VTI Instruments AMETEK EX1044A User manual

EX1000A/EX1000A-TC
48-C
HANNEL
P
RECISION
V
OLTAGE
M
EASUREMENT
I
NSTRUMENT
EX1016A
32-C
HANNEL
P
RECISION
V
OLTAGE
M
EASUREMENT
,
16-C
HANNEL
P
RECISION
T
HERMOCOUPLE
I
NSTRUMENT
EX1032A
16-C
HANNEL
P
RECISION
V
OLTAGE
M
EASUREMENT
,
32-C
HANNEL
P
RECISION
T
HERMOCOUPLE
I
NSTRUMENT
EX1048A
48-C
HANNEL
P
RECISION
T
HERMOCOUPLE
I
NSTRUMENT
EX10SC
16-C
HANNEL
S
IGNAL
C
ONDITIONING
E
XPANSION
C
HASSIS
EX1000A-51C
51-C
HANNEL
P
RECISION
V
OLTAGE
M
EASUREMENT
RX1032
32-C
HANNEL
P
RECISION RUGGED
T
HERMOCOUPLE
I
NSTRUMENT
EX1044A
2-C
HANNEL
P
RECISION
V
OLTAGE
I
SOLATED
M
EASUREMENT
2-
CHANNEL
P
RECISION
C
URRENT
I
SOLATED
M
EASUREMENT
44-C
HANNEL
P
RECISION
T
HERMOCOUPLE
I
NSTRUMENT
EX1044
44-C
HANNEL
P
RECISION
T
HERMOCOUPLE
I
NSTRUMENT
,
W
/4-CH 5B MOD SLOT
U
SER
’
S
M
ANUAL
P/N: 82-0122-000
September 12, 2018
VTI Instruments Corp.
2031 Main Street Irvine,
CA 92614-6509, [phone]

VTI Instruments Corp.
2 EX10xxA Preface
T
ABLE OF
C
ONTENTS
I
NTRODUCTION
Certification .......................................................................................................................................................... 9
Warranty ............................................................................................................................................................... 9
Limitation of Warranty ......................................................................................................................................... 9
Restricted Rights Legend ...................................................................................................................................... 9
D
ECLARATION OF
C
ONFORMITY
............................................................................................................................. 10
D
ECLARATION OF
C
ONFORMITY
............................................................................................................................. 11
G
ENERAL
S
AFETY
I
NSTRUCTIONS
........................................................................................................................... 12
Terms and Symbols ............................................................................................................................................ 12
Warnings ............................................................................................................................................................. 12
S
UPPORT
R
ESOURCES
............................................................................................................................................. 14
S
ECTION
1 .................................................................................................................................................................. 15
I
NTRODUCTION
....................................................................................................................................................... 15
Overview ............................................................................................................................................................ 15
Features ............................................................................................................................................................... 16
Combined Thermocouple and Analog Inputs ................................................................................................ 16
End-to-end Self-calibration ........................................................................................................................... 16
Scalable for Synchronized High-Speed, High-Channel Count ...................................................................... 16
Open Thermocouple Detection (OTD) .......................................................................................................... 16
Cold Junction Compensation (CJC) .............................................................................................................. 17
Simplified Installation, Setup and Control .................................................................................................... 17
Channel Independence .................................................................................................................................. 17
Measurement Range ...................................................................................................................................... 17
Hardware Filter ............................................................................................................................................. 18
Input Connectors ........................................................................................................................................... 18
Sampling Rate ............................................................................................................................................... 18
Digital I/O and Limits ................................................................................................................................... 18
LXI Trigger Bus ............................................................................................................................................ 19
Triggering ...................................................................................................................................................... 19
EX10xxA Specifications .................................................................................................................................... 19
EX10xxA Dimensional Diagram ........................................................................................................................ 24
RX1032 Diagram ................................................................................................................................................ 26
EX1044A/EX1044 Diagram ............................................................................................................................... 28
Explanation of Specifications ............................................................................................................................. 30
Maximizing Measurement Performance ............................................................................................................. 31
Utilize self-calibration ................................................................................................................................... 31
Dynamic Calibration in RX1032 ................................................................................................................... 31
Utilize self-test .............................................................................................................................................. 31
Allow for cold junction thermal stabilization ................................................................................................ 31
Select the proper hardware filter ................................................................................................................... 33
Choose an appropriate sampling rate ............................................................................................................ 33
Select the proper location .............................................................................................................................. 33
Use the correct wiring ................................................................................................................................... 33
S
ECTION
2 .................................................................................................................................................................. 35
P
REPARATION FOR
U
SE
........................................................................................................................................... 35
Unpacking EX10xxA, EX1000A-51C ............................................................................................................... 35
Unpacking RX10xx ............................................................................................................................................ 35
Unpacking EX1044A/EX1044 ........................................................................................................................... 35
Installation Location ........................................................................................................................................... 36
Installation Options ............................................................................................................................................. 36
Rackmount Installation Option of EX10xxA ................................................................................................ 36

www.vtiinstruments.com
EX10xxA Preface 3
Rack Ear Installation Option ......................................................................................................................... 38
Tabletop Installation Option .......................................................................................................................... 39
Installation Option of RX10xx ...................................................................................................................... 40
Software Installation ........................................................................................................................................... 43
Network Configuration ....................................................................................................................................... 45
Reset button for EX10xxA/EX10xxA-51C ................................................................................................... 45
Network Troubleshooting ................................................................................................................................... 46
Restore the EX10xxA’s Default Network Settings ....................................................................................... 46
Determine PCs Network Settings .................................................................................................................. 46
Set the EX10xxA to Auto IP ......................................................................................................................... 47
Set the EX10xxA to Static IP ........................................................................................................................ 48
Restore the Host PCs Network Settings ........................................................................................................ 48
Using Multiple Network Cards ..................................................................................................................... 49
Time Configuration ............................................................................................................................................ 51
Input Connections / Wiring ................................................................................................................................ 51
Thermocouple Connections ........................................................................................................................... 51
Voltage Connections ..................................................................................................................................... 52
RX10xx Connections .................................................................................................................................... 54
S
ECTION
3 .................................................................................................................................................................. 57
B
ASIC
O
PERATION
.................................................................................................................................................. 57
Introduction ........................................................................................................................................................ 57
Engineering Unit (EU) Conversion .................................................................................................................... 57
Linear Correction .......................................................................................................................................... 58
Voltage Measurement Ranges ............................................................................................................................ 58
Hardware Filter ................................................................................................................................................... 58
Measurement Range / Input Protection............................................................................................................... 58
Cold Junction Compensation (CJC) ................................................................................................................... 59
Temperature Units .............................................................................................................................................. 60
Sampling Rate / Noise Performance ................................................................................................................... 60
Scan List Configuration ...................................................................................................................................... 61
Scan List Timing ................................................................................................................................................ 61
Self-calibration ................................................................................................................................................... 62
Dynamic Calibration in RX1032 ........................................................................................................................ 63
Open Transducer Detection / Limits ................................................................................................................... 63
Digital I/O and DIO Limit Events ...................................................................................................................... 63
LXI Trigger Bus ................................................................................................................................................. 65
Locking ............................................................................................................................................................... 67
Triggering ........................................................................................................................................................... 67
Data Format ........................................................................................................................................................ 67
Acquiring Data ................................................................................................................................................... 67
Retrieving Data ................................................................................................................................................... 68
User-defined Conversions .................................................................................................................................. 69
S
ECTION
4 .................................................................................................................................................................. 70
TRIGGERING ....................................................................................................................................................... 70
Overview ............................................................................................................................................................ 70
Events ................................................................................................................................................................. 71
Maximizing Measurement Performance ............................................................................................................. 72
Maximum Trigger Rate ...................................................................................................................................... 73
S
ECTION
5 .................................................................................................................................................................. 75
W
EB
P
AGE
O
PERATION
........................................................................................................................................... 75
Introduction ........................................................................................................................................................ 75
Common Issues................................................................................................................................................... 76
Multiple Network Ports ................................................................................................................................. 77
Firewall ......................................................................................................................................................... 77
General Web Page Operation ............................................................................................................................. 77
Trigger Menu ...................................................................................................................................................... 79

