long grass to check the trim and stability. The model should always be launched into the
wind and only fly in light wind conditions. Adjustments to the flight path can be made by slightly bending the rear edges
of the tail surfaces. Deflecting the rear edge of the tailplane down will make the model dive, bending it up will make the
nose rise (too much will make the model stall) Bending the rear of the fin will make the model turn or the wing can be
“slewed” so that it is not square to fuselage.
Correct glide Stall - add weight Dive - remove weight
