VQ 141A08 User manual

1-Trial fit the vertical stabilizer in place . Check the
alignment of the vertical stabilizer. When you are
satisfied with the alignment, use a pencil to trace
around the right and left of the stabilizer where it
meets the fuselage.
2-Remove the vertical stabilizer from the fuselage.
Using the sharp hobby knife, carefully cut away the
covering inside the lines which were marked above.
3-Spread epoxy (30 minute) onto the right and left and
bottom of the vertical stabilizer along the area where
the covering was removed and to the fuselage where
the vertical stabilizer mounts.
4-Install the vertical stabilizer into the fuselage and
adust the alignment as described in steep 1.
5-Wipe off any excess epoxy using a paper towel and
rubbing alcohol.
Allow the epoxy to cure before proceeding to next step.
A
B
Cut away only the covering both
the right and left side
C = C’
Both the left and
right side
CC’
Securelyglue together. If coming o during ight,
youlose control of your air plane.
AB
AB
A = A’
B = B’
Securelyglue together. If coming o during
ight,you lose control of your air plane.
Cut away only the covering
both the top and bottom side
AA’
90
O
90
O
Both the top and
bottom side
Cut away only the covering both
the right and left side
BB’
1-Trial fit the horizontal stabilizer in place .
Checkthe alignment of the horizontal
stabilizer.When you are satisfied with the
alignment,use a pencil to trace around the top and
bottomof the stabilizer where it meets the fuselage.
2-Remove the horizontal stabilizer from the fuselage. Using the
sharphobby knife, carefully cut away the covering inside the
lineswhich were marked above.
3-Spread epoxy (30 minute) onto the top and bottom of the horizontal stabilizer
alongthe area where the covering was removed and to the fuselage where the
horizontalstabilizer mounts.
4-Install the horizontal stabilizer into the fuselage and adust the alignment as described in steep 1
5-Wipe off any excess epoxy using a paper towel and rubbing alcohol.
Allowthe epoxy to cure before proceeding to next step.
*WARNING: When removing any covering fromthe air frame, please ensurethat you secure the
cut edge with CA or similar cement. This will ensure the covering remain tight.
*WARNING: When removing any covering fromthe air frame, please ensurethat you secure the cut edge with CA or similar
cement.This will ensure the covering remain tight.
20- HORIZONTALSTABILIZER
21- VERTICAL STABILIZER
X
Elevator push rod
Throttle push rod
Rudder push rod
Tailwheel push rod
4-49/64”
(120mm)
2-61/64”
(75mm)
Carefully cut a 2-9/32”(58mm) wide area which is 2-61/64”
(75mm) in length through both the covering and the balsa
wood. Remove the excess balsa.
Put the battery pack into the box (pre-build at factory) and
fasten down with rubber bands or similar, ensuring it will not
come loose or rattle during flights.
Link the battery wire with the battery extension cord.
Reposition the hatch in place and secure it with CA glue.
Battery area
(in case of 4T engine)
Battery area
(in case of 2T engine)
800-1000mah, flat pack
BOTTOMVIEW
Hatch
Hatch
2-9/32”
(58mm)
2”(51mm)
2-61/64”(75mm)
FUSELAGE
BOTTOM
Elevator push rod
Elevator push rod
Tailwheel push rod
Rudder push rod
Throttle push rod
................2
....................3
2mm
Connector
Elev.servo
Rudder servo
Thrott. servo
X
Elevator pushrod
or rudder pusshrod
D=5/64”(2mm)
Tailwheel pushrod
D=.050”(1.2mm)
3mm set Screw
2 mm
Elevator pushrod
ELEVATOR/ RUDDER SERVO
X
3mm set Screw
2 mm
THROTTLE SERVO
throttle pushrod
D=.050”(1.2mm)
Bottomview
Bottomview
24- SERVO
25- LINKAGES
IMPORTANT: Pleasedo not clean your model with pure alcohol, only use liquid soap with water or use glass cleaner
to clean on surface of your model to keep the colour not fade.
Note: Cut out the stickers and apply them in the proper area. Do not
peel the backing paper off all at once.
Peel off one corner of the backing and cut off with scissors.
Arrange sticker on model and when satisfied adhere the corner
without backing.