VTI Instruments Corp.
4 EX10xxA Preface
Configuration ................................................................................................................................................ 79
Initialize ......................................................................................................................................................... 80
Abort ............................................................................................................................................................. 80
Software Arm ................................................................................................................................................ 80
Software Trigger ........................................................................................................................................... 80
LAN Events Menu .............................................................................................................................................. 80
Configuration ................................................................................................................................................ 80
Event Log ...................................................................................................................................................... 81
Status ............................................................................................................................................................. 82
Scan List Menu ................................................................................................................................................... 82
Configuration ................................................................................................................................................ 82
Filters............................................................................................................................................................. 83
Ranges ........................................................................................................................................................... 83
Data Menu .......................................................................................................................................................... 83
Get FIFO Count ............................................................................................................................................. 83
Retrieve Data ................................................................................................................................................. 83
Continuous Polling ........................................................................................................................................ 83
FIFO Configuration ....................................................................................................................................... 83
IO Menu .............................................................................................................................................................. 84
Digital IO ...................................................................................................................................................... 84
Trigger Bus .................................................................................................................................................... 84
Limits Menu ....................................................................................................................................................... 85
Limits ............................................................................................................................................................ 85
DIO Limit Events .......................................................................................................................................... 85
Device Menu....................................................................................................................................................... 87
Self-calibration .............................................................................................................................................. 87
Dynamic Calibration in RX1032 ................................................................................................................... 88
Get Calibration Files ..................................................................................................................................... 88
Network Configuration.................................................................................................................................. 89
Device Identify .............................................................................................................................................. 90
Time Configuration ....................................................................................................................................... 90
LXI Synchronization ..................................................................................................................................... 92
Reset Device .................................................................................................................................................. 93
Hard Reboot .................................................................................................................................................. 93
Upgrade Firmware ......................................................................................................................................... 93
Locking Menu..................................................................................................................................................... 94
Lock............................................................................................................................................................... 94
Unlock ........................................................................................................................................................... 94
Break Lock .................................................................................................................................................... 94
Advanced Menu .................................................................................................................................................. 94
User Conversions .......................................................................................................................................... 94
User CJC Temp ............................................................................................................................................. 94
Configuration Examples ..................................................................................................................................... 95
Example #1 .................................................................................................................................................... 95
Example #2 .................................................................................................................................................... 96
S
ECTION
6 .................................................................................................................................................................. 97
P
ROGRAMMING
....................................................................................................................................................... 97
Programming Sequence ...................................................................................................................................... 97
Default Settings .................................................................................................................................................. 98
EX10xxA Backward Compatibility .................................................................................................................... 99
General Commands / Queries ............................................................................................................................. 99
Initializing the device .................................................................................................................................... 99
Resetting the device .................................................................................................................................... 100
Performing Self-Calibration ........................................................................................................................ 100
Dynamic Calibration in RX1032 ................................................................................................................. 101
Acquiring a Lock ......................................................................................................................................... 101
Configure the Scan List .................................................................................................................................... 102

www.vtiinstruments.com
EX10xxA Preface 5
Configure the EU Conversions ......................................................................................................................... 102
Configure the Range ......................................................................................................................................... 103
Configure the Advanced Conversion Options .................................................................................................. 103
Employing an external cold junction ........................................................................................................... 103
Employing custom thermocouple conversions ............................................................................................ 103
Configure the Voltage Measurement Channels ................................................................................................ 104
Configure the Filter Frequencies ...................................................................................................................... 104
Configure the FIFO .......................................................................................................................................... 105
Configure the Limit System .............................................................................................................................. 105
Configure the Digital I/O System ..................................................................................................................... 106
Configure DIO Limit Events ....................................................................................................................... 108
Configure the Trigger Model ............................................................................................................................ 109
Configure the ARM event system ............................................................................................................... 109
Configure the TRIG event system ............................................................................................................... 111
Configure general trigger model parameters ............................................................................................... 112
Resetting the trigger model configuration ................................................................................................... 113
Initiate the Trigger Model ................................................................................................................................. 113
Configure the LXI Trigger Bus ........................................................................................................................ 113
Trigger Event .................................................................................................................................................... 115
Retrieving Data (Read FIFO and Streaming Data) ........................................................................................... 115
Read FIFO ................................................................................................................................................... 115
Asynchronous Streaming Data .................................................................................................................... 118
Example Program ............................................................................................................................................. 124
S
ECTION
7 ................................................................................................................................................................ 127
F
UNCTION
C
ALLS
................................................................................................................................................. 127
Introduction ...................................................................................................................................................... 127
Alphabetical Function Set ................................................................................................................................. 127
Sample Function Definition .............................................................................................................................. 131
Function_Name ........................................................................................................................................... 131
vtex10xxA_abort ......................................................................................................................................... 133
vtex10xxA_append_scanlist ........................................................................................................................ 134
vtex10xxA_break_lock ............................................................................................................................... 135
vtex10xxA_check_lock ............................................................................................................................... 136
vtex10xxA_clear_lan_eventlog ................................................................................................................... 137
vtex10xxA_close ......................................................................................................................................... 138
vtex10xxA_disable_streaming_data ............................................................................................................ 139
vtex10xxA_enable_streaming_data ............................................................................................................ 140
vtex10xxA_enable_streaming_dataEx ........................................................................................................ 142
vtex10xxA_error_message .......................................................................................................................... 144
vtex10xxA_error_query .............................................................................................................................. 145
vtex10xxA_get_accum_limit_status ........................................................................................................... 146
vtex10xxA_get_alarm ................................................................................................................................. 147
vtex10xxA_get_alarm_enable ..................................................................................................................... 148
vtex10xxA_get_arm_count ......................................................................................................................... 149
vtex10xxA_get_arm_delay ......................................................................................................................... 150
vtex10xxA_get_arm_infinite ....................................................................................................................... 151
vtex10xxA_get_arm_lan_eventID .............................................................................................................. 152
vtex10xxA_get_arm_lan_filter.................................................................................................................... 153
vtex10xxA_get_arm_source ........................................................................................................................ 154
vtex10xxA_get_arm_sourceEx ................................................................................................................... 155
vtex10xxA_get_calibration_file .................................................................................................................. 156
vtex10xxA_get_calibration_running ........................................................................................................... 157
vtex10xxA_get_channel_conversion .......................................................................................................... 158
vtex10xxA_get_channel_count ................................................................................................................... 159
vtex10xxA_get_channel_range ................................................................................................................... 160
vtex10xxA_get_channel_type ..................................................................................................................... 161
vtex10xxA_get_dio_input ........................................................................................................................... 162

