Jntech JNP550L-V5 Original operating instructions

Quick Installation
用户手册
Solar pumping inverter
JNP550L-V5 JNP750L-V5 JNP1K1L-V5
JNP1K5L-V5 JNP2K2L-SE-V5 JNP2K2L-V5
JNP3KL-V5 JNP3K7L-V5
JNP2K2H-V5 JNP3KH-V5 JNP3K7H-V5 JNP4KH-V5
JNP5K5H-V5 JNP7K5H-V5
JNP11KH-V4 JNP15KH-V4 JNP18K5H-V4
JNP22KH-V5 JNP30KH-V5 JNP37KH-V5
JNP45KH-V5 JNP55KH-V5
JNP11KH-V5 JNP15KH-V5 JNP18K5H-V5
JNPxG-QI-EN-V1.1

·1·
CONTENT
QUICK INSTALLATION GUIDELINE FOR SOLAR PUMPING
INVERTER –JNP550L-V5 JNP750L-V5 JNP1K1L-V5 JNP1K5L-V5
JNP2K2L-SE-V5 .....................................................................................4
JNP2K2L-V5 JNP3KL-V5 JNP3K7L-V5 JNP4KL...............................4
JNP2K2H-V5 JNP3KH-V5 JNP3K7H-V5 JNP4KH-V5 JNP5K5H-V5
JNP7K5H-V5 ...........................................................................................4
1INVERTER UNPACKING ................................................................................... 4
2INSTALLATION............................................................................................... 5
2.1 Prepare Installation Tools.................................................................. 5
2.2 Installation Direction and spacing dimension ................................... 5
2.3 Installation of Inverter....................................................................... 6
3ELECTRICAL CONNECTION............................................................................... 7
3.1 Connecting Terminals of Inverter ...................................................... 7
3.2 Cable Selection for Electrical Connection .......................................... 8
3.3 AC Side(AC IN and MOTOR) Electrical Connection ............................ 9
3.4 DC Side Connection ......................................................................... 10
3.5 Inverter grounding .......................................................................... 11
3.6 Water Level Sensor Connection....................................................... 11
3.7 Communication connection ............................................................ 15
QUICK INSTALLATION GUIDELINE FOR SOLAR PUMPING
INVERTER –JNP11KH-V4 JNP15KH-V4 JNP18K5H-V4...........16
4INVERTER UNPACKING ................................................................................. 16
5INSTALLATION............................................................................................. 17
5.1 Prepare Installation Tools................................................................ 17
5.2 Installation Direction and spacing dimension ................................. 17
5.3 Installation of Inverter..................................................................... 17
6ELECTRICAL CONNECTION............................................................................. 18

·2·
6.1 Connecting Terminals of Inverter .................................................... 18
6.2 Cable Selection for Electrical Connection ........................................ 19
6.3 AC Side Electrical Connection .......................................................... 19
6.4 DC Side Connection ......................................................................... 20
6.5 Inverter grounding .......................................................................... 21
6.6 Water Level Sensor Connection....................................................... 21
6.7 Communication connection ............................................................ 21
QUICK INSTALLATION GUIDELINE FOR SOLAR PUMPING
INVERTER –JNP22KH-V5 JNP30KH-V5 JNP37KH-V5
JNP45KH-V5 JNP55KH-V5...............................................................23
7INVERTER UNPACKING ................................................................................. 23
8INSTALLATION PROCEDURE............................................................................ 24
8.1 Prepare Installation Tools................................................................ 24
8.2 Installation Direction....................................................................... 25
8.3 Installation of Inverter..................................................................... 26
9ELECTRICAL CONNECTION AND DISASSEMBLING ................................................ 28
9.1 Connecting Terminals of Inverter .................................................... 28
9.2 Cable Selection................................................................................ 29
9.3 DC Side Connection ......................................................................... 30
9.4 AC Side Electrical Connection .......................................................... 31
9.5 Inverter grounding .......................................................................... 34
9.6 Water Level Sensor Connection....................................................... 34
9.7 Communication Connection ............................................................ 37
9.8 Disassembling ................................................................................. 39
COMMISSIONING GUIDELINE FOR SOLAR PUMPING INVERTER
................................................................................................................41
10 COMMISSIONING...................................................................................... 41
10.1 Verify before Commissioning ........................................................ 41
10.2 LCD Panel Operating Instructions.................................................. 42
10.3 Commissioning for JNP1K1L-V5~JNP18K5H-V4 ............................ 43

