Vulcan-Hart VCH5 ML-126365 User manual

VULCAN-HART 3600 NORTH POINT BLVD.
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC BALTIMORE, MD 21222
www.vulcanhart.com Vulcan ©2010 All Rights Reserved F-41179 (07-10)
PARTS MANUAL
VCH SERIES
OVENS
MODELS:
VCH5 ML-126365
VCH8 ML-126366
VCH16 ML-126367
VCH88 ML-126368
VRT SERIES
OVEN
MODEL:
VRT32I ML-138024
For additional information on Vulcan-Hart or to locate an authorized parts
and service provider in your area, visit our website at www.vulcanhart.com

VCH & VRT OVEN SERIES F-41179 (07-10)
1
Vulcan-Hart Food Holding and Transport Equipment is produced with quality
workmanship and material. Proper installation, usage and maintenance will result in
many years of satisfactory performance.
Before performing maintenance on the Oven, thoroughly read the Service Manual and
carefully follow all instructions in the order given. Refer to the Installation and Operation
Manual for detailed operating instructions.
This manual is applicable only to models listed on the cover page.
To obtain Service and Parts information, contact the Vulcan-Hart Service Department at
the address listed on the front cover of this manual or refer to our website:
www.vulcanhart.com.
Technical Service 1-800-814-2028
Service Parts 1-866-628-0485
When calling for Technical Service or Parts, have the model number and serial
number available.
NOTES:

VCH & VRT OVEN SERIES F-41179 (07-10)
2
VCH5, VCH8, VCH16, VCH88
(INST. OVENS)
DESCRIPTION
VULCAN #
HOBART #
BLOCK, TERMINAL (INTERNAL DISTRIBUTION)
AD-206-2000-0
851800
-84
BLOCK, TERMINAL (POWER CONNECT)
AD-206-1000-0
851800
-85
BOLT, RETAINING RACK (PACK OF 4)
WP-305
851800
-26
BUTTONS, TIMER (SET OF 3)
AD-235-0000-0
851800
-90
CONTACTOR, 2POLE - 40AMP(208/240V)
AD-260-2000-0
851800
-41
CONTACTOR, 3POLE - 25AMP(208/240V)
AD-260-3000-0
851800
-42
CONTACTOR, 2POLE - 25AMP(120V)
AD-260-4000-0
851800
-40
CONTROLLER, COMPLETE (120V)
AD-247-2000-1
851800
-46
CONTROLLER, COMPLETE (208/240V)
AD-247-2000-2
851800
-47
CORD, POWER 120V (750/1000/1400/RT-32-H)
AD-161-1000-0
851800
-50
CORD, POWER 208/240V (1000/1400/1300)
AD-161-2000-0
851800
-48
CORD, POWER 208/240V (1200/RT-32)
AD-161-3000-0
851800
-49
CORD, POWER 208/240V (750)
AD-161-4000-0
851800
-669
CORD, POWER 208/240V (OVEN 3PH)
AD-161-5000-0
851800
-670
ELEMENT, OVEN 208/240V/1900W
AD-280-1000-0
851800
-57
FAN, COOLING 120V
AD-305-1000-0
851800
-647
FAN, COOLING 208/240V
AD-305-2000-0
851800
-648
FUSE, 3 AMP
AD-207-0000-0
851800
-62
GASKET, DOOR (PER FOOT)
WP-302
851800
-17
GRATE, RETURN AIR
AD-266-0000-0
851800
-37
GUARD, FAN
AD-253-0000-0
851800
-60
HANDLE, SIDE
AD-307-1000-0
851800
-587
HINGE, DOOR
WP-111
851800
-18
HOLDER, FUSE
AD-210-0000-0
851800
-61
HOLDER, PROBE ( TEMP.)
AD-150-1
851800
-631
HOLDER, PROBE (THERMOMETER)
AD-150-2
851800
-668
KNOB, THERMOSTAT
WP-242
851800
-31
LATCH, DOOR (COMPLETE)
AD-134-0000-0
851800
-56
LATCH, SPRING LOADED W/CATCH
AD-310-0000-0
851800
-68
LIGHT, INDICATOR ROUND 240V
AD-226-0000-0
851800
-70
MOTOR, BLOWER (120V)
AD-301-1000-0
851800
-35
MOTOR, BLOWER (208/240V)
AD-301-2000-0
851800
-36
RACK, MEAT
AD-400
851800
-294
SLIDES, TRAY METRIC (EACH)
WP-291
851800
-310
STANDOFFS, CONTROLLER (SET OF 3)
WP-527
851800
-629
STRAIN RELIEF, POWER CORD (OVEN 3PH ALL)
AD-252-1000-0
851800
-672
STRAIN RELIEF, POWER CORD (750/1000/1300) 1PH
AD-252-0000-0
851800
-80
SUPPRESSER, ORANGE (W/RESISTOR)
AD-135-0000-0
851800
-81
SWITCH, ROCKER
AD-213
851800
-636
SWITCH, PUSH BUTTON
AD-244-0000-0
851800
-83