VTI Instruments Corp.
6 EX10xxA Preface
vtex10xxA_get_dio_limit_event ................................................................................................................. 163
vtex10xxA_get_dio_limit_event_invert ...................................................................................................... 164
vtex10xxA_get_dio_limit_event_latch ....................................................................................................... 165
vtex10xxA_get_dio_output ......................................................................................................................... 166
vtex10xxA_get_dio_output_enable ............................................................................................................. 167
vtex10xxA_get_fifo_config ........................................................................................................................ 168
vtex10xxA_get_fifo_count .......................................................................................................................... 169
vtex10xxA_get_filt_freq ............................................................................................................................. 170
vtex10xxA_get_init_cont ............................................................................................................................ 171
vtex10xxA_get_lan_event_domain ............................................................................................................. 172
vtex10xxA_get_lan_event_source_state ..................................................................................................... 173
vtex10xxA_get_lan_eventlog_count ........................................................................................................... 174
vtex10xxA_get_lan_eventlog_enabled ....................................................................................................... 175
vtex10xxA_get_lan_eventlog_overflowmode ............................................................................................. 176
vtex10xxA_get_limit_set0 .......................................................................................................................... 177
vtex10xxA_get_limit_set0_manual ............................................................................................................. 178
vtex10xxA_get_limit_set1 .......................................................................................................................... 179
vtex10xxA_get_linear_correction ............................................................................................................... 180
vtex10xxA_get_model ................................................................................................................................ 181
vtex10xxA_get_OTD_enable ...................................................................................................................... 182
vtex10xxA_get_ptp_info ............................................................................................................................. 183
vtex10xxA_get_scanlist .............................................................................................................................. 184
vtex10xxA_get_serialNumber ..................................................................................................................... 185
vtex10xxA_get_shield_gnd_config ............................................................................................................. 186
vtex10xxA_get_system_time ...................................................................................................................... 187
vtex10xxA_get_trig_lan_eventID ............................................................................................................... 188
vtex10xxA_get_trig_lan_filter .................................................................................................................... 189
vtex10xxA_get_trigger_count ..................................................................................................................... 190
vtex10xxA_get_trigger_delay ..................................................................................................................... 191
vtex10xxA_get_trigger_infinite .................................................................................................................. 192
vtex10xxA_get_trigger_source ................................................................................................................... 193
vtex10xxA_get_trigger_sourceEx ............................................................................................................... 194
vtex10xxA_get_trigger_timer ..................................................................................................................... 195
vtex10xxA_get_user_cjc_enable ................................................................................................................. 196
vtex10xxA_get_user_cjc_temp ................................................................................................................... 197
vtex10xxA_get_user_conversion ................................................................................................................ 198
vtex10xxA_get_vtb_input ........................................................................................................................... 199
vtex10xxA_get_vtb_output ......................................................................................................................... 200
vtex10xxA_get_vtb_output_enable ............................................................................................................. 201
vtex10xxA_get_vtb_wiredor ....................................................................................................................... 202
vtex10xxA_get_vtb_wiredor_bias .............................................................................................................. 203
vtex10xxA_init ............................................................................................................................................ 204
vtex10xxA_init_imm .................................................................................................................................. 205
vtex10xxA_lock .......................................................................................................................................... 206
vtex10xxA_pop_logged_LAN_event .......................................................................................................... 207
vtex10xxA_read_fifo................................................................................................................................... 208
vtex10xxA_read_fifoEx .............................................................................................................................. 209
vtex10xxA_reset .......................................................................................................................................... 210
vtex10xxA_reset_fifo .................................................................................................................................. 211
vtex10xxA_reset_trigger_arm ..................................................................................................................... 212
vtex10xxA_revision_query ......................................................................................................................... 213
vtex10xxA_self_cal_clear ........................................................................................................................... 214
vtex10xxA_self_cal_clear_stored ............................................................................................................... 215
vtex10xxA_self_cal_get_status ................................................................................................................... 216
vtex10xxA_self_cal_init ............................................................................................................................. 217
vtex10xxA_self_cal_is_stored .................................................................................................................... 218
vtex10xxA_self_cal_load ............................................................................................................................ 219

