VTS Medical Systems VTS2000 Series User manual

VTS2000 Series Frequency
Inverter User Manual
Controlling and protecting your motor

Contents
Foreword..........................................................................................................................................................................................- 1 -
Safety Precautions................................................................................................................................................- 2 -
1 General technical specifications and product models ..................................................................................................................- 4 -
Model table .....................................................................................................................................................................- 11 -
2 Installation and wiring................................................................................................................................................................- 12 -
4 Peripheral equipment selection...................................................................................................................................................- 21 -
5 Parameter monitor and fault record............................................................................................................................................- 23 -
6 Parameter summary and instructions..........................................................................................................................................- 32 -
7 Communication Protocol............................................................................................................................................................- 80 -
8 Regular inspection and maintenance..........................................................................................................................................- 89 -

VTS2000 Series frequency inverter
- 1 -
Foreword
Thank you for using our company's inverter. Before using it, you must read this instruction manual carefully. Please use
it after you are familiar with the precautions of this product.
Installation Environment：
1. Installed indoors and in a well-ventilated place, generally should be installed vertically to ensure the best cooling
effect.
2. The ambient temperature is required to be in the range of -10~45℃.
3. The ambient humidity is required to be less than 90%, without water droplets condensing.
4. Install in a place with vibration less than 0.5G to prevent falling damage. The inverter is not allowed to suffer
sudden impact.
5. Install in an environment away from magnetic fields and free of flammable and explosive substances.
6. Make sure to install the inverter on fireproof materials (such as metal) to prevent fire.
7. Make sure that no foreign objects enter the inverter to prevent circuit shortcuts from burning down the inverter.

VTS2000 Series frequency inverter
- 2 -
Safety Precautions
1. Before wiring, please confirm whether the input power is in the power off state.
2. It is strictly forbidden to operate with wet hands during wiring operation, and professional electrical engineering
personnel are required.
3. The main circuit terminal and the cable must be firmly connected, otherwise the inverter may be damaged due to
poor contact.
4. For safety reasons, the ground terminal of the inverter must be reliably grounded.
5. It is strictly forbidden to connect the AC 220V or 380V power supply to the terminals other than TA and TC in
the control terminal.
6. It is strictly forbidden to connect the AC power supply to the output U, V, W terminals of the inverter.
7. On the input power supply side of the inverter, be sure to configure a fuseless circuit breaker for circuit protection
or a circuit breaker with leakage protection to prevent the accident caused by the inverter from expanding.
8. Please confirm whether the voltage of the AC main circuit power supply is consistent with the rated voltage of the
inverter.
9. Do not intervene the contactor in the output circuit. If necessary, please consult our company or relevant qualified

VTS2000 Series frequency inverter
- 3 -
personnel in advance.
10. When the inverter is powered on, do not open the cover or perform wiring work.
11. Do not touch the inside of the inverter after power-on, and do not put conductive rods or other objects into the
inverter.
12. .For inverters that have been stored for more than half a year, a charging experiment should be conducted before
use to restore the characteristics of the filter capacitor of the inverter main circuit. When charging, the voltage
regulator should be used to gradually increase the voltage to the rated value. Within 1~2 hours, otherwise there is
a risk of electric shock or explosion.
13. Since the output voltage of the inverter is a PWM pulse wave, please do not install capacitors or inrush current
absorbers at its output. If it has been installed, be sure to remove it.
14. It is strictly forbidden to use contactors and other switching devices on the input side of the inverter to directly
start and stop frequently.
15. Derating is required for areas with an altitude of more than 1000 meters. -Generally, the derating is about 10%
every 1000 meters.。
16. If there are abnormal phenomena such as smoke, odor, strange noise, etc. in the inverter, please immediately cut
off the power and carry out maintenance or call the agent for service.
17. When carrying out inspection and maintenance, the main circuit power should be cut off first.

VTS2000 Series frequency inverter
- 4 -
18. The company will not be responsible for any loss of property and personnel caused by unauthorized modification
of the inverter or failure to follow the procedures in this manual.
1 General technical specifications and product models
General technical specifications
Item
Description
Input
Rated voltage
frequency
380V or 220V：50HZ/60HZ
Allowable voltage
working range
Fluctuation range: ≤±20%; voltage unbalance rate: <3%; frequency: ±5%
Output
Rated voltage
0~380V or 0 ~220V
Frequency
0~999.9HZ
Overload capacity
150% rated current for 1 minute
Main control
Control model
V/F control, advanced VF control, separate VF control, VF square curve