Carefully peel back the rest of the backing while at the same
time adhering the rest of the sticker.
Try not to make air bubbles, if there are some, carefully
puncture sticker (center of bubble) but not model surface with
the tip of the knife or sharp pin and squeeze out the air.
At curves stretch sticker and apply a little heat so that no ceases
occur.
Cut off the excess that is produced.
Fuel cap
Black sticker White sticker
(Apply on the top and bottom of ailerons)
MR
J
Sticker
White stripe sticker (apply on the bottom)
Black stripe sticker (apply on the bottom)
P51D
US.ARMYP51D5NA
SERIALNOAAF3136542
CREWWEIGHT300LBS
Fuel cap
“Obsession” sticker
474976
141A08 (Obsession)
GUNNIN’ GLORY
for
23580
P51D
US.ARMYP51D5NA
SERIALNOAAF3136542
CREWWEIGHT300LBS
Fuel cap
Sticker White stripe sticker (apply on the bottom)
Black stripe sticker (apply on the bottom)
Sticker
Sticker Sticker
141A07S (Gunnin for glory)
141A08 (Obsession)
N151MW
Fuel cap
Sticker
Sticker
Sticker
141A07L Lady Alice version
29- DECAL
! Engine thrust on balk head
is already adjust at factory
! Align the mark on both mounts
with the mark on the fuselage A
B
B’
B=B’
FRONT-VIEW
- Remove the engine mount and drill a 13/64”
(5mm) hole through the fire-wall at each of the
four marks marked.
- Attach the four blind-nut to the fire-wall as show
- Using a pencil or felt tipped pen, mark the fire wall
where the four holes are to be drilled
- Reposition the engine mounts on to the fire-wall
and secure them with four 4x25mm screw
- Reposition the engine on to the engine mounts so
the distance from the prop hub to the fire wall is
4.4”(114mm)
114mm
! Engine thrust on balk
head is already adjust
at factory
1.5
TOP-VIEW
5mm
13/64”
- Mark the engine mounting plate where the four
holes are to be drilled.
Note: Mark the mounting plate through the engine
mounting flanges.
- Remove the engine and drill a 1/8”(3mm) holes
through the beam at each of the four marks made
above.
- Reposition the engine on the engine mount beams,
aligning it with the holes. Secure the engine to the
engine mount using four 1/8x51/64”(3x25mm)
screws.
Note: Apply Silicon sealer to
each of the 1/8x51/64” screw.
...4
.................4
4x25mm screw
Blind-nut
3x20mm screw
1/8”(3mm) nut
.................4
...4
1/8x5-1/64”
5/32x1”
(4.4”)
With hang silencer
FRONT-VIEW
INC ASE OF 2T ENGINE
With side silencer
17- ENGINE MOUNT
A
Pull the magnetic top hatch
out of the fuselage.
X
Tomuffler
Filler tube
Toengine
3x25mm
screw
Rubber stopper
1
After confirming the direction . Insert this assembly,clunk end first, into the fuel
tank and tighten and screw the fuel tank cap on firmly.
3x35 mm screw 4mm
2
Firewall
114mm
(4.4”)
B’
B
B=B’
A
A=A’
A’ ! Engine thrust on balk head
is already adjust at factory
-Using a aluminum motor mounting plate as a template,
mark the plywood motor mounting plate where the four
holes are to be drilled.
-Remove the aluminum motor mounting plate and drill a
1/8”(3mm) hole through the plywood at each of the four
marks marked .
3mm
Note: The aluminum motor mounting included with electric
motor set.
5x70mm.......4
5mm nut.......12
5mm washer...16
3mm screw/nut...4
SIDE-VIEW TOP-VIEW
3
Ensure that the fuel tank clunk does not touch the rear of the fuel tank.
Checking for leaks - block the vents and blow
into the feed - if in doubt submersing the tank
in a blow of water will show up any problems.
Blow
Water
Carefully install the fuel tank to ensure that they will not
shift during flight (secure the fuel tank in place using
foam padding).
4
18- FUEL TANK
19- ELECTRIC MOTOR
1
2
2.5x10mm
1~2mm
Board or
transparent
plastic
Adhesive
tape
1-Attach the board or transparent plastic on the side of the fuselage
with the adhesive tape as show.