www.vtiinstruments.com
EX10xxA Preface 7
vtex10xxA_self_cal_store ........................................................................................................................... 220
vtex10xxA_self_test .................................................................................................................................... 221
vtex10xxA_self_test_init............................................................................................................................. 222
vtex10xxA_set_alarm .................................................................................................................................. 223
vtex10xxA_set_alarm_enable ..................................................................................................................... 224
vtex10xxA_self_test_init............................................................................................................................. 225
vtex10xxA_set_arm_count .......................................................................................................................... 226
vtex10xxA_set_arm_delay .......................................................................................................................... 227
vtex10xxA_set_arm_infinite ....................................................................................................................... 228
vtex10xxA_set_arm_lan_eventID ............................................................................................................... 229
vtex10xxA_set_arm_lan_filter .................................................................................................................... 230
vtex10xxA_set_arm_source ........................................................................................................................ 231
vtex10xxA_set_arm_sourceEx .................................................................................................................... 232
vtex10xxA_set_channel_conversion ........................................................................................................... 233
vtex10xxA_set_channel_range.................................................................................................................... 234
vtex10xxA_set_communication_timeout .................................................................................................... 235
vtex10xxA_set_dio_limit_event.................................................................................................................. 236
vtex10xxA_set_dio_limit_event_invert ...................................................................................................... 237
vtex10xxA_set_dio_limit_event_latch ........................................................................................................ 238
vtex10xxA_set_dio_output ......................................................................................................................... 239
vtex10xxA_set_dio_output_enable ............................................................................................................. 240
vtex10xxA_set_dio_pulse ........................................................................................................................... 241
vtex10xxA_set_fifo_config ......................................................................................................................... 242
vtex10xxA_set_filt_freq .............................................................................................................................. 243
vtex10xxA_set_init_cont............................................................................................................................. 244
vtex10xxA_set_lan_event_domain ............................................................................................................. 245
vtex10xxA_set_lan_eventlog_enabled ........................................................................................................ 246
vtex10xxA_set_lan_eventlog_overflowmode ............................................................................................. 247
vtex10xxA_set_limit_set0 ........................................................................................................................... 248
vtex10xxA_set_limit_set0_manual ............................................................................................................. 249
vtex10xxA_set_limit_set1 ........................................................................................................................... 250
vtex10xxA_set_linear_correction ................................................................................................................ 251
vtex10xxA_set_OTD_enable ...................................................................................................................... 252
vtex10xxA_set_scanlist ............................................................................................................................... 253
vtex10xxA_set_trig_lan_eventID ................................................................................................................ 254
vtex10xxA_set_trig_lan_filter ..................................................................................................................... 255
vtex10xxA_set_trig_source_timer .............................................................................................................. 256
vtex10xxA_set_trigger_count ..................................................................................................................... 257
vtex10xxA_set_trigger_delay ..................................................................................................................... 258
vtex10xxA_set_trigger_infinite ................................................................................................................... 259
vtex10xxA_set_trigger_source .................................................................................................................... 260
vtex10xxA_set_trigger_sourceEx ............................................................................................................... 261
vtex10xxA_set_trigger_timer ...................................................................................................................... 262
vtex10xxA_set_user_cjc_enable ................................................................................................................. 263
vtex10xxA_set_user_cjc_temp ................................................................................................................... 264
vtex10xxA_set_user_conversion ................................................................................................................. 265
vtex10xxA_set_vtb_output ......................................................................................................................... 266
vtex10xxA_set_vtb_output_enable ............................................................................................................. 267
vtex10xxA_set_vtb_pulse ........................................................................................................................... 268
vtex10xxA_set_vtb_wiredor ....................................................................................................................... 269
vtex10xxA_set_vtb_wiredor_bias ............................................................................................................... 270
vtex10xxA_soft_arm ................................................................................................................................... 271
vtex10xxA_soft_trigger............................................................................................................................... 272
vtex10xxA_unlock ...................................................................................................................................... 273
vtex10xxA_get_shield_gnd_config ............................................................................................................. 274
vtex10xxA_set_communication_timeout .................................................................................................... 275
vtex10xxA _get_utc_offset ......................................................................................................................... 276

VTI Instruments Corp.
8 EX10xxA Preface
vtex10xxA_self_cal_init_ex ........................................................................................................................ 277
Error Messages ................................................................................................................................................. 278
S
ECTION
8 ................................................................................................................................................................ 281
T
HEORY OF
O
PERATION
........................................................................................................................................ 281
Introduction ...................................................................................................................................................... 281
Voltage / Thermocouple Input Options ............................................................................................................ 281
Thermocouple Connector Inputs ................................................................................................................. 281
D-sub Connector Inputs............................................................................................................................... 282
Signal Conditioning Circuitry ........................................................................................................................... 282
Cold Junction Compensation ............................................................................................................................ 283
Calibration ........................................................................................................................................................ 283
Thermocouple Calculations .............................................................................................................................. 283
S
ECTION
9 ................................................................................................................................................................ 285
EX10SC S
IGNAL
C
ONDITIONING
.......................................................................................................................... 285
Overview .......................................................................................................................................................... 285
Connecting Power to the EX10SC.................................................................................................................... 285
Connecting to an EX10xxA to the EX10SC ..................................................................................................... 286
Connector Pin/Signal Assignment ............................................................................................................... 286
Connecting to the EX10SC to the DUT ............................................................................................................ 287
Changing Signal Conditioning Modules ........................................................................................................... 288
Jumper Settings ........................................................................................................................................... 288
Shunt Resistors ............................................................................................................................................ 289
Software Interface ............................................................................................................................................. 290
EX10SC General Specifications ....................................................................................................................... 294
EX10SC Module Specifications ....................................................................................................................... 295
S
ECTION
10 .............................................................................................................................................................. 305
EX10
XX
A/EX10
XX
A-51C/RX10
XX
/EX1044A/EX1044C
ALIBRATION
.............................................................. 305
Introduction ...................................................................................................................................................... 305
Required Resources .......................................................................................................................................... 305
Equipment Needed ...................................................................................................................................... 305
Software Needed ......................................................................................................................................... 305
Setting Up the Instruments ............................................................................................................................... 306
Connecting to the EX10xxA/RX10xx/EX1044A/EX1044 ............................................................................... 307
Login into SFP .................................................................................................................................................. 308
Time Configuration .......................................................................................................................................... 308
Performing Calibration ..................................................................................................................................... 309
Monitoring Calibration Progress ...................................................................................................................... 310
S
ECTION
11 .............................................................................................................................................................. 311
O
NBOARD
M
EMORY
............................................................................................................................................. 311
Onboard Memory and Clearing Procedure ....................................................................................................... 311
S
ECTION
12 .............................................................................................................................................................. 312
Q
UICK
R
EFERENCE GUIDE FOR
RX1032 ............................................................................................................... 312
S
ECTION
13 .............................................................................................................................................................. 317
Q
UICK
R
EFERENCE GUIDE FOR
EX1044A/EX1044 .............................................................................................. 317
I
NDEX
....................................................................................................................................................................... 320

www.vtiinstruments.com
EX10xxA Preface 9
C
ERTIFICATION
VTI Instruments Corp. (VTI) certifies that this product met its published specifications at the time of shipment from
the factory. VTI further certifies that its calibration measurements are traceable to the United States National Institute
of Standards and Technology (formerly National Bureau of Standards), to the extent allowed by that organization’s
calibration facility, and to the calibration facilities of other International Standards Organization members.
W
ARRANTY
The product referred to herein is warranted against defects in material and workmanship for a period of one year from
the receipt date of the product at customer’s facility. The sole and exclusive remedy for breach of any warranty
concerning these goods shall be repair or replacement of defective parts, or a refund of the purchase price, to be
determined at the option of VTI.
For warranty service or repair, this product must be returned to a VTI Instruments authorized service center. The
product shall be shipped prepaid to VTI and VTI shall prepay all returns of the product to the buyer. However, the
buyer shall pay all shipping charges, duties, and taxes for products returned to VTI from another country.
VTI warrants that its software and firmware designated by VTI for use with a product will execute its programming
when properly installed on that product. VTI does not however warrant that the operation of the product, or software,
or firmware will be uninterrupted or error free.
L
IMITATION OF
W
ARRANTY
The warranty shall not apply to defects resulting from improper or inadequate maintenance by the buyer, buyer-
supplied products or interfacing, unauthorized modification or misuse, operation outside the environmental
specifications for the product, or improper site preparation or maintenance.
VTI Instruments Corp. shall not be liable for injury to property other than the goods themselves. Other than the limited
warranty stated above, VTI Instruments Corp. makes no other warranties, express or implied, with respect to the
quality of product beyond the description of the goods on the face of the contract. VTI specifically disclaims the
implied warranties of merchantability and fitness for a particular purpose.
R
ESTRICTED
R
IGHTS
L
EGEND
Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subdivision (b)(3)(ii) of the
Rights in Technical Data and Computer Software clause in DFARS 252.227-7013.
VTI Instruments Corp.
2031 Main Street
Irvine, CA 92614-6509 U.S.A.