VCH & VRT OVEN SERIES F-41179 (07-10)
3
DESCRIPTION
VULCAN #
HOBART #
THERMOSTAT, COOLING FAN W/BRACKET
AD-251-0000-0
851800
-87
THERMOSTAT, HIGH-LIMIT
AD-241-1000-0
851800
-86
THERMOMETER, DIAL (400 DEGREE)
AD-245-1000-0
851800
-588
TIMER, OVEN 120V
AD-232-2000-0
851800
-88
TIMER, OVEN 208/240V
AD-232-1000-0
851800
-89
UPRIGHT, SIDE RACK 750-IS (EACH)
AD-291-5000-0
851800
-335
UPRIGHT, SIDE RACK 1000-IS/1200-IS (EACH)
AD-291-3000-0
851800
-334
VENT, SCREEN
AD-253-1000-0
851800
-60
KNOB, CONTROL
WP-384
851800
-772
TRANSFORMER, STEP DOWN 208/240 12v
WP-391
851800
-773
ENCODER, ROTARY OP
WP-392
851800
-774
HARNESS, WIRING
WP-393
851800
-775
CABLE, ENCODER
WP-394
851800
-776
RELAY, SOLID STATE CRYDOM #D24
WP-395
851800
-777
SWITCH, PUSH BUTTON
WP-396
851800
-778
PROBE, TEMP (THERMOCOUPLE)
WP-397
851800
-779
CONTROLLER, ELECTRONIC BOARD
WP-398
851800
-780
OVERLAY, CONTROL PANEL
WP-592
851800
-781

VCH & VRT OVEN SERIES F-41179 (07-10)
4
VRT32I
(RETHERM)
DESCRIPTION
VULCAN #
HOBART #
BLOCK, TERMINAL (INTERNAL DISTRIBUTION)
AD-206-2000-0
851800
-84
BLOCK, TERMINAL (POWER CONNECT)
AD-206-1000-0
851800
-85
BOLT, RETAINING RACK (PACK OF 4)
WP-305
851800
-26
BUTTONS, TIMER (SET OF 3)
AD-235-0000-0
851800
-90
CONTACTOR, 2POLE - 50AMP(208/240V)
AD-260-5000-0
851800
-675
CONTACTOR, 3POLE - 50AMP(208/240V)
AD-260-6000-COR
851800
-676
CONTROLLER, COMPLETE (208/240V)
AD-247-2000-2
851800
-47
CORD, POWER 208/240V (1200/RT-32)
AD-161-3000-0
851800
-49
CORD, POWER 208/240V (RT-32 COR&3PH)
AD-161-6000-0
851800
-671
ELEMENT, OVEN 208/240V/1900W
AD-280-1000-0
851800
-57
FAN, COOLING 208/240V
AD-305-2000-0
851800
-648
FUSE, 3 AMP
AD-207-0000-0
851800
-62
GASKET, DOOR (PER FOOT)
WP-302
851800
-17
GRATE, RETURN AIR
AD-266-0000-0
851800
-37
GUARD, FAN
AD-253-0000-0
851800
-60
HANDLE, SIDE
AD-307-1000-0
851800
-587
HINGE, DOOR
AD-306-1000-0
851800
-677
HOLDER, FUSE
AD-210-0000-0
851800
-61
HOLDER, PROBE ( TEMP.)
AD-150-1
851800
-631
HOLDER, PROBE (THERMOMETER)
AD-150-2
851800
-668
KNOB, THERMOSTAT
WP-242
851800
-31
LATCH, DOOR BLACK HANDLE
AD-134-5000-0
851800
-668
LATCH, SPRING LOADED W/CATCH
AD-310-0000-0
851800
-68
LIGHT, INDICATOR ROUND 240V
AD-226-0000-0
851800
-70
MOTOR, BLOWER (208/240V)
AD-301-2000-0
851800
-36
RACK, MEAT
AD-400
851800
-294
RACK, SHELF
AD-500
851800
-679
STANDOFFS, CONTROLLER (SET OF 3)
WP-527
851800
-629
STRAIN RELIEF, POWER CORD (RT-32/1200)
1PH
AD-252-2000-0
851800
-673
STRAIN RELIEF, POWER CORD (RT-32-COR &
RT-32 3PH)
AD-252-3000-0
851800
-674
SUPPRESSER, ORANGE (W/RESISTOR)
AD-135-0000-0
851800
-81
SWITCH, ROCKER
AD-213
851800
-636
SWITCH, PUSH BUTTON
AD-244-0000-0
851800
-83
THERMOSTAT, COOLING FAN W/BRACKET
AD-251-0000-0
851800
-87
THERMOSTAT, HIGH-LIMIT
AD-241-1000-0
851800
-86
TIMER, OVEN 208/240V
AD-232-1000-0
851800
-89
VENT, SCREEN
AD-253-1000-0
851800
-60
KNOB, CONTROL
WP-384
851800
-772

VCH & VRT OVEN SERIES F-41179 (07-10)
5
DESCRIPTION
VULCAN #
HOBART #
TRANSFORMER, STEP DOWN 208/240 12v
WP-391
851800
-773
ENCODER, ROTARY OP
WP-392
851800
-774
HARNESS, WIRING
WP-393
851800
-775
CABLE, ENCODER
WP-394
851800
-776
RELAY, SOLID STATE CRYDOM #D24
WP-395
851800
-777
SWITCH, PUSH BUTTON
WP-396
851800
-778
PROBE, TEMP (THERMOCOUPLE)
WP-397
851800
-779
CONTROLLER, ELECTRONIC BOARD
WP-398
851800
-780
OVERLAY, CONTROL PANEL
WP-592
851800
-781