2-Using a pencil or felt tipped pen trace around the engine head where
it meet the cowl. Cut the opening the board or transparent plastic for
the engine head as marked before.
3-Remove the engine and insert the cowl on to the fuselage so the
distance from the fire wall to the front of the cowl approx 4.4”(112mm).
Tracearound inside the hole on the board or transparent plastic with a
pencil.
4-Remove the cowl from the fuselage and carefully cut the opening for
the engine head as marked above. Do the same way with the hole for
needle-valve.
5-Again. Insert the cowl on to the fuselage and secure it in place with
five 2.5x10mm self tapping screws.
112mm
Ruler
Cut the opening
Cut the opening
1.5mm
1/16”
1.5mm
1/16”
2.5x10mm self
tapping screw
3/32x25/64” self tapping screw
.................4
1/16”
Wing center section
DONOT try to y an out-of-balance model !
5-13/64” (132mm)
Note: If necessary,move the battery pack or add weight to either
the tail or nose until the correct balance is achieved.
13/32”(10mm)
13/32”(10mm)
1-23/64”(35 mm)
1-23/64”(35 mm)
RUDDER
15/64”(6mm)
15/64”(6mm)
AILERON
IMPORTANT:Flying your model at these throws will provide you with the greatest chance for successful first flights.
If,after you have become accustomed to the way the P-51 flies, you would like to change the throws to suit your taste
that is fine. However,too much control throw could make the model difficult to control, so remember, “more is not always better”.
ELEVATOR
26- COWLING
27- BALANCE
28- CONTROL SURFACE
Takeoff 10mm (25/64”)
Landing 22mm
(55/64”)
FLAP
P51D MUSTANG
GUNNIN’ GLORY
for
23580
P51D
US.ARMYP51D5NA
SERIALNOAAF3136542
CREWWEIGHT300LBS
Instruction manual
Radio controlled model
141A07S (Gunnin for glory)
141A08 (Obsession)
ALLBALSA, PLYWOOD CONSTRUCTION AND ALMOST READY TO FLY
N151MW
141A07L(Lady Alice)
141AR03
1.5mm
A
B
!
CA L/R
Assemble left and right
sides the same way.
X
Drill holes using the stated
size of drill
(in this case 1.5 mm ÿ)
Use epoxy glue
Takeparticular care here
Hatched-in areas:
remove covering
film carefully
Not included.
These parts must be
purchased separately
Check during assembly that these
parts move freely,without binding
Apply cyano glue
Low setting
SILICON
EPOXY A
EPOXY B
CA
GLUE
Epoxy Glue ( 5 minute type)
Silicon sealer Cyanoacrylate Glue
Minimum 6 channel radio
for airplane with 3 standard
and 4 mini servos.
.60 ~.70 - 4 cycle
10.5x6 for .40 - 2 cycle engine
11x6for .46 - 2 cycle engine
12x6 for .60 - 4 cycle engine
12x7 for .70 - 4 cycle engine
13x6 for Quantum 4120/05
Silicone tube
Extension for aileron
servo, retract servo
and Rx battery pack.
.46 ~ .50 - 2 cycle
Linkage Stopper x2
(for retract servo)
Epoxy Glue (30 minute type)
TOLLS REQUIRED
Hobby knife
Needle nose Pliers
Phillip screw driver
Awl
Scissors
Wire Cutters
(Purchase separately) Hex Wrench
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
Sander
Masking tape - Straight Edged Ruler - Pen or pencil - Rubbing alcohol - Drill and Assorted Drill Bits
Read through the manual beforeyou begin, so you will have an overall idea of what to do.
Symbols used throughout this instruction manual, comprise:
(Purchase separately)
Retract landing
gear
Retract servo x1
.Motor control x1 .Elevator x1
.Rudder x1.Aileron x2 (mini servo)
.Flap x2 (mini servo)
XPower XC4220/14
Brushless Motor
or equivalent.