VTI Instruments Corp.
10 EX10xxA Preface
D
E C L A R A T I O N O F
C
O N F O R M I T Y
Declaration of Conformity According to EN ISO/IEC 17050-1:2004
M
ANUFACTURER
’
S
N
AME
VTI Instruments Corp.
M
ANUFACTURER
’
S
A
DDRESS
2031 Main Street
Irvine, California 92614-6509
P
RODUCT
N
AME
Precision Voltage/Temperature Measurement Instrument
M
ODEL
N
UMBER
(
S
) EX1000A, EX1000A-TC, EX1016A, EX1032A, EX1048A,
EX10SC
P
RODUCT
O
PTIONS
All
P
RODUCT
C
ONFIGURATIONS
All
VTI Instruments declares that the aforementioned product conforms to the requirements of the Low Voltage
directive (European Council directive 2014/35/EU, dated 22 July 1993) and the Electromagnetic
Compatibility directive (European Council directive 2014/30/EU; generally referred to as the EMC
directive). In substantiation, the products were tested and/or evaluated to the standards shown below:
S
AFETY
EN61010-1:2010
EMC EN61326-1:2013
EN55011 Class A Group 1
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
EN61000-4-8
EN61000-4-11
CISPR 22
June 2016
Steve Mauga, QA Manager

www.vtiinstruments.com
EX10xxA Introduction 11
D
E C L A R A T I O N O F
C
O N F O R M I T Y
Declaration of Conformity According to EN ISO/IEC 17050-1:2004
M
ANUFACTURER
’
S
N
AME
VTI Instruments Corp.
M
ANUFACTURER
’
S
A
DDRESS
2031 Main Street
Irvine, California 92614-6509
P
RODUCT
N
AME
Rugged Precision Temperature & Voltage Measurement Instrument
M
ODEL
N
UMBER
(
S
) RX1032
P
RODUCT
O
PTIONS
All
P
RODUCT
C
ONFIGURATIONS
All
VTI Instruments declares that the aforementioned product conforms to the requirements of the Low Voltage
directive (European Council directive 2014/35/EU, dated 22 July 1993) and the Electromagnetic
Compatibility directive (European Council directive 2014/30/EU; generally referred to as the EMC
directive). In substantiation, the products were tested and/or evaluated to the standards shown below:
EMC EN61326-1:2013
EN55011 Class A Group 1
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
EN61000-4-8
EN61000-4-11
CISPR 11
S
HOCK AND
V
IBRATION
MIL-PRF-28800F
RH: Class 2 (3.8.2.3 & 4.5.5.1)
Vibration: Class 2 (3.8.4.1 & 4.5.5.3.1)
Shock (Functional) Class 1 (3.8.5.1 & 4.5.5.4.1)
I
NGRESS
P
ROTECTION
(IP 65) EN60529:1992+A2:2013
October 2016
Steve Mauga, QA Manager

VTI Instruments Corp.
12 EX10xxA Introduction
G
ENERAL
S
AFETY
I
NSTRUCTIONS
Review the following safety precautions to avoid bodily injury and/or damage to the product. These
precautions must be observed during all phases of operation or service of this product. Failure to
comply with these precautions, or with specific warnings elsewhere in this manual, violates safety
standards of design, manufacture, and intended use of the product. Note that this product contains
no user serviceable parts or spare parts.
Service should only be performed by qualified personnel. Disconnect all power before servicing.
T
ERMS AND
S
YMBOLS
These terms may appear in this manual:
WARNING
Indicates that a procedure or condition may cause bodily injury or death.
CAUTION
Indicates that a procedure or condition could possibly cause damage to equipment
or loss of data.
These symbols may appear on the product:
ATTENTION - Important safety instructions
Frame or chassis ground
Indicates that the product was manufactured after August 13, 2005. This mark is
placed in accordance with EN 50419, Marking of electrical and electronic
equipment in accordance with Article 11(2) of Directive 2002/96/EC (WEEE).
End-of-life product can be returned to VTI by obtaining an RMA number. Fees
for take-back and recycling will apply if not prohibited by national law.
W
ARNINGS
Follow these precautions to avoid injury or damage to the product:
Use Proper Power Cord
The power cable provided with this instrument meets the required
regulatory and statutory safety standards as indicated by this
product’s declaration of conformity. VTI recommends that the power
cord provided be used with the instrument that it is provided with. If
a different power cord is must to be used, however, it is the
responsibility of the user to select a power cord that meets any and
all regulatory and statutory requirements for their industry and
country.
Do not use the power cord supplied with this instrument with any
other equipment.
Use Proper Power Source
To avoid electrical overload, electric shock, or fire hazard, do not use
a power source that applies other than the specified voltage.
The mains outlet that is used to power the equipment must be within
3 meters of the device and shall be easily accessible.

www.vtiinstruments.com
EX10xxA Introduction 13
W
ARNINGS
(C
ONT
.)
Avoid Electric Shock
To avoid electric shock or fire hazard, do not operate this product
with the covers removed. Do not connect or disconnect any cable,
probes, test leads, etc. while they are connected to a voltage source.
Remove all power and unplug unit before performing any service.
Service should only be performed by qualified personnel.
Ground the Product
This product is grounded through the grounding conductor of the
power cord. To avoid electric shock, the grounding conductor must
be connected to earth ground.
Operating Conditions
To avoid injury, electric shock or fire hazard:
- Do not operate in wet or damp conditions.
- Do not operate in an explosive atmosphere.
- Operate or store only in specified temperature range.
- Provide proper clearance for product ventilation to prevent
overheating.
- DO NOT operate if any damage to this product is suspected.
Product should be inspected or serviced only by qualified
personnel.
Improper Use
The operator of this instrument is advised that if the equipment is
used in a manner not specified in this manual, the protection
provided by the equipment may be impaired.
Conformity is checked by inspection.