VTS2000 Series frequency inverter
- 5 -
performance
control, without PG current vector control
Modulation
Space voltage vector PWM modulation
Speed range
1: 100 (without PG vector control)
Starting torque
150% rated torque at 3.0 Hz (Advanced VF control)
Speed stabilization
accuracy
≤±0.2% rated synchronous speed
Speed fluctuation
≤±0.5% rated synchronous speed
Torque response
≤50ms without PG vector control
Torque control
Support torque control without PG vector control mode
Torque control accuracy:±5%
Frequency accuracy
Digital setting: maximum frequency×±0.01%;
Analog setting: maximum frequency×±0.2%
Frequency resolution
Digital setting: 0.01Hz;
Analog setting: maximum frequency×0.05%
Torque boost
Automatic torque boost, manual torque boost 0.1%~30.0%
V/F curve
6 control modes: 1 user setting V/F curve mode, 4 torque reduction
characteristic curve modes (2.0 power, 1.7 power, 1.5 power, 1.3 power)

VTS2000 Series frequency inverter
- 6 -
and linear curve, square curve, multi-point VF curve
Acceleration and
deceleration curve
Linear acceleration and deceleration. Time unit (minutes/second) optional,
up to 999.9 seconds
DC braking
Starting frequency of DC braking at stop: 0.00-50.00HZ
Braking time: 0.0-30.0S; braking current: 0.0%-50.0% rated current
Automatic Voltage
Adjustment (AVR)
When the grid voltage changes, it can automatically keep the output
voltage constant
Automatic current
limit
Automatically limit the current during operation to prevent frequent
overcurrent fault tripping
Voltage stall
Control the voltage during deceleration to prevent overvoltage protection
from stopping
Automatic carrier
adjustment
Automatically adjust carrier frequency according to load characteristics
and temperature characteristics; multiple carrier modes are optional
Customization
Separate VF control
Easy to implement various power supply designs
Textile swing
frequency
Textile swing frequency control, can realize fixed swing frequency and
variable swing frequency .

VTS2000 Series frequency inverter
- 7 -
function
Frequency
combination function
The running command channel and frequency reference channel can be
combined arbitrarily
Jog
The jog forward rotation frequency can be set and the jog priority is
enabled. The jog frequency range: 0.00Hz~50.00Hz; the jog acceleration
and deceleration time can be set from 0.1 to 999.9s, and the jog interval
time can be set from 0.1 to 999.9s .
Multi-speed
operation
Achieve multi-speed operation through built-in PLC or control terminal
Built-in process
closed-loop control
Can easily form a closed-loop control system.
Water supply burst
detection
Burst detection delay time, high pressure detection threshold, low pressure
detection threshold
Operation function
Run command
channel
Operation panel. Bolt terminal, serial communication port, can be switched
in various ways
Frequency given
channel
2 kinds of digital setting, analog voltage setting, analog current setting,
pulse setting, terminal setting, multi-speed setting, etc.
Auxiliary frequency
Achieve flexible auxiliary frequency fine-tuning and frequency synthesis

VTS2000 Series frequency inverter
- 8 -
setting
Pulse output terminal
0~50kHz pulse square wave signal output, can realize the output of
physical quantities such as set frequency and output frequency
Analog output
terminal
2 analog signal outputs. The output range is flexibly set between 0~20mA
or 0~1OV, which can realize the output of physical quantities such as set
frequency and output frequency
operating
panel
LED display
Can display 26 parameters such as set frequency, output frequency, output
voltage, output current, etc.
Key function
selection
Define the action range of some keys to prevent misoperation
Protective function
Phase loss protection (optional), over-current protection, over-voltage
protection, under-voltage protection, over-temperature protection.
Overload protection, load loss protection, etc.
Environment
Location
Indoor. Free from direct sunlight, dust, corrosive gas, flammable gas, oil
mist, water vapor, dripping or salt etc.
Altitude
Use derating above 1000 meters, derate 10% for every 1000 meters raised

VTS2000 Series frequency inverter
- 9 -
Ambient temperature
-10C~+40C (If ambient temperature is 40C-50C, please use derating)
Humidity
5%~95%RH, no condensation
Vibration
Less than 5.9m/s( 0.6g)
Storage temperature
-40C~+70C
Structure
Protection level
IP20
Cooling method
Air-cooled, with fan control
Efficiency
7.5KW and below＞93%
Product Design Executive Standard
• EN 61800-3: 2017 Adjustable speed electric drive system. Part 3: Electromagnetic compatibility (EMC) requirements
and specific test methods
• EN61800-2: 2015 speed adjustable electric drive system. Part 2: General requirements. Rating specifications for low
voltage adjustable frequency AC drive systems
• EN 61800-5-1:2007/Al:2017 Adjustable speed electric drive system-Part 5-1: Safety requirements-electricity, heat and
energy

VTS2000 Series frequency inverter
- 10 -
4. Model specification
VTS2000 –7R5 G- 4
VTS Inverter Type
No.
Inverter Type
G
General type
P
Fan pump type
No.
Voltage
S2
Single-phase 220V
2
Three-phase 220V
4
Three-phase 380V
No.
Adaptation
0R7
0.75kW
7R5
7.5kW
011
11kW