XPower XREG60 Brushless
Motor Controller
Li-Po Battery,14.8V, 4000mAH, 80A
CONVERSIONTABLE
1.0mm = 3/64”
1.5mm = 1/16”
2.0mm = 5/64”
2.5mm = 3/32”
3.0mm = 1/8”
4.0mm = 5/32”
5.0mm = 13/64”
6.0mm = 15/64”
10mm = 13/32”
12mm = 15/32”
15mm = 19/32”
20mm = 51/64”
25mm = 1”
30mm = 1-3/16”
45mm = 1-51/64”
If exposed to direct sunlight and/or heat, wrinkels can appear. Storing the
model in a cool place will let the wrinkles disappear. Otherwise, remove
wrinkles in covering film with a hair dryer, starting with
low temperature. Youcan fix the corners by using a hot iron.
REQUIRED FOR OPERATION(Purchase separately)
AB
ABCenter line
Use epoxy glue to bury the
opening
1- Using a pencil, mark the center of the brace.
2- Trialfit the wing joiner into one of the wing panels. It should insert smoothly up to the center line marked above.
3- Slide the other wing half onto the dihedral brace until the wing panel meet. If the fit is over tight, it may be necessary to
lightly sand the dihedral brace.
4- Check for the correct dihedral angle.
5- Mix up some 30 minute epoxy and apply a generous amount of epoxy into the wing joiner cavity of one wing half.
6- Coat one half of the dihedral brace with epoxy up to the center line. Install the epoxy-coated side of the dihedral brace
into the wing joiner cavity up to the center line, marking sure that the “V” of the dihedral brace is positioned correctly
7- Do the same way with the other wing half.
8- Carefully slide the wing halves together,ensuring that they are accurately aligned. Firmly press the two halves
together, allowing the excess epoxy to run out. Clean off the excess epoxy with paper towel and kerosene.
Binder clip
Nylon wing bolt
Rubber band
(both the top
and bottom)
IMPORTANT: Pleasedo not clean off the excess epoxy on the wing with strong solvent or pure alcohol, only use
kerosene to keep the colour of your model not fade.
1-Depending on the position of the linkage, determine the location of aileron control horn.
Thehorn holes must be perfectly aligned with the axis of articulation.
2-Mark the position of the “foot” of the horn on the aileron. Then, with the drill, make the 2
holes.
3-Install the aileron control horn as shown.
Plastic control horn
..........4
2x30mm....8
..........4
Control horn Alignment
Dothe same way with second
winghalf.
WING - BOTTOM VIEW
1-Cut away the covering of the wing bottom
wherethe aileron servo goes.
2-Connect the aileron servo cord to the aileron
extensioncord.
3-Install the aileron servo on the servo mount.
-Switch on the radio (trims centered)
then mount the ailerons servo horn
in neutral position.
-The servo horn should be
perpendicular to the servo
YES NO
Adhesive
tape
Dothe same way with second wing half
WING - BOTTOM VIEW
1- JOINING THE WING
2- SERVO
3-CONTROL HORN
CA
Cut away the covering inside the line
before install the air scoop and wing cover
Plastic air scoop
CA
Wing bolt mount
Plastic air scoop
Plastic cover
6x40 plastic bolt
(Ply wood)
Plastic mount nut
Bottom
12mm
15/32”
6x40mm nylon bolt
.........2
WING
Bottom view
14- AIR SCOOP
15- INSTALLATIONTHE WING
Nylon wing bolt
Bottomview /Ansicht von unten
16- INSTALLATIONTHE WING
2x6mm screw
..........4
....2
...2
CA
4mm collar
ABS Wheel well cover
CA
Bottomview /Ansicht von unten
11- GEAR COVER
12- GEAR COVER
Bottomview /Ansicht von unten
13- INSTALLATIONTHE WING
Cut away the covering inside the line
before install the air scoop and wing cover
1-Using theABS air scoop as a template, trace
aroundthe outside edge of the ABS air-scoop,and
thenremove it.
2-Using a sharp hobby knife, cut away the covering
inside the line, not to cut into the wood.
*WARNING: When removing any covering fromthe
airframe,please ensure that you secure the cut edge
withCA or similar cement. This will ensure the
coveringremain tight.
Cut away only the
covering both sides
Retract servo
Retract gear
Retract gear
Link the servo and retract gear arm with push rod.
Be sure to adjust the stroke so that the landing
gear locks in both up and down position.