VTI Instruments Corp.
14 EX10xxA Introduction
S
UPPORT
R
ESOURCES
Support resources for this product are available on the Internet and at VTI Instruments customer
support centers.
VTI Instruments Corp.
World Headquarters
VTI Instruments Corp.
2031 Main Street
Irvine, CA 92614-6509
Phone: [phone]
Fax: [phone]
VTI Instruments
Cleveland Instrument Division
5425 Warner Road
Suite 13
Valley View, OH 44125
Phone: [phone]
Fax: [phone]
VTI Instruments
Lake Stevens Instrument Division
3216 Wetmore Avenue, Suite 1
Everett, WA 98201
Phone: [phone]
Fax: [phone]
AMETEK Instruments India Pvt. Ltd.
VTI - Bangalore Instrument Division
Divyasree N R Enclave, Block A,
4th Floor, Site No 1, EPIP Industrial Area,
Whitefield, Bengaluru 560066, India
Phone: [phone]
Fax: [phone]
Asia Support
Phone: [phone]
Technical Support
Phone: [phone]
Fax: [phone]
E-mail: [email protected]m
Visit http://www.vtiinstruments.com for worldwide support sites and service plan information.

www.vtiinstruments.com
EX10xxA Introduction 15
S
ECTION
1
I
NTRODUCTION
O
VERVIEW
In general, EX10xxA family of products provides a total of 48-channels, with an exception of
RX10xx products which has 32-channels, of high-performance thermocouple and/or voltage
measurement in a single instrument. This family includes the EX1000A, EX1000A-TC, EX1016A,
EX1032A, EX1048A, EX1000A-51C and RX1032. The last two digits of the model name indicate
the number of thermocouple channels/voltage channels available on the model. For example, the
EX1016A has sixteen thermocouple channels and thirty-two voltage channels. Its combination of
measurement performance and integrity, configuration flexibility, package density, and network
connectivity make it the most powerful, yet easy-to-use, instrument of its kind. The EX10xxA is a
complete, self-contained temperature measurement system that communicates over Ethernet. Unlike
other data acquisition offerings in its class, the EX10xxA offers a tightly integrated solution that
frees the user from the complexity of marrying terminal blocks, signal conditioning cards, digitizer,
power supply, and chassis together.
EX1000A-51C is the enhanced version of the EX10xxA family of products, has 51 Voltage
Channels and has additional features such as additional sensors to measure internal box temperature
and additional API’s provided to read UTC offset & warmup time.
RX10xx is the rugged version of the EX10xxA family of products, has 32 Channels and most
importantly provides the user with the flexibility to place this instrument even in extreme conditions
and directly in the test cells because of its rugged build.
EX1044A is the customized version of the EX10xxA family of products, has 44 TC Channels and
2 channels for voltage and 2 channels for current whereas EX1044 has only 44 TC Channels with
5B module slots provision (user can select any 5B modules). This provides thermal labs customers
the ability to place instrumentation directly in the thermal test labs. The EX10xx product has already
demonstrated some of the highest accuracy in the market for Thermocouple measurements and the
EX1044A/EX1044 will continue to provide as good or better accuracy for gas turbine test cell users
trying to improve engine efficiency by better understanding temperature effects on the DUT.
The EX10xxA also provides a level of measurement integrity and channel independence that far
exceeds the typical data acquisition system. Absent are caveats about scanning speed, channel order,
and overload effects. In the EX10xxA, channels have no influence on each other, regardless of
scanning speed or channel state. Excellent common mode rejection performance provides immunity
from not only power line interference, but also high frequency noise. Moreover, it aids in
maintaining overall system integrity by offering a high-performance open transducer detection
system.
The EX10xxA provides a high level of configuration flexibility as well. Each channel can be
configured independently with regards to measurement function, hardware filter setting, and limit
values. In addition to measuring all standard thermocouples, the EX10xxA can be programmed with
user-defined thermocouple polynomial equations or be used as a low-noise voltmeter. Scanning
speed is programmable up to a maximum of 1 kSa/s, independent of the number of channels being
scanned. This combination of filtering and scanning speed provides the EX10xxA with the low noise

VTI Instruments Corp.
16 EX10xxA Introduction
performance required for sensitive applications as well as the speed necessary to measure fast, fine-
gauge thermocouples.
For highest accuracy and stability, the EX10xxA provides an embedded isothermal input section
that is monitored by up to twelve precision thermistors (depending on model), one for every four
thermocouple channels. Moreover, it features an internal calibration source that can be used to self-
calibrate the unit upon command. This extends the unit’s high accuracy over a wide ambient
temperature range. Thermocouple accuracy is detailed in Table 1-2.
The EX10xxA is as easy-to-use as it is powerful. An integrated web page provides a convenient
way to instantly verify communications and instrument functionality, while industry standard VXI
plug & play and IVI drivers provide a familiar application programming interface to reduce
integration and program development time.
F
EATURES
Combined Thermocouple and Analog Inputs
Easily combine thermocouple and analog signals on these versatile instruments with sampling rates
up to 1 kSa/s (kilo samples per second) per channel. Each input incorporates an independent signal
conditioning path with software selectable filters for maximum flexibility. Complete channel
independence ensures data integrity regardless of sample speed or input overload conditions.
End-to-end Self-calibration
Complete end-to-end self-calibration is provided for each signal path on a programmable basis. A
highly accurate calibration source provides reference signals that are applied prior to analog filtering
and gain circuits to compensate for drift, aging, or temperature variations. Self-calibration is simple
and quick, and can be performed as often as desired.
Scalable for Synchronized High-Speed, High-Channel Count
With LXI™ Class A compliant features like a built-in Trigger Bus™ hardware trigger subsystem,
the EX10xxA supports easy integration and synchronization of multiple devices, including existing
VXI bus instrumentation.
Open Thermocouple Detection (OTD)
While the integration of the EX10xxA removes many of the reliability and connectivity problems
typically faced by system designers, they still must contend with the reliability of the sensor
connections. Fortunately, the EX10xxA aids a great deal in that regard as well. Each thermocouple
input channel generates a very small current (±7.5 nA/channel) which drives the input to an open-
circuit state if the transducer is disconnected. Implemented in this way, open transducer detection is
continuous and requires no discrete function call on the part of the user to be activated, offering
more protection than systems that only check on command, as a broken sensor can occur at any time
during testing, not just at installation. In a typical application, the OTD has no effect on the
measurement. However, many thermocouple simulators have a much higher impedance than a
thermocouple so an offset may be introduced into the reading when using a simulator. In general,
the OTD should only be active on channels that are being used with actual thermocouples.
The EX10xxA additionally offers a front panel OTD LED for each channel that illuminates upon
the recognition of a fault condition. This provides for quick and easy problem channel identification.
Moreover, to ensure that even intermittent problems are identified, the fault recognition is a latching
mechanism, retaining the information of the current acquisition sequence until a new acquisition is
initiated. Note that voltage channels do not include internal CJC thermistors, but that each voltage
D-sub includes connections for the connection of user-supplied thermistors.
Note: OTD functionality will not be applicable for EX1000A-51C. RX1032 doesn’t have option to
provide OTD LED indication in a fault condition due to its rugged design.