·3·
10.4 Commissioning for JNP22KH-V5~JNP55KH-V5.............................. 45
11 APPENDIX:TROUBLESHOOTING ................................................................... 52
11.1 Troubleshooting for JNP550L-V5~JNP18K5H-V4 ........................... 52
11.2 Troubleshooting for JNP22KH-V5~JNP55KH-V5 ............................ 54
QUICK INSTALLATION GUIDELINE FOR SOLAR PUMPING
INVERTER –JNP11KH-V5 JNP15KH-V5 JNP18K5H-V5........... 59
12 INVERTER UNPACKING ............................................................................... 59
12.1 Unpacking Check........................................................................... 59
13 INSTALLATION PROCEDURE.......................................................................... 60
13.1 Prepare Installation Tools.............................................................. 60
13.2 Installation Direction..................................................................... 61
13.3 Installation of Inverter................................................................... 62
14 ELECTRICAL CONNECTION........................................................................... 64
14.1 Connecting Terminals of Inverter .................................................. 65
14.2 Cable Selection........................................................................... 66
14.3 AC Side Electrical Connection..................................................... 66
14.4 DC Side Connection .................................................................... 69
14.5 Inverter grounding ..................................................................... 70
14.6 Water Level Sensor Connection..................................................... 70
14.7 Communication Connection .......................................................... 73
14.8 Disassembling ............................................................................... 75

·4·
Quick Installation Guideline for solar
pumping inverter –JNP550L-V5 JNP750L-V5
JNP1K1L-V5 JNP1K5L-V5 JNP2K2L-SE-V5
JNP2K2L-V5 JNP3KL-V5 JNP3K7L-V5 JNP4KL
JNP2K2H-V5 JNP3KH-V5 JNP3K7H-V5 JNP4KH-V5
JNP5K5H-V5 JNP7K5H-V5
1 Inverter Unpacking
Check according to Packing List whether all the parts are correct and in good
condition or not. Accessories are shown as below:
1 2 3 4 5
6 7 8 9 10
x7 x2
x2
No.
Description
No.
Description
1
PV pump inverter
6
Water level sensor (Optional)
2
Signal terminal
7
Quick Installation Guideline
3
Cold-pressed
Terminal(SC4-5)
8
Packing lis
4
Cold-pressed
Terminal(UT10-5)
9
Water level sensor (Optional)
5
Expansion bolt(M6*60)
10
Certificate of inspection

·5·
2 Installation
2.1 Prepare Installation Tools
The following tools will be needed in inverter installation and wire connection.
Sketch map
Name
Recommend
specification
Function
Wire crimpers
M2.5~M8
Crimp the PV cable core in
connector tube for PV
connector.
Electric drill
Ф8
Used for drilling holes for
installation bracket.
Straight
screwdriver
Ф3
Used forAC side wire
installation
Cross
screwdriver
Ф5
Used for installing and
disassembling inverter cover
2.2 Installation Direction and spacing dimension
The inverter shall be installed vertically or tilted backwards with a maximum
angle of 10°
The minimum installation spacing dimensions are shown below:
Direction
Minimum spacing
Direction
Minimum spacing
Above
100cm
Sides
100cm
Below
100cm
Front
100cm

·6·
2.3 Installation of Inverter
Step1:
Drill holes in the selected
installation position according to
the size（Hole distance 210mm）.
Step2:
Fix inverter in the located holes
with bolts.
Step3:
Tighten the bolts, make the
bolts cling to the wall.