With the retract and retract servo in the retracted position, mark the position where each of the pushrod will attach to the servo arm,
a small piece of masking tape works well for this. Cut off the excess length each rod.
RETRACTED EXTENDED
EINGEFAHREN AUSGEFAHREN
Ply gear mount
plate x 2
Gear mount x 2
RECEIVER
ELECTRICRETRACT
LANDINGGEAR
ON
OFF
GEAR
EXTENDEDPOSITION
RETRACTEDPOSITION
2mm
Mainlanding gear
2mm
3x12mmscrew
Gearmount
1
3x20mm
Nylongear
strap
2mm
23x20mm
Plygear
mountflat
Square
plastic
2mm
3
3x20mm screw
..........8
3x12mm screw
......16
Nylon gear strap
.......4
3x20mmscrew
Wing- bottom view
2mm
Bottomview
ELECTRIC RETRACT
LANDING GEAR
4
Square plastic x 2
8- LINKAGES
9- ELECTRIC RETRACT
10- FIXED GEAR
(Purchase separately)
Cut away only
the covering
BC
A
CENTER
WING
SECTION
CA
CA
CA
CA
BOTTOM
A
B
C
Retract servo tray installation
Retract servo tray
Retract servo
mount
Retract servo
mount
SchneidenSie etwas Folie weg
Fahrwerkservohalterung
X
Retract landing gear
servo
Note: The head of servo should be positioned
toward the rear of the wing.
Install the retract servo onto the retract servo mount
and secure it in place with four screw (included with
radio set).
BOTTOM
RETRACT SERVO INSTALLATION
1.5mm
1/16”
CENTER
WING
SECTION
Do the same way with second
wing half.
X
3mm set Screw
2 mm
Aileron pushrod
D=5/64”(2mm)
WING - BOTTOM VIEW
5- LINKAGES
6- RETRACT SERVO TRAY
7- RETRACT SERVO
Aileron extension cord
exit hole
Keep the aileron extension cord
in place using sticker.
1
2
4- AILERONS - FLAPS EXTENSION
(Purchase separately)
5 5
Bottom view
3/8 in. (9.5mm)
Hinge
Petroleum jelly
STABILIZER
Control horn
................3
2x12mm screw
..........6
CA
1- Insert the tail wheel pushrod into the hole on the tail gear control
horn(as show).
2- Install the tail wheel control horn in place.
4- Secure the tail wheel control horn in place using a 5/64”(2mm) screw set,
Ensuresmooth non-binding movement.
5- Installing the tail wheel hatch (H) in place using a four 5/64x25/64”(2x10mm)
selftapping screws.
6- Attach the tail wheel doors (D) in place using CAglue.
1
3
4
5
2
5/64 in.(2mm) I.D collar
2x10mm
screw
...............1
Taillanding gear
..........1
............1
2x3mm screw
............4
2x10mm screw
.................1
Tailwheel control-
horn
2mm I.D collar
6
3- Instal the tail wheel gear in place.
H
D
Bottomview
23- TAIL GEAR
CA
Thin CA glue
Apply a thin layer of machine oil or petroleum jelly to only the
topand bottom of the trailing edge of the elevator, then
push the elevator and its hinges into the hinge slots in the
trailing edge of the horizontal stabilizer.
When satisfied with the and alignment, hinge the elevator to
the horizontal stabilizer using CAglue.
Repeat the previous procedures to the hinge the second elevator
to the other side of the horizontal stabilizer.
22- ELEVATOR
SPECIFICATIONS
Wingspan:......................... 1580mm (62.2in)
Length:................................1180mm(46.45 in)
Electric Motor:.....................See next page
Glow Engine:.................... .46 2-T / .70 4-T
RTF Weight: 3.2Kg / 7.05lbs (Will vary with
Equipment Used).
Radio:....................6 Channel / 7 Servos
Function:Ailerons-Elevator-Rudder-Throttle
Flaps-Retractable Landing Gear.
WARNING!This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
VQ model aircraft distribué par / distributed by:
TOPMODEL S.A.S
Le jardin d’entreprises de SOLOGNE
F-41300 SELLES SAINT DENIS
www.topmodel.fr
©TOPMODEL2015