www.vtiinstruments.com
EX10xxA Introduction 17
Cold Junction Compensation (CJC)
For highest accuracy and stability, the EX1000A-TC, EX1016A, EX1032A, EX1048A, EX1044,
EX1044A and RX1032 provide embedded isothermal input sections that are monitored by precision
thermistors (based on Model#, the number of thermistors can vary), one for every four thermocouple
channels. (Note, the EX1000A may utilize external thermistors as described in the Voltage
Connections section). To ensure that the CJC information is current and time correlated with the
input channels, the CJC channels are measured with every scan, providing a maximum time
separation of less than 4 ms between the measurement of an input channel and its associated CJC
measurement. For those users that prefer to employ an external cold junction, the EX10xxA also
allows for the programming input of up to forty-eight unique external cold junction temperatures,
one for every input channel. Moreover, the use of internal and external CJC inputs can be mixed
throughout the unit on a per channel basis.
Simplified Installation, Setup and Control
Full LXI Class A compliance makes the EX10xxA of instruments ideal for distributed
measurements throughout a facility – reducing cabling and installation expense. Connect directly to
an Ethernet network using industry standard Ethernet cable and connections. Experience how
plug&play capability simplifies installation and setup.
An onboard, web-accessible user interface allows you to instantly verify communications and
instrument functionality, while IVI and VXI plug&play drivers provide a familiar application
programming interface to further reduce integration and program development time. For
comprehensive, programming-free data recording setup, management and viewing, use EX10xxA
instruments with one of VTI’s full-featured, turnkey software solutions: EXLab or VTICODA.
Channel Independence
Each of the EX10xxA’s 48 differential input channels is an independent signal conditioning path,
complete with amplification, programmable hardware filtering, and continuous open transducer
detection. This independence frees the user from the problem of channel-to-channel crosstalk that
is pervasive in most multi-channel data acquisition systems. In the EX10xxA, channels have no
influence on each other, regardless of scanning speed or channel state. Specifically, open or
significantly overloaded channels do not affect the measurement results of any other channels.
Measurement Range
The measurement range of the EX10xxA in terms of temperature is a function of its input voltage
range and the capabilities of the thermocouple sensors themselves. Specifically, the measurement
range of the EX10xxA for the standard thermocouple types is the following:
Type Min Temp Max Temp
J
-200 °C (-328 °F)
1200 °C (2192 °F)
K
-200 °C (-328 °F)
1372 °C (2502 °F)
T
-200 °C (-328 °F)
400 °C (752 °F)
E
-200 °C (-328 °F)
900 °C (1652 °F)
S
-50 °C (-58 °F)
1768 °C (3214 °F)
R
-50 °C (-58 °F)
1768 °C (3214 °F)
B
250 °C (482 °F)
1820 °C (3308 °F)
N
-200 °C (-328 °F)
1300 °C (2372 °F)
T
ABLE
1-1: EX10
XX
A M
EASUREMENT
R
ANGE
In terms of voltage, the thermocouple connectors may only accept an input voltage of ±67 mV when
performing temperature conversion. When in voltage mode, these connectors can accept either
±0.067 V or ±0.1 V inputs. The voltage connectors may use either ±0.01 V, ±0.067 V, ±0.1 V,

VTI Instruments Corp.
18 EX10xxA Introduction
±1.0 V, or ±10.0 V inputs for both EU temperature conversion or voltage measurements. When
temperature is selected, the instrument automatically switches the selected channel(s) to the ±67 mV
range. The EX1000A-TC is a special case where thermocouple inputs are used for voltage
measurement and may utilize all input ranges available to the voltage connectors. Table 1- provides
an overview of each models capabilities.
For maximum flexibility, each channel can be independently configured with regards to its
thermocouple conversion. Moreover, non-standard thermocouples are accommodated through the
input of user-defined thermocouple polynomial coefficients.
Hardware Filter
Each EX10xxA input channel can be individually configured with one of six low-pass hardware
filters. Five of these filters are 2-pole Bessel filters with frequencies of 4 Hz, 15 Hz, 40 Hz, 100 Hz
and 500 Hz. The sixth filter is a single-pole Butterworth filter with a frequency of 1 kHz, providing
a simple anti-alias filter when the 1 kSa/s range is used. These filters allow the EX10xxA to cover
a diverse range of applications, even within the same unit. Suitable for most applications, the 4 Hz
setting provides the lowest noise floor and exceptional common mode rejection. For higher speed
applications, the 1 kHz filter will pass the output from even the fastest fine-gauge thermocouples
with little distortion.
Input Connectors
The EX1016A, EX1032A, EX1048A, EX1044 and EX1044A employ uncompensated (Cu-Cu)
mini-thermocouple female jacks as an input connector. This connector provides a solid, reliable
connection that is also easily changeable. Since it is not thermocouple-type specific, different
thermocouple types can be mixed throughout the unit without hardware modification. The
EX1000A, EX1016A and EX1032A also employ a standard 50-pin D-sub connector for the voltage
input channels. All the RX10xx channels are individually routed via the screw terminals which is
placed just below the instrument top cover and the cable bunch is brought out through the cable
gland.
Sampling Rate
The EX10xxA can be configured for a sampling rate up to a maximum of 1 kSa/s, regardless of the
number of channels included in the scan list. When the requested sampling rate is significantly less
than 1 kSa/s, however, the EX10xxA automatically takes and averages multiple samples. This offers
improved noise performance, while maintaining the requested data output rate.
Digital I/O and Limits
The EX10xxA provides two unique sets of programmable limits that are used for open transducer
detection as well as general purpose input channel monitoring. These limits are programmable on a
per channel basis and are evaluated with each completed scan. The output of limit evaluations is
presented in three forms. The operation of the front panel LEDs is tied to the upper and lower limit
values of one limit set. The operation of the digital I/O port can be optionally linked to any
combination of the upper and lower limit values of either or both limit sets. Finally, the limit
condition information is accessible through the instrument driver.
The EX10xxA features an 8-channel digital I/O port on the rear panel of the instrument, except
RX10xx which has 2-channel digital I/O routed through the 13 pin circular connector (P1). This
port can be used as an arm/trigger source, for presentation of limit evaluation information, and as a
general purpose output device. As a general purpose output device, each DIO channel can be
independently programmed with regards to its output functionality and its static level to assume
when enabled as an output. For expanded and more automated operation, each DIO channel can be
independently linked to one or multiple limit conditions on one or more input channels.

