VTech Baby 3-in-1 Starry Skies Sheep Soother User manual

Instruction Manual
3-in-1 Starry Skies
Sheep Soother

C
M
Y
CM
MY
CY
CMY
K
Grow with VTech(101x127)bw1P-V2.pdf 1 08/18/2014 9:29:01

3
3
3
INTRODUCTION
Thank you for purchasing the 3-in-1 Starry Skies Sheep Soother.
Let this sweet lamb soothe your child to sleep with soft music,
peaceful nature sounds and softly pulsing lights. Three light discs
provide a night light, starry night effect or kaleidoscope style light
projections. Choose among three timer options, and rest assured—if
your child wakes up crying, the soother responds with comforting
sounds. Remove the electronic module so you can give the sheep to
your child to cuddle when they wake up.
On/Off Switch
Volume Control Buttons
Light Control Button
Time Setting Switch
Lullaby Button
Sound Button
Nursery Rhyme Button
Sound Sensor

4
4
4
INCLUDED IN THE PACKAGE
• 3-in-1 Starry Skies Sheep Soother
• Electronic module
• Three light discs
• Quick Start Guide
WARNING
All packing materials such as tape, plastic sheets, packaging locks,
removable tags, cable ties, cords and packaging screws are not part
of this toy, and should be discarded for your child’s safety.
NOTE
Please save this Instruction Manual as it contains important
information.
The 3-in-1 Starry Skies Sheep Soother is hand washable. Remove
the electronic module rst. See instructions below and on page 9.
This product is in Try-Me mode in the packaging. After opening
the package, please remove the demo tag from the bottom of the
electronic module, then turn the unit off and on again to proceed with
normal play. If the unit repeatedly powers down or if the light fades
out during play, please install a new set of batteries.
The cord is not part of this toy. For your
child’s safety, please cut and discard the
cord before using the product.

5
5
5
GETTING STARTED
Battery Removal and Installation
1. Make sure the unit is turned OFF.
2. Locate the battery cover on the bottom of the electronic module.
Use a screwdriver to loosen the screw and then open the battery
cover.
3. If used batteries are present, remove these
batteries from the unit by pulling up on one
end of each battery.
4. Install 2 new AA (AM-3/LR6) batteries
following the diagram inside the battery
box. (For best performance, alkaline
batteries or fully charged Ni-MH
rechargeable batteries are recommended).
5. Replace the battery cover and tighten the
screw to secure.
WARNING:
Adult assembly required for battery installation.
Keep batteries out of reach of children.
IMPORTANT: BATTERY INFORMATION
• Insertbatterieswiththecorrectpolarity(+and-).
• Donotmixoldandnewbatteries.
• Donotmixalkaline,standard(carbon-zinc)orrechargeablebatteries.
• Onlybatteriesofthesameorequivalenttypeasrecommended
are to be used.
• Donotshort-circuitthesupplyterminals.
• Removebatteriesduringlongperiodsofnon-use.
• Removeexhaustedbatteriesfromthetoy.
• Disposeofbatteriessafely.Donotdisposeofbatteriesinfire.

6
6
6
RECHARGEABLE BATTERIES:
• Removerechargeablebatteriesfromthetoybeforecharging.
• Rechargeablebatteriesareonlytobechargedunderadultsupervision.
• Donotchargenon-rechargeablebatteries.
Disposal of batteries and product
The crossed-out wheelie bin symbols on products and
batteries, or on their respective packaging, indicates they
must not be disposed of in domestic waste as they contain
substances that can be damaging to the environment and
human health.
The chemical symbols Hg, Cd or Pb, where marked,
indicate that the battery contains more than the specied
value of mercury (Hg), cadmium (Cd) or lead (Pb) set out
in the Batteries and Accumulators Regulation.
The solid bar indicates that the product was placed on the
market after 13th August, 2005.
Help protect the environment by disposing of your product
or batteries responsibly.
VTech® cares for the planet.
Care for the environment and give your toy a second life by
disposing of it at a small electricals collection point so all its
materials can be recycled.
In the UK:
Visit www.recyclenow.com to see a list of collection points near you.
In Australia & New Zealand:
Check with your local council for kerbside collections.

7
7
7
PRODUCT FEATURES
1. On/Off Switch
To turn the unit On, slide the On/Off
Switch to the On position. You will
hear a soothing song, two nursery
rhymes and 10 melodies. To turn the
unit Off, slide the On/Off Switch to
the Off position.
2. Timer Switch
Slide the Timer Switch to select the
length of time the unit will play audio
for. When the time is up, the unit will
automatically shut off.
3. Volume Control Buttons
Press the Button to increase the
volume or the Button to decrease
the volume. There are seven volume
levels, with the default volume set to
level three.
NOTE:
The default volume level is set to level three when the unit is rst
turned on or when the batteries are changed. Select a preferred
volume level, and the unit will use this as its new default volume level
(excluding level one, which is silent mode). If silent mode is selected,
the unit will default to volume level two when reactivated after
automatically powering down.

8
8
8
4. Light Control Button
Press the Light Control Button
to select one of six light effects,
including a no-light setting.
5. Sound Sensor
The 3-in-1 Starry Skies Sheep Soother is equipped with a
special sound sensor. Once the selected time setting has ended,
the unit will automatically shut off. The sensor will reactivate
the program if it detects that your baby’s cry has continued for
approximately four seconds without interruption. The unit will
reactivate and play lullabies. The sound sensor will be disabled
after 12 hours of inactivity.
6. Light Discs
Three Light Discs are included with the sheep, each giving a
different light effect. Snap the star pattern disc on to project a
starry night sky. The refractor pattern projects fun kaleidoscope
style lights. Insert the plain disc cover to give a soft, glowing
night-light effect.
7. Automatic Shut Off
To preserve battery life, the 3-in-1 Starry Skies Sheep Soother
will automatically shut down after the selected time has ended.
The unit can be turned on again by pressing any button. It will
also turn on automatically when the sound sensor detects your
baby’s cry.

9
9
9
ASSEMBLY INSTRUCTIONS
With the 3-in-1 Starry Skies Sheep Soother, safety comes rst.
To ensure your child’s safety, adult assembly is required.
1. To change the Light Disc, pull on the
tab with one hand while removing the
disc with your other hand. To attach
the Light Disc, insert the disc tab
into the slot on the electronic module,
pressing it down until it snaps into
place.
2. Store the light discs under the
electronic module, inside the 3-in-1
Starry Skies Sheep Soother.
3. To remove the electronic module
from the sheep, simply pull out the
electronic module and seal the hook
and loop closure. To insert the
electronic module, open the hook and
loop closure and spread and reshape
material to make a large enough
opening for the electronic module to
t inside.

10
10
10
ACTIVITIES
1. Sound Button
Press the Sound Button to hear
a combination of soothing nature
sounds or white noise. Press the
Sound Button again to hear the next
sound. The light pattern will fade in
and fade out slowly with the sounds
if the Light Control Button has not
been pressed.
2. Nursery Rhyme Button
Press the Nursery Rhyme Button
to hear ve nursery rhymes with fun
sounds followed by soft melodies.
Press the Nursery Rhyme Button
again to hear the next rhyme or
melody. The light pattern will fade in
and fade out slowly with the sounds
if the Light Control Button has not
been pressed.
3. Lullaby Button
Press the Lullaby Button to hear
three soothing songs followed by
soft melodies. Press the Lullaby
Button again to hear the next song or
melody. The light pattern will fade in
and fade out slowly with the sounds
if the Light Control Button has not
been pressed.