·7·
3 Electrical Connection
3.1 Connecting Terminals of Inverter
The input and output terminals are shown as below:
PV array
GPRS antenna
Water level
sensor
Water pump RS485 module
Solar pumping inverter
Grid
Terminals Description
Terminals
Description
PV
PV array DC positive input terminals(PV+、PV-)

·8·
AC IN
AC input terminals (R、S、T、PE)
MOTOR
Output terminal, connect withAC pump (U、V、W)
SENSOR
Water level sensor signal input terminal(SY、COM、DG) ( optional)
COM
RS485 or GPRS communication interface (VCC、A、B、GND)
(optional)
Ground terminal
Inverter model
Recommended parameters of DC circuit breaker
JNP550L-V5
440VDC,10A
JNP750L-V5
440VDC,10A
JNP1K1L-V5
440VDC,10A
JNP1K5L-V5
440VDC,15A
JNP2K2L-V5
440VDC,15A
JNP3KL-V5
440VDC,30A
JNP3K7L-V5
440VDC,30A
JNP4KL-V5
440VDC,30A
JNP2K2H-V5
440VDC,15A
JNP3KH-V5
440VDC,15A
JNP4KH-V5
440VDC,20A
JNP5K5H-V5
440VDC,30A
JNP7K5H-V5
440VDC,30A
Notice!
It must be DC breaker, it’s prohibited to be
replaced by AC breaker.
3.2 Cable Selection for Electrical Connection
User can select cables for electrical connection according to the following
specifications.
Inverter
Cable range（AWG）
Cable recommended（AWG）
DC side
AC side
DC side
AC side
PV+、PV-
U、V、W
R、S、T
PE
PV+、PV-
U、V、W
R、S、T
PE
JNP550L-V5
14-12
14-12
12
12
12
12
PV+
PV+
PV-PV-
DC Breaker

·9·
JNP750L-V5
14-12
14-12
12
12
12
12
JNP1K1L-V5
14-12
14-12
12
12
12
12
JNP1K5L-V5
14-12
14-12
12
12
12
12
JNP2K2L-SE-
V5
14-12
14-12
12
12
12
12
JNP2K2L-V5
14-12
14-12
12
12
12
12
JNP3KL-V5
12-10
12-10
12
10
10
12
JNP3K7L-V5
12-10
12-10
12
10
10
12
JNP4KL-V5
12-10
12-10
12
10
10
12
JNP2K2H-V5
14-12
14-12
12
12
12
12
JNP3KH-V5
14-12
14-12
12
12
12
12
JNP3K7H-V5
14-12
14-12
12
12
12
12
JNP4KH-V5
14-12
14-12
12
12
12
12
JNP5K5H-V5
14-12
14-12
12
12
12
12
JNP7K5H-V5
14-12
14-12
12
12
12
12
3.3 AC Side(AC IN and MOTOR) Electrical Connection
Step1: Please connect the AC wire according to the following steps:
Operation Instruction
Operation Demonstration
1. Step Using wire crimpers, connecting
AC cable and Cold-pressed
Terminal(SC4-5).
Step2:
JNP550L-V5、JNP750L-V5、JNP1K1L-V5、JNP1K5L-V5、JNP2K2L-SE-V5:
The AC conductor (R, S, PE, U, V, W) is fixed on the terminal through the
corresponding waterproof terminal on the terminal cover. Notice: R is connected to the
fire line, S is connected to the zero line, and PE is grounded. R, S and PE pass through
the AC IN waterproof terminal, and U, V and W pass through the MOTOR waterproof
terminal.
JNP2K2L-V5、JNP3KL-V5、JNP3K7L-V5、JNP4KL-V5:
Fix the AC input cable through the AC IN waterproof connector to the corresponding
terminal (R, T, PE), and fix the water pump power supply cable through the Motor