VTS2000 Series frequency inverter
- 11 -
Model table
Input voltage
Model
Capacity
(KVA)
Input Current
（A）
Adapted motor
(KW)
220V 1-phase
VTS2000-0R7G-S2
1.40
4.0
0.75
VTS2000-1R5G-S2
2.60
7.0
1.50
VTS2000-2R2G-S2
3.80
10.0
2.20
VTS2000-004G-S2
8.80
16.0
4.0
VTS2000-5R5G-S2
11.0
22.0
5.5
380V 3-phase
VTS2000-0R7G-4
1.50
2.30
0.75
VTS2000-1R5G-4
3.70
3.70
1.5
VTS2000-2R2G-4
4.70
5.0
2.2
VTS2000-004G-4
5.90
10.5
4.0
VTS2000-5R5G-4
8.90
14.6
5.5
VTS2000-7R5G-4
11.0
20.0
7.5

VTS2000 Series frequency inverter
- 12 -
2 Installation and wiring
1. Dimensions

VTS2000 Series frequency inverter
- 13 -
Model
Dimension（mm）
net weight
W
H
D
W1
H1
D1
φd
（kg）
VTS2000-0R7G-S2
100
151
141.5
89
140
129.5
5
1.1
VTS2000-1R5G-S2
100
151
141.5
89
140
129.5
5
1.1
VTS2000-2R2G-S2
100
151
141.5
89
140
129.5
5
1.1
VTS2000-004G-S2
120
215
165
108
202
155
5
2
VTS2000-0R7G-4
100
151
141.5
89
140
129.5
5
1.1
VTS2000-1R5G-4
100
151
141.5
89
140
129.5
5
1.1
VTS2000-2R2G-4
100
151
141.5
89
140
129.5
5
1.1
VTS2000-004G-4
120
215
165
108
202
155
5
2
VTS2000-5R5G-4
120
215
165
108
202
155
5
2
VTS2000-7R5G-4
120
215
165
108
202
155
5
2

VTS2000 Series frequency inverter
- 14 -
2. Basic wiring diagram

VTS2000 Series frequency inverter
- 15 -
3. Jumper Correspondence:
J2
V
VO position
AO output voltage signal
I
CO position
AO output current signal
J8
OFF position
Indicates that the matched resistance on 485 communication is not
connected
ON position
Indicates that the matched resistance on 485 communication is connected

VTS2000 Series frequency inverter
- 16 -
4.Control circuit terminal description:
Terminal function description of control circuit
Item
Terminal
label
Function Description
Specification
Multi-function
digital input
terminal
X1
X (X1, X2, X3, X4, X5) ~ GND is valid
when they are short connected, its function is
set by parameters P2.13 ~ P2.17. (Common:
GND
INPUT, 0 ～10V level signal,
low level valid, 5mA.
X2
X3
X4
X5
Digital signal
output terminal
Y1
Multi-function programmable open collector
output, It can be programmed as a switching
output terminal with multiple functions.
(Common: GND)
OUTPUT, the maximum load
current cannot bigger than 50mA.
Analog input and
ACI
ACI only receives current input, AVI only
INPUT, input voltage range: 0 ～

VTS2000 Series frequency inverter
- 17 -
output terminals
AVI
receives voltage input. The setting of the
measuring range refers to the description of
function codes P2.00 ～P2.09. (Reference
ground: GND)
10V (input impedance: 100KΩ),
input current range: 0 ～20mA
(input impedance: 500Ω).
AO
AO provides analog voltage / current output,
which can represent 6 kinds of physical
values. The output voltage and current are
selected by the jumper J2 (AO jumper
terminal). The default is voltage output. If
want current output, only need to shorted
connect the middle and the other end. For
details please refer to function code F2.10.
(Reference ground: GND)
OUTPUT, 0 ～10V DC voltage.
The output voltage of the AO
terminal is the PWM waveform
from the CPU. The output voltage
is proportional to the width of the
PWM waveform.
Relay output
terminal
TA
The output of programmable relay terminals
TA-TB: normally closed; TA-TC:
TB

VTS2000 Series frequency inverter
- 18 -
TC
TA and TC can reach 14 kinds. For details,
please refer to the introduction of F2.20
output terminal function.
normally open. Contact capacity:
250VAC / 2A (COSФ = 1);
250VAC / 1A (COSФ = 0.4),
30VDC /1A.
Power supply
port
10V
10V is the common power supply of the
analog input terminal circuit
The maximum output current is
20mA.
12V
12V is the common power supply for digital
signal input terminals
The maximum output current is
100mA.
GND
Analog signal and 10V, digital signal and
12V power supply GND.
Analog signals and digital signals
common grounded.
Communication
port
485+
RS485 signal + port
Standard RS485 communication
interface, not isolated from GND,
please use twisted pair or shielded
wire.
485-
RS485 signal-port