www.vtiinstruments.com
EX10xxA Introduction 19
LXI Trigger Bus
The EX10xxA features an 8-channel LXI (LAN eXtensions for Instrumentation) trigger bus on the
rear panel of the instrument. This differential-pair LVDS (Low Voltage Differential Signal) bus
consists of two identical ports connected in parallel. The primary use of the trigger bus is the
transmission of high-speed signals for multiple-unit triggering and synchronization.
Note: RX1032, EX1044 and EX1044A doesn’t have LXI trigger bus.
Triggering
The EX10xxA supports a full function trigger model with a separate arm source and trigger source
event structure. Trigger and arm source events can be independently programmed from a variety of
sources including Immediate, Timer, Digital I/O, LAN events, the LXI Trigger Bus, and the LXI
alarm.
EX10
XX
A S
PECIFICATIONS
G
ENERAL
S
PECIFICATIONS
N
UMBER OF
C
HANNELS
EX10XXA
EX10XXA-51C
RX10XX
EX1044A
EX1044
48 differential inputs
51 differential inputs
32 differential inputs
44 differential inputs (TC inputs), 2 Voltage and 2 Current
44 differential inputs (TC inputs), 4ch 5B Module options
C
HANNEL
T
YPES
Thermocouple and voltage J, K, T, E, S, R, B, N (EX1000A-TC, EX1016A, EX1032A, EX1048A, RX1032, EX1044,
EX1044A)
mV (RX1032), V (EX1000A, EX1000A-TC, EX1016A, EX1032A, EX1000A-51C,
EX1044, EX1044A, RX1000)
mA, A (EX1044)
S
AMPLING
R
ATE
1000 Sa/s per channel maximum
T
EMPERATURE
R
ESOLUTION
0.1 °C
T
EMPERATURE
A
CCURACY
See Table 1-2 below
T
EMPERATURE
N
OISE
Peak-to-peak
0.08 °C typical (J, K, T, E)
P
ROGRAMMABLE
F
ILTERS
Bessel (2 pole)
Butterworth (1 pole)
4 Hz, 15 Hz, 40 Hz, 100 Hz, and 500 Hz (-3 dB cutoff frequency)
1000 Hz (-3 dB cutoff frequency)
V
OLTAGE
I
NPUT
R
ANGE
Voltage input channels
Thermocouple input channels
±0.01 V, ±0.067 V, ±0.1 V, ±1.0 V, ±10.0 V
±0.067 V for temperature measurement, ±0.067 V and ±0.1 V for voltage measurement.
I
NPUT
P
OWER
Input voltage/frequency
Power
90 V ac – 264 V ac*, 50 Hz/60 Hz (nominal ac)
47 VA
*Note, fluctuations for mains voltage to the power supply not exceeding 10% of the nominal voltage.
V
OLTAGE
R
ESOLUTION
±10.0 V
±1.0
±0.1 V
±0.067 V
±0.01 V
300 µV
30 µV
3.0 µV
2.0 µV
0.3 µV
V
OLTAGE
A
CCURACY
± ( % of reading + offset )
±10.0 V
±1.0 V
±0.1 V
±0.067 V
± (0.025% + 500 µV) with self-cal*, ± (0.05% + 1 mV) without self-cal*
± (0.025% + 50 µV) with self-cal*, ± (0.05% + 100 µV) without self-cal*
± (0.025% + 10 µV) with self-cal*, ± (0.05% + 20 µV) without self-cal*
± (0.025% + 10 µV) with self-cal*, ± (0.05% + 20 µV) without self-cal*

VTI Instruments Corp.
20 EX10xxA Introduction
G
ENERAL
S
PECIFICATIONS
±0.01 V
± (0.050% + 10 µV) with self-cal*, ± (0.10% + 20 µV) without self-cal*
*Note, self-cal is not applicable for RX1032
V
OLTAGE
O
FFSET
S
TABILITY
±10.0 V
±1.0 V
±0.1 V
±0.067 V
±0.01 V
± 20 µV/°C typical
± 10 µV/°C typical
± 5 µV/°C typical
± 2 µV/°C typical
± 2 µV/°C typical
V
OLTAGE
G
AIN
S
TABILITY
Voltage input channels (all ranges)
and thermocouple input channels
*Note, self-cal is not applicable for RX1032
± 25 ppm/°C without self-cal* (typical)
± 5 ppm/°C with self-cal* at any operating temperature (typical)
I
NPUT
I
MPEDANCE
40 MΩ differential
I
NPUT
B
IAS
C
URRENT
5 nA typical
C
OMMON
M
ODE
I
NPUT
R
ANGE
±10 V
C
OMMON
M
ODE
R
EJECTION
R
ATIO
(CMRR)
4 Hz filter
1 kHz filter
dc: 100 dB minimum; (50/60) Hz: 140 dB typical, 120 dB minimum
dc: 100 dB minimum; (50/60) Hz: 100 dB typical, 80 dB minimum
See Figure 7-2 in the Theory of Operation for more information regarding CMRR.
I
NPUT
P
ROTECTION
±15 V
N
ETWORK
C
ONNECTION
10/100 Base-T
I
NPUT
C
ONNECTORS
Thermocouple
EX10xxA
RX10xx
Analog voltage
EX10xxA
EX1000A-51C
EX1000A-TC
Cu-Cu mini-TC jack
Screw terminals (three terminals for each channels “S, +, -“)
M3 X 6MM (PAN HEAD PHILLIPS)
50-pin female D-sub
50-pin female D-sub
Cu-Cu mini-TC jack
O
PERATING
T
EMPERATURE
(
FOR
EX10
XX
A)
-5 °C to 55 °C
P
OWER
I
NPUT
(EX10
XX
A, 51C)
EX10xxA
RX10xx
(90 – 264) V ac, (50/60) Hz
INPUT VOLTAGE DC, 18-36V DC
D
IMENSIONS
( EX10
XX
A/RX10
XX
)
EX10xxA
EX1000A-51C
RX10xx
1.75’’ H x 17.5’’ W x 13.6’’D
1.75’’ H x 17.5’’ W x 13.6’’D
4.92” H x 9.05” W x 9.45” D
; 125 x 238 x 249 mm (including handles and latches)
WEIGHT (RX10
XX
)
RX10xx
5.3 KG; 11 lbs
R
ELIABILITY
(EX10
XX
A)
MTBF
Methodology
> 100,000 hrs (or approximately 11 years)
Telcordia (Bellcore) SR-332, Issue 1
LXI S
PECIFICATIONS
LXI C
LASS
C
OMPLIANCE
LXI Class A
C
LOCK
S
PECIFICATIONS
Clock oscillator accuracy
Synchronization accuracy
Timestamp
Accuracy
Resolution
±50 ppm
Reports “synchronized” when < ±200 µs of the 1588 master clock
As good as time synchronization down to 50 ns
25 ns
IEEE 1588-
BASED
T
RIGGER
T
IMING
